Getting Started

Concept

Ordering Information

Mechanical & Environmental Data

Standards Compliance

Unpack the Console

Page 6
The 301 series console provides 3 modes of operation. Back up, Timed Events,
and 12 Channel Control mode. Back up mode provides cue storage of 144 looks
or cues to any DMX512 based lighting console for one universe of DMX512.
Timed Event mode provides recording and playback for 12 timed events via the
system clock. The events can be played back in any order. 12 Channel Control
mode provides 1 scene 12 channel mode with patch for 512 dimmers. Two
scene operation can be enables with the hold button. This console can be rack
mounted
Catalog #95713 – 301 Back up control system 120 volt
Catalog #91713 – 301 Back up control system 230/240 volt
Catalog #24-004-0815 – 301 console manual
Weight: 4 kg
Finish: Blue powder coat epoxy paint
Construction: Rigid folded sheet steel
Temperature: 0 – 35°C
Humidity Range: 0-90% non-condensing
Ingress Protection: IP20
All units are CE marked. 120 volt consoles include UL, cUL power supplies.
Unpack the console from the packaging and check that the following components
are contained within. If any parts are missing, or damaged, please contact the
carrier and your nearest Strand Lighting office.
List of Parts for North America...
(1) 301 series console
(1) Power cable with UL power supply cable with US 2 pin connector
(1) Manual
(1) Vinyl Dust Cover
List of Parts for Europe and Asia...
(1) 301 series console
(1) Power cable with cUL power supply cable with
(1) UK 2 pin connector and EU 3 pin connector
(1) Manual
(1) Vinyl Dust Cover
Strand 301 Console Manual
