3 . P A R T S D E S C R I P T I O N
Arm Rest
Front
Leg rests
Castor
Enigma Standard Aluminium Wheelchair
Page 3 of 12
Half fold back Push
mechanism handle
24" Rear Stepper
Brake
wheel * tube
Owners Handbook
Part Code: Z17999
* XSAWCSP18 comes with 24" self-propel rear wheels (shown)
* XSAWCTS18 comes with 12½" transit rear wheels (not shown)
4 . A D J U S T M E N T F E A T U R E S
A number of adjustments may be made to the wheelchair to suit
a user's individual requirements. A tool kit is provided with the
wheelchair to make all necessary adjustments.
i.

Rear wheel

Self Propel Wheel
Transit wheel
ii. Upholstery Adjustment
Enigma Standard Aluminium Wheelchair
Page 4 of 12
Use the axle bracket (left) to
alter the vertical or horizontal
position of the 24" self-propel
wheel. Remove the two
screws and nyloc nuts and
reposition as required.
Reattach the fasteners and
alter the brakes as required.
Use axle bracket (not shown)
to alter horizontal position of
the transit wheel. Follow the
same procedure as above
