- Page 1 MOBILITY MADE SIMPLE! Operating instructions NJ1 Adaptive bike Operating instructions Service booklet NJ1 Adaptive bike...
-
Page 2: Table Of Contents
Operating instructions NJ1 Adaptive bike Contents Preface ............................... 3 Legend ..............................3 CE Declaration of Conformity / other information ................3 Classification ..........................3 Declaration of Conformity ......................3 ... - Page 3 Operating instructions NJ1 Adaptive bike 16.5 Disc and rim brakes ........................15 16.6 Back-pedal brake for hub drives ....................16 16.7 PRO ACTIV back-pedal brake & crank release function ............16 16.7.1 Operation ........................
-
Page 4: Preface
Classification Congratulations on purchasing your new PRO ACTIV product. You have bought a quality The NJ1 adaptive bike (referred to as a "prod- product which has been especially customised uct" below) is classified as a class I product. to meet your requirements. -
Page 5: Introduction
Operating instructions NJ1 Adaptive bike Introduction are physically and mentally capable of safely operating the device in all operating situations and can meet the legal require- Before starting your journey, familiarise ments for use on public roads. yourself with these operating instructions pay- ing particular attention to the safety information and hazard warnings contained within them. -
Page 6: Technical Specifications
Operating instructions NJ1 Adaptive bike Commissioning The product is handed over to you ready to use by a PRO ACTIVE dealer. They will fit, if not already done, the required fastening ele- ments to your wheelchair to hold the adapter and, if required, any other accessories. -
Page 7: Safety Instructions - Prior To Driving / Use
Operating instructions NJ1 Adaptive bike 11 Safety instructions - Check tyre pressures at regular intervals. prior to driving / use Ensure that you comply with the manufac- turer's specifications which are fitted to the tyres. Tyre pressure which is too low has a... -
Page 8: Safety Instructions Regarding Obstacles
Operating instructions NJ1 Adaptive bike Do not attach objects (carrier bags, etc.) The product is only designed to be used to the product. These could prevent safe op- to transport persons with limited mobility and eration of the product while driving. -
Page 9: Safety Instructions Regarding Dangerous Locations And Dangerous Situations
Operating instructions NJ1 Adaptive bike Always drive over curbs or other obstacles When crossing main roads, intersections so that you cross them to the front or at right and level crossings, extreme caution is angles. If you drive at them on an angle, or needed. -
Page 10: Parking Stand Height Adjustment
Operating instructions NJ1 Adaptive bike 16.1.2 Parking stand height adjustment It is important to adjust the height of the park- ing stand to bring the adapter into the right position in relation to the product's docking plate. Height adjustment is made by loosening the M6 oval head screw (AF 4 mm) and adjust- ing the position of the adjustment inlet. -
Page 11: Pedal Bearing Position
Operating instructions NJ1 Adaptive bike Sporty drivers with the appropriate trunk A suitable restraint system must be used if stability relieve their arm musculature by mov- you have poor seating stability due to a lack of ing their trunk at the same time. The height of or weak core musculature. -
Page 12: Crank Length And Grip Width
Operating instructions NJ1 Adaptive bike Clamp screws on M6 fastening the pedal bearing screws on the pedal housing (height bearing adjustment) housing Figure 9: Fastening screws on the pedal bearing housing Fastening screws on the clamp (angle adjustment) If your product is fitted with an adjustable... -
Page 13: Grips
Operating instructions NJ1 Adaptive bike Pedal bearing shaft Hand grip rotary axle Crank length Crank han- Grip width dles Figure 11: Crank length and grip width Figure 13: Correct hold of the handle for the Rohloff 16.3 Grips hub drive... - Page 14 Operating instructions NJ1 Adaptive bike right: operation left: operation 3- 3-speed chain wheels 9-speed cassette speed chain wheels 9-speed cassette Thumb: Thumb: lower gear higher gear Index finger: Index finger: higher gear lower gear Figure 16: Shifting using the thumb / index finger...
-
Page 15: Hub Gears
Operating instructions NJ1 Adaptive bike Try to avoid selecting cross gears, as the efficiency and service life of the chain will fall Gear display significantly (more information can be found in chapter 26). For more information, please see the instruc- Gear changes tions provided by the gear manufacturer. -
Page 16: Pedal Bearing Gearshift
Operating instructions NJ1 Adaptive bike The pedal bearing gearshift should be lubri- Gear display cated once or twice a year with the supplied original semi-fluid grease using the syringe. The semi-fluid grease is filled through the slot- ted screw. Slotted screw... -
Page 17: Back-Pedal Brake For Hub Drives
Operating instructions NJ1 Adaptive bike 16.7 PRO ACTIV back-pedal brake & crank release function 16.7.1 Operation The PRO ACTIV back-pedal brake can be used for chain gears or hub drives with a free- wheel. The PRO ACTIV back-pedal brake is a closed... -
Page 18: Operation
Operating instructions NJ1 Adaptive bike At regular intervals, check that all of the connections, lines, bleed screws and the sur- face of the transmitter unit do not leak and that all the screw connections on the brake system are tightened securely. -
Page 19: Components
Operating instructions NJ1 Adaptive bike 16.9 Components If the product should be stored or not used for a long time, the device should be driven a You will be instructed about the functions and few metres forwards and backwards once a operation of the gears, brakes and other brand month to prevent the brakes seizing up. -
Page 20: Cleaning And Care
Operating instructions NJ1 Adaptive bike 20 Cleaning and care Repairs and conversions of the product may only be carried out by your dealer or PRO Regular cleaning of the product is prescribed ACTIV. to prevent the components becoming clogged Tightening torques and securing details for up due to dirt. -
Page 21: Proof Of Maintenance
Operating instructions NJ1 Adaptive bike Subsequent inspections are then always per- 22 Disposal formed after 1,000 kilometres running or after a At the end of the service life, the product can period of 1 year (whichever comes first). The be disposed of by PRO ACTIV or your dealer maintenance schedule can be found in the in a proper, environmentally-friendly manner. -
Page 22: Liability
Operating instructions NJ1 Adaptive bike 25 Liability As the manufacturer of the product, PRO AC- TIV is not responsible for its safety if: the product is handled improperly the product is not maintained in accor- dance with the maintenance schedule laid down by PRO ACTIV ... -
Page 23: Appendix: Avoiding Crossed Gears With The Chain Shift
Operating instructions NJ1 Adaptive bike 26 Appendix: Avoiding crossed gears with the chain shift from the large from the small from the middle from the large from the small chain wheel, you chain wheel, you chain wheel, you chain wheel, you... -
Page 24: Appendix: Tightening Torques And Securing Details
Operating instructions NJ1 Adaptive bike 27 Appendix: Tightening torques and securing details The following table shows the torques for shaft screws with a metric control thread (valid if the drawing or assembly instructions do not state different values!): Torque MA in Nm depending on how tight the screws are Dimension Stability 8.8... -
Page 25: Appendix: Medical Product Passport / Record Of Training
Operating instructions NJ1 Adaptive bike 28 Appendix: Medical product passport / record of training Product specifications: Serial number: Customer data: Surname, forename: Street: Postcode, city: Phone: Paying organisation: Trainingcarried out by: Medical supplies dealer PRO ACTIV representative Stamp / Date / Dealer's signature... -
Page 26: Appendix: Hand-Over Certificate
Operating instructions NJ1 Adaptive bike 29 Appendix: Hand-over certificate 29.1 Required compliance criteria to authorise use completed / Topics Remarks fulfilled The product is suitable for the customer based on their own judgement and the customer informa- tion received regarding the disability-related re- strictions. -
Page 27: Check List For Training The User
Operating instructions NJ1 Adaptive bike 29.2 Check list for training the user com- Topics pleted / fulfilled Advised of the applicable legal regulations when driving on public roads. All mechanical functional controls were explained and their function demonstrated. Adaptation of the adapter to the wheelchair and removing the adapter from the wheelchair was demonstrated and then performed by the user themselves and / or their assistant. -
Page 28: Appendix: Inspection Lists
Operating instructions NJ1 Adaptive bike 30 Appendix: Inspection lists Initial inspection: After 200 km or 5 months OK / not OK resolved Kilometre reading:___________________ carried out Check all screws / fastening elements are firmly seated Functional / safety check of all lights, steering, adaptation to the product and the adapted wheelchair / wheelchairs Check and if nec. - Page 29 Operating instructions NJ1 Adaptive bike Subsequent inspection: After a further 1000 km or 1 year after the last inspection or after heavy use OK / not OK resolved Kilometre reading:___________________ carried out Check all screws / fastening elements are firmly seated...
- Page 30 Operating instructions NJ1 Adaptive bike Subsequent inspection: After a further 1000 km or 1 year after the last inspection or after heavy use OK / not OK resolved Kilometre reading:___________________ carried out Check all screws / fastening elements are firmly seated...
- Page 31 Operating instructions NJ1 Adaptive bike Subsequent inspection: After a further 1000 km or 1 year after the last inspection or after heavy use OK / not OK resolved Kilometre reading:___________________ carried out Check all screws / fastening elements are firmly seated...
- Page 32 Operating instructions NJ1 Adaptive bike Subsequent inspection: After a further 1000 km or 1 year after the last inspection or after heavy use OK / not OK resolved Kilometre reading:___________________ carried out Check all screws / fastening elements are firmly seated...
- Page 33 Operating instructions NJ1 Adaptive bike Subsequent inspection: After a further 1000 km or 1 year after the last inspection or after heavy use OK / not OK resolved Kilometre reading:___________________ carried out Check all screws / fastening elements are firmly seated...
- Page 34 Operating instructions NJ1 Adaptive bike Subsequent inspection: After a further 1000 km or 1 year after the last inspection or after heavy use OK / not OK resolved Kilometre reading:___________________ carried out Check all screws / fastening elements are firmly seated...
- Page 35 Operating instructions NJ1 Adaptive bike Subsequent inspection: After a further 1000 km or 1 year after the last inspection or after heavy use OK / not OK resolved Kilometre reading:___________________ carried out Check all screws / fastening elements are firmly seated...
- Page 36 Operating instructions NJ1 Adaptive bike Your dealer: PRO ACTIV Reha-Technik GmbH Im Hofstätt 11 72359 Dotternhausen - Germany Tel. +49 7427 9480-0 Fax +49 7427 9480-7025 E-Mail: info@proactiv-gmbh.de www.proactiv-gmbh.com...
