User, Installation & Servicing Instructions
This appliance is for use on NATURAL GAS (G20) ONLY at a supply pressure of 20mbar
Please hand this booklet to the user and advise to keep in a safe place
Important Notice: Before disposal of the outer packaging, please enter the product code, purchase and
installation details in section 1.1 of this booklet.
18" Inset Taper 010710
Advertisement
Table of Contents
Related Manuals for Royal Cozyfires 18''
Summary of Contents for Royal Cozyfires 18''
- Page 1 0102 095 52541 18”Inset Raised User, Installation & Servicing Instructions This appliance is for use on NATURAL GAS (G20) ONLY at a supply pressure of 20mbar Please hand this booklet to the user and advise to keep in a safe place Important Notice: Before disposal of the outer packaging, please enter the product code, purchase and installation details in section 1.1 of this booklet.
-
Page 2: Table Of Contents
This booklet details instructions for USER (section 1), INSTALLATION (section 2) & SERVICING (section 3). IMPORTANT NOTICE It is important for the safe and continued operation of this appliance that the instructions contained in this booklet are observed! TABLE OF CONTENTS Section Instructions for Use Record of purchase/installation... -
Page 3: Instructions For Use
Page 1 Section 1 – Instructions for Use RECORD OF PURCHASE/INSTALLATION 18” Inset Purchase Details Date of purchase ______ / ______ / ______ Purchase from _____________________ Address _____________________ _________________________________________ Installation Details Date of installation ______ / ______ / ______ Installed by _____________________ Registration number _____________________... -
Page 4: Important Notes
Page 2 IMPORTANT NOTES 18 “ Inset CAUTION – THIS PACKAGE WEIGHS 6.5Kgs – assess the load before you move it and note any other handling information on the packaging. If you think the load is beyond your safe capability, DO NOT PUT YOURSELF AT RISK! Seek assistance from other person(s) and/or use appropriate handling equipment. - Page 5 Page 3 RE - LAYING THE BED 18 “ Inset Fig. 3 The support shelf is positioned on the fibre support metalwork. There are two metal `stops’ that prevent the support shelf from sitting on the main burner outlet (Fig. 3). Fig.
-
Page 6: Spare Parts
To obtain the best visual appearance, it may be necessary to `slightly’ adjust the position of the coals. If any of the coals or coal bed become damaged or lost, replacements MUST be obtained before further use. Page 4 ADDITIONAL COALS/PEBBLES MUST NOT BE USED SPARE PARTS 18”... -
Page 7: Important Notes
Section 2 – Instructions for Installation IMPORTANT NOTES 18” Inset CAUTION – THIS PACKAGE WEIGHS 6.5Kgs – assess the load before you move it and note any other handling information on the packaging. If you think the load is beyond your safe capability, DO NOT PUT YOURSELF AT RISK! Seek assistance from other person(s) and/or use appropriate handling equipment. -
Page 8: Technical Data
TECHNICAL DATA 18” Inset Fig. 7 Fig. 8 Minimum height of opening is 555mm Minimum 295mm Depth of opening is 215mm Minimum width of 215mm 415mm opening is 415mm SPECIFICATIONS Injector 044/341/196/087M Gas Control MP 21301B Main Burner Aeromatix AC03/211658 Thermocouple T100/927-400 Ignition... -
Page 9: Clearance To Sides And Shelves
2.4.1 INSTALLING THE APPLIANCE (Flue) 18” Inset Any permanent flue restriction must be removed and any variable dampers locked fully open or removed. If the flue has been used previously for solid fuel, it MUST be swept PRIOR to installation. This appliance is suitable for installation into CLASS 1 flues ONLY. 540mm Class 1 A conventional brick or stone chimney with a minimum effective... -
Page 10: Hearth Clearances
2.4.3 INSTALLING THE APPLIANCE (Hearth clearances) 18” Inset A non-combustible hearth with a minimum thickness of 12.5mm and having a perimeter of 50mm above floor level is required to discourage placing carpets or combustible materials close to the hearth. The width must be a minimum of 150mm either side of the fireplace opening and a depth of 300mm from the front face of the fire opening (Fig. -
Page 11: Checking The Appliance Setting Pressure
2.4.4.2 INSTALLING THE APPLIANCE (Checking the appliance setting pressure) 18 “ Inset The pressure test point enables verification of the inlet pressure at the appliance under operating conditions and can also be used to check the gas soundness of the connections to the appliance gas controls (Fig. - Page 12 2.5 LAYING THE BED 18 “ Inset Fig. 17 The support shelf is positioned on the fibre support metalwork. There are two metal `stops’ that prevent the support shelf from sitting on the main burner outlet (Fig. 3). Fig. 18 Metal `stops’...
-
Page 13: Clearance Ofcombustion Products
CLEARANCE OFCOMBUSTION PRODUCTS 18” Inset Smoke match Fig. 21 to be positioned Relight the appliance and allow to run for five minutes with 100mm down the gas control in the `HIGH’ position. Check for and 10mm in satisfactory clearance of combustion products by inserting from this point a lighted smoke match into the opening 100mm below the top of the opening and 10mm in from the face of the... -
Page 14: Removal Of Debris Or Soot
Section 3 – Maintenance & Servicing REMOVAL OF DEBRIS OR SOOT 18” Inset Allow the appliance to cool for two to three hours before removing all of the fibre components for cleaning purposes. Once all the fibre is removed, check that no debris is located in the burner holes of the appliance. If any debris is located, carefully remove any foreign matter from the burner holes. -
Page 15: Spare Parts
18” Inset Fig. 27 SPARE PARTS PART DESCRIPTION CROSSLEE PART No QUANTITY Aeromatix Burner (Natural Gas) (Manuf No AC03/211658 ) 0102 078 04311 Piezo Ignitor c/w Steel Nut (Manuf No 66142/100) 40245 087M Straight Injector (Manuf No 044-341-196-087M) 0102 078 04321 Ignition Lead (250mm) 40244 Inlet Bundy... -
Page 16: Useful Telephone Numbers
USEFUL TELEPHONE NUMBERS In the event that you may require service, spares or technical information, please contact us at: - Crosslee PLC Halifax West Yorkshire HX3 8DE Telephone Customer Service 01422 203963 01422 204767 Service Engineer (REPAIRCARE) 0844 8797422* *Calls cost 5p per minute from a UK BT landline. Charges from mobile and other network providers may vary. Page 15 18”...
