Page 1 Service Manual Models: S, SN, BF, RB, C, CB,V A, B, N & R Part # 673-04-1 Ontario Drive & Gear Limited 05/06 www.odg.com PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 2 General Information Argo Service Manual Ontario Drive & Gear Limited www.odg.com GI-28 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 3 Argo Service Manual How to use this manual This manual is divided into general sections which are identi- Service Guide fied by a 2 letter designation. General Information..... GI Find the section you want in the Engine........EN guide on this page, and then turn Electrical System....
Page 4 Argo Service Manual Ontario Drive & Gear (519)-662-2840 FAX (519)-662-2421 www.odg.com...
Page 5 Available Service Instruction............. GI-4 Argo Vehicle Capacity..............GI-5 Model Identification (early models only)........GI- 6, 7 Identification and Location of Controls........GI-8, 9 Argo Model Specifications............GI-10, 11 Information Labels..............GI-12 Argo Torque Specifications............GI-13, 14 Maintenance Chart..............GI-15 Trouble Shooting Charts............GI-16, 17 Flat Rate Schedule (Service)............
Page 6 All information contained in this service manual is based on the product specification records of Ontario Drive & Gear Ltd. If the ARGO that you are servicing differs from the specifications contained in this manual, contact Ontario Drive & Gear for information.
Page 7 Argo Service Manual General Information Read your owner/operators manual before you operate your ARGO. It contains safe operating instructions and warns the user about potential hazards that can result in personal injury. Warnings are identified in the text by the following symbol: Warning text warns the user about potential hazards that can result in personal injury or death.
Page 8 8x8 Conquest model powered by the 20 H.P Kawasaki FD620D Liquid cooled engine which was introduced in 1993 & The Avenger Argo model, introduced in January of 2004. Although many parts and service procedures outlined in the 673-04 Service Manual also pertain to Avenger, additional supplement sections have been created in order to cover parts and procedures unique to Avenger (See supplement part number above).
Page 9 Argo Service Manual General Information A MESSAGE FROM THE PEOPLE WHO BUILD THE ARGO Ontario Drive & Gear Limited has been building ARGO vehicles since 1967. By listening carefully to our customers and responding to their needs, we have been constantly improving the ARGO and will continue to do so.
Page 10: General Information
General Information Argo Service Manual Model Identification & Description List of Earlier Models Tecumseh V688-20 Conquest V894-37 V888-20 (Mid 1999) V894-38 V888-21 Briggs& Stratton Twin V888-22 Vanguard V693-22 V688-22 V693-36 V891-22 V694-36 V691-22 V697-51 V892-22 V699-51 V692-22 Magnum V888-23 Vanguard2...
Page 11 Argo Service Manual General Information Model Identification & Description (continued) List of Earlier Models Response V899-65 - MU Transmission Response V899-65E - Bearing Extensions, MU Response V899-66 - Skidplate, MU Response V899-67 - Horn & Parking Brake, MU Response V899-68 - 22"...
Page 12 General Information Argo Service Manual Identfication and Location of Controls Prior to serial # N14708, B14700, R22452 Prior to serial # C22453 & A14743 Ontario Drive & Gear Limited www.odg.com GI-8 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 13 Argo Service Manual General Information From serial # N14708, B14700, R22452 From serial # C22453 & A14743 Ontario Drive & Gear Limited www.odg.com GI-9 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 14: Argo Model Specifications
Clutch: Variable speed torque converter Transmission: 2 forward speeds, neutral and reverse Fuel Capacity: 29 Litre (6.3 Imp. Ga., 7.6 U.S Gal.) Clutch: Variable speed torque converters Steering/Brakes: Hydraulic Caliper, 10.25" with holding brake system Fuel Capacity: 32 litres (7.0 Imp. Gal., 8.4 U.S. Gal.) Drive Chains: Double RC-50 roller chains &...
Page 15 Clutch: Variable speed torque converters Transmission: 2 forward speeds, neutral and reverse Fuel Capacity: 32 litres (7.0 Imp. Gal., 8.4 U.S. Gal.) Clutch: Variable speed torque converter Steering/Brakes: Hydraulic, 9" disc with holding brake system Fuel Capacity: 29 Litre (6.3 Imp. Ga., 7.6 U.S Gal.)
Page 16 Information about the use of the holding brake system, the use of the vehicle in water, correct fueling procedures and placement of the floorpans has been provided on distinctive coloured labels fastened to the various locations on the Argo. Figure 1-1 Location of Information Labels - All Models The label shown below is located behind the seat in the rear compartment of all 6-wheel models.
Page 17: Argo Torque Specifications
Argo Service Manual General Information ARGO Torque Specifications Transmission Side Cover Bolts............. 216 IN. LBS. 24.3Nm Differential Bolts.............35 FT. LBS. 47.5Nm Shifter Plate Bolts (Avenger)..........75 IN. LBS 8.5Nm Intake & Exhaust Kawasaki Exhaust Manifold to Engine......204 IN. LBS. 23.2Nm Kawasaki Muffler to Engine........... 204 IN. LBS 23.2Nm...
Page 18 General Information Argo Service Manual Argo Torque Specifications Brake Disc to Output Shaft..........30FT.LBS 40.7 Nm Brake Sprocket to Disc (Avenger)........15 FT. LBS 20.3Nm Master Cylinder Lid Screws........... Snug By Hand Upper Handle Bar Clamp Bolts (Avenger).....12 Ft. LBS 16.3Nm Steering Shaft Nut............Tighten snug. Back off until lower washer can be turned by hand.
Page 19 The intervals shown on the schedule are based on average operating conditions. Vehicles which are subjected to severe use and wet or dusty conditions will require more frequent servicing. Use only Argo replacement parts to ensure safe operation of the vehicle and to comply with the warranty coverage.
Page 20 General Information Argo Service Manual MALFUNCTION PROBABLE CAUSE CORRECTIVE ACTION (SYMPTOM) Electric starter inoperative 1. Loose electrical connections 1. Clean and re-tighten electrical connections 2. Battery charge low or dead 2. Recharge battery or replace as necessary 3. Faulty starter motor 3.
Page 21 Argo Service Manual General Information MALFUNCTION PROBABLE CAUSE CORRECTIVE ACTION (SYMPTOM) Severe vibration when vehicle 1. Engine loose on mounts 1. Secure engine mounts service. 2. Driver or driven clutch or engine 2. Same as above. defective 3. Axle bent 3.
Page 22: Table Of Contents
General Information Argo Service Manual FLAT RATE SCHEDULE ARGO SERVICE Description Maximum TIme (Hours) Number Conq Resp Bigf Van2 Van Aveng Transmission 1000 Transmission Re & Re 1500 Transmission Re & Re & Overhaul 1750 Transmission Shift Lever Re & Re Intake &...
Page 23 Argo Service Manual General Information FLAT RATE SCHEDULE ARGO SERVICE Number Description Maximum TIme (Hours) Conq Resp Bigf Van2 Van Aveng 5800 Intake Hose Re & Re none none 5900 Brake Cooling Air Duct Re & Re none none Vehicle Body & Firewall 6000 Firewall Re &...
Page 24: Table Of Contents
General Information Argo Service Manual FLAT RATE SCHEDULE ARGO SERVICE Number Description Maximum TIme (Hours) Conq Resp Bigf Van2 Van Aveng 8500 Seat Frame Assembly Re & Re 8600 Filler Hose Re & Re 8700 Vent Hose Re & Re...
Page 25 Argo Service Manual General Information FLAT RATE SCHEDULE ARGO ACCESSORY INSTALLATION Part No. Description No.of Hours 614-06 Cargo Tie-Down Kit 615-42K 6 Wheel Track Set - Assembly - Installation - Removal 615-37K Bigfoot Track Set - Assembly - Installation - Removal...
Page 26 General Information Argo Service Manual FLAT RATE SCHEDULE ARGO ACCESSORY INSTALLATION Part No. Description No.of Hours 649-50 Convertible Top ASM - Installation - Removal 650-60 Alternator Kit - Vanguard2 657-00 Snow Plow Kit (Seasonal Availability) 663-10 Full Length Skid Plate - 6x6 663-11K Full Length Skid Plate - 6x6 (V699-51/V699-55) 2.0...
Page 27 Argo Service Manual General Information ARGO Tool List Ext. Retaining Ring Plyers 4R 1/2" Impact Ext. Retaining Ring Plyers 490R 5/8" Socket Side Cutters Nylon Mallet [large] x2 Channel Lock Plyers Torque Wrench Flat Head Screw Driver(long] Air Gun Star Head Screw Driver [short]...
Page 28 General Information Argo Service Manual ARGO Tool List #2 Star Screw Driver [ long ] 10mm Nut Driver 11/32" Nut Driver 8mm Combination Wrench 1/8" Hex Key 6mm Hex Socket [short] 5mm Hex Key 10mm Socket 4mm Hex Key 13mm Combination Wrench & Socket...
Page 29 Argo Service Manual General Information ARGO Tool List 3/8" Torque Wrench [small ] 3/8" Palm Impact Wrench 3/8" Torque Wrench [small] 1/4" Nut Driver Retaining Ring Plyers 2R Angled Air Ratchet 3/8" Box End Air Ratchet Wrench 1/4" - 1/2" Tapping Socket #21 Drill Bit 13/64"...
Page 30 General Information Argo Service Manual 7R VICE GRIP MODIFICATION A pair of modified 7R Vice Grips is required to hold the ends of the drive chain together while inserting the connecting link. This tool can also be used to hold the ends of the idler chain together while inserting the connecting link.
Page 31 Argo Service Manual General Information Starter Removal Ontario Drive & Gear Limited www.odg.com GI-27 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 32 General Information Argo Service Manual Ontario Drive & Gear Limited www.odg.com GI-28 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 33 Argo Service Manual Engine System SECTION EN Engine System Table of Contents Briggs V Twin, Kawasaki L/C & Kohler Engine Photographs..EN-2 General Instructions................EN-3 Checking the Engine Oil............... EN-4 Recommended Engine Oil..............EN-4 Changing the Engine Oil..............EN-5 Draining the Engine Oil................EN-5 Oil Filter Replacement................EN-6...
Page 34 Engine System Argo Service Manual Briggs& Stratton V Twin OHV 16, 18 & 23 H.P Kawasaki FD620D Liquid Cooled Kohler Aegis 20 H.P OHV 26H.P Carburated & 31H.P EFI Ontario Drive & Gear Limited www.odg.com EN-2 PH. (519)- 662-2840 FAX (519)- 662-2421...
Page 35 Models Engine Engine Service Manual Part Number S, SN, BF, F Briggs & Stratton Briggs & Stratton Repair 670-33 RB, R, B, N V Twin OHV 16,18 & 23H.P Manual V Twin OHVN 670-40-1 (23H.P)
Page 36 Engine System Argo Service Manual Engine Oil Information Checking the Engine Oil Level To check the oil during an operating period, shut the engine off, let it cool down and allow the oil time to drain into the sump before checking the oil level. Position the vehicle so the engine is level.
Page 37 Argo Service Manual Engine System Briggs & Stratton API Service Class SE, SF or SG Ontario Drive & Gear Limited. www.odg.com EN-5 PH. (519)- 662-2840 FAX (519)- 662-2421...
Page 38 Engine System Argo Service Manual Changing Engine Oil During the initial engine break-in period, change the oil after the first 8 hours of operation for Briggs & Stratton and 20 hours of operation for the Kawasaki. After the break-in period, change the engine oil every 50 operating hours, or more frequently if the vehicle is operated in dusty or dirty conditions.
Page 39 Argo Service Manual Engine System There is limited space between the engine and power pack frame. Cut down an empty plastic container to the correct height so it will fit under the engine oil drain. Make sure the container will hold the amount of oil in the engine.
Page 40 Replace the spark plugs if the electrodes are corroded or damaged or if the insulator is cracked. Use the correct plug for the engine as detailed in the engine owner’s manual. Re-install the spark plugs carefully, taking care to start the threads properly. Torque the plugs to 10 - 15 ft.
Page 41 Argo Service Manual Engine System Removing the Engine (FD620D Kawasaki Liquid Cooled OHV) Accessing the 4 mounting bolts that secure the engine to the power pack frame requires the power pack frame to be removed from the vehicle. Both engine and transmission can be removed through the engine access opening using an overhead hoist.
Page 42 Engine System Argo Service Manual Disconnect the ground wire (leading from the battery ground terminal post), at the engine. Remove the radiator overflow bottle at the front of the engine. Conquests manufactured prior to CB14963 have an O.D.G overflow bottle and holder to remove.
Page 43 Argo Service Manual Engine System 12. Disconnect the fuel line at the carburetor. Photo EN-9 IMPORTANT Before proceeding any further, be sure to cover the mouth of the carburetor with a rag, or other option. This will prevent anything from entering the carburetor unintentionally.
Page 44 Engine System Argo Service Manual EN-12 EN-11 17. Perform the servicing procedure, Removing the Drive Belt in section CS of this service guide. 18. Perform the servicing procedure, Removing the Driven Clutch, in section CS of this service guide. 19. Perform the servicing procedure, Removing the Brake Pads ( Hydraulic ) steps 1- 4, in section BR of this service guide.
Page 45 Argo Service Manual Engine System EN-15 EN-16 24. Perform the servicing procedure, Idler Chain Removal, in section WA of this serv- ice guide. 25. Loosen off the 2 power pack mounting bolts that run through the power pack frame and connect it with the lower main frame. One is located in front of the idler shaft, the other behind.
Page 46 EN-23 EN-22 If the engine is being replaced, you will need to remove all Argo components that are not available with the new engine. These will need to be reassembled to the new engine. Components include, throttle cable, choke cable, exhaust manifold, driver clutch, etc.
Page 47 Argo Service Manual Engine System Apply blue 242 LOCTITE to the threads of each mounting bolt and install. Torque to specifications. Installing the Engine (Kawasaki FD620D L/C) Attach the overhead hoist to the front engine hook and lower the power pack into the vehicle through the engine access opening.
Page 48 Engine System Argo Service Manual Lower the rear of the power pack frame aligning the mounting bolt with the main frame. Photo EN-28 Install the 3rd mid mounting bolt paying close attention to the hardware that is re- quired along with it. See your illustrated parts manual. Photo EN-29...
Page 49 Argo Service Manual Engine System 10. Reconnect the fuel line at the carburetor and secure with the hose clamp. 11. Secure the fuel line to the nylon clips at the front of the vehicle. 12. Assemble the lower metal air filter plate to the top of the carburetor. Photo EN-31 13.
Page 50 Engine System Argo Service Manual 20. Reposition the adjustable dash support back down to the top of the transmis- sion and secure the carriage bolt. Photo EN-33 21. Perform the servicing procedure, Idler Chain Installation and Idler Chain Adjustment in section WA of this serv- EN-33 ice guide.
Page 51 Argo Service Manual Engine System IMPORTANT Ensure that all levels of fluid (oil and antifreeze), in engine are correct before starting the vehicle. Run the engine for 5 minutes and recheck all levels. Add or remove as necessary. Removing the Engine (Briggs & Stratton 16 h.p & 18h.p) Unlike the Kawasaki FD620D L/C OHV engine, the Briggs &...
Page 52 19. Lift the engine out of the vehicle using an overhead hoist. Photo EN-38 EN-37 EN-38 If the engine is being replaced, all Argo components must be removed first and reinstalled on the new engine. These include driver clutch, muffler, exhaust manifold and any return springs.
Page 53 Argo Service Manual Engine System Installing the Engine (Briggs Models) Attach the overhead hoist to both en- gine hooks and lower the engine into the vehicle. Photo EN-39 Secure the engine to the power pack frame with 4 bolts, 8 flat washers and 4 nylon locknuts.
Page 54 Engine System Argo Service Manual Reattach the ground wire to the isolated ground at the front of the engine, and plug the charging wire from the main wire harness back into the engine wire harness. Reconnect the fuel line at the fuel filter.
Page 55 Argo Service Manual Engine System 15. Perform the servicing procedure, Installing the Intake Duct (Briggs Models), in section DE of this service guide. 16. Install the battery and reconnect battery terminals. 17. Perform the servicing procedure, Installing the Firewall, in section VB of this service guide.
Page 56 General Information Argo Service Manual Ontario Drive & Gear Limited www.odg.com GI-28 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 57 Argo Service Manual Engine System SECTION EN Supplement Pages Ontario Drive & Gear ltd. www.odg.com/centaur (519) 662-2840 FAX (519) 662-2421...
Page 58 Engine System Argo Service Manual Ontario Drive & Gear ltd. www.odg.com/centaur (519) 662-2840 FAX (519) 662-2421...
Page 59 Argo Service Manual Engine System Removing the Engine (Kohler Aegis N.A) Locate the tailpipe assembly and detach the connecting springs between the tailpipe assembly and muffler. Photo 1 & 2 Pull the assembly out through the hood area. Remove the heat deflector shield covering the muffler. Photo 3 Disconnect the fuel line from the fuel filter at the carburetor.
Page 60 Engine System Argo Service Manual Disconnect the ground wire attached at the front of the engine to the valve cover fastener. Photo 7 Locate the main wire harness plug-ins at the front of the engine compartment and disconnect all wires. Photo 8 Locate the starter at the front of the engine compartment and disconnect both red and black power wires from the starter solenoid.
Page 61 Argo Service Manual Engine System 10. Disconnect the brake cooling hose at the brake duct. Photo 13 Disconnect the choke & throttle cables from the control panel on the Kohler engine. Photo 14 & 15 Make note of which hole the throttle cable is inserted.
Page 62 Engine System Argo Service Manual Lifting the Engine From the Vehicle This procedure requires the use of an overhead hoist. Do NOT attempt to lift out by hand. Ensure all components attached to the engine have been detached. Lift out slowly and carefully.
Page 63 Argo Service Manual Engine System 16. Remove the engine to a clean workbench for further disassembly. 17. Remove the muffler if it was not previously removed. (EFI models will have an O2 sensor threaded into the muffler that will need to be removed as well. Photo 22 18.
Page 64 Secure the driver with the hex head fastener. Apply blue LOCTITE and Torque to specifications. Photo 5 IMPORTANT For part number and descriptions of all components and hardware, always refer to your illustrated Argo parts manual. Install the muffler assembly to the engine manifold. Photo 6 IMPORTANT Always use new manifold gaskets Ontario Drive &...
Page 65 Argo Service Manual Engine System IMPORTANT If you have removed the Kohler Aegis radiator assembly from the engine for any reason (repair, replacement etc.), ensure, when reinstalling it, that you tie-wrap the bottom of it securely to the lower bracket as in photo 7 & 8. This will prevent the lower radiator locating pins from dislodging from the rubber gromments under heavy vehicle application.
Page 66 Engine System Argo Service Manual Slowly and gently lower the engine through the hood area. Some manuevering is required as the engine does not necessarily drop in straight on. Avoid damage to any vehicle components as well as the upper body. Photo 10 & 11 IMPORTANT Align the mounting holes of the engine block with the powerpack frame studs.
Page 67 Argo Service Manual Engine System 11. Reconnect the brake cooling hose at the brake duct. Photo 14 12 Reconnect the choke & throttle cables to the control panel on the Kohler engine. Photo 15 Insert the throttle cable into the correct hole. Photo 16 13.
Page 68 Engine System Argo Service Manual 16. Locate the starter at the front of the engine compartment and reconnect both red and black power wires to the starter solenoid. Photo 19 These wires are enclosed within a red rubber boot. 17. Reconnect the ground wire attached at the front of the engine to the valve cover fastener.
Page 69: Table Of Contents
Argo Service Manual Engine System 22. Locate and install the tailpipe assembly. Attach the connecting springs between tailpipe assembly and muffler. Photo26 & 27 Feed the tailpipe assembly in through the hood area. 23. Replenish all fluid levels. EN-30A Ontario Drive & Gear Limited.
Page 70 Engine System Argo Service Manual Ontario Drive & Gear Limited www.odg.com PH. (519)- 662-2840 FAX (519)- 662-2421...
Page 71 Argo Service Manual Electrical System SECTION ES Electrical System Table of Contents General Instructions................ES-5 Battery....................ES-6 Checking Battery Fluid Level.............. ES-6 Charging the Battery................ES-6 Cleaning the Battery Terminals & Cable Connections......ES-6 Cleaning the Battery................ES-7 Battery Removal..................ES-7 Battery Inspection................. ES-7 Battery Installation................
Page 72 Calibrating the Digital Gauge Package......Supl. Page ES-52 Wiring Diagrams and Schematics Models T, TB, HT, HTB From 1977; KB From 1981-86; K From 1983 S From 1986; SB From 1987;..........ES-22, 23 Argo Standard & Heavy Duty (Models V688-20,V888-20, V888-21; After T6460, TB8446, HTB8592 11/88).........ES-23 Argo Twin (Model V888-22, V688-22 From SB8355, S6308).....ES-24...
Page 73 From NKB9466, NK 6812 10/90............ES-29 Argo Magnum Model V891-23 From NKB 10785; Models V891-27, V691-27 06/93......ES-30 Argo Magnum Model V894-23, V894-27 From NKB 10973 03/94..ES-31 Response Model V896-65 From RB 12075 08/95.........ES-32 Response Model V896-65 From RB 12702 11/96.........ES-33 Response Model V896-65 From RB 14121 10/97........ES-34 Reponse Model V899-65 From RB 16104 06/99........ES-35...
Page 74 Electrical System Argo Service Manual Argo Vanguard2 Model V696-55 From SN7841 04/95..... ES-45 Argo Vanguard2 Model V697-55 From SN8138 11/95......ES-46 Argo Vanguard2 Model V697-55 From SN8138 11/95......ES-47 Argo Vanguard2 Model V699-55 From SN12227 02/01....ES-48 Bigfoot Model V698-58 From BF9212 08/97........ES-49 Bigfoot Model V698-58 From BF12097 12/00........ES-50...
Page 75 Argo Service Manual Electrical System General Instructions Detailed information on standard workshop and safety procedures, and general servicing operations is not included in this manual, which has been prepared to assist qualified service personnel. ODG assumes no responsibility or liability for PERSONAL INJURY or VEHICLE DAMAGE which results from any servicing procedure performed, including those instructions outlined in this manual.
Page 76 If the battery loses its electrical charge, remove the battery from the ARGO and recharge it with a 12 volt battery charger at the rate of 10- 12 amps maximum. The battery should remain on charge until the specific gravity reaches 1.265 on a hydrometer.
Page 77 Argo Service Manual Electrical System Cleaning the Battery Clean the top of the battery every 250 hours with a mixture of baking soda and water. Before cleaning the battery, remove it from the vehicle and make sure the pod vents are in place.
Page 78 Electrical System Argo Service Manual Battery fluid contains sulphuric acid. If it comes into contact with your skin or eyes, serious personal injury will occur. Always wear rubber gloves and safety goggles when servicing the battery. Batteries produce explosive gas. Keep sparks, flames and cigarettes away from the battery.
Page 79 Argo Service Manual Electrical System Pull the headlamp assembly from the vehicle. Unwrap the electrical tape from the power wire and disconnect. Disconnect the ground wire at the headlamp mounting bracket. Remove the trim screws and separate the lens from the headlamp housing.
Page 80 Electrical System Argo Service Manual ES-2 ES-3 Disconnect the bulb from the lens. Pry the 2 locking clips on the bulb apart while pulling it from the wiring. Photo ES-3 Installing a Headlamp Bulb When installing the new bulb, avoid any contamination of the glass surface. Do not touch the bulb with your fingers.
Page 81 Argo Service Manual Electrical System Installing the Lens Assembly (Conquest Models from CB12581) Install the rubber headlamp bezel into the headlamp opening. Photo ES-7 Install the bulb into the headlamp housing. Insert and turn 1/4 turn clockwise. Photo ES-8 Snap the lens assembly into the rubber headlamp bezel.
Page 82 Electrical System Argo Service Manual Headlamp Removal ( Response, Bigfoot and Later Vanguard2 & Vanguard Models) Locate the 4 screws securing the metal headlamp bezel to the upper body. Photo ES-9 Some earlier Response models incorporated a plastic headlamp bezel that secured itself to the upper body by 2 tabs to the inside of the headlamp opening.
Page 83 Argo Service Manual Electrical System Removing the Starter (Conquest Models) The Kawasaki starter motor is located between the engine and transmission near the brake cooling duct. Photo ES-11 Perform the servicing procedure, Removing the Firewall, in section VB of this service guide.
Page 84 Electrical System Argo Service Manual Installing the Starter (Conquest Models) Maneuver the starter and solenoid assembly vertically between the engine and trans- mission, turning horizontally to mount to the starter bracket. Align the holes of the starter motor with the threaded holes of the mounting bracket and start the first mounting bolt.
Page 85 Argo Service Manual Electrical System ES-16 ES-17 Perform the servicing procedure, Removing the Intake Duct, in section DE of this service guide. Remove the bolt securing the ground cable to the engine. Remove the rest of the hardware securing the blower housing to the engine.
Page 86 Electrical System Argo Service Manual The flywheel is aligned with a key on the crankshaft. Be aware of the key and ensure that it is reinstalled when the flywheel is assembled back to the engine. The flywheel contains magnets used for the charging system of the engine. Place the flywheel on a clean work surface with the magnets facing up to ensure no metalic foreign objects are attracted to the magnet, and go undetected during reassembly.
Page 87 Argo Service Manual Electrical System When the flywheel is assembled to the crankshaft, use a small technicians mirror to check the key and keyway alignment. Install the recoil cup and mounting nut to the crankshaft. Torque the flywheel nut to specifications.
Page 88 Electrical System Argo Service Manual ES-24 ES-25 Remove the fan. Photo ES-25 Remove the mounting bracket from the old fan if it is being replaced, and install it to the new one. Installing the Brake Cooling Fan (Response & Bigfoot models) Install the mounting bracket to the fan.
Page 89 Argo Service Manual Electrical System Removing the Brake Cooling Fan (Conquest Models) Conquest models have the brake cooling fan mounted to the intake duct assembly located on the right hand side of the vehicle. Conquest models manufactured prior to CB17117, utilize a sheet metal style intake duct, while later models have a molded plastic version.
Page 90 Electrical System Argo Service Manual vi. Remove the fan from the mounting base by drilling out the 4 rivets securing the two components together. vii. If replacing the fan, remove the band clamp from the fan. Install the band clamp to the new fan.
Page 91 Argo Service Manual Electrical System Remove the 2x4's used to space the upper and lower body apart and re-rivet the two back together using the required body rivets and washers. Slip the rubber bumper back on. Replace the radiator overflow bracket and bottle to the front of the vehicle. Install the lid and connect the overflow hose.
Page 92 Electrical System Argo Service Manual Models T, TB, HT, HTB FROM 1977 KB FROM 1981-86 K FROM1983 S FROM 1986 SB FROM 1987 Ontario Drive & Gear Limited www.odg.com ES-22 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 93: Electrical System
Argo Service Manual Electrical System Models T, TB, HT, HTB FROM 1977 KB FROM 1981-86 K FROM1983 S FROM 1986 SB FROM 1987 Argo Standard & Heavy Duty (Models V688-20,V888-20,V888-21 After T6460, TB8446, HTB8592 11/88 After T6460, TB8446, HTB8592 Ontario Drive & Gear Limited www.odg.com...
Page 94 Electrical System Argo Service Manual Argo Twin (Model V888-22, V688-22 From SB8355, S6308) Ontario Drive & Gear Limited www.odg.com ES-24 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 95 Argo Service Manual Electrical System Argo Vangard Model V891/892-22, V691/692-22 from S6834, SB9691 Ontario Drive & Gear Limited www.odg.com ES-25 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 96 Electrical System Argo Service Manual Argo Model NKB From 1987 1/87 Ontario Drive & Gear Limited www.odg.com ES-26 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 97 Argo Service Manual Electrical System Argo I/C Model V888-23, V688-23 From NKB 8187, NK 6192 11/88 Ontario Drive & Gear Limited www.odg.com ES-27 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 98 Electrical System Argo Service Manual Argo Magnum Model V890-23, V690-23 12/89 Ontario Drive & Gear Limited www.odg.com ES-28 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 99 Argo Service Manual Electrical System Argo Magnum Model V890-23, V690-23 From NKB9466, NK 6812 10/90 Ontario Drive & Gear Limited www.odg.com ES-29 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 100 Electrical System Argo Service Manual Argo Magnum Model V891-23 From NKB 10785, Models V891-27, V691-27 06/93 Ontario Drive & Gear Limited www.odg.com ES-30 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 101 Argo Service Manual Electrical System Argo Magnum Model V894-23, V894-27 From NKB 10973 03/94 Ontario Drive & Gear Limited www.odg.com ES-31 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 102 Electrical System Argo Service Manual Response Model V896-65 From RB 12075 08/95 Ontario Drive & Gear Limited www.odg.com ES-32 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 103 Argo Service Manual Electrical System Response Model V896-65 From RB 12702 11/96 Ontario Drive & Gear Limited www.odg.com ES-33 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 104 Electrical System Argo Service Manual Response Model V896-65 From RB 14121 10/97 Ontario Drive & Gear Limited www.odg.com ES-34 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 105 Argo Service Manual Electrical System Reponse Model V899-65 From RB 16104 06/99 Ontario Drive & Gear Limited www.odg.com ES-35 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 106 Electrical System Argo Service Manual Response Model V899-65 From RB 17665 12/00 Ontario Drive & Gear Limited www.odg.com ES-36 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 107 Argo Service Manual Electrical System Conquest Parts Manual Conquest V894-37, V894-38 From CB 10847 01/94 Ontario Drive & Gear Limited www.odg.com ES-37 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 108 Electrical System Argo Service Manual Conquest Model V894-37, V894-38 From CB 12580 03/96 Ontario Drive & Gear Limited www.odg.com ES-38 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 109 Argo Service Manual Electrical System Conquest Model V899-37, V899-38 From CB 16049 05/99 Ontario Drive & Gear Limited www.odg.com ES-39 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 110 Electrical System Argo Service Manual Conquest Model V899-37, V899-38 From CB 17857 02/01 Ontario Drive & Gear Limited www.odg.com ES-40 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 111 Argo Service Manual Electrical System Argo Vanguard Model 693-22 From S6999 02/92 Ontario Drive & Gear Limited www.odg.com ES-41 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 112 Electrical System Argo Service Manual Argo Vanguard Model V693-36 From S7304 06/93 Ontario Drive & Gear Limited www.odg.com ES-42 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 113 Argo Service Manual Electrical System Argo Vanguard Model V697-51 From S8131 09/97 Ontario Drive & Gear Limited www.odg.com ES-43 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 114 Electrical System Argo Service Manual Argo Vanguard Parts Manual Model V699-51 From S12222 03/02 Ontario Drive & Gear Limited www.odg.com ES-44 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 115 Argo Service Manual Electrical System Argo Vanguard2 Model V696-55 From SN7841 04/95 Ontario Drive & Gear Limited www.odg.com ES-45 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 116 Electrical System Argo Service Manual Argo Vanguard2 Model V697-55 From SN8138 11/95 Ontario Drive & Gear Limited www.odg.com ES-46 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 117 Argo Service Manual Electrical System Argo Vanguard2 Model V697-55 From SN8138 11/95 Ontario Drive & Gear Limited www.odg.com ES-47 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 118 Electrical System Argo Service Manual Argo Vanguard2 Model V699-55 From SN12227 02/01 Ontario Drive & Gear Limited www.odg.com ES-48 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 119 Argo Service Manual Electrical System Bigfoot Model V698-58 From BF9212 08/97 Ontario Drive & Gear Limited www.odg.com ES-49 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 120 Electrical System Argo Service Manual Bigfoot Model V698-58 From BF12097 12/00 Electrical System Bigfoot Parts Manual Ontario Drive & Gear Limited www.odg.com ES-50 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 121 Argo Service Manual Electrical System Conquest 6x6 Model V601-62 From C12747 11/01 Ontario Drive & Gear Limited www.odg.com ES-51 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 122 Electrical System Argo Service Manual Calibrating the 613-119 Digital Gauge Package In the event that the Digital Gauge Package needs to be re-calibrated or replaced, follow the below steps. 1) Hold down both the “MODE” and “KM/MILE” buttons and turn the key to “Run”.
Page 123 Argo Service Manual Brake System SECTION BR Brake System Table of Contents General Instructions................BR-3,4 Brake System Maintenance ..............BR-5 Brake Pad Inspection (Hydraulic)............BR-6 Removing the Brake Pads (Hydraulic)..........BR-6 Installing Brake Pads (Hydraulic)............BR-8 Hydraulic Brake Caliper Maintenance Schedule......BR-9 Hydraulic Brake Caliper Removal............
Page 124 Brake System Argo Service Manual SECTION BR Brake System Table of Contents Mechanical Brake Pad Inspection & Replacement......BR-29 Replacing the Brake Pads (Mechanical)..........BR-29 Installing the Brake Pads (Mechanical)..........BR-30 Mechanical Brake Caliper Installation..........BR-31 Adjusting the Mechanical Brake Caliper..........BR-33 Steering Lever Adjustment (Mechanical)........... BR-34 Holding Brake Adjustment..............
Page 125: Brake System
This is essential to locating and ordering the correct components that were used during that particular manufacturing period when the ARGO was built. It is also very helpful using the illustrations to clearly see and define the component being referred to. If...
Page 126 Brake System Argo Service Manual General Instructions Detailed information on standard workshop and safety procedures, and general servicing operations is not included in this manual, which has been prepared to assist qualified service personnel. ODG assumes no responsibility or liability for PERSONAL INJURY or VEHICLE DAMAGE which results from any servicing procedure performed, including those instructions outlined in this manual.
Page 127 Please refer to the appropriate illustrated parts manual for the vehicle being serviced. The parts manual is identified with either the vehicle’s model number, serial number or both written on the front cover. These parts manuals are availible on CD in PDF format. .
Page 128 The pads are coated with oil or grease Removing Brake Pads ( Hydraulic) The hydraulic brake system is used on all models of ARGO vehicles with the exception of the Vanguard 6x6. To replace hydraulic brake pads (Gremica Calipers only)on models manufactured prior to 1996, remove the cotter pins securing the pads within the caliper and slip the brake pads from the caliper towards the drivers compartment.
Page 129 Argo Service Manual Brake System secure the hydraulic brake caliper to the transmission housing. To do this you will need to rotate the tires by hand until they are lined up. Photo BR-1 NEVER attempt to align these with the engine running and in gear.
Page 130 Brake System Argo Service Manual Installing Brake Pads (Hydraulic) When replacing worn or contaminated pads, replace both pads in the brake caliper assembly even if both pads do not require replacing. Using one new and one old brake pad in a caliper assembly may provide poor braking/steering performance.
Page 131 Maintenance Schedule - Inspect every 50 hrs of vehicle operation The brakes must be inspected regularly by a qualified mechanic. Damaged or leaking calipers can seriously impair the ARGO steering/ braking capability. Severe personal injury or property damage could result from a damaged or poorly adjusted brake system.
Page 132 Brake System Argo Service Manual Remove Hydraulic Brake Caliper Perform the servicing procedure Removing the Firewall (Quick Release) in section Raise the vehicle off the ground Disconnect the brake line at the caliper. Photo BR-6 Be aware of the brake fluid present in the system.
Page 133 2 or 4 mounting bolts. Vehicles manufactured prior to S/N CB 12455, RB 12474 & SN 8285 utilize the 2 bolt configuration. The 4 bolt style is fully exchangeable and replaces the 2 bolt pattern.
Page 134 Brake System Argo Service Manual BR-11 BR-10 Remove the bleed screws and check the steel ball from the caliper casting. Photo BR-12 Clean all components in a varsol bath, then a mild soap solution. Use com- pressed air to blow out the caliper cast- ings.
Page 135 Argo Service Manual Brake System When reassembling the caliper, work with clean hands, tools, and parts. Perform the reassembly on a clean, neat surface. Dirt or contaminants on component parts will cause a reduction in brake efficiency and may damage the brake components.
Page 136 Brake System Argo Service Manual BR-15 BR-16 Reinstall the socket head bolts which hold the caliper assembly together. Use blue LOCTITE on the threads of the fasteners. Torque the bolts to the specified torque. Photo BR-17 Place the check ball and bleeding screw back into the threaded mount of the caliper casting.
Page 137 Argo Service Manual Brake System Reattach the brake line at the caliper. Photo BR-20 Always use new copper washer seals at all brake line connections Perform the servicing procedure, Bleed- BR-20 ing the Hydraulic Brake System. Removing the Master Cylinder Clean the master cylinder casting and caliper casting and fittings.
Page 138 Brake System Argo Service Manual There are 2 bolts that hold the master cylinders to their mounting bracket. These are secured by 2 nylon locknuts. Remove the 2 nylon locknuts and remove the master cyl- inders from the vehicle to a clean work bench.
Page 139 Argo Service Manual Brake System Models manufactured after May 25, 2000 from S/N CB17145, RB17120, BF11608 and SN11630 have a tapered spring which attaches to the end of the piston. Models prior to this had a shorter spring which did not attach to the piston. The newer spring is fully exchangeable with the older style but should be replaced as a set.
Page 140 The older and newer style spring are fully exchangeable if necessary, but should be changed as a set. Vehicles manufactured from S/N CB17145, RB17120, BF11608 & SN11630 will have the newer spring style.
Page 141 Argo Service Manual Brake System Install the piston into the piston bore. Slide the end with the primary seal in first. Photo BR-27 BR-26 BR-27 Temporarily install the cover and gas- ket onto the master cylinder reservoir. Master Cylinder Installation...
Page 142 Clean any stray brake fluid that might have found its way on to the brake disc with brake cleaner. Brake fluid on the brake disc can seriously affect braking capabilities of the ARGO vehicle. Pump the steering levers a few times to build up proper pressure and locate the pads in the caliper assembly.
Page 143 Use only Dot 5 silicon brake fluid. Other brake fluids may not be compatible with ARGO brake components and operating temperatures. Inspecting the Brake Fluid Condition Maintenance Schedule- Inspect every 50 hours of vehicle operation.
Page 144 Brake System Argo Service Manual Inspect the condition of the brake fluid and replace if: the fluid appears cloudy the fluid appears discoloured the fluid contains particles of dirt, rust, water, or other contaminants the level is below the viewing window If any of these conditions are noted, Perform the servicing procedure, Changing the Brake Fluid below.
Page 145 Argo Service Manual Brake System Hydraulic Brake Plunger Pin Adjustment IMPORTANT It is critical that the master cylinder pistons are adjusted properly when the steering levers are at the dash block position. Overheating of the brake system could occur due to the piston being adjusted too far in. This could cause a drag on the system and a possible brake lockup.
Page 146 Push the collar up tightly against the tab stop of the steering bracket assembly and re-tighten set screw(s). Apply Blue 242 LOCTITE to the threads of the set screw. The 1/4" clearance between the dash block and engagement of the plunger pin is now set.
Page 147 Argo Service Manual Brake System Holding Brake Adjustment The holding brake system has been factory adjusted to ensure proper braking effectiveness. However, before the vehicle is used for the first time, and after every 25 hours of operation, the adjustment of the holding brake must be inspected.
Page 148 ARGO vehicle. Severe personal injury could result from a damaged or poorly adjusted brake system.
Page 149 Argo Service Manual Brake System The mechanical brake caliper assembly probably needs adjustment and servicing when: a drag on vehicle power and acceleration occurs • a loss of braking effectiveness is noted • steering does not respond properly • excessive strength is required to steer or stop the vehicle •...
Page 150 Brake System Argo Service Manual Remove all locknuts and jam nuts from the 2 bolts that secure the two halves of the mechanical calipers together at the power pack frame. Photo BR-38 Remove the brake cam assembly and flat washer. Photo BR-39 Remove both mounting bolts and separate the calipers from the power pack frame.
Page 151 Using one new and one old brake pad in a caliper assembly may provide poor braking and steering performance. Quality ARGO replacement brake pads are available only in a set of 2. Perform the servicing procedure, Me- chanical Brake Caliper Removal.
Page 152 Brake System Argo Service Manual Take care in drilling out old pop rivets. Damage to the caliper casting could occur, requiring a more expensive caliper replacement. Clear the remainder of the rivets with a 11/64" drill bit. Remove the pad and discard.
Page 153 Argo Service Manual Brake System Mechanical Brake Caliper Installation Lay out mechanical brake caliper components onto the work bench. Photo BR-46 Take note of the orientation of the brake cam to the adjustment rod, and be sure to assemble accordingly if this assembly has been disassembled for any reason.
Page 154 Brake System Argo Service Manual BR-51 BR-52 Apply a little axle grease to the two ball bearing cavities of the second caliper and place two ball bearings into these cavities. Lightly tap each ball bearing with a soft faced mallet to seat it within the cavity.
Page 155 Argo Service Manual Brake System Always use new locknuts whenever servicing mechanical brake calipers. Adjusting the Mechanical Brake Caliper (Vanguard Models) Remove the vehicle firewall and proceed to tighten both front and rear nuts so that the mechanical caliper assembly is snug to the brake disc. Photo BR-57 This is a good starting point to begin brake caliper clearance adjustment.
Page 156 Brake System Argo Service Manual Using two opened end wrenches, tighten the jam nut against the adjust- ment nut. Recheck the clearance one more time and adjust if necessary. Install return spring & flat washer to adjustment rod and loosely start the BR-61 locknut to the end.
Page 157 If components are no longer listed in your Spare Parts Price List (Distributors and Dealers Only) generally the superceded section will indicate which part(s) will update or replace it. All parts manuals are available in PDF format on CD.
Page 158 Brake System Argo Service Manual Removing a Brake Disc When servicing a left side brake disc, you will need to remove the driven clutch from the transmission. Refer to Removing the Driven Clutch in section CS of this service guide.
Page 159 If the ARGO is equipped with a brake cooling fan system, as is the case with all CB, RB, BF & C vehicles, you will need to loosen and slide the brake shroud out of the way before the brake disc can be slid off the output shaft.
Page 160 There are two 1/4" x 1/4" keys used on the keyed output shafts. Vehicles produced from S/N's: S11188, SN11196, CB16459, RB16446 & BF11143, are splined. These accommodate the newer style splined output shafts. These splined brake discs are fully exchangeable with the keyed versions if desired, however this would also mean replacing the output shaft as well.
Page 161 Argo Service Manual Brake System Installing the Brake Disc On vehicles produced prior to S/N CB16459, RB16446, BF11143, S11188 & SN11196 Apply an anti-seize compound to both output shafts. ii.. Place both keys in the keyways of the output shafts.
Page 162 Brake System Argo Service Manual Align the spline of the brake disc with those on the output shaft and slip the disc on and up to the shoulder of the output. (See NOTE previous page) iii. Re-position the cooling duct and and secure with the two 1/4"-20x1" phillip head screws (CONQUEST MODELS) or retightening the gear clamp on the overhead mounting bracket ( BIGFOOT &...
Page 163 2 short spacers. The bracket should be oriented as the right side, with the top hole closest to the back edge of the bracket facing the assembler. Secure with 2 more locknuts. Photo’s 71 & 72 Brackets should look as in BR-73 from the assembler’s perspective.
Page 164 Photo BR-76 BR-75 BR-76 Install 4 roll pins to secure both shafts to the parking brake lever. Photo’s BR-77 & 78 BR-77 BR-78 11. Thread the jam nut to the 2 parking emergency brake rods. Photo BR-79 12.
Page 165 Argo Service Manual Brake System BR-80 BR-81 Do not install the bearing balls to the single caliper with the notched area. 13. Assemble the ball joint to the brake cam as shown in Photo BR-81. Secure it with a nylon locknut. Orient the cam as illustrated in the photo.
Page 166 Brake System Argo Service Manual 17. Place the previously assembled ball joint and cam to the longer of the two bolts. Slip the flat washer on to the bolt at the cam first, then start the 2 way locknut to both the front and rear caliper mounting bolts.
Page 167 Argo Service Manual Brake System 23. Tighten the jam nut at the ball joint on the parking/emergency brake rod. Photo BR-88 24. Apply blue 242 LOCTITE to the threads of the bolt at the brake cam and thread a second locknut up to and against the first one.
Page 168 Brake System Argo Service Manual BR-93 BR-94 27. Mount the other side of the brake cooling duct using a bolt, lock washer and flat washer. Attach this end using the same bolt that secures the steering bracket to the rear threaded transmission boss. Photo BR-94...
Page 169 Argo Service Manual Brake System SECTION BR Supplement Pages Ontario Drive & Gear ltd. www.odg.com/centaur (519) 662-2840 FAX (519) 662-2421...
Page 170 Brake System Argo Service Manual Ontario Drive & Gear ltd. www.odg.com/centaur (519) 662-2840 FAX (519) 662-2421...
Page 171 Argo Service Manual Brake/Steering System Read all the instructions thoroughly before starting and attempting ANY repairs. Consult your Argo Dealer if you have any questions. Disassembling the Moto Cross Style Steering Column (All Models) Perform the servicing procedure, Removing the Firewall.
Page 172 Brake/Steering System Argo Service Manual Avenger Models Only Slip the Steering Shaft from the Steering Column Assembly. Photo ST-5 ST-4 ST-5 On all models manufactured from C22453, R22452, B14700, A14743, N14708 Remove the (3) fasteners securing the 612-117 steering column assembly to the transmission.
Page 173 Argo Service Manual Brake/Steering System ST-6 ST-7 Reassembling Steering Column (Avenger Models Only - Prior to V22441) Install the Spring Pin into the Steering Shaft at the 4th hole from the end. Photo ST-8 The roll pin should be installed such that the slot of the pin is parallel to the shaft, and an equal amount of pin protrudes on each side of the shaft.
Page 174 Brake/Steering System Argo Service Manual ST-11 ST-10 ST-12 ST-13 Roll pin slot parallel with shaft Vehicles manufactured from V22441, C22453, R22452, B14700, A14743, N14708: Install the Spring Pin at the 2nd hole from the end on the Steering Shaft The...
Page 175 Argo Service Manual Brake/Steering System ST-15 ST-16 Apply some axle grease to the length of the Steering Shaft, Photo ST-17, and insert it from the bottom up, into the Steering Column Assembly with the small keyway facing towards you. Photo ST-18...
Page 176 N14990, V23535, R23560, A15022 utilize 2 keyways and 2 keys. 11. Align the keyway(s) of the Lower Handle Bar Clamp with that of the previously installed key(s) and assemble to the Steering Shaft. Photo ST-20 & 21...
Page 177 Argo Service Manual Brake/Steering System 14. Set the Handle Bar assembly into place and cover with the Upper Handle Bar Clamp. The Handle Bar clamp is se- cured into place with four fasteners. Tighten down the fasteners in an "X"...
Page 178 Brake/Steering System Argo Service Manual Hydraulic Brake Plunger Pin Adjustment IMPORTANT It is critical that the master cylinder pistons are adjusted properly when the steering handle bar is at the centered position. Overheating of the brake system could occur due to the piston being adjusted too far in. This could cause a drag on the system and a possible brake lockup.
Page 179 Ensure the tab stops that the collars come into contact with are not bent in any way. This will affect how the plunger pin sits when the opposite brake is applied. Any deformity in the tab could cause the plunger pin to become misaligned with it's own steering arm during the application of the opposite brake.
Page 180 Brake/Steering System Argo Service Manual Re-check the brake plunger piston to ensure it is still flush to the casting and fine adjust if necessary. Install the rubber boot. Steering Bar Centering Adjustment (Early Model Avengers With Handle Bar Centering Springs Only)
Page 181 Argo Service Manual Brake/Steering System BR-7 Perform the servicing procedure, Hydraulic Plunger Pin Adjustment (Avenger Model), in this section of the service guide. Re-hook the springs and test. Adjust either upper, lower or both springs as necessary until the desired outcome is achieved.
Page 182 Brake/Steering System Argo Service Manual Ontario Drive & Gear Limited www.odg.com BR-12A PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 183 Accessory Instructions October 2007 850-98 - Parking Brake Service Assembly Ref. Qty. Part # Description 850-98 Kit, Service, Parking Brake includes Ref. 2 - 7 Cam Tension Spring (compression) Left & Right Brake Pads Cam Arm Spring (tension) Brake Pad Retaining Screw Castle Nut Cotter Pin Detailed information on standard workshop and safety procedures, and general instal-...
Page 184 5. Split and remove the caliper assembly. Figure 5 Take note of all spacers, shims and washers within the assembly. Refer to your illustrated parts list in your Argo Parts manual for all locations of these components. 6. Locate the 850-84 Dead Side Brake Housing and remove the screw securing the brake puck.
Page 185 9. Install the new brake pad to the dead side housing and secure with screw. Apply some LOCTITE 242 Blue to the threads of the screw before installing. 10. Locate the live side brake housing and slip the shim washer into the cavity first (Figure 8), before installing the brake pad.
Page 186 Figure 10 - Shim. Figure B - Right Side. Assembling the Left Hand Side Emergency/Parking Brake Caliper 12. Install the live side housing to the inside of the brake disc. Insert (2) two mounting bolts with spacers to the head of each bolt. Place a thin washer (to each bolt) on the inside of the mounting bracket.
Page 187 Locate the brake lever assembly and reattach the exten- sion spring to the hole provided. If the spring was com- pletely removed, it should be attached first to the tab on the mounting bracket, then to the cam lever. Figure 16. Figure 13 - Secure With Nylon Locknuts.
Page 188 If the emergency/parking brake system is adjusted too tight when the lever is in the down position, overheat- ing of the brake system will occur due to drag between brake pads and brake discs. Adjusting the Emergency/Parking Brake 1. Ensure the parking brake lever is fully down. 2.
Page 189 Adjust if necessary. 10. Check the effectiveness of the parking brake by parking the Argo on the steepest hill encountered and by loading to it’s maximum working load. The parking brake should hold the Argo from moving.
Page 190 General Information Argo Service Manual Ontario Drive & Gear Limited www.odg.com GI-28 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 191 Argo Service Manual Clutch System SECTION CS Clutch System Table of Contents General Instructions................CS-2 Maintenance Information..............CS-3 Drive Belt Inspection................CS-3 Removing the Drive Belt...............CS-4 Installing the Drive Belt.................CS-5 Driver Clutch Inspection..............CS-5 Driver Clutch Removal................. CS-5 Disassembling the Driver Clutch (Threaded Bushing Spring Cap). CS-7 Disassembling the Driver Clutch (Cap Screw Spring Cap)....CS-9...
Page 192 (Top No Load Speed). At the same time, the transmission’s driven clutch plates spread apart as the belt rides down between the faces. The tension in this clutch is also regulated by a spring.
Page 193 Argo Service Manual Clutch System Maintenance Information The maintenance information provided in this manual refers to an ARGO vehicle operating under normal conditions and use. Service more often when the vehicle is used under heavy duty applications. Servicing of the Automatic Torque Converter system is necessary when:...
Page 194: Clutch System
Clutch System Argo Service Manual Replace the drive belt if: the width of the belt is worn to 1 - 1/16" (27mm) the belt is cracked, frayed or shredding the belt has become contaminated with oil or other fluids Check the condition of the belt in the table below and perform the necessary servicing procedure.
Page 195 Argo Service Manual Clutch System Installing Drive Belt Use only ARGO quality replacement drive belts. If this procedure is not carried out as described, the edge of the fixed face may cut or damage the drive belt. Position the belt around the driver clutch first.
Page 196 Locate and loosen out the FHSC M10x1.5x100 fastener using an allen head socket. This fastener’s bevelled head sits flush to the end of the fixed faced pulley shaft. This is due to the countersink in the end of the shaft . There is no lockwasher, only blue 242 LOCTITE used to secure it in place.(Threaded Bushing Spring Cover)
Page 197 Argo Service Manual Clutch System The driver clutch must be slid from the PTO with the mounting bolt hardware within the clutch. The mounting bolt is too long to remove first. The driver clutch may contact the lower body first before completely being free of the PTO, however the lower body will give enough in that area to free the clutch.
Page 198 Remove the spring. Photo CS-7 CS-6 CS-7 Remove the retaining ring and any spacer(s) that may be present. Photo CS-8 Remove the spring guide plate. Photo CS-9 CS-8 CS-9 10. Remove the second retaining ring and any shim(s) that may be present.
Page 199 Argo Service Manual Clutch System CS-10 CS-11 12. Wash clutch components in a clean varsol bath to eliminate accumulated dirt and grease build up, and perform the servicing procedure, Inspecting the Driver Clutch, in this section of the service guide...
Page 200 Clutch System Argo Service Manual This cap is under spring tension and will fly apart if precautions are not taken to hold it down while the cap screws are removed. Be sure to always wear eye protection when servicing the clutches, or any other vehicle component for that matter, with the potential of flying parts.
Page 201 Argo Service Manual Clutch System On all RB, BF, SN, S, R, N & B Models,(Briggs & Stratton), remove the lower retaining ring from the fixed pulley shaft. Photo CS-18 All CB, C & A Models (Conquest) driver clutches have a machined shoulder on the shaft of the fixed half pulley.
Page 202 CS-21 CS-00 CS-22 Install the lower retaining ring to the fixed shaft along with any shim(s) to the top of the retaining ring. Photo CS-22 (Response, Bigfoot & Vanguard clutches only) Place the spring guide washer on next. Photo CS-23 Install the second retaining ring to the fixed face shaft along with any shim(s) that may have been installed before..
Page 203 Argo Service Manual Clutch System Thread the spring cap into the top of the moveable face until it sits approximately 0.100" above the top edge of the moveable face. Use a vernier to measure this. Photo CS-27 Once this measurement is set, you may need to turn the threaded cap in either direction to align the machined keyway in the cap with the set screw in the moveable face.
Page 204 Slip the moveable face on to the shaft of the fixed face pulley and install the retain- ing ring. (This retaining ring is used only in clutches installed on RB, BF, SN, B, N, R & S model ARGOS) Photo CS-33 See Note Below. CS-32 CS-33 This retaining ring is not used in clutches manufactured for the Conquest vehicle.
Page 205 Argo Service Manual Clutch System Place the spring guide washer on top of the retaining ring (or to the machined shoul- der on Conquest clutches). Photo CS-34 Install the spring ring to the second position on the shaft of the fixed pulley.
Page 206 Clutch System Argo Service Manual Place each of the weights and blocks into the moveable face and orient as shown in Photo CS-38 & 39 CS-39 CS-38 Clutch Weight Chart Response & Bigfoot Vehicles 225g Conquest Vehicles prior to CB17506...
Page 207 Argo Service Manual Clutch System CS-43 CS-42 Installing the Driver Clutch Apply anti-seize compound to the engine PTO shaft. Install the key to the keyway of the PTO shaft. Install the mounting hardware into the driver clutch before attempting to slip the clutch on to the PTO of the engine.
Page 208 Clutch System Argo Service Manual Driven Clutch Lubrication Lubricate the driven clutch every 50 hours with a silicone based lubricant such as WD-40. Spray the lubricant into the clutch unit, directing the spray onto the spring, bushing and the sliding areas of the cam pulley and the fixed cam where the cam shoes make contact.
Page 209 Argo Service Manual Clutch System Perform the servicing procedure, Driven Clutch Removal/Disassembly if the vehi- cle: is not changing speed smoothly hesitates or sticks at one speed lacks turning power won’t move when the engine is accelerated in gear and brakes are disengaged does not backshift under load Ontario Drive &...
Page 210 With the retaining ring removed, slowly release the arbor press off the cam until the cam is free of the fixed pulley’s shaft and the spring has un- wound . Photo CS-46 Ontario Drive & Gear Limited www.odg.com...
Page 211 CS-47 Slide the movable face from the fixed pulley. Photo CS-48 Remove the retaining ring and spacer(s) from the shaft of the fixed pulley. Photo CS-49 The Oilite bushing of the 126-24 driven Clutch movable face is secured with a spring pin.
Page 212 Clutch System Argo Service Manual CS-50A CS-50 To replace the nylon cam slider shoes, pry each out with a slot screwdriver or CS-51 small chisel. You may need to use a small hammer applying quick blows to pop the slider shoes loose.
Page 213 Argo Service Manual Clutch System Driven Clutch Reassembly (126-24 & 127-129) Press the oilite bushing into the movable face and secure with the roll pin or retain- ing ring. A new bushing requires re-drilling the hole in the movable face (126-24 driven clutches only),once the bushing is in position.
Page 214 Clutch System Argo Service Manual CS-54A CS-53A All Driven Clutches Install the cam and spring to the fixed face shaft aligning the key on the fixed shaft with the keyway in the cam. Photo CS-55 Take to the arbor press and push the cam onto the shaft while turning the movable face counter clockwise 120 degrees, or one cam notch past the first cam shoe .
Page 215 Argo Service Manual Clutch System Testing The Spring Load Of The Driven CS-57 Clutch Place the driven clutch in a soft faced aluminum jawed vise and clamp so that the movable face is free to turn. Clamp a good digital or regular spring fish scale to the edge of the moveable pulley.
Page 216 Clutch System Argo Service Manual IMPORTANT The driven clutch should slip on and up to the shoulder by hand. There should not be any reason to use a mallet to install the clutch. Be sure that all spacers previously used behind the driven clutch have been reinstalled.
Page 217 Argo Service Manual Clutch System SECTION CS Supplement Pages Ontario Drive & Gear ltd. www.odg.com/centaur (519) 662-2840 FAX (519) 662-2421...
Page 218 Clutch System Argo Service Manual Ontario Drive & Gear ltd. www.odg.com/centaur (519) 662-2840 FAX (519) 662-2421...
Page 219 Argo Service Manual Clutch System Disassembling the Driver Clutch (Avenger Models) 1. Remove the large hex nut, flat washer and cap. Photo 1 2. Remove the (3) block and 275gr weight assemblies. Photo 2 3. Remove the (3) fasteners securing spring cover to the sliding flange. Photo 3...
Page 220 Clutch System Argo Service Manual IMPOR IMPORT T T T T ANT IMPOR IMPOR IMPOR There are (3) small lockwashers on these (3) fasteners. Ensure that they are still in place before re-installing and torquing the spring cap back down.
Page 221: Table Of Contents
Argo Service Manual Wheels, Axles & Chains SECTION WA Wheels, Axles & Chains Table of Contents General Instructions................WA-3 Main Frame Information..............WA-4 Drive Chain Maintenance..............WA-4 Drive Chain Removal................WA-5 Drive Chain Inspection................. WA-6 Drive Chain Installation............... WA-7 Drive Chain Lubrication..............WA-9 Drive Chain Cleaning................
Page 222 Wheels, Axles & Chains Argo Service Manual SECTION WA Wheels, Axles & Chains Table of Contents Removing the Idler Shaft (Vanguard & Vanguard2)......WA-29 Idler Shaft Inspection................WA-31 Installing the Idler Shaft (Conquest 8& 6, Response,Bigfoot... WA-33 Installing the Idler Shaft (Avenger &...
Page 223 Argo Service Manual Wheels, Axles & Chains SECTION WA Wheels, Axles & Chains Table of Contents Removing a Tire..................WA-55 Wheel Disassembly................WA-55 Tire Pressure...................WA-55 TireInspection..................WA-56 Temporary and General Tire Repair...........WA-56 Wheel Reassembly................. WA-57 Valve Replacement................WA-57 Wheel Installation................. WA-58 Ontario Drive & Gear Limited www.odg.com...
Page 224 Wheels, Axles & Chains Argo Service Manual General Instructions Detailed information on standard workshop and safety procedures, and general servicing operations is not included in this manual, which has been prepared to assist qualified service personnel. ODG assumes no responsibility or liability for PERSONAL INJURY or VEHICLE DAMAGE which results from any servicing procedure performed, including those instructions outlined in this manual.
Page 225 S/N S8153 Vanguard2 Frame from S/N SN8153 (1995) Front Tube Threaded for Extensions Vanguard & Vanguard2 from S/N SN10191 & Extended Wheel Base and New S10178 (1998) Self Adjust Chain Tensioners Conquest Frame from S/N CB16049 (1999)
Page 226 Wheels, Axles & Chains Argo Service Manual Drive Chain Installation Drive Chain Lubrication Drive Chain Removal Perform the servicing procedure, Removing the Firewall in section VB of this guide. Remove the front and rear floorpans. On 8x8 models manufactured prior to serial numbers CB16049 &...
Page 227 Argo Service Manual Wheels, Axles & Chains Drive Chain Removal On 8x8 models manufactured from serial numbers CB16049 & RB16104, or 6x6 models from serial numbers BF9212, SN10191 & S10178: Turn the tensioner cam assembly in the direction which winds up the torsion spring and push the assembly down as close as possible to the cam follower block in the bottom of the frame.
Page 228 Some drive chains have no slack, and replacement of the connecting link is difficult without this tool. Modified Vice Grips can be ordered from Ontario Drive & Gear (ARGO Part No. 658-08) or refer to Section GI under special tools for modification information.
Page 229 6x6 models from serial numbers BF9212, C12747, SN10191 & S10178: Position the drive chain over the slider block and around the drive sprockets. The chain tensioner system must be secured in it’s lowest position to the frame as illustrated in DIAGRAM WA-5 on page WA-6.
Page 230 Remove both front and rear floor pans. Lubricate the chains with Aerosol Chain Lube (ARGO part No. 125-86). Idler Chain Lubrication Lubricate the idler chains after 10 hrs. of operation, and more frequently if the vehicle is operated in dirty or wet conditions.
Page 231 Argo Service Manual Wheels, Axles & Chains Chain Tensioner Inspection (Earlier Style) On 8x8 models manufactured prior to serial numbers CB16049 & RB16104, or 6x6 models prior to serial numbers SN10191 & S10178: This chain tensioning system consists of an...
Page 232 Wheels, Axles & Chains Argo Service Manual Chain Tensioner Inspection (Later Style) On 8x8 models manufactured from serial numbers CB16049 & RB16104, or 6x6 models from serial numbers C12747, BF9212, SN10191 & S10178: This chain tensioning system consists of a torsion spring loaded cam assembly with a slider block which takes up the slack on the bottom side of all but the front final drive chains.
Page 233 Argo Service Manual Wheels, Axles & Chains Replacing the Slider Block: Remove the floor pans and the appropri- ate drive chain. Turn the tensioner cam assembly in the direction which winds up the torsion spring and push the assembly down as...
Page 234 Wheels, Axles & Chains Argo Service Manual Locate the required chain take up system and remove the tensioner spring. Photo WA-18 Remove the cotter pin which secures the chain tensioner system to the vehicle frame. Photo WA-19 WA-18 WA-19 Slide out the pivot pin which holds the chain tensioner assembly together. Photo...
Page 235 WA-24 WA-00 With the chain removed, unfasten the clamp holding the chain tensioner system and let it unwind to its top most position. Unfasten the spring at the cam's tab. Photo WA-24 To pull the tensioner assembly free of the frame guides, push the the long shaft side of the cam assembly down to the bottom of the guide.
Page 236 Wheels, Axles & Chains Argo Service Manual WA-26 WA-27 Slip the one torsion spring off the cam, and remove the second torsion spring from the frame assembly by removing the cotter pin that secures it. Photo WA-27 Assembling the Chain Tensioner System On 8x8 models manufactured prior to serial numbers CB16049 &...
Page 237 Argo Service Manual Wheels, Axles & Chains WA-30 WA-31 Place the bushing, spring, lower tensioner arm and upper tensioner arm on to the pivot pin as you push the pivot pin through. Photo WA-31 Insert end of pivot pin into the frame bushing and align the cotter pin holes.
Page 238 Wheels, Axles & Chains Argo Service Manual If the Chain tensioner is being installed on an inside chain: Photo WA-35 Insert the end of the pivot pin with the WA-35 cotter pin hole through the inner chan- nel of the vehicle frame.
Page 239 Insert the extended length of the torsion spring, assembled to the cam, into the hole of the welded tab on the frame. Photo WA-39 At the same time, place the same side of the cam's shaft into the tensioner systems guide. WA-39...
Page 240 Wheels, Axles & Chains Argo Service Manual WA-42 WA-43 WA-44 WA-45 Idler Chain Maintenance Regular maintenance of the idler chains is essential to good vehicle performance and personal safety. Poorly maintained idler chains can result in rusted, corroded or seized up chains, damaged brake discs, worn or broken idler shaft assemblies, and costly repair procedures.
Page 241 Argo Service Manual Wheels, Axles & Chains Idler Chain Removal Idler Chain Cleaning Idler Chain Inspection Idler Shaft Inspection Idler Shaft Installation Idler Chain Adjustment Idler Chain Lubrication Idler Chain Removal Perform the servicing procedure, Removing the Firewall. Loosen off the power pack frame On 6x6 vehicles manufactured prior to S8131, locate and loosen off the four 1/2"-...
Page 242 Wheels, Axles & Chains Argo Service Manual WA-47 WA-48 Place the vehicle in neutral gear and roll the vehicle until the connecting link on the idler chain is half way between the brake disc sprocket and the idler assembly sprocket. Photo WA-48 Using a small slot screwdriver, pry off the clip securing the connecting link to the chain.
Page 243 Argo Service Manual Wheels, Axles & Chains Allow the idler chain to dry. Perform the servicing procedure, Idler Chain Inspection Perform the servicing procedure, Idler Chain Installation Perform the servicing procedure, Idler Chain Lubrication Idler Chain Inpsection The idler chains will stretch and wear after extensive vehicle use. If not regularly...
Page 244 Wheels, Axles & Chains Argo Service Manual Perform the servicing procedure Installing the Firewall. Idler Chain Installation Rotate the power pack adjustment bolts. This will lower the brake disc sprocket toward the idler sprocket assembly. See the servicing procedure, Idler Chain Re- moval on Page WA-20 step 3.
Page 245 Argo Service Manual Wheels, Axles & Chains 10. Tension the idler chains 6x6 Models prior to S7304 will require a 3/4" socket on the adjustment bolt head to raise the power pack frame. On 6x6 models produced from S7304 and prior to S8131, use an allen head wrench to turn the adjustment bolts clockwise.
Page 246 Refering to Photo WA-49 on page WA-22, tension the chains until the amount of deflection is less than 1/8" Secure the jam nuts of each tensioner bolt. (Prior to S8131 6x6’s only). Tighten all power pack mounting bolts. Ontario Drive & Gear Limited www.odg.com...
Page 247 IMPORTANT Idler shafts on Conquest, Response, Bigfoot & 6x6 Conquest models manufactured from S/N CB16970, RB17033, BF11543 & V6016200000C12747, utilize 1 retaining ring on each shaft. These are seated to a machined groove on each of the shafts. One idler shaft has an “inboard” retaining ring and the other an “outboard” retaining ring.
Page 248 Photo WA-53 WA-52 WA-53 On vehicles manufactured prior to S/N CB16970, RB17033 and BF11543: Remove the hardware securing the flanges of the inner and outer bearings. Photo WA-54 Slide the idler shaft assembly towards the inner bearing, and lift up and out at the outer bearing and flange assembly.
Page 249 Argo Service Manual Wheels, Axles & Chains On vehicles manufactured from S/N CB16970, RB17033, BF11543 and C Vehi- cles: Argos manufactured from the above serial numbers utilize a retaining ring on each idler axle shaft. The left hand side idler axle shaft has 1 retaining ring which is “outboard” to the floating double sprocket.
Page 250 (Right side idler shaft only), in section ES. (Vehicles prior to S/N S8131 have the battery box welded to the lower frame.) Perform the servicing procedure, Removing the Driven Clutch, (Left side idler shaft only), in section CS.
Page 251 Argo Service Manual Wheels, Axles & Chains Perform the servicing procedure, Idler Chain Removal. Perform the servicing procedure, Removing the Brake Disc in section BR. (Op- tional, if you find it easier to access the idler shaft). Perform the servicing procedure, Drive Chain Removal. Remove the front drive chain connecting the front wheel to the idler axle, as well as the drive chain connect- ing the center wheel to the idler axle.
Page 252 IMPORTANT If any wear is noted on the idler shaft or it’s components, it is advisable to check the brake disc drive sprocket as well to ensure that the misalignment has not caused any damage to this drive component either.
Page 253 IMPORTANT Idler shafts on Conquest, Response, Bigfoot & 6x6 Conquest models manufactured from S/N CB16970, RB17033, BF11543 & V6016200000C12747 utilize 1 retaining ring on each shaft. These are seated to a machined groove on each of the shafts during assembly of the floating sprocket. The right hand side idler shaft has an “inboard”...
Page 254 Place a gasket to each of the previouly installed flanges. Photo WA-69 WA-68 WA-69 On vehicles manufactured prior to S/N CB16970, RB17033 and BF11543: Assemble the floating sprocket to the idler shaft with the set screw side facing out- wards (towards the outer bearing). Photo WA-70 Slip the greasable flange to the same side as the sprocket.
Page 255 Argo Service Manual Wheels, Axles & Chains WA-73 WA-72 Install the idler shaft assembly into the vehicle. Slip the inner bearing end of the shaft in first, then drop the outer bearing end connecting bearing and flanges to the studs. Photo WA-74 IMPORTANT Ensure that the greasable flanges are installed with the greaseable fitting facing up.
Page 256 Torque to specifications. Photo WA-77 WA-77 On vehicles manufactured from S/N CB16970, RB17033, BF11543 & V6016200000C12747: Left Hand Side Idler Axle Slip the “outboard” retaining ring on to the idler shaft past both machined grooves (vehicles manufactured from 2007 will have (4) machined grooves on this idler shaft), and to the end of the spline.
Page 257 Argo Service Manual Wheels, Axles & Chains WA-81 WA-82 Slip the greasable flange to the same side as the sprocket. Photo WA-82 iii. Slip the inner bearing on to the shaft with the set screws and collar facing towards the sprocket. Photo WA-83 Install a greasable flange and the outer bearing to the opposite side of the shaft, once again facing the collar and set screws of the bearing inwards.
Page 258 Wheels, Axles & Chains Argo Service Manual vi. Install all bearing flange hardware and tighten securely. Torque to specifications. vii. Seat the "outboard" and "inboard" retaining rings to the grooves on the idler shaft. If Idler shaft has (4)four machined retaining ring grooves, refer to Supplement Pages WA- 36A for correct retaining ring groove location.
Page 259 Argo Service Manual Wheels, Axles & Chains 11. Perform the servicing procedure, Installing the Firewall in section VB. Installing the Idler Shaft (Vanguard & Vanguard2 Models) IMPORTANT 6x6 Vanguard and Vanguard2 idler axles, unlike those used on Conquest, Response, Bigfoot or Conquest 6x6, have a distinct left and right hand side. When replacing an idler axle, keep this in mind and order accordingly.
Page 260 Install all mounting hardware to the flanges and tighten securely. Torque to specifi- cations. On vehicles manufactured prior to S/N S10178 & SN10191, slide an open end wrench between the lower body and frame at the outer idler axle bearing flange assembly. Hold the head of the bolt while tightening the mounting hardware.
Page 261 Argo Service Manual Wheels, Axles & Chains 10. Place the V block and square on to the idler shaft, pushing the square up against the inner drive sprocket. Photo WA-94 WA-94 WA-95 11. Tap the idler shaft using a soft face mallet until the square contacts the upper sprocket.
Page 262 The grease fittings become more accessible when the idler chains are removed. Alternatively, ARGO Part# 658-16 Right Angle Coupler, can be used to access these fittings (also sold at automotive supply stores as a Right Angle Grease Coupler, Thexton part no.
Page 263 Remove the set screw from the drive sprocket. Photo WA-100 (Except for all front sprockets which float) Front axles on Vanguard 6x6's manufactured prior to S/N S8131 are not splined. These axles and sprockets are keyed and allow the front sprocket to float. Loosen the set screw on the locking collar used to limit the amount the sprocket can float.
Page 264 WA-104 punch. Photo WA-104 6x6 Vanguards manufactured prior to S/N S7447 have only a single seal in the outer bearing greasable flange. Later 6x6 models,as well as all other models, have 2 grease seals in the outer bearing greasable flange. Single seal outer bearing greasable flanges are no longer available and must be updated to the to the double seal if replaced.
Page 265 Argo Service Manual Wheels, Axles & Chains Clean the cavity of the greasable flange in a varsol bath to remove any accumulated dirt and grease. Blow the greasable flange with compressed air to thoroughly dry and remove any remaining dirt.
Page 266 Wheels, Axles & Chains Argo Service Manual WA-108 WA-109 On dual seal greasable flanges: There are 2 different styles of grease seals used in the dual seal outer bearing greasable flange. Photo WA-108 These grease seals are differentiated in size & by 2 part numbers.
Page 267 Argo Service Manual Wheels, Axles & Chains Slip the outer bearing greasable flange over the axle shaft. Photo WA-112 Slip the outer bearing over the axle shaft, orienting it with the collar facing up. Photo WA-113 Align the flat machined surface closest to the sprocket end of the axle, with the set screw hole of the bearing.
Page 268 Wheels, Axles & Chains Argo Service Manual 10. Place a cork gasket on to the outer flange. Photo WA-117 11. Place the inner flange on top of the cork gasket. Photo WA-118 12. Place a second gasket to the top of the inner flange. Photo WA-119 13.
Page 269 Torque to specifications. . WA-124 Keyed Front Axles - used on Vanguard 6x6's manufactured prior to S/N S8131: Assemble the keys to the axle shaft and apply anti-seize to the keyed area. Slip the keyed sprocket on to end of the axle shaft with the longer shoulder side facing inwards.
Page 270 Wheels, Axles & Chains Argo Service Manual 20. Perform the servicing procedure, Outer Axle & Bearing Lubrication 21. Perform the servicing procedure, Inner Axle Bearing Lubrication Outer Axle Flange & Bearing Lubrication Do not use high pressure pneumatic greasing equipment Each outer axle flange is equipped with two grease fittings.
Page 271 There are also some differences in the mounting of the outer flanges to the extension with regards to components, depending on the date of manufacture. On Models manufactured prior to S/N CB19200, RB19204, BF13178 & C13176, there is no inner flange or second gasket assembled to the extension. Install gasket, then bearing and greasable flange.
Page 272 Wheels, Axles & Chains Argo Service Manual Assemble the axle as shown in Photo WA-127 Install the axle assembly into the lower body and extension. Orient the greasable fittings so that the outer grease fitting is at the 9 o'clock position, and the inner one is at 12 o'clock.
Page 273 WA-132 require a new style gasket as well. Vehicles manufactured from S/N CB19200, RB19204, BF13178 & C13176 feature this new design. Older design extensions are no longer available as a stock item. Photo WA-133 & 134...
Page 274 WA-137 IMPORTANT 6x6 Vanguards manufactured prior to S/N S7447, differ in axle and bearing setup. These vehicles require the inner bearing to be assembled to the greasable flange with the collar facing up, but still aligning the small hole in the bearing with the grease fitting in the flange.
Page 275 Argo Service Manual Wheels, Axles & Chains Place a gasket to the top of the greasable flange. Photo WA-138 Vehicles manufactured from serial numbers A13984, R20470, C20468 & B13985 do not require this inner gasket due to a tooling change to the inner flange assembly.
Page 276 Wheels, Axles & Chains Argo Service Manual Removing a Tire Loosen each of the wheel nuts on the tire. Raise the vehicle off the ground and remove all 5 wheel nuts. Pull the tire from the vehicle. Wheel Disassembly IMPORTANT Proper tools are required for tire removal Remove the valve core to deflate the tire.
Page 277 Tire Repair and Replacement To repair or replace a tire you will need to remove it from the rim. Use of a non-standard tire on any Argo model will affect the steering characteristics of the vehicle. Serious injury could result.
Page 278 Wheels, Axles & Chains Argo Service Manual Wheel Reassembly Be sure the rim is clean and smooth Apply lubricant to the bead and rim bead seat. Never use petroleum or silicon based solutions as lubricants. Rim slippage, bead damage or dislodging of the bead may result. Regular tire lube or a thin liquid soap and water solution works best.
Page 279 Argo Service Manual Wheels, Axles & Chains Inflate the tire to remount the bead. See servicing procedure, Wheel Reassembly in this section of the service guide. Wheel Installation Apply anti-seize compound to the threads of the axle hub studs. Place the wheel on to the mounting studs.
Page 280 General Information Argo Service Manual Ontario Drive & Gear Limited www.odg.com GI-28 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 281 Argo Service Manual Wheels, Axles & Chains SECTION WA Supplement Pages Ontario Drive & Gear ltd. www.odg.com/centaur (519) 662-2840 FAX (519) 662-2421...
Page 282 Wheels, Axles & Chains Argo Service Manual Ontario Drive & Gear ltd. www.odg.com/centaur (519) 662-2840 FAX (519) 662-2421...
Page 283 Argo Service Manual Wheels, Axles & Chains Assembling The Idler Shafts To The Vehicle (Avenger Models Prior to 25622) Apply some LOCTITE anti-sieze compound to each end of the 810-32 idler shafts . Right Hand Idler Shaft Install a 606-72 idler sprocket to a 810- 32 idler shaft.
Page 284 Wheels, Axles & Chains Argo Service Manual 101-35 bearing, 101-80 right angled greasable flange & 605-63 flange.. Photo 15E & F Secure Loosely with (4) flat washers and (4) nylon locknuts. IMPOR IMPORT T T T T ANT IMPOR IMPOR...
Page 285 Argo Service Manual Wheels, Axles & Chains There are 2 different lengths of grease tubing for the left and right hand side idler shaft assembly. See your Avenger parts manual for correct lengths. 15 H 15 I Install the 100-111 bulk head fittings to the left and right side of the frame and con- nect the tube to the swivel grease fittings of the two inner bearings.
Page 286 Diagram B Assembling Frontier Idler Shafts to Vehicle Installation of the 606-78 Idler Shaft assembly on ARGO Frontier models requires the assembly of a 107-10 Retaining Ring to each side of the 606-81 Idler Sprocket. These retaining rings help limit allowable movement of the idler sprocket under application.
Page 287 Argo Service Manual Wheels, Axles & Chains Diagram D Retaining Ring Locations For Conquest, Response and Bigfoot (810-59 Idler Shafts With (4) Retaining ring Grooves) DIAGRAM E DIAGRAM F Ontario Drive & Gear Limited www.odg.com WA-36A PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 288 Service Guide Remove the drive chain between front sprocket and idler shaft sprocket. Photo WA-1 Refer to Drive Chain Removal in the 673-04 Argo Service Guide. Remove the inner axle fastener and washer located at the inner bearing on the axle end.
Page 289 Photo WA-7 15. Clean all components in a varsol bath and inspect. 16. Perform the servicing procedure, Removing the Axle Seals, in the Wheels, Axles & Chain section of the 673-04 Argo Service Guide. Ontario Drive & Gear Limited www.odg.com WA-51A PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 290 Installing the Front Axle (Avenger Models) Perform the servicing procedure, Installing the Axle Seals, in the Wheels, Axles & Chains section of the 673-04 Argo Service Guide. Slip the greasable flange over the axle and slide it up close to the hub. Install the bearing to the shaft with the collar side facing up.
Page 291: Table Of Contents
Wheels, Axles & Chains Argo Service Manual Install a cork gasket at the front aluminum axle extension followed by a steel inner flange and second cork gasket. Photo WA-12 WA-12 WA-13 Apply some anti-seize compound to the spline area of the axle shaft. Photo WA-13 Slip the axle assembly into the front bearing extension.
Page 292 Argo Service Manual Wheels, Axles & Chains WA-16 WA-17 11. Secure with nylon locknuts and torque to specifications. Photo WA-18 WA-18 WA-19 12. Apply blue LOCTITE to the threads of the fastener (Photo WA-19), used to se- cure the end of the axle to the inner bear- ing and install.
Page 293 673-04 Argo Service Guide. 16. If you removed the driven clutch and drive belt, reinstall. Refer to Driven Clutch Installation and Drive Belt Installation in the Clutch Section of your 673-04 Argo Service Guide. 17. Replace the firewall and floor pans. WA-55A Ontario Drive &...
Page 294 General Information Argo Service Manual Ontario Drive & Gear Limited www.odg.com GI-28 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 295 Argo Service Manual Fuel System SECTION FS Fuel System Table of Contents General Instructions................FS-2 Fueling the Vehicle................FS-3 Removing the Fuel Tank (All Models, except Avenger)..... FS-4 Removing the Fuel Tank (Avenger Models) Supplement Pages..FS-4A Vented Fuel System................FS-4 Removing the Fuel Tank (6x6 Vehicles Prior to S7304).....FS-7...
Page 296 Keep all open flame or spark away from the Argo while servicing the fuel system. Gasoline is extremely flammable, and can cause serious PERSONAL INJURY or DEATH.
Page 297 Never use gasoline containing methanol or white gas since engine or fuel system damage could occur. All models of the ARGO are equipped with a 32 litre (7.0 Imp. Gal., 8.4 U.S. Gal.) “see- thru” polyethelene fuel tank located underneath the driver’s seat. depending on loading and driving conditions, an ARGO can be driven for 7 to 12 hours on one tank of fuel.
Page 298 These deposits clog the fuel system and cause engine starting and operating problems. When storing the ARGO for 45 days or more, use ARGO Part No. 127-77 Fuel Stabilizer to treat fuel in the fuel tank and fuel containers.
Page 299 Argo Service Manual Fuel System IMPOR IMPORT T T T T ANT IMPOR IMPOR IMPOR Depending on the design of the fuel tank, earlier models may require that the tank be removed from the vehicle by pulling it from the seat frame into the rear compartment.
Page 300 FS-6 Slip the new or cleaned tank through the top of the seat support frame, or in from the rear compartment of the Argo. See IMPORTANT on previous page. Reconnect the filler hose to the tank and secure with the gear clamp.
Page 301 Argo Service Manual Fuel System cracks, breaks or punctures in all fuel lines and hoses. • cracked fuel filter casing • If any of these conditions exist, replace the affected component parts immediately. Removing the Fuel Tank (6x6 Vanguards prior to S7304) Drain the fuel tank.
Page 302 ARGO Part No. 125-64). On Conquest models the fuel filter is located in the fuel hose, next to the fuel tank. On all other Argo models the fuel filter is located at the engine. Replace the fuel filter after every 250 hours of operation or once a year. To replace the filter, loosen the gear clamps with a standard screw driver and pull the rubber fuel lines off of the filter.
Page 303 Argo Service Manual Fuel System SECTION FS Supplement Pages Ontario Drive & Gear ltd. www.odg.com/centaur (519) 662-2840 FAX (519) 662-2421...
Page 304 Fuel System Argo Service Manual Ontario Drive & Gear ltd. www.odg.com/centaur (519) 662-2840 FAX (519) 662-2421...
Page 305 Argo Service Manual Fuel System Removing the fuel Tank (Avenger) Drain any fuel that may be present in the fuel tank. Remove the seat to expose the storage tray & battery. Remove the battery. Drill out the 11 rivets that secure the tool box to the seat frame and remove.
Page 306 Fuel System Argo Service Manual FS-3 FS-4 Slip the new or cleaned tank into the vehicle from the drivers compartment, recon- necting the filler hose to the tank at the same time and secure it with the gear clamp. IMPOR...
Page 307 Argo Service Manual Vehicle Body SECTION VB Vehicle Body Table of Contents General Instructions................VB-2 Removing the Firewall (Conquest, Response, Bidfoot, Van2)...VB-3 Installing the Firewall................VB-4 Removing the Firewall (6x6 Vanguards)..........VB-4 Installing the Firewall (6x6 Vanguards)..........VB-5 Removing the Floor Pans..............VB-7 Installing the Floor Pans...............VB-7...
Page 308 General Information Argo Service Manual Ontario Drive & Gear Limited www.odg.com GI-28 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 309 Vehicle Body Argo Service Manual General Instruction Detailed information on standard workshop and safety procedures, and general servicing operations is not included in this manual, which has been prepared to assist qualified service personnel. ODG assumes no responsibility or liability for PERSONAL INJURY or VEHICLE DAMAGE which results from any servicing procedure performed, including those instructions outlined in this manual.
Page 310 There are 4 “finger” access holes in the bottom part of the firewall. This pro- vides a place to grab the firewall while pulling it out towards the driver's com- partment. Photo VB-3 Pull the firewall into the drivers com- partment.
Page 311 Remove the 2 steering adjustment locknuts and lay the steering levers back against the driver's seat. Remove the fasteners on each side of the firewall at the lower frame assembly. Refer to your illustrated parts manual for firewall design and hardware breakdown.
Page 312 Remove the 2 steering adjustment locknuts and lay the steering levers back against the driver's seat. Remove the fasteners securing the firewall to each side of the lower frame assembly. Refer to your illustrated parts manual for firewall design and hardware breakdown.
Page 313 Argo Service Manual On 6x6 Vanguards produced from S8131 and prior to S10769: With the steering levers pulled back against the driver's seat, install the firewall into the vehicle aligning the mounting holes of the firewall, with those in the lower frame assembly.
Page 314 Argo Service Manual Vehicle Body Removing the Floor Pans Draining water from the lower body, or any servicing of the Argo drive train, will require the removal of the floor pan assemblies. Removing the Front Floor Pan Perform the servicing procedure, Removing the Firewall, in this section of the serv- ice guide (Conquest, Response, Vanguard2 and Bigfoot only).
Page 315 Vehicle Body Argo Service Manual Removing the Rear Seat (All 8x8 Models) Rear seats on all 8x8 models are quick release and require no tools to remove. Grab the rear seat and raise it high enough for the plastic bumper fastened to the underside of the seat cushion, to clear the hole in the upper body below.
Page 316 Argo Service Manual Vehicle Body Lift up on the plastic at the rear seat cushion. Using a ratchet wrench and socket, unthread the bolt from the seat. Remove the seat. Installing the Rear Seats (6x6 models) Place the seat into the rear compartment.
Page 317 Rear Floor Pan. See Photo VB-14 VB-14 Exact location of drain plug depends on year and model of Argo Locate the plug and lift the lever up- wards to loosen the plug. Pull the plug from the lower body hole.
Page 318 Argo Service Manual Vehicle Body Upper Body Removal Remove the floorpans and firewall as outlined in this section of the service guide. Lift off the engine access cover. Remove and disconnect all accessories from the upper body. Slide the rubber bumper free of the vehicle.
Page 319 Vehicle Body Argo Service Manual Upper Body Installation Install the rear seats and all trim to the upper body. Install the headlamps. Install all gauges and indicator lights. Install the vehicle wire harness. On 6x6 Vanguards manufactured prior to S7304, fasten the back rest pad to the upper body.
Page 320 Argo Service Manual Vehicle Body Using a 3/16" drill bit, drill upward through the upper body, using the existing holes • in the lower body as guides. place body rivets through each hole. Hold a washer over the end of each rivet and •...
Page 321 All lower bodies ordered as replacement parts are not predrilled. Holes for axles, trailer hitches etc., should be drilled using the vehicle’s original frame as a jig. Position the frame into the new lower body and drill as required from the inside out. Refer to the original body being replaced to calculate the correct hole-saw size for axles, and drill bit sizes for mounting hardware.
Page 322 Argo Service Manual Vehicle Body Frame Inspection Inspect the vehicle frame, seat support assembly and power pack frame thoroughly for: cracks or breakage in the welding joints • cracked or broken mounting lugs or inserts • rusted through or bent frame members •...
Page 323 Argo Service Manual Ducting & Exhaust SECTION DE Ducting & Exhaust Table of Contents General Instructions................DE-2 Removing the Muffler (Conquest Models Prior to C19672)............ DE-3 Disassembling the Muffler Assembly (Conquest Models Prior to C19672)............ DE-5 Assembling the Muffler Assembly (Conquest Models Prior to C19672)............
Page 324 General Information Argo Service Manual Ontario Drive & Gear Limited www.odg.com GI-28 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 325 Ducting & Exhaust Argo Service Manual General Instructions Detailed information on standard workshop and safety procedures, and general servicing operations is not included in this manual, which has been prepared to assist qualified service personnel. ODG assumes no responsibility or liability for PERSONAL INJURY or VEHICLE DAMAGE which results from any servicing procedure performed, including those instructions outlined in this manual.
Page 326 Argo Service Manual Ducting & Exhaust Removing the Muffler (Conquest Models) On Conquests manufactured prior to C19672: Remove the 2 fasteners in the top of the heat shield. Photo DE-1 Depending on the age of the vehicle, a few earlier models utilized a fiberglass heat shield. This part is no longer available but is fully exchangeable with the newer version.
Page 327 Ducting & Exhaust Argo Service Manual DE-5 DE-6 There are 2 fasteners securing the the entire muffler assembly to the lower body. These are located at the lower body under the front wheel. It may prove easier to remove the front wheel to access the fastener heads with a socket or wrench. Photo DE-6 &...
Page 328 Argo Service Manual Ducting & Exhaust DE-10 DE-11 Disassembling the Muffler Assembly (Conquest Models) On a clean work surface, remove the single fastener and spacer securing the heat shield to the muffler assembly. Photo DE-11 The above heat shield removed exposes another fastener securing the muffler to the shrouding.
Page 329 Ducting & Exhaust Argo Service Manual Assembling and Installing the Muffler Assembly (Conquest Models) On an uncluttered work surface, orient the muffler heat shield assembly with the rubber shock lower support, to the back. Insert the muffler into the shroud with the exhaust inlet situated to the right.
Page 330 Argo Service Manual Ducting & Exhaust DE-19 DE-20 Re-fasten the exhaust manifold to the engine. Torque to specification. IMPOR IMPOR IMPORT T T T T ANT IMPOR IMPOR Exhaust manifold gaskets should be replaced with new ones Assemble the muffler assembly to the exhaust manifold. The original compression springs may be reused but new hardware is recommended.
Page 331 Ducting & Exhaust Argo Service Manual Disconnect the 2 extension springs connecting the tailpipe to the muffler and remove the tailpipe. Photo DE-22 Unfasten the muffler at the engine and remove. DE-21 DE-22 Installing the Muffler (Conquest Models ) Install the muffler to the engine exhaust manifold and torque to specifications.
Page 332 Argo Service Manual Ducting & Exhaust Disconnect the extension springs. On models manufactured prior to R19647, S13434 & N13436: Remove the extension springs connecting the muffler to the exhaust manifold. Photo DE-24 DE-23 DE-24 On models manufactured from R19647, S13434 & N13436: Disconnect the extension springs connecting the tailpipe to muffler and pull the tailpipe out of the vehicle from the engine compartment.
Page 333 Ducting & Exhaust Argo Service Manual Installing the Muffler (Response, Vanguard2 and Vanguard Models) Install the muffler On vehicles manufactured from S6999, SN8138, RB12075 and prior to S13434, N13436, R19647: Assemble the muffler into the exhaust ducting aligning the tailpipe with the outlet hole in the exhaust screen.
Page 334 Argo Service Manual Ducting & Exhaust Removing the Muffler (Bigfoot Models) Remove the four fasteners securing the muffler heat shield and remove the shield. Disconnect the extension springs between the tailpipe and muffler and pull the tailpipe from the engine compartment.
Page 335 Ducting & Exhaust Argo Service Manual Remove the tail pipe assembly by disconnecting the springs from the muffler at- tached to the tail pipe. The screen-type spark arrester assembly is located inside the tail pipe. It is fastened with one (1) slotted washer-head hex screw. Find the screw on the side of the outlet tube.
Page 336 Argo Service Manual Ducting & Exhaust Installing the Intake Duct (Response, Bigfoot, Vanguard2 & Vanguard Models) Install the intake duct inserting it closest to the front of the vehicle. This is where the widest available area allows it to be pushed into the vehicle. Position it in front of the engine flywheel fan assembly.
Page 337 Ducting & Exhaust Argo Service Manual Installing the Intake Duct (Conquest Models) Slip the intake duct between upper and lower body. Position the duct so that both duct and lower body mounting holes are aligned. Install the hardware required to fasten the duct to the lower body Re-rivet the upper body to the lower using washers on the underside of the vehicle.
Page 338: Table Of Contents
Argo Service Manual Ducting & Exhaust Fasten the duct at the upper hood brace assembly Perform the servicing procedure, Installing the Muffler (Response, Vanguard2 and Vanguard Models) or: Installing the Muffler (Bigfoot Models) Reinstall the bumper. Removing the Exhaust Ducting (Conquest from C19686, all 6x6 Conquests and all...
Page 339 Argo Service Manual Transmission SECTION TR Transmission Table of Contents General Instructions................TR-2 Transmission Oil/Maintenance Schedule..........TR-3 Recommended Oil................TR-3 Oil Level Inspection................TR-4 Changing the Transmission Oil............TR-5 Refilling the Transmission with Oil...........TR-7 General Inspection of the Transmission..........TR-7 Removing the Transmission...............TR-8 Disassembling the Transmission ............
Page 340 General Information Argo Service Manual Ontario Drive & Gear Limited www.odg.com GI-28 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 341 Do not attempt to move the gearshift from the neutral starting position until the engine idles down completely. The Argo is equipped with an automatic clutch that is activated by engine speed. If the engine idle speed is too high, the transmission will grind during gear engagement.
Page 342 Using any other than the recommended oil could cause serious damage to the transmission components. The approximate refill capacity of the ARGO transmission is 0.85 Liters (1.5 imperial pints, 1.8 U.S pints). However, be sure that it is filled to the full mark on the dipstick. DO NOT OVERFILL.
Page 343 Oil Level Inspection Inspect the transmission oil on a daily basis Do not run the ARGO if the oil level in the transmission shows above or below the mark on the dipstick. Damage to transmission components could occur Place the vehicle on a level surface. This will allow the correct measurement of gear lube in the transmission.
Page 344 3/8" opened end wrench. Changing The Transmission Oil You may drain the transmission’s oil through the oil fill/dipstick, by using a vacuum style pump such as the one available through your ARGO dealer (part # 638-02) or preferably, at the drain plug located at the bottom of the transmission just behind the firewall.
Page 345 Transmission Argo Service Manual Perform the servicing procedure, Removing the Firewall, in Section VB of this service manual. Perform the servicing procedure, Removing the Front Floor Pan, in Section VB of this service manual. Remove the hood. Clean the transmission around the dipstick location. This will keep dirt from enter- ing the gearbox.
Page 346 Place a clean funnel into the oil fill dipstick hole. Fill the gear box with approximately 0.85 litres (1.5 Imperial Pints, 1.8 U.S. Pints) of clean fresh 80W/90 Gear Lube Hypoy-C or an EP rated 80W/90 gear oil for Ex- treme Gear Pressure applications.
Page 347 Transmission Argo Service Manual Removing the Transmission Disconnect all wiring to the battery before proceeding with the following component removal. Perform the servicing procedure, Removing the Firewall (Quick Release), for Response, Bigfoot and Conquest in Section VB of this manual.
Page 348 Argo Service Manual Transmission Unfasten the twist grip assembly from the steering handle and remove it. Photo TR-05 Remove the entire hydraulic brake system from the vehicle. The calipers, master cylinders and brake lines can all remain attached without the loss of any brake fluid.
Page 349 Transmission Argo Service Manual Disassembling the Transmission Remove the Drain Plug & drain the oil from the transmission. Photo TR-09 Remove the Dipstick. Remove the Retaining Ring that secures the Reverse Idler Dowel Pin on the outside of the Cover. Photo TR-10 Tap the Dowel pin back into the transmission far enough to free it from the Side Cover.
Page 350 Argo Service Manual Transmission TR-13 TR-14 All retaining rings, spacers & seals need to be replaced during a transmission rebuild. It is usually recommended to replace all bearings as well. Bearings should only be reused if the technician has determined to his/her own satisfaction that they are okay to reuse.
Page 351 Transmission Argo Service Manual Separating the Side Cover on Transmissions Manufactured From Serial Numbers: 25631GU, 25668HU 25700MU These Side Covers utilize a threaded boss in 2 locations. Photo TR-17 10. Remove the Retaining Ring and Shim on the Output Shaft side of the Cover, Photo TR-18, and ensure that the reverse idler dowel pin has been freed of the cover as in step 3 &...
Page 352 14. Slip the Reverse Idler gear from the ½” Dowel Pin. Photo TR-24 TR-21 TR-22 TR-23 TR-24 15. Remove the Input Shaft’s Oil Seal. Photo TR-25 16. Remove the Input Shaft’s Retaining Ring. Photo TR-26 17. Remove the Shim installed below the TR-25 Retaining Ring.
Page 353 Transmission Argo Service Manual TR-27 TR-26 Some transmissions may have (2) Shims instead of (1). In rare cases there may be none used. In any case, when reassembling, use the same amount as were used originally. 18. Using a soft faced hammer, tap the Input Shaft out of the Housing. Photo TR-28 19.
Page 354 Argo Service Manual Transmission TR-30 TR-31 23. Flip the Housing over to remove the outer Retaining Ring. Photo TR-32 24. Using the drift punch and hammer remove the inner Bearing in the same manner as in step 20. Photo TR-33...
Page 355 First you must remove the Retaining Ring and Shim washer from the Output Shaft. Photo TR-37 & 38 28. Supporting the Cover on each side with 2 short 2x4’s, place it in an arbor press and apply pressure to the Output Shaft. Press the differential from the Cover.
Page 356 Argo Service Manual Transmission IMPOR IMPOR IMPOR IMPOR IMPORT T T T T ANT Transmissions manufactured from Oct of 2000 have had a design change to the Side Cover. This new Side Cover begins on vehicles manufactured from serial numbers: SN11905 TB Oct.
Page 357 Transmission Argo Service Manual TR-43 TR-44 33. Take a piece of flat stock with a hole drilled to the center and slip it on to the threaded adjustment rod of the puller. Secure it with a nut. Photo TR-44 34. Flip the Cover on the assembly jig so that the 101-01 Bearings are facing down.
Page 358 Photo TR-51 TR-51 When removing the 3 fasteners that secure the differential's Gear Plate and Aluminum cage together, earlier transmissions may also have a lockwasher installed. If this is the case, when reassembling the differential, eliminate the lockwashers and use Red 271 LOCTITE on both the threads of the fastener as well as on the internal threads of the aluminum cage.
Page 359 Transmission Argo Service Manual 41. Hold the Output Shaft from turning while removing the 3 Fasteners that hold the Gear Plate and Aluminum Cage together. Photo TR-52 42. With the Fasteners removed, gently tap the Gear Plate from the Aluminum Cage using a soft faced mallet.
Page 360 Argo Service Manual Transmission TR-56 TR-57 47. Slip the Sun Gear from the Output Shaft. Photo TR-58 48. Press the Output Shafts from both Cage and Gear Plate. Photo TR-59 & TR-58 TR-59 TR-60 49. Remove each of the 101-15 Bearings from both Cage and Gear Plate.
Page 361 Transmission Argo Service Manual TR-62 TR-63 50. Remove all (12) Oilite Bushings from both Cage and Gear Plate using a bushing removal tool. This procedure will also push out the Output Shaft Bearing that has more than likely remained assembled to both of these components.
Page 362 Argo Service Manual Transmission 52. Wash all parts in a clean varsol bath and dry all parts with compressed air or a lint free rag. Lay out all parts for inspection. Photo TR-67 TR-67 Always exercise extreme caution when using compressed air. Compressed air can be potentially dangerous causing serious injury or even death if misused.
Page 363 The installation of a badly damaged gear or shaft will lead to premature wear of other components and other potential breakdowns. Replace all badly worn, broken or missing components immediately with genuine ARGO replacement parts. If there is any doubt as to whether the transmission component needs replacing, generally the best thing to do is to replace it while the job is at hand.
Page 364 ARGO. If the component is no longer listed in your Spare Parts Price List (Distributors & Dealers Only), check the Superceded Section for the correct part(s) that replace(s) the original.
Page 365 Transmission Argo Service Manual Transmission Component Description of Change Transmission Cover Aug 11/2000 The side cover is cast solid in the area of the input shaft and shifter assembly at the 101-01 bearings. This eliminates the need for the 31-07 plug From Serial Numbers: plates &...
Page 366 Argo Service Manual Transmission Transmission Assembly Assembling the Differential Secure the Aluminum Cage to the base of the arbor press using a spacer and nut. Photo TR-69 Install (6) Oilite Bushings into the Aluminum Cage. Photo TR70 Repeat the process installing these bushings into the appropriate Gear Plate. Photo...
Page 367 Transmission Argo Service Manual Install a Bearing into both Cage and Gear plate. Photo TR-73 & 74 Wipe the Output Shaft free of debris with a lint free rag. Install this Output Shaft into the Aluminum Cage. Photo TR-75 & 76 See Transmission Component Changes chart on page TR-25 regarding output shafts.
Page 368 Argo Service Manual Transmission Orient the Sun Gear as in Photo TR-78 with the higher shoulder side facing up. Install it to the splined end of the Output Shaft. Photo TR-79 & 80 Secure the Sun Gear with a Snap Ring. Photo TR-81 Be sure the Retaining Ring is properly seated to the machined groove of the Output Shaft.
Page 369 Transmission Argo Service Manual 10. Wipe down the 2 Output Shaft and assemble to the Gear Plate using the same method as described for the Aluminum Cage. Photo TR-84, 85 & 86 TR-84 TR-85 TR-86 TR-87 11. Orient the 2...
Page 370 Argo Service Manual Transmission TR-90 TR-91 12. Set the assembled Aluminum Cage into an assembly stand or an aluminum jawed vise Photo TR-91 13. Install (6) Pinions into the Oilite Bushings of the Aluminum Cage alternating the Pinions in an up and down manner as shown in Photo TR-92 & 93 14.
Page 371 Transmission Argo Service Manual 16. Seat the Gear Plate to the Aluminum Cage using a soft faced mallet. Photo TR-97 17 Apply Red 271 LOCTITE to each of the (3) fasteners, Photo TR- 98, and tighten down. Torque to specifications. Photo TR-99 & 100...
Page 372 Argo Service Manual Transmission 18. Locate the Spline Shaft and assemble the appropriate Drive Gear to the splined end of it. Orient the gear with the machined side down. Photo TR-101, 102 & 103 Drive Gears are as follows: M Drive Gear...
Page 373 Transmission Argo Service Manual TR-105 TR-106 TR-107 TR-108 21. Place a Ball Bearing to the top of the spring. Photo TR-108 & 109 TR-109 22. Compress the Ball Bearing into the hole of the Double Gear with a flat screwdriver, at the same time inserting the Spline Shaft from the opposite side with the shift gate notches facing down.
Page 374 Argo Service Manual Transmission TR-110 TR-111 TR-112 TR-113 23. Use a soft face mallet to tap the Spline Shaft completely through the Double Gear. Photo TR-113 & 114 24. Remove the assembly to the bench. Grabbing the Double Gear in your hands, shift the Double Gear up and down the length of the Spline to check that all shift gates are smooth and lock securely.
Page 375 IMPOR IMPOR IMPORT T T T T ANT IMPOR IMPOR Vehicles Manufactured prior to S/N CB17471, RB17525, BF11917, SN11905 & TR-120 S11906 require 2 retainings rings to be installed to the cover first before the bearings are pressed into place.
Page 376 Transmission TR-121 TR-122 28. Install a Retaining Ring to the inner groove of the Housing’s Output Shaft side. Photo TR-123 & 124 29. Install a Retaining Ring into the Housing at the shifter assemblies bearing side. Photo TR-125 & 126...
Page 377 TR-127 TR-128 31. Tap a burnishing tool through the shifter assembly's Oilite Bushing if the old bushing has been replaced with a new one Photo TR-129 32. Place a Shim Washer on top of the previously installed Retaining Ring in the Hous- ing’s Output Shaft side.
Page 378 Argo Service Manual Transmission TR-133 TR-134 TR-135 TR-136 35. Install the 34-63 Shifter Yoke to the 34-65 Shifter Assembly securing it with a 107- 05 Retaining Ring. Photo TR-136, 137 & 138 TR-138 TR-137 36. Install the 113-01 “O” ring to the 34-65 Shifter Assembly. Photo TR-139 & 140 (following page) 37.
Page 379 Transmission Argo Service Manual TR-140 TR-139 TR-142 TR-141 38. Orient and secure the Shift Lever Holder to the Shift Shaft using (2) Roll Pins as shown in Photo TR-143. Be sure to support the shaft from below with a piece of metal stock when hammering the pins through the Holder.
Page 380 Argo Service Manual Transmission 39. Insert the Dowel Pin into the boss of the transmission housing and using a soft face mallet, tap it flush to the sealing edge of the housing. Photo TR-145 TR-145 40. Install the Retaining Ring to the bottom of the Dowel Pin.
Page 381 Transmission Argo Service Manual 43. Use compressed air to blow any foreign debris from the Housing before attempt- ing to install the sub-assembled com- ponents. Photo TR-149 TR-149 Install the Differential Assembly. 44. Place the Differential into the Housing, slipping the Output Shaft into the Output Shaft Bearing.
Page 382 Argo Service Manual Transmission TR-152 TR-153 46. Install the Shifter Assembly into the TR-154 Housing, lining up the one end of the Spline Shaft with the bearing in the Housing. At the same time, be sure to slip the Shift Yoke over the larger di- ameter gear of the Double Gear.
Page 383 Argo Service Manual TR-159 TR-158 49. If the old bushing(s) was/were replaced with new, press a burnishing tool through the Oilite Bushing of the Reverse Idler. Photo TR-159 & 160 50. Slip the Reverse Idler on to the Dowel Pin making sure that the chamfer side is facing down.
Page 384 Argo Service Manual Transmission 51. While one hand holds the top of the Shifter Assembly, Use the other to shift the Lever through all gates. Check that all shift smoothly. Photo TR-164 52. Spin the entire assembly at the Output Shaft to check for any tight spots or unusual noises.
Page 385 Transmission Argo Service Manual TR-168 TR-169 TR-170 TR-171 TR-172 TR-173 Ontario Drive & Gear Limited www.odg.com TR-46 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 386 Argo Service Manual Transmission 57. Secure the Cover using (1) Cap Screw, (4) Bolts and (4) Lock Washers. Apply LOCTITE Silver Grade anti-seize to the cap screw before installing to the lower end of the transmission assembly. Photo TR-174 & 175...
Page 387 Transmission Argo Service Manual 59. Press the inner Oil Seal to the Output Shaft. Seat it to the Retaining Ring that was previously installed in the Housing in step 29. Do not over press. Photo TR-179, 180 & 181 60. Install a Retaining Ring to the top of the Oil Seal. Photo TR-182 & 183...
Page 388 Argo Service Manual Transmission 61. Press the outer Sealed Bearing into the Side Cover and seat it to the Retaining Ring. Photo TR-184, 185 & 186 62. Rotate the transmission assembly and repeat steps 59-61 to the Housing side. TR-184...
Page 389 65. Rotate the transmission to access the Input Shaft side of the transmission. Photo TR-192 66. Seat the Reverse Idler Pin's Retaining Ring to the pin boss located in the transmis- sion Housing. Through the Input Shaft opening, use a hammer and pin installer to tap the Reverse Idler Pin through the boss and out the Transmission Cover side.
Page 390 Argo Service Manual Transmission TR-195 TR-194 67. Rotate the Transmission and secure the opposite end of the Reverse Idler Pin with a Retaining Ring. Photo TR-195 68. Once the Retaining Ring has been secured to the Cover Side, use a hammer and tap the pin back in the opposite direction to seat the Retaining Ring to the Cover.
Page 391 Transmission Argo Service Manual 70. Rotate the Input Shaft to check that it turns freely. Photo TR-200 71. Place the Input Bearing over the Input Shaft and seat it with a soft faced mallet and installation tool. Photo TR-201, 202 & 203...
Page 392 Argo Service Manual Transmission TR-206 TR-207 TR-208 TR-209 74. Install the Oil Seal to the Input Shaft using a soft faced mallet and seal instal- lation tool. Photo TR-207, 208 & 209 75. Apply 680 Green LOCTITE to the plug plate sealing edge and tap it into the Housing using a steel hammer.
Page 393 Transmission Argo Service Manual TR-212 TR-213 76. Place the transmission on the bench and perform a final shift through all gears. 77. Fill with .805 Litres of 80/90 Gear Oil. Photo TR-213 78. Install the Dipstick and check oil level.
Page 394 Argo Service Manual Transmission TR-217 TR-216 If the vehicle utilizes the hydraulic brake TR-218 system, reattach the entire assembly to the transmission using the 3 mounting bolts and lockwashers. Torque to speci- fications. Photo TR-218 All brake lines and calipers should still be attached to the assembly.
Page 395 Transmission Argo Service Manual Perform the servicing procedure, Installing the Idler Chain. Perform the servicing procedure, Installing the Driven Clutch. Perform the servicing procedure, Installing the Drive Belt. 10. Perform the servicing procedure, Installing the Firewall. Ontario Drive & Gear Limited www.odg.com...
Page 396 General Information Argo Service Manual Ontario Drive & Gear Limited www.odg.com GI-28 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 397 Argo Service Manual Transmission SECTION TR Supplement Pages Ontario Drive & Gear ltd. www.odg.com/centaur (519) 662-2840 FAX (519) 662-2421...
Page 398 Transmission Argo Service Manual Ontario Drive & Gear ltd. www.odg.com/centaur (519) 662-2840 FAX (519) 662-2421...
Page 399 Argo Service Manual Transmission Transmission Re & Re 34-100 Series Ontario Drive & Gear Limited www.odg.com TR-1A PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 400 Transmission Argo Service Manual Argo Transmission Disassembly Drain oil and unthread the 4 fasteners securing the shifter lever assembly to top end of the transmission and remove the lever. Photo TR-1 & 2 TR-1 TR-2 Remove all fasteners securing the housing halves together. There are 11 located on the input shaft side and 4 located on the opposite side.
Page 401 Argo Service Manual Transmission Thread each of these bolts a little at a time and in an uniform alternating pattern. DO NOT overtighten to avoid the risk of breaking the housing tab. Stop occasionally to tap the output shaft with a soft faced hammer. Repeat this until the cover has separated.
Page 402 Transmission Argo Service Manual Place shift shaft back into neutral. Photo TR-10 10. Place reverse shift shaft into reverse. Photo TR-11 TR-10 TR-11 11. Pull the input shaft from the transmission housing. Photo TR-12 12. Remove the spline shaft drive gear assembly.
Page 403 Argo Service Manual Transmission TR-15 TR-16 TR-17 TR-18 17. Using an arbor press, remove the smaller ball bearing from the end of the input shaft. Photo TR-19 18. Remove the retaining ring at the reverse gear. Photo TR-20 TR-19 TR-20 19.
Page 404 Transmission Argo Service Manual TR-22 TR-21 TR-23 TR-24 22. Remove the last ball bearing from the input shaft at the arbor press. Photo TR-24 Disassemble the Spline Shaft Drive Gear Assembly 23. Remove the bearing and high gear from the spline shaft at the arbor press.
Page 405 Argo Service Manual Transmission TR-26 26. Press the differential from the housing at the arbor press. Photo TR-28 The use of wood blocks beneath the housing prevents damage to the sealing edge of the casting as well as provides height for removing the differential...
Page 406 Transmission Argo Service Manual 28. Remove the 3 steel balls located in the housing, between the hi/lo shift shaft and the reverse shift shaft. Photo TR-34 TR-35 TR-34 29. To remove the reverse shift shaft and reverse idler gear from the housing, first re- move the retaining ring located above the reverse idler.
Page 407 Argo Service Manual Transmission TR-38 TR-39 35. Remove all remaining Retaining Rings, Bearings and Seals from both the left and righthand side housings. 36. Wash and soak all components in a degreasing bath before inspection. Reassembling the Transmission IMPOR IMPORT T T T T ANT...
Page 408 Transmission Argo Service Manual Reassembling the Transmission Lay out all components of the AVENGER Transmission on a clean work surface. See Photo below and following page. Ontario Drive & Gear Limited www.odg.com TR-10A PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 409 Argo Service Manual Transmission Ontario Drive & Gear Limited www.odg.com TR-11A PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 410 Transmission Argo Service Manual Assembling the Idler Gear Bore Assembly Install the 34-109 High Gear to the short side of the 34-112 Splined Shaft. Photo TR-41 IMPOR IMPOR IMPORT T T T T ANT IMPOR IMPOR Install the High Gear with the machined shoulder up. See Photo TR-41 Press the 101-01 Bearing to the High Gear end of the Splined Shaft with the shielded side facing out.
Page 411 Argo Service Manual Transmission Slip on the 34-111 Reverse Gear up against the previously installed Low gear. Photo TR-45 TR-44 IMPOR IMPOR IMPORT T T T T ANT IMPOR IMPOR The 34-111 Reverse gear must be assembled to the Splined Shaft with the chamfered teeth side facing up.
Page 412 Transmission Argo Service Manual Assembling the Input Shaft (Transmissions built prior to A5883) For transmissions built from A5883 see Pages TR-35A for revised Input Shaft Assembly guidance. Install the 107-02 Retaining Ring to the 34-104 Input Shaft. Photo TR-48 IMPOR...
Page 413 Argo Service Manual Transmission Transmissions manufactured prior to serial #A2856 utilize 4 dog teeth and from #A2856, 3 dog teeth. Photo TR-50 Orient the the High Gear Pinion with the dog teeth facing up. Install the second Thrust Washer to the top of the High Gear Pinion. Photo TR-51...
Page 414 Transmission Argo Service Manual Gear Pinion. Orient the Reverse Gear Pinion with the chamfered teeth facing up. Photo TR-55 TR-54 TR-55 Secure the Reverse Gear Pinion with a 107-12 Retaining Ring. Photo TR-56 10. Press a 101-01 bearing to the end of the Input Shaft with the shielded side up.
Page 415 Argo Service Manual Transmission Assembling the Differential Install all 105-03 Oilite Bushings into both 34-122 cage and 34-124 Gear Plate. Photo TR-58 & 59 TR-59 TR-58 Blow all foreign debris from the Cage and Gear Plate. Install the 101-15 Bearing into both Cage and Gear plate. Photo TR-60 & 61 Wipe the 34-98 Output Shaft free of debris with a lint free rag.
Page 416 Transmission Argo Service Manual Use a specialized spacing tool to secure the previously installed 101-15 Bearing inside the Aluminum Cage while the Output Shaft is press into place. Photo TR-64 Orient the 34-14 Sun Gear as in Photo TR-65 with the higher shoulder side fac- TR-64 ing up.
Page 417 Argo Service Manual Transmission TR-69 TR-70 10. Wipe down the 2 34-98 Output Shaft and assemble to the Gear Plate using the same method as described for the Aluminum Cage. Photo TR-71, 72 & 73 TR-71 TR-72 TR-73 TR-74 11. Orient the 2...
Page 418 Transmission Argo Service Manual TR-76 TR-75 TR-77 TR-78 12. Set the assembled 34-122 Aluminum Cage into an assembly stand. Photo TR-78 13. Install (3) 105-23 Hollow Dowl Pins into the mounting holes of the aluminum cage. Photo TR-79 TR-79 TR-80 14.
Page 419 Argo Service Manual Transmission TR-82 TR-81 TR-83 TR-84 16. Assemble the Gear Plate to the Aluminum Cage. Align the top of the Pinions in the Cage, with the Oilite Bushings in the Gear Plate. Photo TR-82 & 83 17. Seat the Gear Plate to the Aluminum Cage using a soft faced mallet. Photo TR-84 Apply Red 271 LOCTITE to each of the (3) 112-143 fasteners, Photo TR- 85, and tighten down to 35 FT/LBS.
Page 420 Transmission Argo Service Manual Assembling Transmission Components to Housing Apply some LOCTITE pipe sealant to the threads of the 103-02 drain plug and in- stall into the housing. Photo TR-87 & 88 TR-88 TR-87 Start the 34-114 Reverse Shift Shaft into the housing boss as illustrated in Photo TR-89.
Page 421 Argo Service Manual Transmission TR-91 TR-92 TR-93 TR-94 IMPOR IMPORT T T T T ANT IMPOR IMPOR IMPOR Transmissions Manufactured From Serial Number A3784, require a 113-16 O-Ring installed to the machined groove located near the end of the reverse shift shaft and require these extra steps to install it.
Page 422 Transmission Argo Service Manual Push the reverse shift shaft back through the housing ensuring that you don't damage the O-ring as re-enters the housing. Pull the Reverse Shift Shaft up until the lower retaining ring groove location is visible. shaft is Photo TR-95 Install the 107-11 Retaining Ring onto the Reverse Shift Shaft.
Page 423 Argo Service Manual Transmission TR-99 TR-100 Install the 104-40 Dowel Pin to secure the Reverse Shift Shaft. Photo TR-101 13. Assemble the 34-115 Reverse Shift Block to the Reverse Shift Shaft by aligning the keyway with the previously installed Dowel Pin. Photo TR-102...
Page 424 Transmission Argo Service Manual TR-104 TR-103 TR-105 TR-106 15. Install a 106-03 Retaining Ring to top groove of the Housing. Photo TR-106 16. Press and install the 101-03 bearing into the Housing. Photo TR-107 & 108 TR-107 TR-108 If the differential consists of the high ratio 3.3 Gear Plate, it will be advantages to install the 101-01 Bearing into the cover as well at this point to avoid any interference later when installing the assembled Idler Gear Bore Assembly.
Page 425 Argo Service Manual Transmission TR-109 TR-110 TR-111 TR-113 TR-112 19. Next, push the Reverse Shift Shaft and Block down against the Housing boss (out of reverse). Install (3) 109-05 Steel Balls into the Hi/Low Shift Shaft cavity of the Housing, and push each one into the machined hole at the Reverse Shift Shaft.
Page 426 Transmission Argo Service Manual 20. Install the 34-113 Hi/Low Shift Shaft into the Housing with the 3 machined gates facing to the outside of the housing and the 1 machined gate facing the Reverse Shift Shaft. Photo TR-115 TR-115 TR-116 21.
Page 427 Argo Service Manual Transmission TR-120 TR-121 TR-122 TR-123 25. Place the transmission into the neutral position. Photo TR-123 26. Secure the Hi/Lo Shift Fork to the Shift Shaft using a 104-39 Spring Pin. Photo TR-124 TR-124 TR-125 27. Install a 106-03 Retaining Ring to the top groove of the 34-101 Left Transmission...
Page 428 Transmission Argo Service Manual 28. Press a 101-03 & 101-16 Bearing into the Left Transmission Housing. Photo TR- 29. Apply Black 598 LOCTITE RTV Silicon Gasket Maker around the perimeter of the Transmission Housing 30. Press the Left Hand Housing to the Right Hand Housing at the arbor press. Tap with a soft face mallet while pressing at the output shaft area.
Page 429 Argo Service Manual Transmission TR-131 TR-130 35. Install the 102-05 Oil Seal to the Input Shaft. Photo TR-131 & 132 36. Install the 102-03 Oil Seal to the Output Shaft. Seat below the Retaining Ring groove. Photo TR-133 & 134 37.
Page 430 Transmission Argo Service Manual 38. Install a 101-05 Bearing to the Output Shaft. Photo TR-136 & 137 TR-136 TR-137 39. Repeat Steps 36 through 38 for the other Output Shaft. 40. Using the Output Shaft puller, pull each of the Output Shafts. Install a 114-04 Shim under the 107-02 Retaining Ring at the Output Shaft on the Left Side Housing.
Page 431 Argo Service Manual Transmission TR-141 41. Locate the shift lever opening and place the transmission shift blocks in the neutral postion. See Photo TR-141 42. Place the 113-11 O-ring into the 34-118 Shifter Plate. Photo TR-142 43. Assemble the 34-117 Shift Lever to the Shifter Plate. Apply a small amount of axle grease to the ball area of the shifter lever.
Page 432 Transmission Argo Service Manual 46. Install the CE-035 Dipstick. Photo TR-146 47. Fill the transmission with 1.1 L (38.7 oz of 80 W 90 Gear Lube HYPOY-C. TR-146 Ontario Drive & Gear Limited www.odg.com TR-34A PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 433 Argo Service Manual Transmission 1. Transmissions built from A5883: Locate the 34-130 Input Shaft and install the first half of the 107-14 Retaining Ring to the machined groove at the High Gear Pinion location. Photo 1 & 2 2. Interlock the second half of the 107-14 Retaining Ring into the previously installed one.
Page 434 Transmission Argo Service Manual 4. Locate the 108-85 Retaining Thrust Washer and slip it over the input shaft (cupped side towards retaining ring) and up against the retaining ring assembly. Photo 6 & 7 5. Install the High Gear Pinion on to the Input Shaft (dog teeth facing towards the Thrust Washer).
Page 435 Argo Service Manual Transmission 6. Slip a 108-79 Thrust Washer to the other side of the High Gear Pinion and secure with a 107-02 Retaining Ring. Photos 9, 10 & 11 6. Slip the Dog Clutch to the Input Shaft. Photo 12...
Page 436 Transmission Argo Service Manual 9. Secure the Reverse Gear Pinion with a 107-15 Retaining Ring. Photos 15 & 16 Ontario Drive & Gear Limited www.odg.com TR-38A PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 437 General Information Argo Service Manual Ontario Drive & Gear Limited www.odg.com GI-28 PH.(519)- 662-2840 FAX (519)- 662-2421...
Page 438 ARGO SERVICE MANUAL Ontario Drive & Gear Limited www.odg.com PH.(519)- 662-2840 FAX (519)- 662-2421...
