Summary of Contents for Maxon sd170e
-
Page 2: Safety Information
NEVER operate the radio transmitter without a suitable artificial load or antenna connected. ALWAYS Secure locking nuts on DB09 connector and always disconnect power supply before removing D-type connector. For service or repair always return your radio to an authorised Maxon Dealer or warranty conditions will be invalid. Page 2... -
Page 3: Table Of Contents
User Manual SD170E Series Table of Contents Safety Information ........................2 Table of Contents .........................2 About your SD170E Series data radio ..................4 About Your SD170E Radio .....................4 General SD170E Specification ....................4 SD170E Transmitter Specification ...................5 SD170E Receiver Specification ....................6 Unpacking Information ......................7... -
Page 4: About Your Sd170E Series Data Radio
User Manual SD170E Series About your SD170E Series data radio About Your SD170 Radio The SD-170E Series of RF Link Modules utilize the latest technology in their designs and manufacturing. SD-170E models are Phase Lock Loop Synthesizer (PLL)/microprocessor controlled, and offers 1/ 5 watt (Low/High) programmable output power with 16-channel capability. -
Page 5: Sd170E Transmitter Specification
User Manual SD170E Series SD170E Transmitter Specification Transmitter specification Carrier Power (Nom. Max. Min.) Hi Power 5W < 6W > 4.5W 5W < 6W > 4.5W Low Power 1W<1.5W>0.8W 1W<1.5W>0.8W Sustained Transmission Time 5 10 30Sec Power : >90% >85% >80% Power : >90% >85%... -
Page 6: Sd170E Receiver Specification
User Manual SD170E Series SD170E Receiver Specification Receiver Specification Sensitivity (@ 12dB SINAD) 25 KHz Channel Spacing < 0.28uV < 0.28uV 12.5 KHz Channel Spacing < 0.30uV < 0.30uV Sensitivity ( 1/100 Error Rate) < -113dBm < -113dBm With ACC-513 <... -
Page 7: Unpacking Information
Unpacking Information Remove and carefully inspect the contents of your package(s) for the following items: 1. Radio 2. User Manual * If any items are missing or damaged please contact your Dealer or Maxon Compatible accessory list (sold separate) ACC-513E... -
Page 8: Description Of Radio Components
Jumper Settings. Antenna installation Fasten the antenna to the radio by turning the antenna cable clockwise onto the BNC receptacle on left of radio when looking at front of radio. Programming Programming the SD170E series uses the ACC-916E programmer. Page 8... -
Page 9: Sd-170E Series Operation
User Manual SD170E Series SD-170E Series Operation Channel select / SCAN Your radio’s channel can be selected by inner DIP-S/W or serial command inputted from external control system. To change channel by inner DIP-S/W (4), you should open the upper cover and then look for the DIP-S/W (4) on the digital board of the bottom cover. -
Page 10: Scan Modes
User Manual SD170E Series Scan modes Scanning is a dealer programmable feature that allows you to monitor a number of channels. Your dealer will help you define a scanning mode and your channel “scan list” Channel scan Once the scan list has been established, initiate scan by serial commands. If a conversation is detected on any of the channels in the scan list, the radio will stop on that channel and you will be able to hear the conversation. -
Page 11: Channel Dip Switch Chart
User Manual SD170E Series Channel dip switch chart Serial Command Serial RX/TX Data Format (1) Asynchronous Serial Data Transfer (2) Baud Rate : 4,800 bit/sec (3) Data Bit : 8bit , Non Parity (4) Stop Bit : 1bit (5) MSB first transmission Each serial command is consist of 3 bytes. -
Page 12: Data Protocol
User Manual SD170E Series Data Protocol Protocol for input Serial command Protocol of data transmission from external equipment or device (: PC) to radio: External equipment or device Radio Input serial command Response Receive response Protocol for output data Protocol of data transmission from radio to external equipment or device (: PC) -
Page 13: Serial Commands
User Manual SD170E Series Serial Commands Transmit Command & data Mode Transmit Transmit data Check sum (BYTE2) Command (BYTE1) Transmit Command + (BYTE0) data 0x64 0x?? :Current ( 0x64 + Channel ) Channel Change channel 0x61 R(0x72) : Rx mode ( 0x61+0x72 ) RTX Mode Send. -
Page 14: Audible Alert Tones
User Manual SD170E Series Receive Command & data Mode Transmit Transmit data Check sum( BYTE2 ) Command ( BYTE1 ) : Transmit Command (BYTE0) + data Process 0xaa Complete 0x55 NACK Commands Note) This command is return signal for receiving command. - Page 15 User Manual SD170E Series DB 15 PIN descriptions with input/output level D-Type Function Description Signal Type Input/Outp Pin No. Analog signal 1KHz audio at 60% Data Signal is directly injected to MOD peak system modulation IN through data low pass filter...
- Page 16 User Manual SD170E Series The Serial data to be transmitted is input to this pin. It’s only Serial data IN available when option modem for option board is installed. Inputted data RS-232 level modem are modulated by modem IC and then injected to MOD.
-
Page 17: Modem Option For Data Commmunication
User Manual SD170E Series Modem option for data commmunication Description The ACC-513 and ACC-514 are internal option-modems, which are applied to the SD-170E series to increase capability for data applications. The goal of an internal modem is to improve the efficiency for data transmission and provide maximum flexibility for user applications. -
Page 18: Acc-515E Gps Option Board
User Manual SD170E Series ACC-515E GPS Option board Transmission GPS Data through Modem The SD-170E supports GPS data handling. That may help your implementation for a system related to GPS. If it is not enough for your application, received position data from the GPS module placed in an SD-170E can be reprocessed by your own application. -
Page 19: Acc-514E Ffsk Option Board
User Manual SD170E Series ACC-514E FFSK Option board Connector Input/ Function Description Output 6V to 12V Power Input Ground Signal from the digital board to transmit data key the SD-170 transmitter It ensures that the radio has stabilized in TXD_EN transmission before the data is processed for modulation. -
Page 20: Acc-513E Gmsk Option Board
User Manual SD170E Series ACC-513E GMSK Option board Connector Input/ Function Description Output 6V to 12V Power Input Ground Signal from the digital board to enable transmitter circuit of modem board. It ensures that the radio has stabilized in TXD_EN transmission before the data is processed for modulation. -
Page 21: User Statement
User Manual SD170E Series User Statement SD170E Series This product is marked with Declaration of Comformity In accordance with the Class II product requirement specified in the R&TTE Directive 1999/5/EC. This equipment is intended for use in:- Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany,... - Page 22 User Manual SD170E Series Maxon House, Cleveland Road, Hemel Hempstead, Hertfordshire, United Kingdom, HP2 7EY Tel: + 44 (0) 1442 267 777 Fax: + 44 (0) 1442 215 515 info@maxoncic.co.uk www.maxoncic.co.uk Page 1...
