Fora D40 Owner's Manual page 10

TEST SLOT
1
Insert test strip here to turn the
monitor on for testing.
DISPLAY SCREEN
2
RF BUTTON
3
D40g)
Assists you with wireless data
transmission.
AVERAGE BUTTON
D40a)
Assists you with blood pressure
average mode.
S BUTTON
4
Enter and confirm the monitor
settings.
M BUTTON
5
Enter the monitor memory.
ON/OFF BUTTON
6
To start a single blood pressure
measurement.
USER SELECTION BUTTON
7
Assist you with user number
selection.
SPEAKER
8
RF INDICATOR
9
Indicates a wireless data trans-
mission.
10
(For FORA D40b and
(For FORA
USB INDICATOR
10
Indicates when a USB cable
plug inserted.
POWER INDICATOR
11
Indicates the power status of
the device.
BATTERY COMPART-
12
MENT
AC/DC ADAPTER PORT
13
Connect to a power supply.
USB LINK PORT
14
Download test results with a
cable connection.
STRIP EJECTOR
15
Eject the used strip by push-
ing up this button.
AIR JACK
16
PRESSURE CUFF
17
AIR TUBE
18
AIR PLUG
19
Connect to air jack.
