iCamera-1000-ADT Indoor Low-Light Camera Installation Guide

Rear Panel

1. LAN Port
2. Stand Mount
3. Reset Button
IMPORTANT
The default Wireless settings are:
Mode: Infrastructure
SSID: ANY
Wireless Security: Disabled
NOTE:
Domain: USA
Channel No.: Auto
4
Figure 2: Rear Panel
Use in conjunction with the supplied LAN cable to
connect your iCamera to the ADT Pulse Gateway.
The stand mount connects the stand to the iCamera.
The reset button has two (2) functions:
•
Reboot. When the reset button is quickly pressed
then released, the iCamera reboots.
•
Clear All Data. To Clear All Data and restore the
factory default settings:
1. Power On.
2. Press and hold the Reset Button for eight
seconds.
When you release the Reset button, the iCamera is
reset to the factory default settings.
THE RESET BUTTON WILL RESET THE iCAMERA
COMMUNICATION CONFIGURATION SETTINGS AND
SHOULD ONLY BE USED UNDER THE DIRECTION OF
ADT SUPPORT.
ADT Pulse Interactive Solutions
®
