Basic Function Instruction

3.1 Startup and Shutdown

Please make sure all the connections are done properly before you power on the unit. Proper
startup and shutdown are crucial to expanding the life of your NVR.

3.1.1 Startup

Step 1: Connect with the source power.
Step 2: The device will boot and the power LED would turn blue.
Step 3: A WIZZARD window will pop up and show some information about time zone, time
setup, network configuration, record configuration and disk management. You can setup here
and refer to the concrete setup steps from the corresponding chapters. If you don't want to set
up Wizard, please click Exit button to exit.
Note: The default output is HDMI output. Hold and press FN/ESC key to switch the
output among BNC, VGA & HDMI.

3.1.2 Shutdown

You can shut down the device by using IR remote controller and mouse.
By IR remote controller:
Step 1: Press Power button. This will bring up a shutdown window. The unit will shut down
by clicking "OK" button.
Step 2: Disconnect the power.
By mouse:
Step 1: Click
window.
Step 2: Click OK. Then the unit will power off after a while.
Step 3: Disconnect the power.

3.2 Login

You can login or log off the NVR system. Once logged off you cannot do any other operation
except changing the multi-screen display.
button and select "Shut Down" icon. This will take you to a shutdown
