Page 1 Series 8000 Router Reference Manual (Release 2.1) Case Communications Ltd 1997 © X870-300351 Issue 1 Rev.0 Unit 15, Riverside Business Centre, Victoria Street, High Wycombe, Bucks HP11 2LT Web: www.casecomms.com Email: sales@casecomms.com Tel (UK): 08700 263 740 Tel (International): +44 (0) 1494 833 740...
Page 2 Case Communications Limited has made all reasonable efforts to ensure the accuracy of the content of this document but the information contained herein does not constitute a warranty of performance of the equipment and/or software described and no specifications given form part of any contract.
Page 3 Preface This manual provides information for X.25 network supervisors to install and set up the Router module. It forms part of the Series 8000 Systems Documentation, and refers to other manuals in the series. It assumes that you will already have some knowledge of the Series 8000 system obtained either from the systems documentation or from a Cray training course.
Page 4 X870-300351 Issue 1 Rev.0...
Page 5: Table Of Contents
Contents Introduction The Router Module IP Routing The Gateway Function of Router Multiple Sessions Services Profiles Installation Hardware Description 2.1.1 The 8325 TGate/Router Card 2.1.2 The 8425/8525 TGate/Router Module LAN Port Installation and Removal 2.3.1 8325 Card 2.3.2 8425/8525 Module LPIM Installation and Removal 2.4.1 LPIM Installation...
Page 6 4.2.1 Input 4.2.2 General Rules 4.2.3 Using Menus 4.2.4 Using Forms 4.2.5 Initial Entry to the Manager 4.2.6 Menu Hierarchy Main Menu 4.3.1 Quit Manager 4.3.2 Logoff from Router Configuration Menu 4.4.1 Configure General Information Form 4-10 4.4.2 Configure Messages Menu 4-12 4.4.3 Configure Protocols Form...
Page 7 User Procedures The User Environment 5.1.1 The User Welcome Screen 5.1.2 User Input User Commands 5.2.1 Command Specifications 5.2.2 CALL CONN/OPEN 5.2.3 DISC CLOSE 5.2.4 QUIT LOGOFF 5.2.5 SESSION 5.2.6 STATUS 5.2.7 5-10 5.2.8 5-12 DIRECTORY CATALOGUE 5.2.9 5-13 HELP 5.2.10 5-14 LOGIN...
Page 8 Example Applications Example of the Gateway Function of Router Example Application of IP Routing E-10 Failure Codes Glossary Telnet Printer Application Example S/W Program Figures Typical IP Routing Application Typical Application 8325 TGate/Router Card Rear Panel 8425/8525 TGate Module Combination 8425/8525 TGate/Router Module Rear Panel AUI/LPIM Select Links In-Line Cheapernet...
Page 9: Introduction
Introduction 1.1 The Router Module The Router module is a component of the Series 8000 range of X.25 switches. It provides an IP Routing function which allows transparent routing of IP frames between the local Ethernet network and remote IP Ethernet networks via a Series 8000 network.
Page 10: Ip Routing
1.2 IP Routing IP Routing deals with Internet Protocol (IP) packets, which are the most common type of LAN network layer packets. IP is part of the TCP/IP protocol suite. IP Routing in Router allows IP packets to be transparently passed across the X.25 network to remote Ethernet LAN networks, using Series 8000 X.25 PSEs to provide the transport medium.
Page 11: Typical Ip Routing Application
NETWORK NETWORK 1.0.0.0 2.0.0.0 HOST 1 HOST 2 X.25 ROUTER 1 ROUTER 2 Network ROUTER 3 ALIEN NETWORK ROUTER 3.0.0.0 HOST 3 NETWORK 4.0.0.0 HOST 4 Figure 1-1 Typical IP Routing Application In order to route IP packets originating on Ethernet network 1.0.0.0 to a destination on Ethernet network 4.0.0.0, Router 1 will on receipt of a packet from the LAN addressed to network 4.0.0.0 examine its routing tables.
Page 12 new call will be made to the X.121 address of Router 2 before the data can be sent. On receipt of the IP packet, Router 2 will examine its routing tables, which should allow it to forward the packet to the ''next hop'' router on Ethernet network 2.0.0.0 en route to its final destination.
Page 13: The Gateway Function Of Router
1.3 The Gateway Function of Router A user on either X.25 or Ethernet can make a connection to a service on either network via a single call from a terminal; this is commonly known as a 'seamless connection'. Figure 1-1 shows a typical application of the gateway function of Router, allowing X.25 terminals to access host computers connected to an Ethernet LAN.
Page 14: Multiple Sessions
1.4 Multiple Sessions In some circumstances it would be advantageous to allow an operator at a terminal to change between two or more applications, or services, at the press of a key. For example, a sales desk may require quick access to Sales Order Processing, Stock Control, and Electronic Mail services.
Page 15: Services
1.5 Services Router has two basic types of service: WAN Services and LAN Services. Router Services describe the address of the service, an optional password, and connection characteristics (via profiles). Each service has a name which can be employed by users to connect to their required destinations. •...
Page 16: Profiles
1.6 Profiles Profiles are used within Router to define sets of characteristics that should be applied in given circumstances. There are three types of profile: a User Profile that describes the characteristics to be applied to a user, a Service Profile that describes the characteristics of a connection to a service, and a Terminal Profile that describes the characteristics of a manager's terminal.
Page 17: Installation
Installation This chapter is provided as a supplement to the full installation guides for Series 8000, knowledge of and reference to which is assumed throughout. 2.1 Hardware Description The Router software can be loaded onto one of two hardware variants: the TGate/Router card for use within the 8325 card frame, and the TGate/Router module for use in either the 8425 or 8525 card frame.
Page 18: The 8425/8525 Tgate/Router Module
The only indicator is a green LED, serving as a 'heartbeat', blinking at a rate dependent upon processor utilisation. The TGate/Router card displays real-time status information via the 8325 display/control panel, in line with other 8325 cards (see Chapter 7 of the 8325 Installation Guide).
Page 19: Tgate/Router Module Rear Panel
10BaseT (twisted pair) interface. The card also includes an alarm relay (reserved for future use). The PAM rear panel (=TGate/Router Module rear panel) is shown in Figure 2-3. TGate PORT 3 PORT 2 PORT 1 PORT 0 Figure 2-3 8425/8525 TGate/Router Module Rear Panel X870-300351 Issue 1 Rev.0...
Page 20: Lan Port
2.2 LAN Port The single LAN port on any TGate/Router variant can be set up for any of the configurations shown in Table 2-1. CONNECTOR INTERFACE LPIM TYPE TYPE AUI,IEEE None 15-way D 802.3 female IEEE 10BASE2 CPIM BNC 50ohm CHEAPERNET, Coaxial THIN E/NET...
Page 21: Installation And Removal
2.3 Installation and Removal A TGate/Router card (or combination of cards) may be inserted in any slot of the card frame, except slot 1 which is reserved for the Node Manager card. TGate/Router cards (or combinations) may be inserted or removed while the node is powered up, provided that the following procedures are carefully followed: 2.3.1 8325 Card...
Page 22: 8425/8525 Module
2.3.2 8425/8525 Module The following subsections outline the procedure for inserting and removing modules from 8425/8525 systems. 2.3.2.1 UPM4 and TGate/Router (Main Modules) The main modules are accessed by either opening the front door (8425) or by unscrewing the five captive screws on the front door in the centre section of the unit (8525).
Page 23: Lpim Installation And Removal
2.4 LPIM Installation and Removal Live insertion of LPIM modules is not possible. Prior to installation, the TGate/Router card (8325) or PAM (8425/8525) must be removed (see Section 2.3). 2.4.1 LPIM Installation Before installing the LPIM the port must be selected by moving the links to the positions shown in black in the relevant section of Figure 2-4.
Page 24: Cabling
2.5 Cabling 2.5.1 AUI Port The AUI interface provides a standard 15-way D-type female connection. The pinout is defined in Appendix A.4. The TGate/Router AUI port provides 15 VDC (8325) or 12 VDC (84/8525), current limited to 500 mA, on circuit VP. The AUI port does not provide the normal slide locking for securing the cable;...
Page 25: Twisted Pair Port
TGate/Router Coaxial 50 ohm T-piece Cable Terminator Ferrite Figure 2-6 Network Termination 2.5.3 Twisted Pair Port The TPIM provides a 10BaseT interface for TGate/Router. The interface is provided on a 10-way RJ45. The pin-out is described in Appendix A.5. The two possible cabling schemes available for 10BaseT are: Station to Station.
Page 26 X870-300351 Issue 1 2-10 Rev.0...
Page 27: Initial Configuration
Initial Configuration This chapter summarises the tasks that need to be carried out when initially configuring Router. Tasks that are not fully described here, are described in Chapter 4. An example configuration is given in Appendix E. 3.1 Control Panel Displays On the 8325 control panel, the TGate/Router has a board ID of and only uses the first character in its 'Display Status' field.
Page 28: Installing The Application
3.2 Installing the Application Using the Series 8000 Node Manager, select the Utilities menu and then the Install Application menu. When you first enter the screen it lists all the applications. An asterisk (*) in the In Use column indicates that an application has been selected for loading onto one or more slots.
Page 29: Creating The Router Port
3.3 Creating the Router Port Next, a logical port (with a number 7000-7999 inclusive) must be created for Router to use (for example this could be 7050 to indicate that Router is running in slot 5). Configure the X.25 network level and user facilities as required, and bring the port online.
Page 30: Initial Configuration Commands
3.4 Initial Configuration Commands After cold start, Router is placed in an initial state ready for configuring, with the default configuration defined in Appendix B. Cold start normally only takes place when the card is first installed. However, if at any time it is found necessary to go back to the default configuration, then a cold start can be performed by deleting the configuration files from disk B (see...
Page 31 General configuration. Manager password, manager conf gen terminal type and slot number. Protocol configuration. IP address. Other fields can be conf prot left as defaults, unless you are familiar with TCP/IP and wish to optimise these parameters to match your network.
Page 32: Manager-Defined Terminal Configuration
3.5 Manager-Defined Terminal Configuration When a user logs on after a cold start, Router requests selection of a Terminal Type. Option 5 of the menu allows the terminal characteristics to be defined to match the terminal in use. This is only necessary if you are not using one of the predefined terminal types.
Page 33: Manager Procedures
Manager Procedures 4.1 Overview System management is carried out by a supervisor or network manager. The Router software manager facilities (referred to briefly as the 'manager') provide the dialogue between the supervisory/managerial user and Router. It is an intelligent, command-driven, menu/form based system, and provides the ability to configure, monitor, and control Router.
Page 34: How The Manager Works
4.2 How the Manager Works 4.2.1 Input Input to the manager is simple. You enter the command or information as an ASCII string, then terminate and submit it for evaluation by entering carriage return or line feed. The editing functions available are: Deleting a Character When a delete ( ) or backspace (...
Page 35: Using Menus
When a command is processed, any additional information required is prompted for, and if the prompt has an associated menu then the new menu will be displayed with the prompt. Menus are only changed when it is necessary to assist and prompt the user in the selection of commands, actions, or items.
Page 36 Router uses standard form handling throughout. There are several types of field found in a form: Constrained List, Free Format Text, Free Format Blind Text, and Information Only fields. The Constrained List is a list of valid entries for the field, e.g. a directory banner field may only contain ENABLE or DISABLE.
Page 37 Restore ( – Restores the field to its current configuration state (or initial state). Space – When the cursor is at a Constrained List, the list is sequenced forward one item. Backslash ( – When the cursor is at a Constrained List, the list is sequenced backward one item.
Page 38: Initial Entry To The Manager
4.2.5 Initial Entry to the Manager After connecting to Router, you can gain entry to the manager by using the command. Once you are logged on, the manager assumes it is logon communicating with a terminal of the type configured as the 'manager terminal type'.
Page 39: Menu Hierarchy
4.2.6 Menu Hierarchy Figure 4-1 shows the hierarchy of the five menus and the forms accessible from each. MAIN CONFIGURATION CONTROL STATUS (General Router (General) (Ethernet I/F) (General) Configuration) CONN MESS (X.25 I/F) (Connections) (Messages) (Routing Table) SERV LINE PROT (Services) (Line Status) (Protocols)
Page 40: Main Menu
4.3 Main Menu Router : Watford MAIN MENU Rel x.y -------------------------------------------------------------------------------- CONF - Configuration menu CONT - Control menu STAT - Status menu - IP Router QUIT or LOGOFF -------------------------------------------------------------------------------- PF2 - Help PF4 - Main Menu PF3 - Prev Menu -------------------------------------------------------------------------------- Enter command: From this menu it is possible to execute commands directly, or to enter...
Page 41: Configuration Menu
4.4 Configuration Menu command) conf The Configuration Menu displays the options that are available for configuring Router. Router : Watford CONFIGURATION MENU Rel x.y -------------------------------------------------------------------------------- - General MESS - Messages PROT - Protocols PROF - Profiles SERV - Services LOAD - Load Configuration DUMP - Dump Configuration -------------------------------------------------------------------------------- PF2 - Help...
Page 42: Configure General Information Form
4.4.1 Configure General Information Form ( command) conf gen Router : Watford CONFIGURE GENERAL INFORMATION FORM Rel x.y -------------------------------------------------------------------------------- Router Identity Router Slot Number Default User prof Default Service prof Manager Password Verify Password Manager Terminal Type -------------------------------------------------------------------------------- PF2 - Help ^R - Restore PF1 - Submit ^C - Abort...
Page 43 the service address without using the service table; or in the service table, the service profile was not specified). Manager Password/Verify Password (Free Format Blind Text, 12) These are optional fields. The two fields must be identical and are provided as a protection from entering incorrect information.
Page 44: Configure Messages Menu
4.4.2 Configure Messages Menu ( command) conf mess Router : Watford CONFIGURE MESSAGES FORM Rel x.y -------------------------------------------------------------------------------- - Welcome Banner - Connect Message BUSY - Destination Busy - Incompatible Destination DISC - Disconnect Message User Prompt: -------------------------------------------------------------------------------- PF2 - Help -------------------------------------------------------------------------------- (conf mess) Enter message type: This menu allows you to edit the welcome banner, and to configure general...
Page 45: Configure Protocols Form
4.4.3 Configure Protocols Form ( conf prot command This form allows each of the LAN protocols to be configured for correct operation. Router : Watford CONFIGURE PROTOCOLS FORM Rel x.y -------------------------------------------------------------------------------- MAC Ethernet Address : 00:00:60:00:00:02 Framing Protocol : Ethernet IP Internet address : 001.001.001.001 Subnet mask...
Page 46 Internet address classes (Class A=255.0.0.0; Class B=255.255.0.0; Class C=255.255.255.0 – see Appendix C.2); but more flexibility is provided by this mask, as other ranges may be defined. IP Fragmentation (Free Format Text, 6) This is a mandatory field, but defaults to 576. It contains a number between 128 and 1500, which specifies the maximum IP datagram size before fragmentation occurs.
Page 47: Configure Profiles Menu
Keepalive Time (Free Format Text,6) This field specifies the number of seconds between each poll and has a range of 30-999 seconds. The field defaults to 30 seconds. X.121 Address (Free Format Text, 15) This field represents the X.25 Address of this Router. From X.25, the user should enter dialogue mode when selecting this address.
Page 48 4.4.4.1 Configure User Profiles Menu ( command) conf prof user conf up Router : Watford CONFIGURE USER PROFILES MENU Rel x.y -------------------------------------------------------------------------------- ----------------- ----------------- ----------------- ----------------- def-user ----------------- ----------------- ----------------- ----------------- ----------------- ----------------- ----------------- ----------------- ----------------- ----------------- ----------------- ----------------- ED - Edit CO - Copy CL - Clear --------------------------------------------------------------------------------...
Page 49 4.4.4.2 Configure User Profile Form ( command) conf up ed Router : Watford CONFIGURE USER PROFILE FORM Rel x.y -------------------------------------------------------------------------------- Name : Number : 1 Escape seq Disc. seq Switch seq1 Switch seq2 Switch seq3 Switch seq4 Directory banner : ENABLE Manager Login : ENABLE Free Service selection...
Page 50 Switch Seq1/2/3/4 (Free Format Text, 15) These fields are optional. The strings must begin with a control character (a carat) and may contain embedded control characters to be used to define the key sequence required to indicate that a switch to that session number is required.
Page 51 Parity (Constrained List) This allows you to define the parity of text to be generated when in dialogue. – Generate odd parity – Generate even parity EVEN – Generate mark parity MARK – Generate space parity SPACE – Transparent from user NONE Router always ignores incoming parity.
Page 52 Break Map (Constrained List) This field indicates whether Break is to be transmitted by Router, and selects the TELNET character that is to be used to indicate a Break character on the LAN. – Translate WAN Break to TELNET BREAK BREAK –...
Page 53 4.4.4.4 Configure Service Profile Form ( command) conf sp ed Router:Watford CONFIGURE SERVICE PROFILE FORM Rel x.y -------------------------------------------------------------------------------- Name : def-service Number : 1 Inactivity Timeout Initial sequence Refresh sequence CR map to X.25 : CR CR map from X.25 : CR LF map to X.25 : LF...
Page 54 Refresh Sequence (Free Format Text, 9) This field is optional. It may contain embedded control characters. This string will be sent to the service whenever the service is selected (excluding initial connection). CR/LF mapping (Constrained List) Four fields are provided to select CR and LF character mapping to and from X.25.
Page 55 Remote X.3 Parameters (Constrained List) This field selects whether Router sets the remote X.3 parameters when making an X.25 connection. - Set remote X.3 parameters ENABLED - Do not set remote X.3 parameters DISABLED Echo (Constrained List) This field selects whether the local device will echo characters. With this option disabled it is assumed that the remote device will echo all characters.
Page 56 Editing If editing is enabled (X.3 parameter 15), data held in a local buffer may be edited using the delete character (parameter 16) and the buffer may be deleted using the buffer delete character (parameter 17). In addition the contents of the buffer may be displayed using the buffer display character (parameter 18).
Page 57 The first four profiles are fixed and cannot be edited, cleared or copied to. It is however possible to view, and copy from, these profiles. 4.4.4.6 Configure Terminal Profile Form ( conf tp ed conf tp vi command) Page 1 of the form is: Router : Watford CONFIGURE TERMINAL PROFILE FORM (page 1) Rel x.y...
Page 58 CursorUp (Free Format Text, 15) This field defines the character sequence generated from the terminal to indicate a move-cursor-up. CursorDown (Free Format Text, 15) This field defines the character sequence generated from the terminal to indicate a move-cursor-down. Redisplay (Free Format Text, 15) can be generated from the terminal to indicate that a redisplay of the entire screen is required.
Page 59 Previous Menu (Free Format Text, 15) can be generated from the terminal to indicate that a move to the previous menu is required. This field allows an additional key sequence to be defined, if required. Txt (Free Format Text, 11) This text corresponds to the adjacent key sequence and is used to represent the key sequence in menus, etc (e.g.
Page 60 Back Tab (Free Format Text, 15) This field defines the character sequence generated from the terminal to indicate that a move to the previous field is required. Txt (Free Format Text, 8) This text corresponds to the adjacent key sequence and is used to represent the key sequence in menus, etc (e.g.
Page 61 Highlight On (Free Format Text, 15) This field defines the character sequence to be sent to the terminal to indicate that the subsequent characters should be output in a highlighted fashion. Highlight Off (Free Format Text, 15) This field defines the character sequence to be sent to the terminal to indicate that the subsequent characters should no longer be output in a highlighted fashion.
Page 62: Configure Services Menu
4.4.5 Configure Services Menu ( command) conf serv This menu allows each of the individual service menus to be accessed. Router : Watford CONFIGURE SERVICES MENU Rel x.y -------------------------------------------------------------------------------- X.25 Service LAN Service -------------------------------------------------------------------------------- PF2 - Help PF4 - Main Menu PF3 - Prev Menu -------------------------------------------------------------------------------- (conf serv) Enter service type:...
Page 63 4.4.5.1 Configure X.25 Services Menu ( conf serv wan conf wan command) Router : Watford CONFIGURE WAN SERVICES MENU Rel x.y -------------------------------------------------------------------------------- Name Name Name *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName>...
Page 64 4.4.5.2 Configure X.25 Service Form ( conf serv wan ed conf wan ed command) Router : Watford CONFIGURE WAN SERVICE FORM Rel x.y -------------------------------------------------------------------------------- Name Internet Address : TCP port X.121 Address : Sub-Address Password User Prof. Service Prof Service Type : Printer timeout -------------------------------------------------------------------------------- PF2 - Help...
Page 65 Password (Free Format Blind Text, 13) This is an optional field. If you enter a password here, then the user will be requested to confirm it prior to a connection being allowed to take place. User prof (Free Format Text, 15) This is an optional field.
Page 66 4.4.5.3 Configure LAN Services Menu ( command) conf serv lan conf lan Router : Watford CONFIGURE LAN SERVICES MENU Rel x.y -------------------------------------------------------------------------------- Name Name Name *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName>...
Page 67 4.4.5.4 Configure LAN Service Form ( conf serv lan ed conf lan ed command) Router : Watford CONFIGURE LAN SERVICE FORM Rel x.y -------------------------------------------------------------------------------- Name X.121 Address Sub-Address: Internet TCP Port Address Password User Prof Service Prof.: -------------------------------------------------------------------------------- PF2 - Help ^R - Restore PF1 - Submit ^C - Abort...
Page 68 User prof (Free Format Text, 15) This is an optional field. It contains a user profile number or name. If this service is selected automatically, then the user connection (originator Router) will adopt the characteristics of this user profile. If no profile is specified, then the default user profile will be used.
Page 69: Configure Load
4.4.6 Configure Load ( command) conf lo This command causes Router to load the last saved configuration from disk and place it into the current configuration in memory: this operation over- writes any previous configuration not saved to disk. A message is displayed signifying whether the load was successful or not.
Page 70: Control Menu
4.5 Control Menu command) cont This menu allows you to control the X.25 and Ethernet interfaces, new gateway calls and connections, and also allows you to access the Service menu. Router : Watford CONTROL MENU Rel x.y -------------------------------------------------------------------------------- * LAN further LAN calls (ENable/DIsable) further WAN calls (ENable/DIsable) SERV...
Page 71: Serv
4.5.3 SERV ( command) cont serv Router : Watford CONTROL SERVICES MENU Rel x.y -------------------------------------------------------------------------------- X.25 Service TCP/IP Service -------------------------------------------------------------------------------- PF2 - Help PF4 - Main Menu PF3 - Prev Menu -------------------------------------------------------------------------------- (cont serv) Enter service type: This menu allows you to choose the WAN or LAN control service menu. X870-300351 Issue 1 4-39 Rev.0...
Page 72 4.5.3.1 Control WAN Services Menu ( command) cont serv wan cont wan Router : Watford CONTROL WAN SERVICES MENU Rel x.y -------------------------------------------------------------------------------- Name Name Name *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName>...
Page 73 4.5.3.2 Control LAN Services Menu ( command) cont serv lan cont lan Router : Watford CONTROL LAN SERVICES MENU Rel x.y -------------------------------------------------------------------------------- Name Name Name *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName> *<ServiceName>...
Page 74: Clear
4.5.4 CLEAR ( command) conn cl This command can be used to clear connections. If the specified connection is a user (source), this clears all the calls (sessions) associated with the user. Connections are identified by their channel number (<connId>). These numbers can be obtained from the status screens.
Page 75: Status Screen
4.6 Status Screen command) stat The status screen provides status and statistics on the operational aspects of Router for supervisors and engineers. Router : Watford STATUS MENU Rel x.y -------------------------------------------------------------------------------- Connections overview CONN Detailed connections LINE Line status -------------------------------------------------------------------------------- PF2 - Help PF4 - Main Menu PF3 - Prev Menu --------------------------------------------------------------------------------...
Page 76: General Status Menu
4.6.1 General Status Menu ( command) stat gen This screen displays up to a page of connections. Router : Watford GENERAL CONNECTION STATUS Rel x.y -------------------------------------------------------------------------------- Connid Source Connid Destination State 1100001321 001.001.001.003 192.000.002.200 111.111.111.111 001.001.001.001 111.111.111.111 110001123456 110000112345 192.000.002.001 * = Currently selected CLEAR Connid = clear connection --------------------------------------------------------------------------------...
Page 77 State This displays the current status of the session as follows: – connecting – a call attempt is being made and the user is waiting for the call to be accepted by the service – clearing – the connection has been broken and Router is waiting for the clear to be processed –...
Page 78: Connection Status/Statistics Menu
4.6.2 Connection Status/Statistics Menu ( command) stat conn Router : Watford CONNECTION STATUS/STATISTICS Rel x.y -------------------------------------------------------------------------------- LAN STATISTICS= TELNET: Tx Data Chr Rx Data Chars Tx Non-Data Rx Non-Data TCP: Local Ip address Rem IP address Local Port Rem Port Tx Packets Rx packets Re-Transmit...
Page 79 TELNET:Tx Data Chr This is the number of data characters that have been transmitted to the LAN from this TELNET connection. TELNET:Rx Data Chr This is the number of data characters that have been received from the LAN to this TELNET connection. TELNET:Tx Non-Data This is the number of non-data (special TELNET) characters that have been transmitted to the LAN from this TELNET connection.
Page 80 TCP:Incoming Window The current window size that we are reporting to the remote user/service on the LAN. A window size of zero indicates flow control when we are not accepting any data. TCP:Outgoing Window The current window size reported by the remote user/service on the LAN. WAN STATISTICS= PAD: Tx Data Chr The number of characters transmitted on this channel since the current...
Page 81: Line Status/Statistics Menu
4.6.3 Line Status/Statistics Menu ( command) stat line Router : Watford LINE STATUS/STATISTICS Rel x.y -------------------------------------------------------------------------------- MAC: Tx frames Rx frames CRC errors Long frames Overruns Datagrams Checksum err : Short Pkts Version err ICMP: Received Sent Echo Request : Echo Request : Dest unreach : Dest unreach :...
Page 82 IP: Short Packets The number of IP datagrams that were too small. IP: Version err The number of IP datagrams that had an incorrect version number. ICMP: Echo request The number of echo request messages which have been received and sent. (Receipt of an echo request message causes an echo reply to be sent.) ICMP: Dest unreach The number of destination unreachable messages which have been...
Page 83 4.6.3.1 ARP Status Table ( commands) stat line arp stat arp Router : Watford ARP TABLE STATUS Rel x.y -------------------------------------------------------------------------------- Internet Address Ethernet Address <InternetAddress> <EthernetAddress> <InternetAddress> <EthernetAddress> <InternetAddress> <EthernetAddress> <InternetAddress> <EthernetAddress> <InternetAddress> <EthernetAddress> <InternetAddress> <EthernetAddress> <InternetAddress> <EthernetAddress> <InternetAddress> <EthernetAddress> <InternetAddress>...
Page 84: Ip Router Screen
4.7 IP Router Screen command) The IP Router screen is used to control and view all aspects of the IP Routing function of Router. Router : Watford IP ROUTER MENU Rel x.y -------------------------------------------------------------------------------- General Router Configuration Routing Table Remote Router Status Remote Router Configure MAC, IP and ICMP statistics UDP and RIP statistics...
Page 85: General Router Configuration Form
4.7.1 General Router Configuration Form Router : Watford GENERAL ROUTER CONFIGURATION FORM Rel x.y -------------------------------------------------------------------------------- Internet Address : 001.001.001.001 Subnet Mask : 255.000.000.000 IP Broadcast Address : 001.255.255.255 WARNING: Changes to IP parameters will only take effect after a warm restart X.25 IP Address : 255.255.255.255 X.25 Subnet Mask...
Page 86 X.25 IP Broadcast (Free Format Text, 16) This field represents the X.25 IP Broadcast address that will be used when receiving incoming RIP responses over X.25. The network portion should match the X.25 IP Address network number and the host part is optionally all zeros or the decimal value obtained when all host bits are set to one.
Page 87: Routing Table
4.7.2 Routing Table ( command) rtr rt This screen allows you to page through the local routing table. Router : Watford ROUTING TABLE STATUS Rel x.y -------------------------------------------------------------------------------- Item Network Subnet Mask Next Hop Metric 001.000.000.000 255.000.000.000 LOCAL 100.000.000.000 255.000.000.000 Reading ED - Edit DE - Delete --------------------------------------------------------------------------------...
Page 88 Metric (Information) This field displays the number of ''hops'' or routers through which an IP packet must pass before it reaches its final destination (a value of 16 means unreachable). TTL (Information) This field displays the ''time to live'' in seconds for this entry in the routing table.
Page 89: Static/Default Routes Form
4.7.3 Static/Default Routes ( command) rtr rt ed Router : Watford STATIC/DEFAULT ROUTES FORM Rel x.y -------------------------------------------------------------------------------- Static route : Network Next hop Metric 109.0.0.0 1.0.0.21 Default route : Next hop Metric 1.0.0.19 -------------------------------------------------------------------------------- PF2 - Help ^R - Restore PF1 - Submit ^C - Abort --------------------------------------------------------------------------------...
Page 90: Remote Router Status
4.7.4 Remote Router Status ( command) rtr rs This screen displays the remote Router which may be accessed across the X.25 network. Router : Watford REMOTE X25 ROUTER STATUS Rel x.y -------------------------------------------------------------------------------- Name IP Address X.121 Address SVCs Tx Packets Rx Packets Reading 1.0.0.21...
Page 91 Rx Packets (Information) This field displays the number of IP packets received from the remote router. X870-300351 Issue 1 4-59 Rev.0...
Page 92: Remote Router Configure
4.7.5 Remote Router Configure ( command) rtr rc This screen displays the configured remote routers. Router : Watford CONFIGURE REMOTE ROUTER Rel x.y -------------------------------------------------------------------------------- Router Router Router * bermuda * sydney * miami * = Service Disabled ED - Edit EN - Enable DE - Delete DI - Disable...
Page 93: Configure X.25 Router Form
4.7.6 Configure X.25 Router Form ( command) rtr rc ed Router : Watford CONFIGURE X25 ROUTER FORM Rel x.y -------------------------------------------------------------------------------- Name Interface : IP Address X.121 Called Adr Password Maximum SVCs Inactivity timeout RIP updates -------------------------------------------------------------------------------- PF2 - Help ^R - Restore PF1 - Submit ^C - Abort --------------------------------------------------------------------------------...
Page 94: Mac, Ip And Icmp Statistics
Maximum SVCs (Free Format Text, 2) This field specifies the maximum number of SVCs which will be allowed between this and the remote Router. Inactivity timeout (Free Format Text, 24) This field specifies the length of time in seconds, after which if no packets have been received or sent on a particular SVC, it will be disconnected.
Page 95: Udp And Rip Statistics
4.7.8 UDP and RIP Statistics Router : Watford UDP and RIP STATISTICS Rel x.y -------------------------------------------------------------------------------- UDP: udpInDatagrams : udpOutDatagrams : udpInErrors udpNoPorts RIP: riplnResponse ripOutResponse riplnRequest ripOutRequest Version 0 Must be zero RE - Reset stats -------------------------------------------------------------------------------- PF2 - Help PF4 - Main Menu PF3 - Prev Menu --------------------------------------------------------------------------------...
Page 96 RIP: ripIn Request The number of RIP request, messages received by this Router. RIP: ripOutRequest The number of RIP request messages originated by the Router. Version 0 Count of RIP messages discarded because their version number is zero. Must be zero Count of RIP messages discarded because a non-zero value was found in a ''must be zero'' field.
Page 97: Summary Of Manager Commands
4.8 Summary of Manager Commands Commands are listed alphabetically. Each command and its associated short form is summarised using the following notation: – optional part italic (form) – command invokes a form COMMAND EXPLANATION SHORT FORM Clear a connection/user <connid> Clear a TCB connection/user Dump configuration conf...
Page 98 Clear connection/user on X.25 side cont cl <connid> Disable Ethernet calls cont Enable Ethernet calls cont Disable an X.25 service cont serv Enable an X.25 service cont serv Disable a LAN service cont serv Enable a LAN service cont serv Logoff manager and disconnect logoff Logoff manager and disconnect...
Page 99: Item Definitions
4.9 Item Definitions The following definitions describe parameters to various commands and are used throughout this manual. <Flag> A flag is used to indicate a positive or negative response. A positive response can be indicated in several ways: TRUE ENABLE A negative response is indicated using the inverse of these: FALSE DISABLE...
Page 100 <Name> (<ServiceName>, <ProfileName>) A name is an ASCII name from one to fifteen characters. All names must start with an alphabetic character (A-Z). All letters are not case- significant, but are stored in the correct case for visual clarity. Names can be used to identify Services (LAN and X.25) and profiles (USER, SERVICE, and TERMINAL).
Page 101 <TCP port> A TCP port is a number in the range 0 to 65535 (16 bits). The port refers to a logical device within a physical device (Internet Address). This number is often translated into a service, e.g. 23 is commonly used for the TELNET service on hosts that support TCP/IP.
Page 102 X870-300351 Issue 1 4-70 Rev.0...
Page 103: User Procedures
User Procedures This chapter is self-contained. It provides instructions for every-day users of Router's gateway facilities. 5.1 The User Environment A connection to a service is called a session. You are given the ability to hold more than one session simultaneously. You cannot communicate with all sessions simultaneously, but you can switch between them with ease.
Page 104: User Input
W E L C O M E T H E N E T W O R K Please select one of the following Services MAIL SALES SPARES STOCK > 5.1.2 User Input You can enter a character string on your input line (shown by the > symbol).
Page 105: User Commands
5.2 User Commands 5.2.1 Command Specifications The following explanation will help you to understand the specifications of the commands that are available to you, all of which are described in the subsequent subsections. When you submit an entry line with etc, then the line is subject to RETURN the following evaluation:...
Page 106 The following commands are available to you. They include the ability to make/break connections, gain status information, and obtain help. Make connection commands: CALL CONN OPEN SESSION Break connection commands: DISC CLOSE QUIT LOGOFF Status/configure commands: STATUS Helpful commands: HELP DIRECTORY CATALOGUE Ancillary commands:...
Page 107: Call/Conn/Open
5.2.2 CALL/CONN/OPEN These commands allow you to establish a connection to a service. <InternetAddress> <TcpPort> CALL <ServiceName> <ServiceName> CONN OPEN <X.121 Address> W = only available to WAN users connecting to LAN. L = only available to LAN users connecting to X.25. Prior to connection, if a password has been set on the selected service, you are requested to enter it.
Page 108: Disc/Close
5.2.3 DISC/CLOSE These commands allow you to disconnect either the last session used, or a specified session by its SessionId. DISC <SessionId> CLOSE The session is disconnected and you are then presented with a disconnection message. You will stay in dialogue. X870-300351 Issue 1 Rev.0...
Page 109: Quit/Logoff
5.2.4 QUIT/LOGOFF These commands terminate all sessions and disconnect you from Router. QUIT LOGOFF You are not presented with disconnection messages for each session. The WAN or HOST to which you are attached sends you an appropriate message. X870-300351 Issue 1 Rev.0...
Page 110: Session
5.2.5 SESSION This command allows you to enter communication with the last session used, or with a specific session. SESSION <SessionId> You go directly into communication with the session selected. In general it is preferable to switch sessions using 'hot-keys'. X870-300351 Issue 1 Rev.0...
Page 111: Status
5.2.6 STATUS This command provides you with information about currently-established sessions. STATUS Session status is output as in the following example: Sess Service TimeCnctd TxChrs RxChrs State DEVSYSA 3:25:10 2148 27352 Connected MAIL 2:40:22 Connected DEVSYSB 2:50:35 1292 600249 Connected 100.2.3 10:20 Connected...
Page 112: Set
5.2.7 This command allows various operational parameters to be viewed or changed. <SessionId> <Flag> ECHO <RefString> REFRESH <KeyDef> ESCAPE DISCONNECT <KeyDef> <SessionId> SWITCH is entered on its own, a list of current settings is output, for example: Sess ECHO SWITCH REFRESH TIMEOUT Loc.
Page 113 occasion. This option has no effect when executed from a LAN user; it is only relevant in the case of a WAN user calling a TELNET service. The REFRESH string is sent to the service when a session is reselected. In some applications it is possible to request that your screen is updated (refreshed).
Page 114: Directory/Catalogue
5.2.8 DIRECTORY/CATALOGUE These commands list the services that are available to you. The list is tabulated and sorted into alphabetical order. DIRECTORY CATALOGUE Typical output provided by this command: Directory of services. BARCODE DEVSYSA DEVSYSB MAIL MVAX SEQUENT X870-300351 Issue 1 5-12 Rev.0...
Page 115: Help
5.2.9 HELP/? This command provides you with several levels of help. MORE HELP <Command> FULL without any parameters gives a list of all the commands available, HELP and advice on how to connect/disconnect services. gives general help on syntax and line editing commands. HELP MORE gives the syntax definition of that command, and a brief HELP <Command>...
Page 116: Login/Logon
5.2.10 LOGIN/LOGON This command allows access to the management facilities of Router, but is restricted to personnel who know the manager password. LOGIN LOGON The password is entered in the same way as passwords for the CALL/OPEN/CONN commands. If you get the password wrong three times in succession then you will be disconnected from Router and any calls will be cleared.
Page 117: Technical Specifications
Appendix A Technical Specifications A.1 Configuration Limits Number of User Profiles Number of Service Profiles Number of Terminal Profiles Number of Services 128 (sum of all services) Maximum Simultaneous Sessions Maximum Simultaneous Users Maximum Simultaneous Users in Dialogue 16 A.2 Terminal Types Pre-defined Profiles: VT100/ANSI ADM3A...
Page 118 A.4 AUI Port The following table shows the pin-out for the AUI port. SIGNAL DESCRIPTION D0-A DATA OUT CIRCUIT A D0-B DATA OUT CIRCUIT B D0-S DATA OUT CIRCUIT SHIELD DI-A DATA IN CIRCUIT A DI-B DATA IN CIRCUIT B DI-S DATA IN CIRCUIT...
Page 119: Tpim Port
A.5 TPIM Port The following table shows the pin-out for the TPIM 10-way RJ45 connector. SIGNAL DESCRIPTION Transmit Data + – – Transmit Data Receive Data + – – Receive Data All remaining pins are unused. X870-300351 Issue 1 Rev.0...
Page 120: Standards And Approvals
A.6 Standards and Approvals The Ethernet Physical Interface conforms to IEEE 802.3 10BASE5, electrical and mechanical specifications. Cheapernet or IEEE 802.3 10BASE2 can be connected to by using a Cray IEEE 802.3 10BASE2 Transceiver. All LAN protocols operate to the relevant RFC (Request For Comment) documents.
Page 121 RFC 855 (TELNET OPTIONS) TELNET option specifications. Postel, J., Reynolds, J. Network Working Group. May 1983 (Information Sciences Institute, University Southern California.) RFC 856 (TELNET BINARY OPTION) TELNET Binary Transmission. Postel, J., Reynolds, J. Network Working Group. May 1983 (Information Sciences Institute, University Southern California.) RFC 857 (TELNET ECHO OPTION) TELNET Echo Option.
Page 122 The Ethernet: A Local Area Network: Data Link Layer and Physical Layer Specifications. DEC/INTEL/XEROX Corporations. Version 2.0. September 1982. IEEE 802.3 Standard 1985. Carrier Sense Multiple Access with Collision Detect (CSMA/CD) Access Method and Physical Layer Specifications. (10BASE5 and 10BASE2) RFC 813 Window Acknowledgement Strategy in TCP David D Clark...
Page 123: Default Configuration
Appendix B Default Configuration The default configuration of Router is as follows: General Default User Profile Information Default Service Profile Manager Password carriage return Manager Terminal Type none Date/Time preset value Messages Welcome Banner none General Text standard text ( etc) DISC prompt =...
Page 124 Terminal Empty Profiles (5-8) Protocols MAC Ethernet Address Pre-Programmed Prom MAC Protocol Ethernet IP Internet address 1.1.1.1 Subnet Mask 255.0.0.0 IP Fragmentation IP Time to Live TCP Window Size TCP Max Segment Size TCP Initial RTT WAN Services (1) Name SERVICE IP Address 1.1.1.1...
Page 125: Ethernet, Tcp/Ip And Rip
Appendix C Ethernet, TCP/IP and RIP This appendix contains brief descriptions of Ethernet Local Area Networks, TCP/IP and RIP. They are introductory and are provided as additional information. It is not necessary to understand these systems to make use of the Series 8000 TGate successfully, and this appendix may be ignored if desired.
Page 126: C-1 Ethernet Topology
The CSMA/CD type of MAC is 'probabilistic' or 'non-deterministic'; this is because the ability of any one station to transmit information has a probability corresponding to the activity on the bus and the nature of that activity, thus preventing the pre-determination of performance or propagation delays for any given station on the network.
Page 127 The IEEE standard allows the use of good quality coaxial cable ('yellow cable') or a thinner cheaper coaxial cable (RG58). These are known as Ethernet IEEE 802.3 10BASE5 and Thinwire Ethernet IEEE 802.3 10BASE2 (Cheapernet). Thinwire Ethernet has the disadvantage of reduced distance from 500 metre segments to 185 metre segments, and a maximum number of nodes (taps) per segment from 100 to 30.
Page 128: Tcp/Ip Protocols
C.2 TCP/IP Protocols TCP/IP is currently the de facto standard for LAN interworking. It was developed by researchers within and around the Advanced Research Projects Agency (ARPA) in the United States. It is currently the most popular non-proprietary protocol in use today. TCP and IP both refer to specific protocols within a complete suite of interworking protocols known as the 'Internet Protocol Suite';...
Page 129 The Internet Protocol (IP) layer is the common networking and inter- networking layer within the TCP/IP protocol suite. This allows a standard carrier network to deliver 'datagrams' independent of the higher layer protocols (applications), and conversely it allows an application to communicate without any knowledge of the underlying media/network.
Page 130 character set may be different (e.g. IBM-EBCDIC), without requiring different terminal equipment. FTP is a File Transfer Protocol; it allows the transfer of ASCII or IMAGE files from one machine to another across the network. Again the use of ASCII allows a common interchange to take place, even if the hosts have different character sets.
Page 131: Ieee 802.3 And Ethernet Differences
C.3 IEEE 802.3 and Ethernet Differences In September 1980, Digital, Intel and Xerox (DIX) published 'the blue book' Version 1.0: A Local Area Network, Data Link Layer and Physical Layer specifications. It was later revised as Version 2 in November 1982. Version 2.0 stated that it was an interim specification and the Ethernet Specification would now evolve with the Standards bodies (IEEE).
Page 132 DIX defines that frames contain a 2-byte type field as opposed to a 2-byte length field in the ISO/IEEE specifications. The addressing parts of the frame are identical in both the IEEE and DIX specifications. The type field has the advantage of using the same cabling for efficiently operating many different protocol sets (e.g.
Page 133: Rip
C.4 RIP Router implements the Routing Information Protocol (RIP) in order to propagate routing information throughout the network. The protocol is a straightforward implementation of vector-distance routing for local networks that partitions participants into active and passive (silent) machines. Active routers advertise their routes to others; passive machines listen and update their routes based on advertisements, but do not advertise.
Page 134 X870-300351 Issue 1 C-10 Rev.0...
Page 135: Ascii Conversion Table
Appendix D ASCII Conversion Table The following table shows equivalence between decimal and ASCII control characters. Name Symbol NULL ^~ * * This is specific to Router and does not follow the standard ASCII convention. X870-300351 Issue 1 Rev.0...
Page 136 X870-300351 Issue 1 Rev.0...
Page 137: Example Applications
Appendix E Example Applications This appendix illustrates example applications of Router. It refers to information explained in Chapter 4. E.1 Example of the Gateway Function of Router SALES DEVSYS (1.1.1.1) X.25 ROUTER (1.1.1.3) WAREHOUSE COMSYS (1.1.1.2) DEVELOPMENT Figure E-1 Example Bulk Serving Application Figure E-1 shows a network with two host computers, one for development (DEVSYS) and one for commercial use (COMSYS).
Page 138 The Router IP address should be set to using the command. 1.1.1.3 conf prot Two user profiles are required, one for the seamless connections (warehouse and development), and one for the dialogue connections (sales). To edit each user profile, enter the command followed by the conf up ed profile number, and complete the forms as follows:...
Page 139 Router : Watford CONFIGURE USER PROFILE FORM REL x.y ------------------------------------------------------------------------------- Name : MultiSess Number Escape Seq : ESC PF4 Disc. Seq Switch Seq1 : ESC PF1 Switch Seq2 : ESC PF2 Switch Seq3 Switch Seq4 Directory banner : ENABLE Manager Login : ENABLE Free Service selection : ENABLE...
Page 140 Router : Watford CONFIGURE SERVICE PROFILE FORM REL x.y ------------------------------------------------------------------------------- Name : Standard Number Inactivity Timeout: Initial seq Refresh seq Telnet Options Service will Echo : YES Supress GO-AHEAD: NOT SUPRESSED BINARY: DISABLED Local X.3 Parameters ECHO: DISABLED Char. Forwarding: 126 LF INSERTION: DISABLED Forward Timeout : 2 Remote X.3 Parameters : DISABLED...
Page 141 Router : Watford CONFIGURE SERVICE PROFILE FORM REL x.y ------------------------------------------------------------------------------- Name : Saleslogin Number Inactivity Timeout: Initial Seq : Login Sales^M Refresh seq : Telnet Options Service will Echo : YES Supress GO-AHEAD: NOT SUPRESSED BINARY: DISABLED Local X.3 Parameters ECHO: DISABLED Char.
Page 142 Router : Watford CONFIGURE SERVICE PROFILE FORM REL x.y ------------------------------------------------------------------------------- Name : Stocklogin Number Inactivity Timeout: Initial seq LOGIN STOCK^M Refresh seq Telnet Options Service will Echo : YES Suppress GO-AHEAD: NOT SUPRESSED BINARY: DISABLED Local X.3 Parameters ECHO: DISABLED Char.
Page 143 Each service can then be configured using the command, conf lan ed followed by the service name, and completing the forms as follows: Router : Watford CONFIGURE LAN SERVICE FORM REL x.y ------------------------------------------------------------------------------- Name : DevSys X.121 Address Sub-Address : Internet 1.1.1.1 TCP Port :...
Page 144 Router : Watford CONFIGURE LAN SERVICE FORM REL x.y ------------------------------------------------------------------------------- Name : Sales X.121 Address Sub-Address Internet 1.1.1.2 TCP Port Address Password User Prof : MultiSess Service Prof : Saleslogin ------------------------------------------------------------------------------- PF2 - Help ^R - Restore PF1 - Submit ^C - Abort ------------------------------------------------------------------------------- This service uses the pre-configured user and service profiles to connect to...
Page 145 Router : Watford CONFIGURE LAN SERVICE FORM REL x.y ------------------------------------------------------------------------------- Name : Stock X.121 Address : 11000017050 Sub-Address : 01 Internet : 1.1.1.2 TCP Port : 23 Address Password User Prof : Seamless Service Prof : Stocklogin ------------------------------------------------------------------------------- PF2 - Help ^R - Restore PF1 - Submit ^C - Abort...
Page 146: Example Application Of Ip Routing
E.2 Example Application of IP Routing ROUTER ROUTER 1.0.0.6 3.0.01 3.0.02 2.1.1.3 (LONDON) (BIRMINGHAM) X.25 11000047050 11000127050 Figure E-2 Example IP Routing Application Figure E-2 shows two IP Ethernet LANs at remote sites. The Routers are to be used for file transfer using FTP between the two host computers. The following should be configured: X870-300351 Issue 1 E-10...
Page 147 At London's Router: Enter and complete the form as follows: rtr gen Router : London GENERAL ROUTER CONFIGURATION FORM REL x.y ------------------------------------------------------------------------------- Internet Address : 001.000.000.006 Subnet Mask : 255.000.000.000 IP Broadcast Address : 001.255.255.255 WARNING: Changes to IP parameters will only take effect after a warm restart X.25 IP Address : 003.000.000.001 X.25 Subnet mask...
Page 148 Enter followed by the name of the remote Router (e.g. Birmingham) rtr rc ed and complete form as follows: Router : London CONFIGURE X25 ROUTER FORM REL x.y ------------------------------------------------------------------------------- NAME Birmingham Interface : IP Address 003.000.000.002 X.121 Called Adr 11000127050 Password Maximum SVCs Inactivity timeout :...
Page 149 At Birmingham's Router: Enter and complete the form as follows: rtr gen Router : Birmingham GENERAL ROUTER CONFIGURATION FORM REL x.y ------------------------------------------------------------------------------- Internet Address : 002.001.001.003 Subnet Mask : 255.000.000.000 IP Broadcast Address : 002.255.255.255 WARNING: Changes to IP parameters will only take effect after a warm restart X.25 IP Address : 003.000.000.002 X.25 Subnet mask...
Page 150: The Routing Table Screen
Enter followed by the name of the remote Router (e.g. London) and rtr rc ed complete the form as follows: Router : Birmingham CONFIGURE X25 ROUTER FORM REL x.y ------------------------------------------------------------------------------- NAME London Interface : IP Address 003.000.000.001 X.121 Called Adr 1100047050 Password Maximum SVCs...
Page 151: Failure Codes
Appendix F Failure Codes The following is a list of failure codes that may be displayed during the power-up sequence. Test Number Description EPROM checksum DRAM data/addressing DRAM refresh Random data pattern DRAM execution Bus cycle and software watchdog VIA device DRAM parity Vector table read/write No test...
Page 152 Test Number Description NOVRAM test NOVRAM recall test Visual status LED test SCC1/UPM interface test SCC1 test; no interrupts/internal clock SCC1 test, Tx interrupt, internal clock SCC1 test, Rx interrupt, internal clock SCC1 test, no interrupts, baud rate clock Channel 1 Rxd-Txd loop test Channel 1 CTS-RTS loop test Channel 1 CTS-BO loop test Channel 1 DSR-DTR loop test...
Page 153: Glossary
Appendix G Glossary Address Resolution Protocol. A member of the 'Internet Protocol Suite'. See Appendix C for more information. ARPA Advanced Research Projects Agency. An American Academic community involved in research, often for the Military (DoD). Baseband Transmission of a signal at its original frequency, without modulation.
Page 154 Data Terminal Ready. A CCITT V.24 interface signal. Normally pin 20 on a 25-way connector. FDDI Fibre Distribute Data Interface. ANSI definition of a fibre optic LAN at 100 Mbps. File Transfer Protocol. A member protocol of the 'Internet Protocol Suite'. See Appendix C for more information. IEEE Institute of Electrical and Electronics Engineers (a standards body based in US).
Page 155 Transmission Control Protocol. TELNET TELNET Virtual Terminal protocol. A member protocol of the 'Internet Protocol Suite'. See Appendix C for more information. Technical Office Protocols. Transport Protocol. Usually followed by a class number, e.g. TP4. TSAP Transport Service Access Point. Wide Area Network.
Page 156 X870-300351 Issue 1 Rev.0...
Page 157: H Telnet Printer Application Example S/W Program
Appendix H Telnet Printer Application Example S/W Program This appendix provides an example of Telnet printer application software which may be used to transfer files from a host to a printer, configured on the Router WAN service menu, and mimicking a host spooler facility. For applicability see your Customer Services representative.
Page 158 /********************************************************************************************/ TITLE : Printer TELNET application /********************************************************************************************/ set #define constants for BSD_4_2+ ULTRIX*/ #include <sys/types/h> #include <netinet/in.h> #include <sys/socket.h> #include <netdb.h> #include <stdio.h> #include <signal.h> #define DSTPORT 2000 /* Default TCP port number - dec. - 1 per app*/ #define NULADDR (struct sockaddr *) /* System assigns socket address #define TYPE SOCK_STREAM /* Sequenced, reliable two way connection...
Page 159 if ((argc == 4) || ((argc == 3) && (expand == 0) ) ) /* Requested port number - decimal addr.sin_port = atoi( argv[2] ); else addr.sin_port = DSTPORT; /* Default port number addr.sin_port = htons(addr.sin_port); /* Byte flip port number addr.sin_family = AF_INET;...
Page 160 if (newline) if (--newline) *array++ = '\000'; /* (1) now \r\000 else *array++ = '\n'; /* (0) now \r\000\n • return (1); else if ((c = getchar() ) == EOF) break; /* End of File if (c == '\n') /* Needs expanding to (2) /* now \r newline = 2;...
Page 161 /*------------------------------- E R R O R -------------------------------------------*/ error( message1, message2) register char *message1; register char *message2; extern int errno; /* print system errors like perror() extern int sys_nerr; extern char *sys_errlist[]; if (progname) fprintf( stderr, ”%s: ”, progname ); fprintf ( stderr, message1, message2 ); if ((errno >...
Page 162 X870-300351 Issue 1 Rev.0...

This manual is also suitable for:

8325 8425 8525

Case 8000 Series Reference Manual

Introduction

Installation

Initial Configuration

Manager Procedures

User Procedures

Call/Conn/Open

Disc/Close

Quit/Logoff

Session

Status

Set

Directory/Catalogue

Help

Login/Logon

Technical Specifications

Default Configuration

Ethernet, TCP/IP and RIP

ASCII Conversion Table

Example Applications

Failure Codes

Appendix G Glossary

Glossary

Quick Links

Need help?

Questions and answers

Related Manuals for Case 8000 Series

Summary of Contents for Case 8000 Series

This manual is also suitable for:

Table of Contents
