UC-8410/8416/8418/8430
Hardware User's Manual
Fifth Edition, March, 2011
www.moxa.com/product
© 2010 Moxa Inc. All rights reserved.
Reproduction without permission is prohibited.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UC-8410 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Moxa Technologies UC-8410

Summary of Contents for Moxa Technologies UC-8410

  • Page 1 UC-8410/8416/8418/8430 Hardware User's Manual Fifth Edition, March, 2011 www.moxa.com/product © 2010 Moxa Inc. All rights reserved. Reproduction without permission is prohibited.

  • Page 2: Copyright Notice

    UC-8410/8416/8418/8430 Hardware User's Manual The software described in this manual is furnished under a license agreement and may be used only in accordance with the terms of that agreement. Copyright Notice Copyright ©2011 Moxa Inc. All rights reserved. Reproduction without permission is prohibited.

  • Page 3: Table Of Contents

    Table of Contents Introduction ............................1-1 Overview ............................1-2 Package Checklist ..........................1-2 Product Features ..........................1-2 Product Hardware Specifications ......................1-3 Appearance and Dimensions ......................2-1 Appearance ............................2-2 Dimensions ............................2-6 Hardware Block Diagrams ........................2-10 LED Indicators ..........................2-12 Reset Button ............................

  • Page 4: Introduction

    CompactFlash and USB ports for adding additional memory. All of these features make the UC-8410/8416/8418/8430 ideal for your embedded applications. Note, too, that the UC-8430 comes with 2 VGA outputs, offering dual display connections for field site monitoring.

  • Page 5: Overview

    2 USB ports (6 USB ports for UC-8430) for adding additional memory (such as a USB flash drive). The UC-8410/8416/8418/8430 uses an Intel XScale IXP435 533 MHz RISC CPU. Unlike the X86 CPU, which uses a CISC design, the IXP435's RISC design architecture and modern semiconductor technology provide the UC-8410/8416/8418/8430 with a powerful computing engine and communication functions, but without generating a lot of heat.

  • Page 6: Product Hardware Specifications

    UC-8410/8416/8418/8430 Hardware User's Manual Introduction Product Hardware Specifications Computer CPU: Intel XScale IXP435, 533 MHz OS (pre-installed): Linux or Windows CE 6.0 DRAM: 256 MB DDR2 SDRAM onboard (512 MB max.) SRAM: 256 KB, battery backup Flash: • NOR Flash onboard to store OS >...

  • Page 7: Physical Characteristics

    Housing: SECC sheet metal (1 mm) Weight: 1 kg Dimensions: UC-8410: 200 x 37 x 120 mm (7.87 x 1.46 x 4.72 in) UC-8416/8418: 200 x 57 x 120 mm (7.87 x 2.24 x 4.72 in) Mounting: DIN-Rail, wall Environmental Limits Operating Temperature: Standard Models: -10 to 60°C (14 to 140°F)
  • Page 8 UC-8410/8416/8418/8430 Hardware User's Manual Introduction Warranty Warranty Period: 5 years Details: See www.moxa.com/warranty Note: The Hardware Specifications apply to the embedded computer unit itself, but not to accessories. In particular, the wide temperature specification does not apply to accessories such as the power adaptor and...

  • Page 9: Appearance And Dimensions

    Appearance and Dimensions The following topics are covered in this chapter:  Appearance  Dimensions  Hardware Block Diagrams  LED Indicators  Reset Button  Real Time Clock...

  • Page 10: Appearance

    UC-8410/8416/8418/8430 Hardware User's Manual Appearance and Dimensions Appearance UC-8410 Rear View UC-8410 Top View UC-8410 Front View...
  • Page 11 UC-8410/8416/8418/8430 Hardware User's Manual Appearance and Dimensions UC-8416 Rear View UC-8416 Top View UC-8416 Front View...
  • Page 12 UC-8410/8416/8418/8430 Hardware User's Manual Appearance and Dimensions UC-8418 Rear View UC-8418 Top View UC-8418 Front View...
  • Page 13 UC-8410/8416/8418/8430 Hardware User's Manual Appearance and Dimensions UC-8430 Rear View UC-8430 Top View UC-8430 Front View...

  • Page 14: Dimensions

    UC-8410/8416/8418/8430 Hardware User's Manual Appearance and Dimensions Dimensions UC-8410 (Unit=mm)
  • Page 15 UC-8410/8416/8418/8430 Hardware User's Manual Appearance and Dimensions UC-8416 (Unit=mm)
  • Page 16 UC-8410/8416/8418/8430 Hardware User's Manual Appearance and Dimensions UC-8418 (Unit=mm)
  • Page 17 UC-8410/8416/8418/8430 Hardware User's Manual Appearance and Dimensions UC-8430 (Unit=mm)

  • Page 18: Hardware Block Diagrams

    UC-8410/8416/8418/8430 Hardware User's Manual Appearance and Dimensions Hardware Block Diagrams The following block diagram shows the layout of the UC-8410/8416/8418/8430’s internal components. UC-8410 UC-8416 2-10...
  • Page 19 UC-8410/8416/8418/8430 Hardware User's Manual Appearance and Dimensions UC-8418 UC-8430 2-11...

  • Page 20: Led Indicators

    UC-8410/8416/8418/8430 Hardware User's Manual Appearance and Dimensions LED Indicators The UC-8410/8416/8418/8430 has 14 LED indicators on the top panel. Refer to the following table for information about each LED. LED Name Color Meaning Power Green Power is on. No power input or any other power error.

  • Page 21: Mounting Options

    Mounting Options The following topics are covered in this chapter:  Wall or Cabinet Mounting  DIN-Rail Mounting...

  • Page 22: Wall Or Cabinet Mounting

    The two metal brackets that come standard with the UC-8410/8416/8418/8430 are used to attach the UC-8410/8416/8418/8430 to a wall or the inside of a cabinet. First, use two screws per bracket to attach the brackets to the bottom of the UC-8410/8416/8418/8430 (Fig. A). Next, use two screws per bracket to attach the UC-8410/8416/8418/8430 to a wall or cabinet (Fig.

  • Page 23: Hardware Connection Description

    Hardware Connection Description This section describes how to connect the UC-8410/8416/8418/8430 to serial devices for first time testing purposes. The following topics are covered in this chapter:  Wiring Requirements  Connecting the Power  Connecting to VGA Monitors (UC-8430 only) ...

  • Page 24: Wiring Requirements

    Where necessary, we strongly recommend that you label wiring to all devices in the system. Connecting the Power The UC-8410/8416/8418/8430 has a 3-pin terminal block for a 12 to 48 VDC power input. The following figures show how the power input interface connects to external power source. If the power is properly supplied, t the Ready LED will illuminate with a solid green color after 30 to 60 seconds have passed.

  • Page 25: Connecting To Vga Monitors (Uc-8430 Only)

    UC-8410/8416/8418/8430 Hardware User's Manual Hardware Connection Description SG: The Shielded Ground (sometimes called Protected Ground) contact is the right most contact of the 3-pin power terminal block connector when viewed from the angle shown here. Connect the SG wire to an appropriate grounded metal surface.

  • Page 26: Connecting To The Network

    Use properly wired serial cables to connect the UC-8410/8416/8418/8430 to serial devices. The UC-8410/8416/8418/8430’s serial ports (P1 to P8) use 8-pin RJ45 connectors. The ports can be configured by software for RS-232, RS-422, or 2-wire RS-485. The precise pin assignments are shown in the following table:...

  • Page 27: Connecting To A Can Device

    UC-8410/8416/8418/8430 Hardware User's Manual Hardware Connection Description Connecting to a CAN Device CAN Ports (UC-8418 only) The UC-8418 has 2 CAN ports for connecting CAN devices. The CAN ports (CAN1 and CAN2) use DB9 male connectors. The pin assignments are shown in the following table: –...

  • Page 28: Connecting To The Console Port

    UC-8410/8416/8418/8430 Hardware User's Manual Hardware Connection Description Connecting to the Console Port The UC-8410/8416/8418/8430’s console port is a 4-pin pin header RS-232 port. Refer to the following figure for console port cable pin assignments. Serial Console Port and Pinouts Serial Console Cable Signal The console port is located blow the CF card socket.

  • Page 29: Compactflash

    See the following description for CompactFlash card installation instructions. The CF cover is located on the back of the UC-8410/8416/8418/8430. Use a screwdriver to remove the cover and access the slot. See the following figure for the locations of the CF socket.

  • Page 30: Usb

    If you need device drivers for other kinds of mass storage cards, contact Moxa for information on how to initiate a cooperative development project. The UC-8410/8416/8418/8430 provides two or six USB 2.0 hosts. The USB hosts now support adding USB storage devices.

  • Page 31: Di/Do

    UC-8410/8416/8418/8430 Hardware User's Manual Hardware Connection Description DI/DO The UC-8410/8416/8430 have 4-ch digital outputs and 4-ch digital inputs, while the UC-8418 has 12-ch digital inputs and 12-ch digital outputs. The pinouts for the I/O are shown in the following figures: Digital Input Wiring...

  • Page 32: Regulatory Approval Statements

    Regulatory Approval Statements This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
