Stamp - Provision ISR NVR-16400 User Manual

Fig 5-12 Record Configuration-Time
Pre-alarm Record Time: Set the time in seconds to pre-record before the actual recording
begins.
Post-alarm Record Time: Set the time in seconds to post-record after the actual recording
has finished, five options: 10s, 15s, 20s, 30s, 60s, 120s, 180s and 300s.
Expire Time: Set the expiration time for recorded video. If the set date is overdue, the
recorded files will be deleted automatically.

5.3.4 Stamp

This provides an option to enable or disable the Camera Name and the Time stamp on the
video. The user can also choose a position for the stamp on the screen.
To set up stamp as follows:
Step 1: Enter into Menu SetupRecordStamp interface. Refer to Fig 5-13:
Fig 5-13 Record Configuration-Stamp
Step 2: Checkmark camera name and time stamp. Click Setting button to set up the position of
the stamp. You can drag the camera name and time stamp at random positions. Refer to below
Figures:
