In the interest of improving internal design, operational function, and/or reliability, NETSYS reserves the right to make changes to the products described in this document without notice. NETSYS does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
This is why NH-310H/S is designed to be a cost effective MDU and MTU solution. With plug & play, this simply eliminates the pain in modification and high infrastructure cost. With the data transmission up to 200Mbps and link establish under -145dBm/Hz noise floor, it meets the growing demand for high speed multimedia services.
Use ONLY the dedicated power supply for your device. Connect the power to the right supply voltage (110V AC used for North America and 230V AC used for Europe, NH-310H/S supports 12 VDC power input). Place connecting cables carefully so that no one will step on them or stumble over them. DO NOT allow anything to rest on the power cord and do NOT locate the product where anyone can work on the power cord.
Page 6
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.3.1 Administrator Setting ................................21 4.3.2 System Time Zone ................................22 4.3.3 System Time ..................................23 4.3.4 Firmware Upgrade ................................24 4.3.5 Reboot....................................25 4.3.6 Reset System..................................26 4.3.7 Version Info ..................................27 4.3.8 SNMP....................................28 4.4 S ”LAN”...
Page 7
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.6.2.4 Add User for Bridges ...................................53 4.6.3 User List .....................................57 CHAPTER 5. CONFIGURE THE NH-310H VIA CONSOLE................60 5.1 S .................................60 ETUP ON YPER ERMINAL 5.2 R ..........................60 ESET THE SYSTEM TO DEFAULT CONFIGURATION 5.3 TFTP P...
Thank you for choosing Netsys NH-310H/S. Before installing the router, please verify the contents inside the package. Package Contents: NH-310H or NH-310S Device 4 x rubber foot (NH-310H pre-installed on the bottom, and you can find the rubber foot inside the inner box right side of the NH-310S) 1 x AC to DC...
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Chapter 2. Hardware Description This chapter describes the important parts of the device. It features the front indicators and rear connectors. NH-310H Outward NH-310S Outward 2.1 Front Panel The front panel provides a simple interface monitoring of the concentrator/bridged.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 2.2 Front Indicators The NH-310H has LED indicators. The following Table shows the description. (Table 2-1) Table 2-1 LED Indicators Description and Operation LEDs Color Status Descriptions The HCNA is receiving the power and also functioning properly...
Page 11
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Table 2-2 LED Indicators Description and Operation LEDs Color Status Descriptions The HCNA is receiving the power and also functioning properly Power Green The HCNA is not ready or has malfunctioned...
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 2.3 Rear Panel The rear panel provides the physical connectors connected to the power adapter and any other network device. (Figure 2.2) Figure 2.2 Rear panel of the NH-310H And the table shows the description.
Page 13
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 The following figure shows the rear side of the NH-310S. (Figure 2.3) And the table shows the description. (Table 2-4) Figure 2.3 Rear panel of the NH-310S Table 2-4 Connectors shown on the rear side of the device...
(e.g. a table or shelf). However, please take note of the following minimum site requirements before you begin. NH-310S must be stick the 4 rubber feet at the bottom and the NH-310H pre-installed 4 rubber feet.
Please choose according to different environments to different specifications of the Diplexer (5M-45MHz, 47M-1GHz) or Multi-Splitter (5M-1Ghz). • Attenuator Establish the basic link for NH-310H and NH-310S, please add a attenuator (at least -10 dB 5M-850MHz). Diplexer Multi-Splitter...
-145dBm/Hz noise floor. But make sure that the connector is inserted properly and lock. Ethernet cable used must conform to FCC standard to ensure data integrity and it should not exceed 100meters (328feet). The NH-310H EOC (Ethernet over coaxial) managed MDU concentrator can support up to 60(maximum) NH-310S Bridges (Clients). Notes: 1.
Chapter 4. Configure the NH-310H Via Web Browser The NH-310H provides a built-in HTML based management interface that allows configuration of the NH-310H via Internet Browser. Best viewed using Chrome or Firefox browsers. In order to use the web browser configure the device, you may need to allow: •...
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.2 Select the Menu Level There is an easy Setup for end users at the setup of NH-310H with SYSTEM, LAN, ROUTE, HPNA for more detail configurations. Figure 4.2 Select the Menu Level...
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.3 Select “SYSTEM” Select the “SYSTEM”. The menu below will be used frequently. It includes the sub-menus of Administrator Setting、System Time Zone、System Time、SNMP、Firmware Upgrade、Reboot、Reset System、Version Info Out. A screen is displayed as shown in Figure 4.3...
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.3.1 Administrator Setting To add a user or change user’s password, click on the “Administrator Settings” link in the left navigation bar. A screen is displayed as shown in Figure 4.3.1.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.3.2 System Time Zone User can set Time Zone by connecting to a Simple Network Time Protocol (SNTP) server allows the Device to synchronize the system clock to the global Internet. The synchronized clock in the Device is used to record the security log and control client filtering.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.3.3 System Time If user can't connect to a SNTP server to allows the Device to synchronize the system clock to the global Internet. User can setup “System Time”. A screen is displayed as shown in Figure 4.3.3.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.3.4 Firmware Upgrade To update the system firmware, click on the “Firmware Upgrade” link in the left navigation bar. A screen is displayed as shown Figure 4.3.4 Figure 4.3.4 Firmware Upgrade The screen contains the following detail: •...
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.3.5 Reboot To reboot the unit, click on the “Reboot” link in the left navigation bar. A screen is displayed as shown in Figure 4.3.5. Figure 4.3.5 Reboot NH-310H • Click “Reboot” to restart the unit.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.3.6 Reset System To reset the system, click on the Reset link in the left navigation bar. A screen is displayed as shown in Figure 4.3.6. Figure 4.3.6 Reset NH-310H •...
This function shows the version of Web Interface firmware and EOC Driver. A screen is displayed as shown in Figure 4.3.7. Figure 4.3.7 Version Info Note: 1. Web interface version is also called firmware version, the NH-310H firmware extension file format is “dat”.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.3.8 SNMP Any Network Management running the simple Network Management Protocol (SNMP) can manage the switch, provided the Management Information Base (MIB) is installed correctly on the management station. The SNMP is a Protocol that governs the transfer of information between management and agent.
Page 30
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 1. Use this page to define management stations as trap managers and to enter SNMP community strings. User can also define a name, location, and contact person for the switch. Fill in the system options data, and then click Apply to update the changes on this page.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.4 Select ”LAN” Select “LAN”. The menu below includes the sub-menus of Settings, LAN Switch Port Setting , and LAN Port Status. A screen is displayed as shown in Figure 4.4.
4.4.1 LAN Settings The form below is used to change the IP address of the LAN (Local Area Network) port “adm0” in the NH-310H and the “adm0” IP address is the CPU IP address of NH-310H for PC to remote control the NH-310H with network management.
4.4.2 LAN Switch Port Setting The LAN Port Setting mode allows the user to specify the mode setting for the NH-310H. Users can choose 10Mb or 100 Mb modes for cases as “Force 10Mb Full”, ”Auto 10/100 Full/Half”, ”Force 10Mb Half”, ”Force 100Mb Half”, and “Force 100Mb Full”.
Figure 4.4.3 LAN Port Status For this example, the NH-310H EOC MDU managed Concentrator is connected to two NH-310S Bridges with Port 3 and Port 4.It appears Port3 Link Status Link Up, 100Mb/s, Full Duplex、Port4 Link Status Link Up, 100Mb/s, Full Duplex、...
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.5 Select ”ROUTE” Select the “ROUTE”. The menu below includes the sub-menus of Static Routing, and Routing Table List. A screen is displayed as shown in Figure 4.5. Figure 4.5 Select ”LAN” in the Entry Screen...
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.5.1 Static Routing To setup Static Routing, click on the “Static Routing” link in the left navigation bar. A screen is displayed as shown in Figure 4.5.1. Figure 4.5.1 Static Routing...
Page 37
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Notes: 1. Static Routing functionality is used to define the connected Gateway between the LAN and WAN. For example, if user would like to activate the Network Time Protocol (NTP) service, user have to define the Gateway connected to NTP server in the WAN.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.5.2 Routing Table List To view the Routing entry table list of NH-310H , click on the “Routing Table” link in the left navigation bar. A screen is displayed as shown in Figure 4.5.2.
List. A screen is displayed as shown in Figure 4.6. Figure 4.6 Select ”HPNA” in the Entry Screen Note: The “HPNA” can configure and manage NH-310H (Concentrator) and NH-310S (Bridge) HPNA functions, please refer to the Function Introduction as below.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.6.1 Device Info./Test This sub-menu for Device Info./Test appears the HPNA Device Information of the Numbers、Mode(Concentrator/bridge), MAC Address, Firmware Version , Spectrum for the Concentrator/bridge. It also includes Counter test for Concentrator and Net_Test, and Counter test for Bridges.
Page 41
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 The screen contains the following details: Mode Test Descriptions Concentrator Count Concentrator Read Packet Counter. User List End Point User List Table No. Refer to section 4.6.1.1 bridge Net_Test End Point Net Interface Test.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.6.1.1 Concentrator Read Packet Counter Click on “Count” button in the end of line for Concentrator and it appears the window which shows the MAC Address of the Concentrator. A screen is displayed as shown in Figure 4.6.1.1 and Figure...
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.6.1.2 End Point Net Interface Test Click on “Net_Test “ button in the line for each bridge and it appears the window which shows the MAC Address of the bridge. A...
Page 44
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Click on the “START” button, wait for some time you will see the Concentrator Read Packet Counter test results such as the example of Figure 4.6.1.2.2 below: Figure 4.6.1.2.2 Output of End Point Net Interface Test It shows the network information regarding the network test results for the SNR, the speed(rate), the receive power, transmitted packets, and the PER.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.6.1.3 End Point Read Packet Counter Click on “Count “ button in the line for each bridge and it appears the window which shows the MAC Address of the bridge.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.6.2 Device Control Select “Device Control”. The menu below includes the sub-menus of Numbers, Mode, MAC Address, and Spectrum for the Concentrator/bridge. The table also includes User List, Firmware driver Upgrade, Reboot and User Add for Bridges. A...
Page 47
1. EoC driver and web firmware is different, due to the Web firmware is control web UI management, the EoC driver is control NH-310H and NH-310S HPNA function. Please see the current driver version is “2.8.4”, such as the Figure 4.6.2.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.6.2.1 EOC driver Upgrade for Concentrator Click on “Upgrade” button in the line for Concentrator and it appears the window which shows the MAC Address, the New Version and Band Mode of the firmware which contains the EOC Concentrator driver for upgrading.
Page 49
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Click on the “Start” button, and it only takes short time to upgrade the driver. A screen is displayed as shown in Figure 4.6.2.1.2. Figure 4.6.2.1.2 Complete the EOC driver Upgrade for Concentrator...
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.6.2.2 HPNA driver Upgrade and user speed control for Bridges Click on “Upgrade“ button in the line for each bridge and it appears the window which shows the MAC Address and Enable/Disable Mode of the bridge.
Page 51
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Click on the “Start” button with the default Enable Mode and it only takes short time to upgrade the driver. Figure 4.6.2.2.2 Complete the HPNA driver Upgrade for Bridges...
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.6.2.3 Reboot for Bridges Click on the “Reboot“ button in the line for each one bridge and it appears the window which shows the MAC Address. A screen is displayed as shown in Figure 4.6.2.3.1.
Page 53
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Click on the “Start” button, and it only takes short time to reboot for each one Bridge. Figure 4.6.2.3.2 Reboot for Bridges is done...
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.6.2.4 Add User for Bridges Click the “Add“ button in the line for each bridge and it appears the window which shows the MAC Address and Number/Remark fields. The Remark field is convenient to apply for the User List information such as address and hotel room number…etc.
Page 55
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 For example, A screen is displayed as shown in Figure 4.6.2.4.2 (1) Fill No. as 1 (NO.1~ NO.60). (2) Remark: 9F, NO.208, TATUNG RD, SEC3,HSI CHIH, TAIPEI. (Max characters:60) (3) E1 Vlan ID:0...
Page 56
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 8. In order to comply with the MDU / MTU application, NH-310H/S is characterized by a bridged and can pass through any packets. In addition to, the security considerations, each of the NH-310S is independent.
Page 57
2. ISP ethernet switch VLAN ID 3→NH-310H→ NH-310S VLAN ID 4→ Reject access 3. 1 x NH-310S VLAN ID 3→NH-310H→ another NH-310S VLAN ID 3→ Reject access 4. A NH-310S VLAN ID 3 of Ethernet port 1 → NH-310S VLAN ID 4 of Ethernet port 2 → Both reject access...
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 4.6.3 User List Follow the example in 4.6.2.4 add a bridge, there are several information appears in User Information window. User can click the “Edit” button to modify each bridge or click the “Erase” button to delete each the bridge information. A screen is displayed as shown in Figure 4.6.3.1.
Page 59
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Figure 4.6.3.1 Erase the No. and click “Start” Figure 4.6.3.2 User Erase done...
Page 60
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Figure 4.6.3.3 Edit User Config of End Point Notes: 1. If user needs to change the settings in the User Information, please click on the “Edit” to change the configuration.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Chapter 5. Configure the NH-310H via Console 5.1 Setup on HyperTerminal Open the HyperTerminal and set the baud rate to 115200, 8N1N to properly set the HyperTerminal. A screen is displayed as shown in Figure 5.1.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 5.3 TFTP Protocol for firmware upgrade (1) Powered on and execute HyperTerminal, within three seconds press the <space> to enter Loader menu. You will see the boot Loader menu with the items of function selection. A screen is displayed as shown in Figure 5.3.1.
Page 63
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 (2) Execute the TFTP tool and specify current directory which is stored the NH-310H firmware. Enter the IP address of the TFTP server interface field.Now the TFTP server is ready for firmware upgrading. A screen is displayed as shown in Figure 5.3.2.
Page 64
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 (3) Please enter the number: “2” as set TFTP Client Download. A screen is displayed as shown in Figure 5.3.3. Figure 5.3.3 TFTP Client Download...
Page 65
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 (4)Please enter your option: “s” as set parameters, then enter TFTP Server IP and Remote File Name as the NH-310H firmware for upgrading. A screen is displayed as shown in Figure 5.3.4.
Page 66
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 (5) Enter your option: “D” and it will be beginning the TFTP download. After Erasing and Programming flash process, and NH-310H new firmware upgrade is completed. A screen is displayed as shown in Figure 5.3.5.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Appendix A: Cable Requirements A CAT 3, 4 or 5 UTP (unshielded twisted pair) cable is typically used to connect the Ethernet device to the device. A 10Base-T cable often consists of four pairs of wires, two of which are used for transmission. The connector at the end of the 10Base-T cable is referred to as an RJ-45 connector and it consists of eight pins.
Page 68
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Figure A-2 Pin Assignments and Wiring for an RJ-45 Straight-Through Cable Figure A-3 Pin Assignments and Wiring for an RJ-45 Crossover Cable...
Page 69
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Serial Console Interface Connector Pin Assignments The serial console interface connector is a 9-pin, RS-232 D-type, DTE connector. A null device cable is required to connect a workstation running the Linux or Windows operating system.
Compliant with IEEE802.3 10Base-T and IEEE802.3u 100Base-Tx standards • Compliant with IEEE802.3x Flow Control standard • Provide 4 x 10/100M auto-negotiation RJ-45 Ethernet ports with auto-MDI/MDIX(NH-310H only) • Provide 2 x 10/100M auto-negotiation RJ-45 Ethernet ports with auto-MDI/MDIX(NH-310S only) •...
Page 71
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Support auto logout , user list and each endpoint isolation • Guaranteed QoS based on HomePNA3.1 Parameterized QoS • Supports SNMP v1/v2 • EMI certified by CE and FCC, VCCI •...
Page 72
12MHz ~ 44MHz and coexist at 47MHz Spectrum: NH-310H: 173mm x 142mm x 30mm(Metal Case) (6.81" x 5.59" x 1.18”) (L x W x H) Dimension: NH-310S: 130mm x 94.5mm x 27mm (5.12” x 3.72“ x 1.06“) (L x W x H) Operating: 0ºC ~ 50ºC (32ºF ~ 122ºF)
The link is failed between NH-310H and NH-310S. The functionality of NH-310S is abnormal. Cause: The output level of voltage is too high for short connection. It must use the attenuator to be connected with MDU Concentrator NH-310H and End Point Solution: NH-310S to attenuate the transmission power level to -10dBm(5M-850MHz) at least.
Page 74
The TV port of Concentrator connect to HCNA port of Slave is not correct, It why can link establish the reason using a short cable, causing HPNA signal of NH-310S too strong and pass to HPNA port of NH-310H through TV port (50MHZ high pass filter build in) of NH-310H, so you can create a Answer: weak connection, but as long as extend coaxial over 350m length or plug a -20db attenuator, this link will be loss.
Page 75
TV, If the connection distance is too long lead to output of TV signal no signal or attenuation. 2. Please note NH-310H/S TV signal input power is unlimited, user does not need add the Notes: attenuator before NH-310H/S to weaken the TV signal source.
Page 76
10. Question: I forgot NH-310H password, what can I do ? If you forgot the NH-310H password, only use the console command line to reset system to default value. Please refer to the following steps for your reference: 1. Please connects NH-310H's console port to PC or laptop PC series port.
Page 77
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 System Diagnostics Power and Cooling Problems If the POWER indicator does not turn on when the power cord is plugged in, you may have a problem with the power outlet, power cord, or internal power supply as explained in the previous section. However, if the unit power is off after running for a while, check for loose power connections, power losses or surges at the power outlet, and verify that the fan on back of the unit is unobstructed and running prior to shutdown.
Page 78
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Physical Configuration If problems occur after altering the network configuration, restore the original connections, and try to track the problem down by implementing the new changes, one step at a time. Ensure that cable distances and other physical aspects of the installation that do not exceed recommendations.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Appendix D: Compliance and Safety Information FCC Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a computing device, pursuant to Part 15 subpart B of FCC class A rules.
Page 80
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 The telephone company may make changes in its facilities, equipment, operations or procedures that could affect the proper functioning of your equipment. If they do, you will be notified in advance in order for you to make necessary modifications to maintain uninterrupted service.
Page 81
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 FCC Warning This equipment has been tested to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Appendix E: Home Networking Installation Guide Caution: Please note this install guide only for construction unit to install the HPNA, general of home users do not need read this installation guide. And please note we do not provide the tools mentioned in this guide.
Page 83
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 E-2 Homeowner Site Survey Before beginning the installation, it is important to survey the installation site and plan the job. Meet With the Homeowner and Survey the Home Note the location of the main splitter and any secondary splitters. The main splitter usually connects to an outside coax cable.
Page 84
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 E-3 Pre-Install Inspection For the fastest and smoothest installation, address any wiring or connector problems before starting the installation. Inspect and Fix Wiring Inside and outside the house or residence, check every visible coax or telephone wire for cracks, nicks, splices, and/or other types of coating or shielding damage.
Page 85
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Check Environment and Wiring Integrity Remember to disconnect any devices that are directly connected to the coax network (not connected through an STB). Remove all unused coax cables and devices attached to coax wall outlets.
Page 86
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 AVOID THESE BAD CONDITIONS: B. Low dielectric – a gap between the dielectric and ridge will cause packet loss; dielectric should be flush with the ridge. C. Debris inside connector – for example, loose shielding strands wrapped around the stinger will cause 30dB attenuation.
Page 87
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 E-4 Install Hardware Now you are ready to install the Customer Premises Equipment. Disconnect the Existing Service Find the main splitter (where the service enters the house). If the RG is far away from the main splitter, create a splitter tree (see diagram on right).
Page 88
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Install the Residential Gateway and STBs (Set Top Box) Test the RJ-11 jack to ensure a good DSL signal (using a DSL tester). Plug the RG into the power outlet. Power up the RG, and let it synchronize with the DSL service. Verify the DSL rate on the RG.
Page 89
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 E-5 Complete Installation Verify that the entire home network is functioning correctly. Test and Verify the Home Network Run a long HomePNA test (20,000+ packets or more) with all devices connected. *See shaded box on right for instructions. As the test runs...
Page 90
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 A physical data rate => 96 Mb/sec (Reference Only) Tip: 1. Be sure to test and verify the home network; you will save future truck rolls. 2. Please note that the EOC actual data rate will vary on the coaxial cable attenuation and environmental factors.
Page 91
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 E-6 Troubleshoot & Repair If your HomePNA test passed but your TV service does not work properly. Check your DSL service or replace the RG and/or STB equipment. If your HomePNA test failed, follow these steps to pinpoint and fix the problem(s). After each step, re-run the HomePNA test; if the test still fails, continue to the next step.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Appendix F: MDU Installation Guide Caution: Please note this install guide only for construction unit to install the HPNA, general of home users do not need read this installation guide. And please note we do not provide the tools mentioned in this guide.
Page 93
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 F-2 NH-310H(Concentrator) Installation: Before beginning the installation, survey the installation site. Site Survey Determine the Concentrator’s location. Draw the connection tree (coax network map of the site). Attenuation (map) (depends on the number of splitters/taps and length of the coax cable).
Page 94
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Pre-Installation Inspection For the fastest and smoothest installation, address any wiring or connector problems if seen, before starting the installation. Inspect and replace damaged splitter and F-connectors. Check every coax connector, splitter, tap and amplifier (if exists). Look for missing components, damaged connectors, corrosion and/or other problems.
Page 96
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Verification of Concentrator Installation Connect your PC to the Concentrator using Ethernet cable, run section 4.6.1 Device Info./Test and check that the details of the Concentrator are listed. Still using the PC, open your Internet browser and check if you have Internet access (optional – might require password).
Page 97
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 F-3 NH-310S(End Point (bridge)) Installation: Before beginning the installation, it is important to survey the installation site. Apartment site survey If there was a prior MDU installation in the building, check to make sure that there is no HPF connected to the splitter of the specific apartment.
Page 98
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Pre-Install Inspection For the fastest and smoothest installation, address any wiring or connector problems before starting the installation. Inspect and replace damaged splitters and F-connectors. Check every coax connector and splitter. Look for missing components, damaged connectors, corrosion, and/or other problems.
Page 99
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Verification of bridge installation See the section on troubleshooting, if any problems are found. On Concentrator side Check if the Concentrator link LED is ON. Run the following tests using the PC: Device Info./Test(Refer to 4.6.1 Device Info./Test)
Page 100
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 If these tests don’t solve the problem, replace the bridge and retest. Problem 2: Net Interface Test failure Tighten all screws and check connectors/jacks/coax cable; replace if necessary. Test the Concentrator and bridge units back to back with 8dB attenuation. Rx power should receive atleast +8dBm.
Page 101
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Before leaving (Concentrator unit only) Rerun Device Info./Test and Net Interface Test and service tests (TV reception). These tests ensure the performance of the full MDU network. When running Device Info. / Test , make sure you see all units.
NH-310H/S HPNA3.1 EOC Managed Concentrator and Bridge USER’S MANUAL Ver.D1 Warranty The original owner that the product delivered in this package will be free from defects in material and workmanship for one year parts after purchase. There will be a minimal charge to replace consumable components, such as fuses, power transformers, and mechanical cooling devices.
