INSTALLATION MANUAL & OWNER'S GUIDE
®
A HYDROTECH
COMPANY
ULTRAVIOLET WATER TREATMENT SYSTEMS
UVB SERIES
UV20 SERIES
UVBB SERIES
RACK SYSTEM
UV1 SERIES
ADDON SERIES
Hydrotech, Inc.
25555 West Avenue Stanford, Valencia, CA 91355
Phone: (661) 294-8888
Fax: (661) 294-8880
Making Water Safe - Worldwide™
Advertisement
Table of Contents
Related Manuals for Hydrotech UVB1
Summary of Contents for Hydrotech UVB1
- Page 1 INSTALLATION MANUAL & OWNER’S GUIDE ® A HYDROTECH COMPANY ULTRAVIOLET WATER TREATMENT SYSTEMS UVB SERIES UV20 SERIES UVBB SERIES RACK SYSTEM UV1 SERIES ADDON SERIES Hydrotech, Inc. 25555 West Avenue Stanford, Valencia, CA 91355 Phone: (661) 294-8888 Fax: (661) 294-8880...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION DESCRIPTIONS AND DEFINITIONS CONDITIONS FOR USE ROUTINE MAINTENANCE SPECIFICATIONS INSTALLATION MOUNTING BRACKET AND PLUMBING UVB SERIES INSTALL QUARTZ SLEEVE AND DISINFECT SYSTEM INSTALL ULTRAVIOLET LIGHT AND FILTERS ACTIVATE SYSTEM SERVICE REQUIREMENTS AND RECOMMENDED INTERVALS PARTS ILLUSTRATION PARTS LIST UV20 SERIES INSTALL QUARTZ SLEEVE AND DISINFECT SYSTEM... -
Page 3: Conditions For Use I
INTRODUCTION – DESCRIPTIONS AND DEFINITIONS You have purchased one of the most technologically advanced Ultraviolet Water Treatment System available anywhere in the world. It ® has been designed with you, the consumer, in mind. PURA products are lightweight, easy to use, and simple to maintain. PURA products will provide you with healthy, clean drinking water for years to come. -
Page 4: Routine Maintenance
Gallons Per Minute Outlet Used lbs. (kg) Height x Width x Depth Liters per Minute Watts UVB1 10.0 lbs. (4.5 kg) 15.0” (38.1 cm) x 5.5” (14.0 cm) x 5.5” (14.0 cm) UV Lamp #11 2 gpm (7.6 L/min) 3/8” NPT †... -
Page 5: Mounting Bracket And Plumbing
WARNING: NEVER LOOK DIRECTLY AT A LIGHTED UV LAMP. ULTRAVIOLET RAYS CAN BE HARMFUL TO EYES. ALWAYS SHUT OFF WATER TO SYSTEM AND DISCONNECT POWER WHEN SERVICING. ASSEMBLY IS REQUIRED BEFORE INSTALLATION. FRAGILE PARTS INSIDE. FOLLOW INSTRUCTIONS CAREFULLY! The system must be installed in accordance with applicable city, state, and local plumbing codes. PURA products are designed to provide years of trouble-free service if properly maintained. -
Page 6: Uvb Series
UVB SERIES - SYSTEM ASSEMBLY AND ACTIVATION PROCEDURES Insert filter/sleeve assembly into sump as shown in PREPARATION – INSPECT ALL PARTS Figure 1 with both Filter Gaskets (Item 4) in place. NOTE: Read Mounting Bracket and System Plumbing Installation instructions on Page 1 and all CAUTION: TIGHTEN SUMPS BY HAND ONLY. -
Page 7: Parts Illustration
SEDIMENT FILTER COMPONENTS UV2 EPCB /SD UV COMPONENTS CARBON FILTER COMPONENTS UVB1 EPCB UVB3 EPCB /GC/SD Figure 1 Exploded Schematic, PURA UVB Series Parts List - UVB Series Item Description Part No. Item Description Part No. Item Description Part No. -
Page 8: Uv20 Series
UV20 SERIES - SYSTEM ASSEMBLY AND ACTIVATION PROCEDURES CAUTION: TIGHTEN SUMPS BY HAND ONLY. Do not use PREPARATION – INSPECT ALL PARTS tools as they will over-tighten and may damage NOTE: Read Mounting Bracket and System Plumbing sump. Take care not to cut or pinch “O” Rings Installation instructions on Page 1 and all (Item 2). -
Page 9: Parts Illustration
UV COMPONENTS UV20-1 Figure 2 Exploded Schematic, PURA UV20 Series Parts List - UV20 Series Item Description Part No. Item Description Part No. Item Description Part No. Sump, #20 33801071 Switch, Safety ----- Lamp, UV #20 36002018 “O” Ring, Sump #10/20 34202018 Indicator, LED -----... -
Page 10: Uvbb Series
UVBB SERIES - SYSTEM ASSEMBLY AND ACTIVATION PROCEDURES For UVBB-2 and UVBB-3 Models only: Remove PREPARATION – INSPECT ALL PARTS Sump (Item 18) from Filter Head (Item 20). Remove NOTE: Read Mounting Bracket and System Plumbing Filters (Items 21 and 22) from sump and set aside. Installation instructions on Page 1 and all Disinfect the system (Pages 14-15, Steps 1-7). -
Page 11: Parts Illustration
UVBB-2 SEDIMENT FILTER COMPONENTS UVBB-1 UV COMPONENTS UVBB-3 CARBON FILTER COMPONENTS Figure 3 Exploded Schematic, PURA UVBB Series Parts List - UVBB Series Item Description Part No. Item Description Part No. Item Description Part No. Sump, UV #20 BB 44100001 Mounting Bracket, 31910202 “O”... -
Page 12: Rack System
RACK SYSTEM - ASSEMBLY AND INSTALLATION PROCEDURES PREPARATION - INSPECT ALL PARTS INSTALL UV SYSTEM TO RACK NOTE: Read Assembly and Installation instructions on NOTE: Items in this section refer to Figure 5 this page and UVBB System Installation and NOTE: Figures 5 and 6 provide examples of configurations Activation Procedures on Page 6 before that may be applied to your PURA system. -
Page 13: Rack System
SERIES SERIES TO PARALLEL PARALLEL PARALLEL TO SERIES Figure 5: Module Attachment Points Figure 6: UVBB Rack System Configurations. DATE INSTALLED SYSTEM OUTPUT RATING LPM/GPM CONFIGURATION: SERIES ڤSERIES TO PARALLEL ڤ PARALLEL ڤPARALLEL TO SERIES ڤ MODULE #1 TYPE: PURA PART NUMBER: MODULE #2... -
Page 14: Uv1 Series
UV1 SERIES - SYSTEM ASSEMBLY AND ACTIVATION PROCEDURE PREPARTATION – INSPECT ALL PARTS Loosen Screw (Item 9) securing slotted side of UV Lamp Retainer (Item 7). Remove the other screw securing the NOTE: Read Mounting Bracket and System Plumbing UV lamp retainer to UV head. Rotate UV lamp retainer Installation instructions on Page 1 and all away from center of UV head. -
Page 15: Parts Illustration
Figure 7 Exploded Schematic, PURA UV1Series Parts List - UV1 Series Item Description Part No. Item Description Part No. Item Description Part No. Sump, #10 SL 33801105 Retainer, UV Lamp UV1 31910408 Cap, Finish ----- “O” Ring, Sump #10 SL 34201027 Washer, #10 Nylon 32800030... -
Page 16: Addon Series
ADDON SERIES - SYSTEM ASSEMBLY AND ACTIVATION PROCEDURES Remove the UV Lamp (Item 16 or 16A) from packing tube PREPARATION – INSPECT ALL PARTS and inspect it for damage. If damage is found, contact the dealer for a replacement. NOTE: Read Mounting Bracket and System Plumbing Installation instructions on Page 1 and all Connect UV lamp into the four-pin socket that is instructions on this page before installing system. -
Page 17: Parts Illustration
UV ADDON 1GPM UV ADDON 3GPM Figure 8 Exploded Schematic PURA ADDON System Parts List - UV ADDON Item Description Part No. Item Description Part No. Item Description Part No. Sump, 1gpm Addon 33803301 Mounting Bracket,Addon 31910401 Cap, Finish ----- Sump, 3gpm Addon 33803303 Screw, #10 x 1”... -
Page 18: Cleaning And Disinfection
CLEANING, DISINFECTING, AND ROUTINE MAINTENANCE PROCEDURE RECOMMENDATIONS HAVE ALL COMPONENTS ON HAND AND READY BEFORE BEGINNING PROCEDURE A CLEAN WORK AREA AND EQUIPMENT ARE ESSENTIAL TO PROPERLY CLEAN AND/OR DISINFECT THE SYSTEM (i.e., CLEAN HANDS, TOOLS, WORK SURFACE, AND CONTAINERS) EQUIPMENT NEEDED Safety Glasses Liquid Dish Soap... -
Page 19: Filter Replacement
4. Slowly open the feed water supply valve. CAUTION: Do not attempt to remove sumps until water flow stops. This reduces pressure inside the 5. Open all downstream faucets. Keep faucets open until a system so sumps may be safely removed. chlorine smell is detected at each faucet, then close faucets. -
Page 20: Limited Warranty
This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state. Consult your authorized PURA Dealer or Hydrotech at 25555 West Avenue Stanford, Valencia, California 91355 for warranty and service information.
