HLNA0188
LENGTH
235mm (9.25in)
WIDTH
172mm (6.8in)
HEIGHT
81mm (3.2in)
WHEELBASE
159mm (6.3in)
WHEEL DIAMETER
42mm (1.65in) X 23mm (0.91in)
TIRE DIAMETER
60mm (2.36in)
WEIGHT*
540g (1.2lb)
BATTERY
1,100mAh NiMH 6-CELL, 7.2v
MOTOR
370 SIZE
RADIO
2.4GHz 2-CHANNEL
CHARGER
AC WALL TRICKLE
*APPROXIMATE OUT-OF-THE-BOX WEIGHT
• Entire contents ©2011 Helion RC
• Before using your product, review all documentation and inspect the products carefully. If for some reason
you decide it is not what you wanted, then do not continue with unpacking, setup or operation of your
product. Your local HobbyTown USA® dealer cannot accept a product for return or exchange after partaking
in the afore mentioned actions
• Read and understand and follow all instructions and accompanying material carefully before operating or
assembling your vehicle to prevent serious damage to your vehicle. Failure to complete these tasks properly
or intentional aversion to the content will be considered abuse and/or neglect
• Product specifications are subject to change without notice. Due to ongoing development, the actual prod-
uct may vary from images shown
• This product contains chemicals known to the State of California to cause cancer and birth defects or other
reproductive harm
• This product is not a toy! (14+) Recommended for ages 14 and up. Adult supervision required for ages under
18 years old. Contains small parts, keep out of reach of children 3 years of age and younger
OWNER'S MANUAL AND EXPLODED VIEW
1/18th SCALE 4x4
ELECTRIC TRUGGY
Advertisement
Table of Contents
Related Manuals for Helion HLNA0188
Summary of Contents for Helion HLNA0188
- Page 1 1/18th SCALE 4x4 ELECTRIC TRUGGY HLNA0188 OWNER’S MANUAL AND EXPLODED VIEW LENGTH 235mm (9.25in) WIDTH 172mm (6.8in) HEIGHT 81mm (3.2in) WHEELBASE 159mm (6.3in) WHEEL DIAMETER 42mm (1.65in) X 23mm (0.91in) TIRE DIAMETER 60mm (2.36in) WEIGHT* 540g (1.2lb) BATTERY 1,100mAh NiMH 6-CELL, 7.2v MOTOR 370 SIZE RADIO 2.4GHz 2-CHANNEL CHARGER AC WALL TRICKLE *APPROXIMATE OUT-OF-THE-BOX WEIGHT • Entire contents ©2011 Helion RC • Before using your product, review all documentation and inspect the products carefully. If for some reason you decide it is not what you wanted, then do not continue with unpacking, setup or operation of your product. Your local HobbyTown USA® dealer cannot accept a product for return or exchange after partaking in the afore mentioned actions • Read and understand and follow all instructions and accompanying material carefully before operating or...
-
Page 2: Package Contents
RECOMMENDED TOOLS (NOT INCLUDED)... • Please use caution and follow the manufacturer’s recommended operating instructions for these items and always wear eye protection METRIC HEX SCREWDRIVER SET HOBBY KNIFE SCREWDRIVERS CURVED HOBBY SCISSORS SIDE CUTTING PLIERS NEEDLE NOSE PLIERS BODY REAMER CA GLUE THE ANIMUS 18TR... SERVO ON/OFF MOTOR MOTOR PLUG ESC/ ANTENNA RECEIVER MOUNT ANTENNA BATTERY... -
Page 3: Getting Started
1/18th SCALE 4x4 ELECTRIC TRUGGY GETTING STARTED... 1. Carefully remove the box contents using side cutting pliers to cut the tie straps 2. Remove body and battery battery from vehicle to prepare for charging a. Read charging instructions and understand all warnings and cautions before proceeding. This product is not a toy and should not be charged, operated, or maintained without supervision of an adult b. Return to this guide in the presence of the charging battery, remembering never to leave the bat- tery unattended while charging 3. Install antenna tube by sliding antenna into tube and inserting tube into mount on receiver. Be careful not to pinch the antenna during installation. Install set screw vertically next to the antenna with included L wrench to secure the antenna in place. NOTE: Do NOT fold end of antenna over end of tube, this will reduce the range of the radio system and can cause interference when operating your vehicle 4. Install the [8] AA type alkaline batteries into the transmitter 5. Install the fully charged battery into the vehicle, be sure to install the pins into the lower of the two holes in the battery mounting posts 6. Ensure the motor is plugged into the ESC... -
Page 4: Features/Batteries
UNDERSTANDING YOUR TRANSMITTER... Features: 1. Steering wheel: controls left/right motion (designed to be operated with right hand) 2. Throttle trigger: controls forward/reverse motion (designed to be operated with left index finger) 3. Handle: For holding the transmitter (designed to be held with left hand) 4. Antenna: Transmits signal to the receiver located in the vehicle 5. Control panel cover: Covers control panel housing radio setting controls 6. ON/OFF Switch: Turns the power ON/OFF for the transmitter 7. Indicator lights: Multifunction Green LED a. Solid Green: Adequate battery voltage for proper operation b. Flashing Green: Low battery voltage warning, batteries should be replaced/recharged before continued use 8. Bind button: Used for binding the transmitter to the receiver 9. Steering Trim: Controls the “hands-off” left/right direction of the vehicle 10. Throttle Trim: Adjusts the motor speed to STOP when trigger is in “hands-off” (neutral) position 11. Battery compartment: houses [8] AA batteries for powering the transmitter 12. Bottom cover: Closes the battery compartment, containing the AA batteries Batteries: WARNING: Do not attempt to charge non-rechargeable batteries • Remove the lower door from the transmitter to access the battery compartment • Install 8x AA type batteries into the compartment ›... - Page 5 1/18th SCALE 4x4 ELECTRIC TRUGGY ...TRANSMITTER CONTINUED... Standard operation: • Turning the transmitter wheel to the left from center makes the wheels on the vehicle turn LEFT • Turning the transmitter wheel to the right from center makes the wheels on the vehicle turn RIGHT • Pulling the transmitter trigger back towards the handle will make the vehicle accelerate forward • Pushing the transmitter trigger forward away from the handle will have the following affects depending on the location of the trigger prior to pushing it forward › From a stop at neutral: the vehicle will travel in reverse › From pulled back: the vehicle will apply brakes to slow the speed » A second push forward of the trigger will apply reverse throttle » WARNING: Causing the vehicle to make quick transitions from forward/reverse motion to the opposite direction using the throttle control can cause damage to your vehicle and will void the warranty Using your transmitter for the first time: 1. Turn the transmitter ON and ensure the LED is lit SOLID indicating the batteries are supplying adequate...
- Page 6 Setting your ERS unit’s ESC: Properly setting the ESC to the transmitter ensures the ESC “knows” when you are trying to apply full throttle or full brake/reverse. NOTE: It is best to perform this procedure with all batteries fully charged 1. With throttle trigger in neutral position, press the Bind/Set button for 3 seconds until LED flashes 2. Without touching the throttle trigger, leave in neutral position, press the Bind/Set button once quickly 3. With throttle trigger in full throttle posiiton, press the Bind/Set button once quickly 4. With the throttle trigger set in full brake position, press the bind/set button once quickly 5. Your ESC is now set, turn off the power to your vehicle and turn it back on 6. Your ESC is now set to your transmitter. Always re-perform this procedure after binding your radio ADJUSTMENTS AND TUNING... The Animus 18TR has been engineered with some available tuning options listed here for reference. Ride height adjustment: It is possible to adjust the ride height of your Animus 18TR by installing and or removing adjustment clips located directly above the shock springs • Adding more clips will raise the ride height of the vehicle and if done excessively may decrease stability. • Removing clips will lower the ride height and may cause the chassis to drag on the ground. • It is ideal to have the drive shafts level with the ground while the vehicle is sitting on a flat surface with the body installed. Add or remove clips to achieve the desired ride height Shock Position: There are two shock installation locations for the top mounting location of the shocks. The default position is inside (located closer to the centerline of the chassis) • Moving the shock mounting location to the outer location will result in a slightly more responsive feel on the front or rear of the vehicle • Always check and adjust, if necessary, the ride height of your vehicle after moving the shock mounting locations Battery position: It is possible to run your Animus 18TR with the battery either in a forward or rear position.
- Page 7 1/18th SCALE 4x4 ELECTRIC TRUGGY ADJUSTMENTS AND TUNING CONTINUED... • If you desire more responsive steering and less stability, moving the battery to the forward position will provide this feeling Body Mount Height: The body mounts on the Animus 18TR are capable of vertical adjustment with 4 height options available • The default setting allows for the lowest body position while maintaining component clearance • Adjust the body mounts to achieve a desired look SAFETY TIPS... Although great for first time users, Helion RC products are indeed advanced radio controlled vehicles with sensitive electronics and moving parts capable of causing injury if used improperly. Always use caution and common sense as failure to operate your Helion RC product in a safe and responsible manner can result in damage to the product or other properties. Therefore this product is not intended for use or maintenance by children without direct adult supervision. Helion RC and HobbyTown USA® shall not be liable for any loss or damages, whether direct, indirect, special, incidental, or consequential, arising from the use, misuse, or abuse of this product or any product required to operate or maintain it • Do not operate your vehicle in rain, electrical, or thunder storms • The vehicle should never be turned ON without the transmitter being turned ON • Never operate your vehicle when with low transmitter batteries › Indicated by flashing LED on the transmitter • Always check for proper radio system operation (steering and throttle) prior to letting go of the vehicle. If the vehicle does not respond properly to transmitter input, turn the vehicle OFF and inspect all connec- tions and operating environment. Also see the Troubleshooting guide in this manual...
-
Page 8: Care And Maintenance
CARE AND MAINTENANCE... General Care: • Always use clean, dry cloth or soft bristle brush to clean your equipment • Never use chemical cleansers to avoid damage to the sensitive electronics and plastics Maintenance: We want you to enjoy your product to its fullest potential. For this to happen it is important to keep your product clean and properly maintained. Lack of cleaning and maintenance can cause component failure. For best and continued performance from your product it is recommended to briefly inspect your product for damage every few runs. Typically, a good time to do this is when changing the battery or while it is charging. If a problem is discovered, stop use immediately and seek repairs. Continued use of failed components can cause more unnecessary damage to your product. Always remember to use genuine replacement parts from your local HobbyTown USA® dealer. Below is a list of items for inspection. Inspection should not be limited to this list; if you notice any problem, listed or not, it is recommended to give it proper attention 1. Electronics: The electronics included in your vehicle are not waterproof. It is critical that they be kept away from moisture and that any moisture noticed on or around them be immediately cleaned up a. Antenna: To achieve full operating range with your radio system, it is critical that the receiver antenna be installed properly and undamaged Inspect any exposed antenna for cuts or abrasions ii. Ensure there are no kinks in the antenna or antenna tube iii. Never fold the end of the antenna over the tube, this will reduce the range and damage the antenna 2. Gears: Periodically remove the gear cover to inspect the gears and ensure there is no debris in the gear compartment a. Proper gear mesh setting is crucial for proper operation and life of gears in your product. It is important to have the pinion gear (attached to motor) as close to the spur gear (attached to drive shaft) as possible yet while providing a minimal amount of backlash. Backlash is the rotation one gear has to make before contacting the other. Having the gear mesh set too tight will cause excess load on the electrical components and may cause premature failure. Having gear mesh set too loose will cause excess wear and possible skipping of teeth during operation thus causing excess wear and premature failure b. Checking the gear mesh Remove the spur gear cover... - Page 9 1/18th SCALE 4x4 ELECTRIC TRUGGY ...MAINTENANCE CONTINUED... 3. Shocks: Periodically inspect the shocks for smooth/free motion, leaking oil and dirt residue build up around the shaft a. Do not allow dirt to build up around the shock shaft and bottom of the shock. Doing so will reduce the life of the shock and cause a shock to leak oil. Be sure to clean the shocks regularly with a clean and dry soft bristle brush and/or rag b. Signs to look out for determining if your shock needs to be maintained or rebuilt Oil around the shaft means the oil leaked from inside and needs to be replaced ii. Persistent oil around the shock shaft or lower portion of the shock typically points to dam- aged O-rings which will need replacing. See your local HobbyTown USA® for replacement parts iii. Refilling your shocks: 01). Remove shock from vehicle, remove spring and top cap 02). With shock shaft extended, add oil to top of body (use only 100% silicone oil) 03). Slowly compress the shock shaft 50% of travel using a towel or paper napkin to clean up overflowed oil 04). Slowly reinstall the shock cap and check for free motion of shock 05). It is normal for the shock to rebound (with the spring removed) after full compression and release iv. Replacing the O-rings: 01). Disassemble shock and remove shaft from the body 02). Carefully remove lower cap by prying with a finger nail or similar object 03). Remove the O-rings and replace with genuine replacement parts 04). Re-assemble the shock following the Refilling instructions above 4. Tires and wheels: a. Inspect the tires to ensure they are properly glued to the wheels. The tires on your vehicle come pre-glued from the factory; however after running your vehicle it is possible for the glue to come loose in some areas.
-
Page 10: Troubleshooting Guide
STORAGE AND DISPOSAL... Storage: • Always store all equipment in a cool dry place when not in use • Always disconnect the batteries before storage • Never store the battery, vehicle or transmitter in direct sunlight for extended periods of time • Never store the transmitter with batteries installed for extended periods of time. Doing so may allow the batteries to leak and cause permanent damage to the transmitter Disposal: Your product is equipped with NiMH batteries which are considered electronic waste and should never be discarded in standard garbage containers. Please visit your local HobbyTown USA® dealer and use the FREE battery disposal center for proper disposal/recycling TROUBLESHOOTING GUIDE... Problem / Symptom Possible Cause Possible Solution Battery voltage too low Charge battery Vehicle will not turn on Battery not connected Re/connect battery Damaged battery Replace battery Battery voltage too low Charge or change batteries Transmitter will not turn on Battery/ies installed improperly Correct installation Check receiver antenna for damage. Ensure Damaged or improperly installed antenna is properly installed in tube and Short radio range (Ve-... -
Page 11: Spare Parts List
1/18th SCALE 4x4 ELECTRIC TRUGGY SPARE PARTS LIST... HLNA0038..ANIMUS 18TR 4X4 ELECTRIC TRUGGY ..................HLNA0002..MAIN CHASSIS (ANIMUS) ......................HLNA0003..TOP PLATE, BATTERY STRAP, FOAM & POSTS (ANIMUS) ............HLNA0004..GEAR COVERS, GEAR BOXES (ANIMUS) ..................HLNA0005..FRONT & REAR SUSPENSION ARMS (ANIMUS) ................. HLNA0006..FRONT & REAR SHOCK TOWERS (ANIMUS) ................HLNA0007..CASTER & STEERING BLOCKS, REAR HUBS (ANIMUS)............... HLNA0008..STEERING BELL CRANKS & SERVO SAVER (ANIMUS) ..............HLNA0009..DRIVE SHAFTS FRONT/REAR & CENTER (ANIMUS) ..............HLNA0010..MOTOR MOUNT & INSERT (ANIMUS) ..................HLNA0011..CAMBER, STEERING & SERVO LINKS WITH BALL STUDS (ANIMUS) .......... HLNA0012..FRONT & REAR SHOCK SET WITH BALL STUDS (ANIMUS) ............HLNA0013..SHOCK SEALS (ANIMUS) ......................HLNA0014..SHOCK SPRINGS (ANIMUS)......................HLNA0015..HINGE PINS AND WASHERS (ANIMUS) ..................HLNA0016..DIFFERENTIAL OUTDRIVES & AXLES (ANIMUS) ................ HLNA0017..DRIVE PINS, WHEEL HEXES, BODY CLIPS, ANTENNA TUBES (ANIMUS) ........HLNA0018..AXLE BEARING SET (ANIMUS) .................... - Page 12 ...ANIMUS 18TR HLNA0050 HLNA0027 HLNA0008 HLNA0029 HLNA0043 HLNA0044 HLNA0006 HLNA0011 HLNA0009 HLNA0008 HLNA0044 HLNA0005 HLNA0012 HLNA0011 HLNA0015 HLNA0009 HLNA0015 HLNA0007 HLNA0002 HLNA0017 HLNA0003 HLNA0043...
-
Page 13: Exploded View
1/18th SCALE 4x4 ELECTRIC TRUGGY EXPLODED VIEW... HLNA0010 HLNA0021 HLNA0004 HLNA0003 HLNA0044 HLNA0006 HLNA0009 HLNA0019 HLNA0019 HLNA0020 HLNA0019 HLNA0044 HLNA0012 HLNA0011 HLNA0015 HLNA0022 HLNA0005 HLNA0015 HLNA0015 HLNA0028 HLNA0019 HLNA0016 HLNA0007 HLNA0018 HLNA0017... - Page 14 SHOCKS EXPLODED VIEW... HLNA0013 HLNA0012 HLNA0014 DIFFERENTIAL EXPLODED VIEW... HLNA0022 HLNA0016 HLNA0019 HLNA0026 HLNA0019 HLNA0016 HLNA0022...
-
Page 15: Declaration Of Conformity
1/18th SCALE 4x4 ELECTRIC TRUGGY DECLARATION OF CONFORMITY... Declaration of Conformity (DOC) Hereby, the manufacturer declares that this product is in compliance with the essential requirements and other relevant provisions of Directives. The declaration of conformity may be consulted at www.helionrc.com Intended Use The remote control is designed exclusively for private use in model construction. The remote control is not for industrial use, e.g. to control machines and equipment, determined. Any use other than as described above, can lead to damage of the product, and beyond this, with the associated risks, such as short circuit, fire, electric shock, etc.. Contact with water must be avoided! The remote control must not technically be changed or rebuilt! The safety precautions are essential to follow! You as a user are solely responsible for the safe operation of your remote control and your model! Disclaimer As compliance with the instructions, the operations and conditions when using the device at no time can be monitored by the manufacturer; the manufacturer assumes no liability for damages, costs and / or losses arising from incorrect use and / or incorrect operation or in any way connected. Disposal Electronic products are raw materials and do not belong in the trash. If the device is at the end of its useful life, dispose the device in accordance with applicable statutory regulations at the municipal collection points. Disposing of household waste is prohibited. NOTES... - Page 16 1/18th SCALE 4x4 ELECTRIC TRUGGY 0678 • ©2011 Helion RC • Technical specifications, features and design are subject to change. • Distribution: Robitronic Electronic GmbH +43 1 982 09 20 www.robitronic.com HLNA0045 [REV A]...
