UC-8410/8416/8418
Hardware User's Manual
Second Edition, September 2009
www.moxa.com/product
© 2009 Moxa Inc. All rights reserved.
Reproduction without permission is prohibited.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UC-8410 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Moxa Technologies UC-8410

Summary of Contents for Moxa Technologies UC-8410

  • Page 1 UC-8410/8416/8418 Hardware User’s Manual Second Edition, September 2009 www.moxa.com/product © 2009 Moxa Inc. All rights reserved. Reproduction without permission is prohibited.

  • Page 2: Copyright Notice

    UC-8410/8416/8418 Hardware User’s Manual The hardware described in this manual is furnished under a license agreement and may be used only in accordance with the terms of that agreement. Copyright Notice Copyright © 2009 Moxa Inc. All rights reserved. Reproduction without permission is prohibited.

  • Page 3: Table Of Contents

    Chapter 4 Hardware Connection Description .............4-1 Wiring Requirements ....................... 4-2 Connecting the Power ......................4-2 Grounding the UC-8410/8416/8418 ..................4-3 Connecting to the Network ...................... 4-3 Connecting to a Serial Device....................4-4 Connecting to a CAN Device....................4-4 Connecting to the Console Port ....................4-5 CompactFlash ..........................

  • Page 4: Chapter 1 Introduction

    The UC-8410/8416/8418 feature 8 RS-232/422/485 serial ports, 3 10/100 Mbps Ethernet ports, digital input and digital output channels, switching ports, and CompactFlash and USB ports for adding additional memory. All of these features make the UC-8410/8416/8418 ideal for your embedded applications.

  • Page 5: Overview

    2 USB ports for adding additional memory (such as a USB flash drive). The UC-8410/8416/8418 uses an Intel XScale IXP435 533 MHz RISC CPU. Unlike the X86 CPU, which uses a CISC design, the IXP-425’s RISC design architecture and modern semiconductor technology provide the UC-8410/8416/8418 with a powerful computing engine and communication functions, but without generating a lot of heat.

  • Page 6: Product Hardware Specifications

    UC-8410/8416/8418 Hardware User’s Manual Introduction Product Hardware Specifications Computer CPU: Intel XScale IXP435 533 MHz OS (pre-installed): Linux DRAM: Onboard 256 MB DDR2 SDRAM, support DDR2 up to 512 MB Flash: Onboard 16 MB NOR Flash to store OS, suport up to 32 MB...
  • Page 7 UC-8410: 850 g UC-8416: 930 g UC-8418: 1 kg Dimensions: UC-8410: 200 x 36.5 x 120 mm (7.87 x 1.44 x 4.72 in) UC-8416/8418: 200 x 56.5 x 120 mm (7.87 x 2.20 x 4.72 in) Mounting: DIN-Rail, wall Environmental Limits...

  • Page 8: Appearance And Dimensions

    Appearance and Dimensions Chapter 2 The following topics are covered in this chapter: Appearance Dimensions Hardware Block Diagrams LED Indicators Reset Button Real Time Clock...

  • Page 9: Appearance

    UC-8410/8416/8418 Hardware User’s Manual Appearance and Dimensions Appearance UC-8410 Rear View LED Indicators (Power, SRAM Battery, Ready, Storage) DI Channel x 4 DO Channel x 4 Power Input 10/100 Mbps 12 to 48 VDC Ethernet x 3 UC-8410 Top View...
  • Page 10 UC-8410/8416/8418 Hardware User’s Manual Appearance and Dimensions UC-8416 Rear View 10/100 Mbps Ethernet Switch Port x 8 DI Channel x 4 LED Indicators Power Input 10/100 Mbps (Power, SRAM Battery, DO Channel x 4 12 to 48 VDC Ready, Storage)
  • Page 11 UC-8410/8416/8418 Hardware User’s Manual Appearance and Dimensions UC-8418 Rear View DI Channel x 8 DO Channels x 8 DI Channel x 4 LED Indicators 10/100 Mbps Power Input (Power, SRAM Battery, DO Channel x 4 12 to 48 VDC Ready, Storage)

  • Page 12: Dimensions

    UC-8410/8416/8418 Hardware User’s Manual Appearance and Dimensions Dimensions UC-8410 200 mm 45.3 mm (Unit=mm)
  • Page 13 UC-8410/8416/8418 Hardware User’s Manual Appearance and Dimensions UC-8416 (Unit=mm)
  • Page 14 UC-8410/8416/8418 Hardware User’s Manual Appearance and Dimensions UC-8418 (Unit=mm)

  • Page 15: Hardware Block Diagrams

    UC-8410/8416/8418 Hardware User’s Manual Appearance and Dimensions Hardware Block Diagrams The following block diagram shows the layout of the UC-8410/8416/8418’s internal components. UC-8410 Ethernet x 1 USB x 2 Ethernet x 2 LAN3 Console LAN2 LAN1 Power Hosts Ethernet CF Card...

  • Page 16: Led Indicators

    Decoder Moxa UART ASIC D/I x 4 D/O x 4 RS-232/422/485 x 8 LED Indicators The UC-8410/8416/8418 has 14 LED indicators on the top panel. Refer to the following table for information about each LED. LED Name Color Meaning Green Power is on.

  • Page 17: Reset Button

    ROM. Real Time Clock The UC-8410/8416/8418’s real time clock is powered by a lithium battery. We strongly recommend that you do not replace the lithium battery without help from a qualified Moxa support engineer. If you need to change the battery, contact the Moxa RMA service team.

  • Page 18: Chapter 3 Mounting Options

    Mounting Options Chapter 3 The following topics are covered in this chapter: Wall or Cabinet Mounting DIN-Rail Mounting...

  • Page 19: Wall Or Cabinet Mounting

    The two metal brackets that come standard with the UC-8410/8416/8418 are used to attach the UC-8410/8416/8418 to a wall or the inside of a cabinet. First, use two screws per bracket to attach the brackets to the bottom of the UC-8410/8416/8418 (Fig. A). Next, use two screws per bracket to attach the UC-8410/8416/8418 to a wall or cabinet (Fig.

  • Page 20: Din-Rail Mounting

    DIN-Rail Mounting An aluminum DIN-Rail attachment plate is included with the product. If you need to reattach the DIN-Rail attachment plate to the UC-8410/8416/8418, make sure the stiff metal spring is situated towards the top, as shown in the following figures.

  • Page 21: Hardware Connection Description

    Hardware Connection Description Chapter 4 This section describes how to connect the UC-8410/8416/8418 to serial devices for first time testing purposes. The following topics are covered in this chapter: Wiring Requ irements Connecting the Power Grounding the UC-841 0/8416/8418 Connecting to the Netw...

  • Page 22: Wiring Requirements

    Where necessary, we strongly recommend that you label wiring to all devices in the system. Connecting the Power The UC-8410/8416/8418 has a 3-pin terminal block for a 12 to 48 VDC power input. The following figures show how the power input interface connects to external power source. If the power is properly supplied, t the Ready LED will illuminate with a solid green color after 30 to 60 seconds have passed.

  • Page 23: Grounding The Uc-8410/8416/8418

    Connecting to the Network Connect one end of the Ethernet cable to one of the UC-8410/8416/8418’s 10/100M Ethernet ports (8-pin RJ45) and the other end of the cable to the Ethernet network. If the cable is properly...

  • Page 24: Connecting To A Serial Device

    Use properly wired serial cables to connect the UC-8410/8416/8418 to serial devices. The UC-8410/8416/8418’s serial ports (P1 to P8) use 8-pin RJ45 connectors. The ports can be configured by software for RS-232, RS-422, or 2-wire RS-485. The precise pin assignments are...

  • Page 25: Connecting To The Console Port

    UC-8410/8416/8418 Hardware User’s Manual Hardware Connection Description Connecting to the Console Port The UC-8410/8416/8418’s console port is a 4-pin pin header RS-232 port. Refer to the following figure for console port cable pin assignments. Serial console Port&Pinouts Serial Console Cable Signal The console port is located blow the CF card socket.

  • Page 26: Compactflash

    See the following description for CompactFlash card installation instructions. The CF cover is located on the back of the UC-8410/8416/8418. Use a screwdriver to remove the cover and access the slot. See the following figure for the locations of the CF socket.

  • Page 27: Usb

    The UC-8410/8416/8418 provides two USB 2.0 hosts. The USB hosts now support adding USB storage devices. DI/DO The UC-8410 and UC-8416 have 4-ch digital outputs and 4-ch digital inputs, while the UC-8418 has 12-ch digital inputs and 12-ch digital outputs. The pinouts for the I/O are shown in the following figures:...

  • Page 28: Digital Output Wiring

    UC-8410/8416/8418 Hardware User’s Manual Hardware Connection Description Wet Contact Note: If are using wet contacts, you must connect “COM” to power. Digital Output Wiring...

  • Page 29: Appendix A Regulatory Approval Statements

    Regulatory Approval Statements Appendix A This device compli es with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
