Contents; Important Safety Warnings; Description - Smart Openers Smart Lifter Installation Manual

Contents

No Package
1 Motor
2 Rail

Important Safety Warnings

The Smart Lifter garage door opener described in this
manual is designed for the automation of residential
sectional overhead doors and one piece overhead tilting
doors. Any other use is considered improper and will void
the warranty.
WARNING:
You are carrying out operations on machine systems
classified in the automatic gates and doors category and
as such failure to comply with the relevant safety rules
may result in serious personal injury and/or property
damage. Reference to the safety rules can be found on
pages 2-4 of the oweners manual and should be read
and understood prior to installation.
Only qualified personnel should install and service the
equipment. It is the responsibility of the installer to adhere
to all relevant safety standards.
The Smart Lifter opener is designed and manufactured
to meet all current Australian standards and it is

Description

The Smart Lifter garage door opener requires a 240VAC
50Hz power input and has a 24V DC 100W motor and
can provide 'Hold to Run' control and automatic modes
for operation. When the door is in operation, movement
can be interrupted by activation of the safety inputs
(manual pull cord, transmitter, wall button (if fitted) and
photo beams (if fitted).
An encoder sets open and close positions and braking
during the end of the travel cycle reducing speed and
noise.
Part
No Description
1 Motor
2 Transmitter
3 Remote Wall Switch
4 Remote Wall Switch Bracket
5 Disengagement Cord
6 Clutch
7 Bracket
8 Bracket
9 Strapping
10 Connector
11 Bolts/Nuts
12 Installation Manual
13 Owners Manual
1 Extrusion
essential that the installer also installs the equipment in
accordance with all local and Australian regulations.
Unqualified personnel or those who do not know the
occupational health and safety standards applicable
to automatic gates and doors category must under
no circumstances carry out installations or implement
systems.
Persons who install or service the equipment without
observing all the applicable safety standards will be
held responsible for any damage, injury, cost, expense
or claim whatsoever suffered by any person as a result
whether directly or indirectly from failure to install the
system correctly and in accordance with the relevant
safety standards and installation manual.
For a more detailed list of the Safety Warnings and safety
Issues associated with the installation and use of a Smart
Lifter sectional door opener refer to the safety warnings in
the OWNERS MANUAL.
A 433.22MHz radio receiver is built into the circuit board
and the rolling code is memorised with the self-learning
technique. As an alternative to the built-in receiver the
unit will accept any of the range of stand alone radio
receivers. The unit has been designed to provide
maximum reliability, safety and flexibility of use.
IMPORTANT:
Before starting to install the unit read all of the
instructions carefully and make sure you are familiar
with the safety warnings included in this manual and
in the OWNERS MANUAL.
-3-
Qty Remark
1 Set
2 Pcs Transmitter
1 Pc
1 Pc
1 Pc
1 Pc
1 Pc For Track
1 Pc For Door Panel
4 Pcs For Rail
2 Pcs For Door Panel
1 Set
1 Pc
1 Pc
1 Set
