2.1.4 Connection Sizes
Air Cooled Units
Model
DALA 06
DALA 08
DALA 10
DALA 13
DALA 06
DALA 08
DALA 10
DALA 13
Field connections at the indoor evaporator and remote condenser or condensing unit
will not necessarily be the same as the fi eld pipe size required. In some cases these
sizes will vary signifi cantly.
Water/Glycol Cooled Units
Model
DALW/G 06
DALW/G 08
DALW/G 10
DALW/G 13
Chilled Water Units with 3-Way Valves
Model
DALC 06
DALC 08
DALC 10
DALC 13
2-Way Chilled Water Units
Model
DALC 06
DALC 08
DALC 10
DALC 13
Fluid Coolers
Fluid Cooler
Model
DAFC 06
DAFC 07
DAFC 09
DAFC 11
DAFC 15
Circuiting Hot Gas
Single circuit 1/2"
Single circuit 3/4"
Single circuit 3/4"
Single circuit 3/4"
Dual circuit 1/2"
Dual circuit 1/2"
Dual circuit 1/2"
Dual circuit 1/2"
Condenser Water In
1 5/8"
1 5/8"
1 5/8"
1 5/8"
Chilled Water In
1"
1 1/4"
1 1/4"
1 1/4"
Chilled Water In
1"
1 1/4"
1 1/4"
1 1/4"
Water IN and OUT
Connections, OD
1 5/8"
1 5/8"
1 5/8"
2 1/8"
2 1/8"
Liquid Suction
1/2" 3/4"
5/8" 1 1/8"
5/8" 1 1/8"
5/8" 1 1/8"
1/2" 3/4"
1/2" 3/4"
1/2" 3/4"
1/2" 3/4"
Condenser Water Out
Fluid Cooler
Model
DAFC 17
DAFC 24
DAFC 28
DAFC 30
10
1 5/8"
1 5/8"
1 5/8"
1 5/8"
Valve CV
14.0
20.0
20.0
20.0
Valve CV
14.0
20.0
20.0
20.0
Water IN and OUT
Connections, OD
2 5/8"
2 5/8"
2 5/8"
2 1/8"
