    Inhoudsopgave Introduction ..................6 Safety instructions.................. 6 Installation requirements ................. 7 The fire ..................7 False Chimney breast ................ 7 Requirements flue system and outlets............ 7 terminals ..................8 Existing chimney ................8 Preparation and Installation instructions ............9 Gas connection ................9 Electric connection ................
  • Page 6 11.1 Points of particular interest: .............. 15 11.2 Sample computations............... 16 Table ..................... 17 12.1 Table Flatburner ................17 12.2 Table logburner ................18 Technical data .................. 19 13.1 Flatburner ..................19 13.2 Logburner..................20 Dimension of the appliance ..............21 Dimension of the surround Wirdum 770 ............
  • Page 7: Introduction

    1 Introduction The appliance can only be installed by a competent person in accordance with the Gas Safety. We urgently advise you to read this installation manual properly. This appliance complies with the guidelines for European gas appliances (Gas Appliances Directive) and bears the CE mark.
  • Page 8: Installation Requirements

    The false chimney breast and its construction may not rest on the appliance Requirements flue system and outlets • You should always make use of the materials prescribed by Faber International Ltd. Only by using these materials can Faber International Ltd. guarantee a proper functioning.
  • Page 9: Terminals

    terminals The flue outlet can end on an external wall or a roof . Check whether the outlet desired by you complies with local requirements concerning good function and ventilation systems . For a proper functioning the terminal should be at least 0.5 m. away from: •...
  • Page 10: Preparation And Installation Instructions

    Remove the packaging of the appliance . Make sure the gas pipes underneath the appliance are not damaged. • Clear a safe space to store the frame and the glass. • Remove the frame , (if necessary) and the glass and take the separately wrapped parts out of the appliance •...
  • Page 11: Mounting The Smoke Emission Outlet Materials

    Mounting the smoke emission outlet materials • In case of a wall or roof terminal, the hole must be at least 5 mm bigger than the diameter of the flue material. • Horizontal parts must be installed at a (3 degree) slope up away the appliance. •...
  • Page 12: Removing The Glass

    5 removing the glass • Remove the cover strips A on the side. (see fig. 2.1) • Remove cover strip B on the bottom. (see fig. 2.2) • Place the suction discs onto the glass. • Remove the sealing cord from the groove (see fig. 2.3) •...
  • Page 13: Imitation Logs Logburner

    Imitation logs Logburner • Place the imitation logs. Make sure that the logs are properly connected to the tube burners.(see fig. 3.2 or imitation logs instruction card supplied) • Now divide the vermiculate pebbles and the chips in the combustion chamber. Avoid the covering of the air vent(s).
  • Page 14: Checking The Burner Pressure And The Pre-Pressure

    Checking the burner pressure and the pre-pressure Check whether the burner pressure and the inlet pressure measured agree with the data indicated on the registration plate Measuring the inlet-pressure: • Turn off the gas control tap. • Open the pressure gauge nipple B (see figure 1.3) a few turns and connect a pressure gauge hose to the gas control valve.
  • Page 15: Instructing The Client

    8 Instructing the client • Recommend that the appliance be serviced annually by a competent person in order to guarantee a safe use and a long lifespan. • Advise and instruct the client about maintenance and cleaning of the glass. Emphasize the risk of burning in fingerprints.
  • Page 16: Conversion To A Different Type Of Gas (E.g. Propane)

    10 Conversion to a different type of gas (e.g. propane) This can only be done by installing the proper burner unit. for this purpose get in touch with your supplier. Always mention the type and serial number of the appliance when ordering. 11 Calculation of flue system The possibilities for the lengths of flue pipes and the possible restrictors have been recorded in a table (see chapter 12) This table works with a vertical and a horizontal length.
  • Page 17: Sample Computations

    11.2 Sample computations Sample calculation 1 Count the horizontal lengths Flue pipe lengths C+E = 1 + 1 Bend D = 1 x 2 m Total Count the vertical lengths Flue pipe length A Roof terminal G Total Sample calculation 2 Count the horizontal lengths Flue pipe lengths J + L = 0,5 + 0,5 1 m Bends...
  • Page 18: Table

    12 Table Find the correct vertical and horizontal lengths in the table. In case of an “x”, or if the values are outside the table, the combination is not permitted. The value found indicates the width of the restrictor to be placed ("0" means no restrictor should be placed).
  • Page 19: Table Logburner

    12.2 Table logburner Horizontal 18 < < < <...
  • Page 20: Technical Data

    13 Technical data 13.1 Flatburner Gas category II2H3e+ II2H3e+ II2H3e+ Type of appliance C11/C31 C11/C31 C11/C31 Reference gas Input Nett Efficiency class NOx class inlet-pressure mbar Gas rate at 15ºC and 1013 mbar Gas rate at 15ºC and gr/h 1013 mbar Burner pressure at full mbar 11.0...
  • Page 21: Logburner

    13.2 Logburner Gas category II2H3e+ II2H3e+ II 2e+3+ Type of appliance C11/C31 C11/C31 C11/C31 Reference gas Input Nett Efficiency class NOx class inlet-pressure mbar Gas rate at 15ºC and 1013 mbar Gas rate at 15ºC and gr/h 1013 mbar Burner pressure at mbar 11.5 23.5...
  • Page 22: Dimension Of The Appliance

    14 Dimension of the appliance 21 < < < <...
  • Page 23: Dimension Of The Surround Wirdum 770

    15 Dimension of the surround Wirdum 770 22 < < < <...
  • Page 24: Dimension Ventilation Grills

    16 Dimension Ventilation Grills 23 < < < <...
  • Page 25: Dimension Service Hatch

    17 Dimension Service Hatch 24 < < < <...
  • Page 26 25 < < < <...
  • Page 27 26 < < < <...
  • Page 28 Saturnus 8 NL - 8448 CC Heerenveen Postbus 219 NL - 8440 AE Heerenveen T. +31(0)513 656500 F. +31(0)513 656501...
