Specifications And Features - Lectrosonics UM195B Operating And Troubleshooting Manual

Operating frequencies:
RF Power output:
Frequency stability:
Deviation:
Preemphasis:
Spurious radiation:
Equivalent input noise:
Input level:
Input impedance:
Input compressor:
Gain control range:
Modulation indicators:
Controls:
Audio Input Jack:
Antenna:
Battery:
Battery Life:
Weight:
Dimensions:
Emission Designator:
The UM195B transmitter is FCC type accepted under Part 74: 470-608 MHz
12

SPECIFICATIONS AND FEATURES

Specifications subject to change without notice.
470 to 608 MHz
70 mW (nominal)
±0.002%
±75 kHz (max)
None
50 dB below carrier
-126 dBV
Nominal 2 mV to 300 mV, before limiting.
Greater than 50 Volts maximum, with limiting.
Taps provided for 500, 1k, 10k Ohm
Soft compressor, >30 dB range
43 dB; semi-log rotary control
Dual LEDs indicate modulation level 20dB below limiting and
at the onset of limiting.
2 position "OFF-ON" slide switch. Front panel knob adjusts
audio gain.
Switchcraft 5 pin locking (TA5F)
Detachable, flexible wire supplied. 50 Ohm port (SMA
connector) allows connection to test equipment.
Precision compartment auto-adjusts to accept any known
alkaline or lithium 9 Volt battery. (We've tried 108 different
ones!)
7.5 Hours with alkaline 9 Volt
6.3 ozs. including battery
3.1 x 2.4 x .75 inches
200KF3E
