Nxt™ Features - Invacare NXT Generation NEXT User Manual

1 1
2 2
3
3
4 4
5 5
6 6
7 7
1. Swing Away Hanger
2. Flip-up Footplates
3. Seat Frame
4. Tilt Mechanism
5. Base Frame
6. Castor Fork
7. Castor Wheel
8. Folding Crossbraces
9. Wheel Lock
10. 12" Mag Wheel
11. Quick Release Axle
NXT
21 21 20 20
8 8 9 9
(pop-up or latch style)
19 19
10 10 11 11
12. Anti-tip Tube without Leverage Bar
13. Axle Adjustment Plate (not shown)
14. Anti-tip Tube with Leverage Bar
15. Backpost Adjustment Plate
16. Backpost Release Trigger
17. Backpost
18. Arm Height Adjustment Clamp
19. Flip up Arm
20. Lifting / Folding Strap
21. Solid Seat & Back (optional)
17
Features
18 18
17 17
16 16
15 15
14
14
13 13
12 12
