Above: Flip back armrest
Below: Remove armrest
Rear Wheels.
The rear wheels on the wheelchair can be easily removed for
transportation or storage. With one hand holding up the
wheelchai r frame, the other hand should grip the centre of the
wheel, push the centre pin inwards and in the same movement
pull the wheel hub away from the wheel. To put the wheels back
the procedure should be reversed. Check that the wheel is
securely fastened bef o re use by pulling the wheel and ensuring
there is no sideways movement.
Enigma Standard Aluminium Wheelchair
Page 7 of 12
Armrests.
The arm rests can be flipped back
to allow access to a desk or table.
To do this lift up the front of the
armrest whilst pushing the button
(as shown on upper photograph)
To replace the armrest, pull down
on the front of the armrest until it
locks in position.
When the armrest is flipped it can
be removed. Pull back on the button
(shown on lower photo graph) whilst
pulling armrest out. Replace
armrest by sliding the armrest back
in to the receiver until it locks.
Owners Handbook
Part Code: Z17999
Folding the wheelchair
The Enigma wheelchair has been designed with an easy fold
mechanism. To fold the chair, ensure that the leg rests are
locked in position and that the plastic footrests are flipped up.
Remove the seat and back cushions and remove the quick
release components if required.
Pull up in the centre of the front and rear straps of the tension
adjustable seat canvas and the wheelchair will naturally fold up.
7 . U S I N G T H E S T E P P E R T U B E A N D
K E R B S
Use the stepper tube to raise the front castors (when mounting
a kerb for example). To use, push down on the stepper tube with
a foot. Do not raise the front castors by pushing down on the
push handles as this could result in damage to the wheelchair.
To mount a kerb. Approach the kerb head on. Then the
attendant uses the stepper tube to raise the front castors, and
lowers the front castors on the raised kerb. Finally the attendant
should push the wheelchair forward, lifting it up slightly to mount
the kerb if required.
To go down a kerb. Line up the front castors with the edge of
the kerb. The attendant uses the stepper tube to raise the front
castors and tip the occupant slightly back. Keeping the castors
raised, slowly lower the wheelchair down the kerb.
