Quick Start Guide

GV-Fisheye IP Camera
Note:
1. GV-FE110 / FE420 / FE520 are excluded from Japan, EU and German markets.
2. No memory card slot or local storage function for Argentina.
Thank you for purchasing GV-Fisheye IP Camera. This guide is designed to
assist the new user in getting immediate results from the GV-Fisheye IP
Camera. For advanced information on how to use the GV-Fisheye IP Camera,
please refer to GV-Fisheye IP Camera User's Manual on Software DVD.
© 2012 GeoVision Inc. All rights reserved.
1
Introduction
Welcome to the GV-Fisheye IP Camera Quick Start Guide. In the following
sections, you will learn the basic installations and configurations of
GV-Fisheye IP Camera. For the detailed user manual, see the GV-Fisheye
IP Camera User Manual on the GV-Fisheye IP Camera Software DVD.
Note: GV-FE110 / FE111 / FE420 / FE421 / FE520 / FE521 are for indoor
use, while GV-FER521 is designed for outdoor environment.
Packing List
• Camera Body
• Support Bracket x 3
• Screw
(Hard Ceiling Mount) x 3
• Screw
(In-Ceiling Mount) x 3
• GV-NVR Software DVD
• GV-Fisheye IP Camera Software DVD
• DC 12V Power Adaptor and 3-Pin or 2-Pin Terminal Block
2012/07
(GV-FE series only)
English
• Silica Gel Bag and Adhesive Tape x 2 (GV-FER521 only)
FE111421521-QG-E
• Camera Cover
(Hard-Ceiling Mount)
• Camera Cover
(In-Ceiling Mount)
• Plastic Screw Anchor x 3
• Torx Wrench
• Installation Sticker
• GV-NVR Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-Fisheye and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GeoVision GV-Fisheye

Summary of Contents for GeoVision GV-Fisheye

  • Page 1: Quick Start Guide

    Introduction Welcome to the GV-Fisheye IP Camera Quick Start Guide. In the following sections, you will learn the basic installations and configurations of GV-Fisheye IP Camera. For the detailed user manual, see the GV-Fisheye IP Camera User Manual on the GV-Fisheye IP Camera Software DVD.

  • Page 2: Hardware Installation

    Hardware Installation In-Ceiling Mount In-Ceiling Mount allows the GV-Fisheye IP Camera to be mounted into Hard Ceiling Mount the ceiling, revealing a small portion of the camera. In-Ceiling Mount 1. Place the installation sticker on the ceiling board. The 3 red dots requires the ceiling board to be between 0.5 –...

  • Page 3: Connecting The Power Cables

    You can use a Power over Ethernet (PoE) adaptor to connect the the ceiling board and pointing outward. GV-Fisheye IP Camera on the network, and the power will be provided over the network cable. Alternatively, you can use a standard network cable to connect the camera to your network, and then follow the steps below to connect to power using the 5-pin data cable and the power adaptor provided.
  • Page 4 Accessing the GV-Fisheye IP Camera Once installed, your GV-Fisheye IP Camera is accessible on a network. 4. Select Static IP address. Type IP Address, Subnet Mask, Router/Gateway, Primary DNS and Secondary DNS in the Configure Make sure your PC has good network connection, and meet this system connection parameters section.

  • Page 5: The Web Interface

    The Web Interface Fisheye View To enable the fisheye options, right-click the live view image and select Geo Fisheye. Right-click the image again and select Fisheye Option to see the following options. ● Image Alignment: By default, the image should be properly aligned already.
  • Page 6 GeoVision ● Adjust AutoPan Speed At Top-Left Channel: Select low, medium, for adjustment. Refer to Chapter 3, GV-Fisheye IP Camera User's Manual or high speed to enable Auto Pan for one PTZ view at the rotation to see how to determine if your device needs adjustment or not.

  • Page 7: Upgrading System Firmware

    GeoVision will periodically release updated firmware on the website. To load You can restore the camera to factory default settings using the Web the new firmware into the GV-Fisheye IP Camera, read the important notes interface or directly on the camera.
  • Page 8 3. Release the default button when the status LED blinks. 4. When the status LED fades, the process of loading default settings is completed and the camera reboots automatically. 9F, No. 246, Sec. 1, Neihu Rd., Neihu District, Taipei, Taiwan Tel: +886-2-8797-8376 Fax: +886-2-8797-8335 support@geovision.com.tw http://www.geovision.com.tw...
