- Page 1 ENIGMA STEEL WHEELCHAIR RANGE OWNER’S MANUAL Steel Wheelchair Range Owners Manual (Z10999 Rev E) Page 1 of 18...
-
Page 2: Table Of Contents
1 . C O N T E N T S 1. Contents 8. Using the Stepper Tube 2. Introduction 9. Disassembly and Folding 3. Parts Description 10. Using the Wheelchair in a 4. Brake Operation Vehicle 5. Leg Rest Adjustment 11. -
Page 3: Parts Description
3 . P A R T S D E S C R I P T I O N PUSH HANDLES HALF FOLD BACK ARM REST QUICK RELEASE PIN LIFTING STRAP STEPPER TUBE 24" REAR BRAKE WHEEL* FRONT RESTS CASTOR Steel Wheelchair Range Owners Manual (Z10999 Rev E) Page 3 of 18... -
Page 4: Brake Operation
* steel wheelchairs come with either 24” rear wheels (for a user to self-propel) or 12½” rear transit wheels (for an attendant to propel). The 24” rear wheels are shown in the diagram. Please note that not all of these features are available on all models of steel wheelchair. -
Page 5: Leg Rest Adjustment
To apply the parking brakes, push the plastic brake handle towards the front of the wheelchair. Push the handle back to release the brakes. The STS18EB model has additional cable brakes, which an attendant may use to apply the brakes to reduce speed whilst in motion. -
Page 6: Folding Back Mechanism
6 . F O L D I N G B A C K M E C H A N I S M diagram left & description below: Push the black paddle (1) towards the back post with your thumb whilst pulling the handle (2) down. -
Page 7: Quick Release Components
7 . Q U I C K R E L E A S E C O M P O N E N T S The wheelchair comes with a number of components which can be easily removed without tools for storage or carrying. For all parts in this section see the relevant description and diagram: A. - Page 8 B. Rear wheels (certain models only) With one hand holding up the wheelchair frame, the other hand should grip the centre of the wheel, push the centre pin inwards (1) & in the same movement pull the wheel hub away from the wheel (2). To put the wheels back the procedure should be reversed.
-
Page 9: Using The Stepper Tube
8 . U S I N G T H E S T E P P E R T U B E Use the stepper tube to raise the front castors (when mounting a kerb for example). To use, push down on the stepper tube with a foot. -
Page 10: Disassembly And Folding
9 . D I S A S S E M B L Y A N D F O L D I N G Before folding, remove any quick release components if required. The Enigma wheelchair has been designed with an easy fold mechanism. -
Page 11: Using The Wheelchair In A Vehicle
10. USING THE WHEELCHAIR IN A VEHICLE The Enigma Steel wheelchair has been tested to Wheelchair Crash Test standard ISO 7176/19 using restraints from Koller Engineering. Wherever possible the wheelchair occupant should use the vehicle’s fitted seats and the wheelchair should be folded away and placed safely in the luggage compartment of the vehicle or restrained. - Page 12 The upper torso belt should be worn over the shoulder. The belt should be worn as firm as possible without being uncomfortable. Ensure the webbing is not twisted. For more information on restraints please contact Medicare Technology. Below is a diagram illustrating the recommended positions for the restraints.
-
Page 13: Tyre Pressure And Inflation
11. TYRE PRESSURE AND INFLATION This Enigma wheelchair comes complete with pneumatic tyres. The tyres should be inflated with a manually operated pump and use a standard car tyre air valve. Note that under no circumstances should a powered or compressed air pump be used. - Page 14 Gloss black paint Metallic paint Vinyl upholstery Jemima' upholstery Economy steel brake Adjustable alu. brake Attendant cable brakes Economy armrest Desk-style armrest Quick release rear wheels Folding back mechanism 12.5" transit rear wheels 24" economy self propel rear wheels 24" standard self propel rear wheels Pneumatic grey tyres Solid grey tyres...
- Page 15 SSP18 Code SSP18E FIXED SSP18FW SSP16 SSP18 SSP18ST SUSP18 Length (cm/in) 104 / 41" 104 / 41" 104 / 41" 104 / 41" 104 / 41" 104 / 41" 104 / 41" Width 69 / 27" 66 / 26" 66 / 26" 61 / 24"...
- Page 16 1 3 . W A R R A N T Y A N D M A I N T E N A N C E To improve the safety and lifespan of your Enigma wheelchair, it is recommended that you have it serviced on a regular basis. Recommended Service Schedules for Enigma wheelchairs are available to service agents.
- Page 17 Consumable items supplied will not generally be covered during the normal warranty period unless such items require repair or replacement clearly as a direct result of a manufacturing or material defect. Such items include (among others): upholstery and tyres. The above warranty conditions apply to brand new wheelchairs. Second-hand wheelchairs supplied...
- Page 18 Other Products in the Medicare Technology Range include: Please contact your local Medicare Technology Dealer for a catalogue. Medicare Technology Ltd, Dale House, Armytage Road, Dealer Stamp Brighouse, West Yorkshire HD6 1PT. Tel: 01484 727301 Email: enquiries@medicaretechnology.com Web: www.medicaretechnology.com Steel Wheelchair Range Owners Manual (Z10999 Rev E) Page 18 of 18...
