  • Page 1 ’ ’ ’...

  • Page 2: Copyright

    In the interest of improving internal design, operational function, and/or reliability, NETSYS reserves the right to make changes to the products described in this document without notice. NETSYS does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.

  • Page 3: Foreword: Vdsl Point To Point Solution

    IP DSLAMs over a fix speed and auto speed function. Therefore, NVF-400L/R supports auto speed and plug & play operations in the subscriber site to form an ideal solution for delivering cost effective, high performance broadband/multimedia services to Multi-Dwelling Units (MDU) and Multi-Tenant Units (MTU) environments such as hotels, campus, hospitals and telecom.

  • Page 4: Safety Warnings

    NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 Safety Warnings For your safety, be sure to read and follow all warning notices and instructions before using the device DO NOT open the device or unit. Opening or removing covers can expose you to dangerous high voltage points or other risks.

  • Page 5: Table Of Contents

    NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 Table of Contents Copyright ....................................1 Foreword: VDSL Point to Point Solution..........................2 Safety Warnings ..................................3 Table of Contents ..................................4 1.1 Check List ........................................5 Chapter 2.

  • Page 6: Check List

    NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 Chapter 1. Unpacking Information 1.1 Check List Carefully unpack the package and check its contents to compare to the checklist. Package Contents • 1 x VDSL 4-Band Bridge (NVF-400L or NVF-400R) •...

  • Page 7: Chapter 2. Installing The Bridge

    NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 Chapter 2. Installing the Bridge 2.1 Hardware Installation This chapter describes how to install the bridge and establishes network connections. You may install the bridge on any level surface (e.g.

  • Page 8: General Rules

    NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 2.3 General Rules Before making any connections to the bridge, note the following rules: • Ethernet Port (RJ-45) All network connections to the bridge Ethernet port must be made using Category 5 UTP for 100Mbps, Category 3, 4 UTP for 10Mbps.

  • Page 9: Connecting The Rj-11 / Rj-45 Ports

    NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 2.5 Connecting the RJ-11 / RJ-45 Ports 1. The bridge’s RJ-11 ports supports maximum distance up to 1.9km at 5M/5M or maximum speed at 25M/25M symmetrical with distances up to 800m data service across existing phone wiring without interfering with standard voice transmissions, it is easy to use and does not require the installation of any additional wiring.
  • Page 10 NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 2. NVF-400L/R bridge has embedded splitter between every VDSL side (Line) and POTS (Phone) side. It permits you to deliver broadband service on the same lines as Plain Old Telephone Service (POTS), PBX, ISDN traffic and VDSL Signal.

  • Page 11: Chapter 3. Hardware Description

    NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 Chapter 3. Hardware Description This section describes the important parts of the bridge. It features the front indicators and rear connectors. NVF-400 Outward 3.1 Front Panel The following figure shows the front panel.

  • Page 12: Front Indicators

    NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 3.2 Front Indicators The Bridge has EIGHT LED indicators. The following Table shows the description. (Table 3-1) Table 3-1 LED Indicators Description and Operation LEDs Color...

  • Page 13: Rear Panel

    NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 3.3 Rear Panel The following figure shows the rear connectors. (Figure 3.2) Figure 3.2 Rear connectors And the table shows the description. (Table 3-2) Table 3-2 Description of the bridge rear connectors...

  • Page 14: Chapter 4. Firmware Description

    Auto speed function description: NVF-400L/R is a 4 band VDSL solution which supports auto speed function and real plug & play. It can support 5M/15M/25M symmetrical data service but depends on installation environment and cable limit length. It can also do auto speed function while phone cable be re-plug in between NVF-400L and NVF-400R, or both be re-power on.

  • Page 15: Appendix A: Cable Requirements

    NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 Appendix A: Cable Requirements A.1 Ethernet Cable A CAT 3, 4 or 5 UTP (unshielded twisted pair) cable is typically used to connect the Ethernet device to the modem. A 10Base-T cable often consists of four pairs of wires, two of which are used for transmission.
  • Page 16 NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 Figure A-2 Pin Assignments and Wiring for an RJ-45 Straight-Through Cable Figure A-3 Pin Assignments and Wiring for an RJ-45 Crossover Cable...
  • Page 17 NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 A.2 Telephone wire Standard telephone wire of any gauge or type-flat, twisted or quad is used to connect the Modem to the telephone network. A telephone cable typically consists of three pairs of wires, one of which is used for transmission. The connector at the end of the telephone cable is called an RJ-11 connector and it consists of six pins.

  • Page 18: Appendix B: Product Specification

    NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 Appendix B: Product Specification Key Features & Benefits • Supports Universal Plug & Play(UPnP) • Compliant with IEEE802.3 10BASE-T and IEEE802.3u 100BASE-TX standard • Compliant with ETSI, ITU, ANSI standards •...
  • Page 19 NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 Product Specification IEEE802.3 standard Standard: IEEE802.3u standard Compliant with ETSI, ITU, ANSI standards 4 * RJ-45 10/100Mbps Ethernet port 1 * RJ-11 connector for EoVDSL Interface:...
  • Page 20 NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 184mm x 146mm x 40mm (7.2" x 5.74" x 1.57”) Dimensions: Weight: 0.78kg & 1.02kg (for metal case) Input: AC 85~240 volts/50~60Hz External Power Adapter Output: DC 12V/1A...

  • Page 21: Appendix C: 4 Band Vdsl Electrical Characteristics

    NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 Appendix C: 4 Band VDSL Electrical Characteristics Parameter Min. Typ. Max. Unit Transmit Spectrum Receive Transmit -61.5 dBm/Hz PSD Level Receive dBm/Hz Noise Margin Transmit 5Mbps Link Margin...

  • Page 22: Appendix D: Troubleshooting

    Solution: 2.5 Check the bridge on the attached device and cable connections for possible defects. 2.6 Make sure phone wire must be connected between NVF-400L and NVF-400R first, when both are powered on. 2.7 Replace the defective bridge or cable if necessary.
  • Page 23 3.1 Please make sure phone wire must be connected between NVF-400L and NVF-400R when both are power on. NVF-400L will do auto speed function depending on phone wire length, therefore if NVF-400L can’t detect NVF-400R over phone wire while both power on, this will Solution: cause the link to fail.
  • Page 24 NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 6. Symptom: VDSL line is at link margin. Cause: When the VDSL line is linking between 2 speeds at 5/15Mbps or 15/25Mbps. Fixed the speed to 5Mbps when it is linking between 5/15Mbps or fixed the speed to 15Mbps when it Solution: is linking between 15/25Mbps.
  • Page 25 NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 System Diagnostics Power and Cooling Problems If the POWER indicator does not turn on when the power cord is plugged in, you may have a problem with the power outlet, power cord or internal power supply as explained in the previous section.
  • Page 26 NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 Physical Configuration If problems occur after altering the network configuration, restore the original connections, and try to track the problem down by implementing the new changes, one step at a time. Ensure that cable distances and other physical aspects of the installation do not exceed recommendations.

  • Page 27: Appendix E: Compliance And Safety Information

    NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 Appendix E: Compliance and Safety Information FCC Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a computing device, pursuant to Part 15 of FCC rules.
  • Page 28 NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 proper functioning of your equipment. If they do, you will be notified in advance in order for you to make necessary modifications to maintain uninterrupted service.
  • Page 29 NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 FCC Warning This equipment has been tested to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 30: Warranty

    NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 Warranty The original owner that the product delivered in this package will be free from defects in material and workmanship for one year parts after purchase.

  • Page 31: Chinese Sj/T 11364-2006

    NVF-400L/R 4 Band VDSL CO/CPE Bridge with 4 Ports Switch USER’S MANUAL Ver. A.5 Chinese SJ/T 11364-2006 有 毒 有 害 物 质 或 元 素 部件名称 铅(Pb) 汞(Hg) 镉(Cd) 六价铬[Cr(VI)] 多溴联苯(PBB) 多溴二苯醚(PBDE) 结构壳体 ○ ○ ○ ○ ○ ○...
