Summary of Contents for Orion SC106

  • Page 1 PROFESSIONAL PROFESSIONAL SuRvEILLANcE SYSTEM SuRvEILLANcE SYSTEM WIDE ANGLE SC106 DOME cAMERA HIGH DEFINITION 600 TvL ccD cOLOuR cAMERA DELIVERING HIGH QUALITY VIDEO WITH ACCURATE COLOUR RENDITION WIDE ANGLE 360˚ WEATHER ADJuSTMENT & vANDAL 3.6mm LENS FOR WIDE 70º RESISTANT VIEW COVERAGE...
  • Page 2 Figure 1. video/power cable. Figure 1. 2. Connect the other end of the 18 metre video/power cable (BNC video connector) to the BNC video input on DVR rear panel. Figure 2. Figure 2. VANDAL PROOF WIDE ANGLE Dome CAmeRA SC106...
  • Page 3 HEX key, unscrew the white cover. 2. Gently press the black camera case downward to adjust the camera into desired location. 3. 360º horizontal axis and 170° vertical axis rotation of the camera is available. 170° 360° 360° VANDAL PROOF WIDE ANGLE Dome CAmeRA SC106...
  • Page 4 Power supply DC 12V 500mA under an eaVe. indoor/outdoor Indoor and Outdoor iP rating IP44 dimensions 92(L) x 92(W) x 60(H)mm Weight 500g operate temperature -5°C ˜ 50°C operating Humidity 10% ˜ 85% VANDAL PROOF WIDE ANGLE Dome CAmeRA SC106...
  • Page 5 When ir night vision is Infra-red LED light is activated This is normal, no action activated, screen only required. displays black and white VANDAL PROOF WIDE ANGLE DOME cAMERA SC106...
  • Page 6 PROFESSIONAL SuRvEILLANcE SYSTEM 7 WaRRaNTy Arlec guarantees this product in accordance with the Australian Consumer Law. The Warranty is in addition to other rights and remedies you may have under a law in relation to the product to which the Warranty relates. Arlec also warrants to the original first purchaser of this product (“you”) from a retailer that this product will be free of defects in materials and Our goods come with guarantees that cannot be excluded under the...
