MODEL SERIES 12301
MODEL SERIES 12303
265 Industrial Road
193 Osborne Road
P.O. Box 5000
Fridley, MN
Cambridge, ON
U.S.A. 55432
Canada N3H 5N3
OWNER'S GUIDE
ADVANCED REVERSE OSMOSIS
WATER TREATMENT SYSTEMS
580 Park Street
Regina, SK
Canada, S4N 5A9
MODEL SERIES 12302
MODEL SERIES 12304
9848 Glenoaks Boulevard
Sun Valley, CA
U.S.A. 91352
Toll Free
U.S. 800.354.7867
Canada 877.299.5999
www.hydrotechwater.com
Advertisement
Table of Contents
Related Manuals for Hydrotech SERIES 12301
Summary of Contents for Hydrotech SERIES 12301
- Page 1 OWNER’S GUIDE ADVANCED REVERSE OSMOSIS WATER TREATMENT SYSTEMS MODEL SERIES 12301 MODEL SERIES 12302 MODEL SERIES 12303 MODEL SERIES 12304 265 Industrial Road 193 Osborne Road 580 Park Street 9848 Glenoaks Boulevard Toll Free U.S. 800.354.7867 P.O. Box 5000 Fridley, MN...
-
Page 2: Options And Accessories
It connects to electronics inside RO Module by a length of phone cord routed to terminal on manifold cover. CONTACT YOUR HYDROTECH DEALER TO PURCHASE REPLACEMENT PARTS AND ACCESSORIES. TO LOCATE YOUR LOCAL DEALER, CALL HYDROTECH IN CANADA 877.299.5999... - Page 3 INTRODUCTION SYSTEM WITH NON-AIR GAP FAUCET - MODEL 12301 DRAIN CLAMP FAUCET WATER SUPPLY TANK TOP VIEW DRAIN CONNECTOR FLOW RESTRICTOR TUBING TO DRAIN (1/4" FLR RED TUBING) Your clear choice in water treatment. Advanced Reverse Osmosis Water Treatment System DUAL PURPOSE SEDIMENT/CARBON FILTER POST FILTER...
- Page 4 INTRODUCTION SYSTEM WITH AIR GAP FAUCET - MODEL 12304 PRODUCT WATER STORAGE TANKS TO MONITOR BALL VALVE FAUCET LIGHT FAUCET AIR GAP COMPRESSION TANK WATER SUPPLY TOP VIEW PRODUCT WATER FAUCET 3/8" WHITE TUBING DRAIN LINE FROM FLR TUBING TO AIR GAP(1/4" RED TUBING) DRAIN LINE FROM AIR GAP TO DRAIN (3/8"...
- Page 5 RO systems contain a replaceable treatment component critical to the efficiency of the system. ® Replacement of the reverse osmosis component should be with one of identical specification, as defined by Hydrotech to assure the same efficiency. Product water shall be tested periodically to verify the system is performing properly.
- Page 6 WATER QUALITY MONITOR ® ® Hydrotech 12303 and 12304 Series Reverse Osmosis Systems incorporate a proven performance indicator. Our patented Smartap Water Quality Monitor uses dual probe LOGIC PULSE MEMORY technology to accurately indicate membrane performance. A split- second power pulse compares feed water Total Dissolved Solids (TDS) level with that of the product water. Then, by reversing the polarity of the electronic pulse, the probes are cleaned and kept free of chemical plating.
- Page 7 SADDLE-TAPPING VALVE INSTALLATION ON COPPER TUBE CAUTION: This saddle-tapping valve is not designed for installation on flex line tubing. NOTE: State and local plumbing codes may prohibit use of saddle-tapping valves. 1. CAUTION: If no shut off valve is installed under 4.
- Page 8 DRAIN OUTLET ASSEMBLY INSTALLATION NOTE: State and local plumbing codes may prohibit use of saddle-tapping drain connections and may require use of an air gap. NOTE: Location and orientation of drain outlet assembly is vital to system performance. VERTICAL SINK SINK MOUNT DRAIN LINE...
- Page 9 PRODUCT WATER FAUCET SITE PREPARATION Refer to Faucet Installation Instructions (Pages 6 or 8) for site location and mounting hole specifications. Primary considerations for site selection are convenience of use and an open area under sink. Always check underside of selected location for obstructions. STAINLESS STEEL SINK PORCELAIN/ENAMEL OVER STEEL OR CAST IRON SINKS...
- Page 10 METAL PRODUCT WATER FAUCET INSTALLATION AND SYSTEM CONNECTIONS Install faucet on flat surface at least 2" in diameter. Unused 1 1/4" hole is ideal. Steps unique to a specific configuration are so noted. All other steps are common to either configuration. New Faucet Installation tube into 3/8”...
- Page 11 9 NON AIR GAP SINK OR COUNTER MATERIAL AIR GAP 5 AIR GAP AIR GAP ONLY AIR GAP DRAIN LINE FROM AIR GAP TO DRAIN (3/8" RED TUBING) FAUCET NIPPLE DRAIN LINE TO AIR GAP DRINKING WATER LINE (1/4" RED TUBING) FROM POST-FILTER TO FAUCET(3/8"...
- Page 12 POLYMER PRODUCT WATER FAUCET INSTALLATION AND SYSTEM CONNECTIONS Install on flat surface at least 2 7/16" in diameter. Unused 1 1/4"- 1 7/16" opening is ideal. New Faucet Installation d. Trim 1/4” red tubing coming from faucet to desired length and connect to Flow Restrictor Connector Refer to Faucet Site Preparation, Page 5.
- Page 13 Item Description Part No. Item Description Part No. Cover, Knob - Chrome - Plated 35800502 “O” ring, Spout 34201004 Screw, Knob 32701021 Body Assembly - Chrome Plated Plain -------- Body Assembly - Chrome Plated 3 LED -------- Knob, Faucet - Black 20800904 Gasket, Sink 20819001...
- Page 14 MODEL 12301 Item Description Part No. Cover, 3-vessel Manifold, Hydrotech Logo 43066770 Cover, 4-vessel Manifold, Hydrotech Logo 43066780 Bracket, Mounting 21100001 Screw, Mounting Bracket 32701006 Screw, inlet Valve Cover 32701038 Cover, Inlet Valve 20500066 "O" Ring, Inlet Valve Cover 34201024...
- Page 15 MODEL 12302 Model 12303 ® Pushbutton Smartap Monitor Module Cover and Monitor Connections FLOW RESTRICTOR LABEL Model 12304 ® Faucet Smartap Monitor Inlet Valve Switch Assembly Model 12304 ® Faucet Smartap Monitor Module Cover and Monitor Connections Figure 10.B: Exploded Schematic, 12302, 12303 and 12304 Model Series...
- Page 16 ACTIVATING THE SYSTEM CAUTION: Make sure all water supply lines, drain lines, and fittings are secure and free from leakage. NOTE: Item callouts refer to Page 10, Figure 10.A, and Replace manifold cover and tighten screws. Page 11, Figure 10.B. Test battery connection by activating monitor.
- Page 17 CLEANING, SANITIZING, AND CARTRIDGE REPLACEMENT PROCEDURE 1. Mix mild cleaning solution of dish soap and clean outside, with washcloth and cleaning solution. Do not potable water in plastic bowl. use abrasive materials. 9. Rinse manifold/housings with clean potable water. 2. Empty storage tank and relieve system pressure. Verify tank valve is open.
- Page 18 CLEANING, SANITIZING, AND CARTRIDGE REPLACEMENT PROCEDURE 19. CAUTION: Do not remove protective plastic bag from pushbutton or open faucet. If an indicator light replacement filter/membrane cartridges until so illuminates, connection is good. instructed. NOTE: Release button or close faucet immediately after light illuminates.
- Page 19 Empty water from storage tank (product water valve must remain open while adjusting pressure) and adjust pressure to 55 kPa (8 psig). ® System does not shut off. Shut-off valve is not closing. Contact your Hydrotech Dealer. No drain water. Clogged Flow Restrictor. Replace Flow Restrictor.
-
Page 20: Limited Warranty
Series Reverse Osmosis Drinking Water Treatment Systems (excluding cartridge filters and battery), when installed in accordance with HYDROTECH, Inc. specifications, to be free from defects in materials and workmanship under normal use within the operating specifications for a period of two (2) years from the date of purchase. HYDROTECH, Inc. also warrants the ®...
