- Page 1 LevelOne USB-0200 USB to Gigabit Ethernet Adapter User’s Manual...
- Page 2 FCC Warning This equipment has been tested and found to comply with the regulations for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment operated commercial...
-
Page 3: Table Of Contents
Table of Contents INTRODUCTION ........1 BOUT THE IGABIT THERNET ..........1 DAPTER ......... 2 RODUCT EATURES INSTALLATION .......... 3 & S ..3 ARDWARE OFTWARE NSTALLATION LED I ........4 NDICATORS SPECIFICATIONS ........5... -
Page 4: Introduction
INTRODUCTION Thanks for purchasing of the USB-0200 USB to Gigabit Ethernet Adapter. This Converter will allow your computer to connect to 10Mbps Ethernet ,100Mbps Fast Ethernet and 1000Mbps Gigabit Ethernet Network through USB 2.0 interface. About the USB to Gigabit Ethernet... -
Page 5: Product Features
Product Features Compliant with USB specification 1.0, 1.1 and 2.0 IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX and 802.3ab 1000BASE-T specification ANSI/IEEE 802.3 Auto-negotiation Plug-and-Play... -
Page 6: Installation
INSTALLATION The USB-0200 USB to Gigabit Ethernet Adapter is designed to be simple and easy install. Hardware & Software Installation Step-1: Make sure the PC is power on and running at Windows Operating System Step-2: Connect to converter to a 10Mbps, 100Mbps or 1000Mbps Hub/Switch through RJ-45 Ethernet Port. -
Page 7: Led Indicators
Step-9: Then the system will ask you to restart your computer. Click “Yes” to restart computer. LED Indicators The USB-0200 is equipped with LED indicator: LAN Port status LED: This indicator lights green when the RJ-45 port is connected to a 10Mbps, 100Mbps or... -
Page 8: Specifications
SPECIFICATIONS Standards: USB Specification V.1.0, 1.1, 2.0 IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Fast Ethernet IEEE 802.3ab 1000Base-T Gigabit Ethernet ANSI/IEEE Std 802.3 auto-negotiation Link Speed: Ethernet:10Mbps/HDX, 20Mbps/FDX Fast Ethernet: 100Mbps/HDX, 200Mbps/FDX Gigabit Ethernet:2000Mbps/FDX LED indicators: Link/Activity USB Port: Series-A Plug x 1 Fast Ethernet Port: RJ-45 10/100/1000BASE-T port x 1...
