Helion Criterion HLNA0302 Owner's Manual

HLNA0302
OWNER'S MANUAL AND EXPLODED VIEWS
LENGTH 386.40mm (15.21in)
WIDTH 249mm (9.80in)
HEIGHT 153.15mm (6.03in)
WHEELBASE 283mm (11.14in)
WHEEL DIAMETER 55.88mm (2.2in)
WHEEL OFFSET 12mm Hex, AE/KYO Compatible
WEIGHT* 1560g (3.44lb)
BATTERY 3,000mAh NiMH 7-CELL, 8.4V
MOTOR Metric 12T High Speed, 540 Size
RADIO HRS-3.1 2.4GHz 3-CHANNEL
CHARGER AC 1Amp
*APPROXIMATE OUT-OF-THE-BOX WEIGHT
• Entire contents ©2013 Helion RC
• Before using your product, review all documentation and inspect the products carefully. If for some reason you decide it is not
what you wanted, then do not continue with unpacking, setup or operation of your product. Your local hobby dealer cannot ac-
cept a product for return or exchange after partaking in actions that produce wear and tear.
• Read, understand and follow all instructions and accompanying material carefully before operating or assembling your vehicle
to prevent serious damage to your vehicle. Failure to complete these tasks properly or intentional aversion to the content will be
considered abuse and/or neglect.
• Product specifications are subject to change without notice. Due to ongoing development, the actual product may vary from
images shown.
• This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
• This product is not a toy! (14+) Recommended for ages 14 and up. Adult supervision required for ages under 18 years old.
Contains small parts, keep out of reach of children 3 years of age and younger.
1622
Scan this QR code
with your smart
phone to view the
getting started video
for this product.
