2.3 Panel explanation

2.3.1 Front Panel Function Explanations
LCD Display
Green LED lights up to indicate the UPS has the capability to run under redundancy mode.
Green LED steadily lights up to indicate that the Utility input voltage is within the window; the LED flashes
flickeringly to indicate that the Utility input voltage is within the acceptable window.
Green LED lights up to indicate Bypass Input is normal.
UPS ON/Alarm Silence
Go to previous page or change the setting of the UPS.
To re-confirm the change of UPS Setting
Go to next page
UPS OFF Switch
Special functions log in/out
UPS is working under ECO(Economic) mode.
UPS Fault or Abnormal
