Summary of Contents for Dodge 2014 Ram 1500

  • Page 2 If you are the first registered retail owner of your vehicle, you may obtain a complimentary printed copy of the Owner’s Manual, Navigation/Uconnect Manuals or Warranty Booklet by calling ® 1-866-726-4636 (U.S.) or 1-800-387-1143 (Canada) or by contacting your dealer. IMPORTANT This User Guide is intended to familiarize you with the important features of your vehicle.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION/WELCOME Uconnect ® 8.4A ....76 Uconnect ® 8.4AN ....95 WELCOME FROM CHRYSLER STEERING WHEEL AUDIO GROUP LLC .
  • Page 4 TABLE OF CONTENTS WHAT TO DO IN EMERGENCIES FUSES ....225 TIRE PRESSURES ... . . 229 ROADSIDE ASSISTANCE .
  • Page 5: Introduction/Welcome

    INTRODUCTION/WELCOME WELCOME FROM CHRYSLER GROUP LLC Congratulations on selecting your new Chrysler Group LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essen- tials that are traditional to our vehicles. Your new Chrysler Group LLC vehicle has characteristics to enhance the driver's control under some driving conditions.
  • Page 6 INTRODUCTION/WELCOME The DVD includes a computer application containing detailed owner's information which can be viewed on a personal computer or MAC computer. The multimedia DVD also includes videos which can be played on any standard DVD player (including the Uconnect ®...
  • Page 7 If your symptoms persist, please see an authorized dealer. CHRYSLER, DODGE, JEEP, RAM TRUCK, SRT, ATF+4, MOPAR and Uconnect are registered trademarks of Chrysler Group LLC.
  • Page 8: Controls At A Glance

    CONTROLS AT A GLANCE DRIVER COCKPIT 1. Headlight Switch pg. 32 6. Electronic Speed Control pg. 33 2. Electronic Vehicle Information 7. Keyless Engine Starting/ Center (EVIC) Controls pg. 117 Stopping pg. 13 3. Turn Signal/Wiper/Washer/High 8. Four Wheel Drive Operation pg. 125 Beams Lever pg.
  • Page 9 CONTROLS AT A GLANCE 11. Switch Panel 12. Power Inverter Outlet pg. 122 13. Glove Compartment • Diesel Exhaust Brake 14. Power Outlet • Tow/Haul pg. 137 15. Shifter • Electronic Stability Control pg. 166 16. Hood Release (below steering •...
  • Page 10: Instrument Cluster

    CONTROLS AT A GLANCE INSTRUMENT CLUSTER Warning Lights - Low Fuel Warning Light - Charging System Light** - Oil Pressure Warning Light** - Anti-Lock Brake (ABS) Light** - Air Bag Warning Light** - Electronic Throttle Control (ETC) Light - Engine Temperature Warning Light - Transmission Temperature Warning Light - Seat Belt Reminder Light BRAKE...
  • Page 11 CONTROLS AT A GLANCE Indicators - Turn Signal Indicators - Electronic Stability Control (ESC) Indicator Light* - High Beam Indicator - Electronic Stability Control - Park/Headlight ON (ESC) Off Indicator Indicator* - Cargo Lamp On Indicator - Front Fog Light Indicator - Door Ajar Indicator - Vehicle Security Indicator* - Electronic Speed Control...
  • Page 12: Getting Started

    GETTING STARTED KEY FOB • This feature allows the driver to oper- ate the ignition switch with the push of a button, as long as the Remote Key- less Entry (RKE) transmitter is in the passenger compartment. • The Keyless Ignition Node (KIN) has four operating positions, three of which are labeled and will illuminate when in position.
  • Page 13 GETTING STARTED NOTE: The EVIC can be setup for driver door first, otherwise this will unlock all doors. • All doors can be programmed to unlock on the first press of the UNLOCK button. Refer to Programmable Features in this guide. Panic Alarm •...
  • Page 14: Keyless Enter-N-Go

    GETTING STARTED KEYLESS ENTER-N-GO™ • The Keyless Enter-N-Go™ system is an enhancement to the vehicle's Key Fob. This feature allows you to lock and unlock the vehicle's door(s) without having to press the Key Fob lock or unlock buttons, as well as starting and stopping the vehicle with the press of a button.
  • Page 15: Remote Start

    GETTING STARTED Engine Starting/Stopping Starting • With a valid Keyless Enter-N-Go™ Key Fob inside the vehicle. • Shift the transmission into PARK or NEUTRAL. • While pressing the brake pedal, press the ENGINE START/STOP button once. If the engine fails to start, the starter will disengage automatically after 10 sec- onds.
  • Page 16: Security Alarm

    GETTING STARTED WARNING! • Do not start or run an engine in a closed garage or confined area. Exhaust gas contains Carbon Monoxide (CO) which is odorless and colorless. Carbon Monoxide is poisonous and can cause you or others to be severely injured or killed when inhaled.
  • Page 17: Seat Belt

    GETTING STARTED SEAT BELT • Be sure everyone in your vehicle is in a seat and using a seat belt properly. • Position the lap belt across your thighs, below your abdomen. To remove slack in the lap portion, pull up a bit on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt.
  • Page 18: Supplemental Restraint System (Srs) - Air Bags

    GETTING STARTED SUPPLEMENTAL RESTRAINT SYSTEM (SRS) — AIR BAGS • This vehicle has Advanced Front Air Bags for both the driver and right front passenger as a supplement to the seat belt restraint system. The Advanced Front Air Bags will not deploy in every type of collision. •...
  • Page 19: Child Restraints

    GETTING STARTED CHILD RESTRAINTS • Children 12 years or younger should ride properly buckled up in a rear seat, if available. According to crash statistics, children are safer when properly restrained in the rear seats rather than in the front. •...
  • Page 20 GETTING STARTED Crew/Mega/Quad Cab Full Or Split Bench Seat • The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seatback. They are just visible when you lean into the rear seat to install the child restraint.
  • Page 21 GETTING STARTED Installing The Child Restraints Using The Vehicle Seat Belts (Standard Cab) • The seat belts in the passenger seating positions are equipped with a Switchable Automatic Locking Retractor (ALR) that is designed to keep the lap portion of the seat belt tight around the child restraint.
  • Page 22 GETTING STARTED To Install A Child Seat Using A Cinching Latch Plate: 1. Place the child seat in the center of the seating position. 2. Next, pull enough of the seat belt webbing from the retractor to pass it through the belt path of the child restraint.
  • Page 23 GETTING STARTED Right or Left Outboard Seats: 1. Raise the head restraint and reach between the rear seat and rear glass to access the tether strap loop. Head Restraint In Raised Position Tether Strap Loop With Center Head Restraint In Raised Position 2.
  • Page 24 GETTING STARTED 4. Attach the hook to the center tether strap loop (see diagram). Tighten the tether strap according to the child seat manufacturer’s instructions. NOTE: If there are child seats in both of the outboard (left and right) seating posi- tions, the tether strap hooks of both child seats should be connected to the center tether strap loop.
  • Page 25 GETTING STARTED 4. Attach the hook to the outboard tether strap loop (see diagram). Tighten the tether strap according to the child seat manufacturer’s instructions. Tether Strap Through Center Tether Strap Loop And Attached To Outboard Tether Strap Loop Installing Three Child Restraints: 1.
  • Page 26: Front Seats

    GETTING STARTED WARNING! • In a collision, an unrestrained child, even a tiny baby, can become a projectile inside the vehicle. The force required to hold even an infant on your lap could become so great that you could not hold the child, no matter how strong you are.
  • Page 27 GETTING STARTED Memory Seat • The memory seat feature allows you to save the driver's seat position (exclud- ing lumbar position), driver's outside mirror position, adjustable brake and accelerator pedals, Automatic Tem- perature Control (ATC) temperature setting and radio station preset set- tings.
  • Page 28: Heated/Ventilated Seats

    GETTING STARTED WARNING! • Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted, and you could be severely injured or killed. Only adjust a seat while the vehicle is parked.
  • Page 29 GETTING STARTED Front Ventilated Seats • Located in the seat cushion are small fans that draw the air from the passenger compartment and pull air through fine perforations in the seat cover to help keep the driver and front passenger cooler in higher ambient temperatures. •...
  • Page 30: Heated Steering Wheel

    GETTING STARTED HEATED STEERING WHEEL • The steering wheel contains a heating element that heats the steering wheel to one temperature setting. • The heated steering wheel switch is located on the center instrument panel below the climate controls. • The heated steering wheel is also con- trolled by soft-keys in the radio screen.
  • Page 31: Tilt Steering Column

    GETTING STARTED TILT STEERING COLUMN • The tilt lever is located on the steering column below the turn signal lever. • To tilt the column, simply pull the tilt lever rearward toward you and then move the steering wheel upward or downward as desired.
  • Page 32: Operating Your Vehicle

    OPERATING YOUR VEHICLE ENGINE BREAK-IN RECOMMENDATIONS • A long break-in period is not required for the engine and drivetrain (transmission and axle) in your vehicle. • Drive moderately during the first 300 miles (500 km). After the initial 60 miles (100 km), speeds up to 50 or 55 mph (80 or 90 km/h) are desirable.
  • Page 33: Turn Signals/Wiper/Washer/High Beams Lever

    OPERATING YOUR VEHICLE TURN SIGNALS/WIPER/WASHER/HIGH BEAMS LEVER Turn Signals/Lane Change Assist • Tap the lever up or down once and the turn signal (right or left) will flash three times and automatically turn off. Wipers Intermittent, Low And High Operation •...
  • Page 34: Headlight Switch

    OPERATING YOUR VEHICLE HEADLIGHT SWITCH Automatic Headlights/Parking Lights/Headlights • Rotate the headlight switch, located on the instrument panel to the left of the steering wheel, to the first detent for parking lights and to the second detent for headlights • With the parking lights or low beam headlights on, push the headlight switch once for fog lights.
  • Page 35: Speed Control

    OPERATING YOUR VEHICLE SPEED CONTROL • The Speed Control switches are located on the steering wheel. Cruise ON/OFF • Push the ON/OFF switch to activate the Speed Control. • The cruise symbol will appear on the instrument cluster to indicate the Speed Control is on.
  • Page 36: Eight-Speed Automatic Transmission - If Equipped

    OPERATING YOUR VEHICLE Cancel • Push the CANCEL switch or apply the brakes to cancel the set speed and maintain the set speed memory. • Push the ON/OFF switch to turn the system off and erase the set speed memory. WARNING! •...
  • Page 37: Electronic Range Select (Ers) Operation

    OPERATING YOUR VEHICLE ELECTRONIC RANGE SELECT (ERS) OPERATION • Electronic Range Select (ERS) allows you to limit the highest available trans- mission gear, and can be activated during any driving condition. When towing a trailer or operating the vehicle in off-road conditions, using ERS shift control will help you maximize both performance and engine braking.
  • Page 38 OPERATING YOUR VEHICLE • Move the console shift lever left (-) or right (+), or toggle the switch on the column shift lever down (-) or up (+) to select the desired top gear. • For maximum deceleration (engine braking) move the console shift lever left (-) and hold, or toggle the switch on the column shift lever down (-) and hold.
  • Page 39: 1500 Air Suspension System

    OPERATING YOUR VEHICLE 1500 AIR SUSPENSION SYSTEM • The air suspension system provides full time load leveling capability along with the benefit of being able to adjust vehicle height by the push of a button. • Automatic height changes will occur based on vehicle speed and the current vehicle height.
  • Page 40 OPERATING YOUR VEHICLE NOTE: Automatic Aero Mode may be disabled through vehicle settings in the Electronic Vehicle Information Center (EVIC) when equipped with Uconnect 3.0, or your Uconnect ® Radio when equipped with UConnect ® 5.0, 8.4A, or 8.4AN. • Entry/Exit Mode (Lowers the vehicle approximately 2 in (51 mm) - This position lowers the vehicle for easier passenger entry and exit as well as lowering the rear of the vehicle for easier loading and unloading of cargo.
  • Page 41: 2500-3500 Air Suspension System

    OPERATING YOUR VEHICLE NOTE: This mode is intended to be enabled with engine running. Protection Mode • In order to “protect” the air suspension system, the vehicle will enter Protection Mode when the payload has been exceeded or load leveling cannot be achieved. Refer to “Electronic Vehicle Information Center (EVIC)”...
  • Page 42: Manual Climate Controls Without Touchscreen

    OPERATING YOUR VEHICLE NOTE: This mode is intended to be enabled with engine running. Wheel Alignment Mode • Before performing a wheel alignment this mode must be enabled. Refer to “Electronic Vehicle Information Center (EVIC)” in “Understanding Your Instru- ment Panel” for further information. NOTE: This mode is intended to be enabled with engine running.
  • Page 43: Manual Climate Controls With Touchscreen

    OPERATING YOUR VEHICLE MANUAL CLIMATE CONTROLS WITH TOUCHSCREEN Touchscreen Manual Climate Controls Climate Control Knobs Air Recirculation • Use recirculation for maximum A/C operation. • For window defogging, turn the recirculation button off. Heated Mirrors • The mirrors are heated to melt frost or ice. This feature is activated whenever you turn on the defroster.
  • Page 44: Automatic Climate Controls With Touchscreen

    OPERATING YOUR VEHICLE AUTOMATIC CLIMATE CONTROLS WITH TOUCHSCREEN Touchscreen Automatic Climate Controls Climate Control Knobs • Press the AUTO button or AUTO soft-key. • Select the desired temperature by pushing the up or down temperature buttons for the driver or passenger. •...
  • Page 45: Parksense® Front And Rear Park Assist

    OPERATING YOUR VEHICLE Air Conditioning (A/C) • If the air conditioning button is pressed while in AUTO mode, the system will exit AUTO mode and stay in A/C. The mode and blower will be set at the closest mode and blower position that the system was operating in AUTO. SYNC Temperature Soft-Key •...
  • Page 46: Parkview® Rear Back-Up Camera

    OPERATING YOUR VEHICLE Cleaning The ParkSense® Sensors • If “CLEAN PARK ASSIST SENSORS” appears in the Electronic Vehicle Informa- tion Center (EVIC), clean the ParkSense sensors with water, car wash soap and a ® soft cloth. Do not use rough or hard cloths. Do not scratch or poke the sensors. Otherwise, you could damage the sensors.
  • Page 47: Power Sliding Rear Window

    OPERATING YOUR VEHICLE POWER SLIDING REAR WINDOW • The switch for the power sliding rear window is located on the overhead console. • Push the switch right to open the glass and pull the switch left to close the glass. POWER SUNROOF •...
  • Page 48 OPERATING YOUR VEHICLE Venting Sunroof • Press and release the button and the sunroof will open to the vent position. This is called “Express Vent” and will occur regardless of sunroof position. During Express Vent operation, any movement of the switch will stop the sunroof. Closing Sunroof Express Closing •...
  • Page 49: Wind Buffeting

    OPERATING YOUR VEHICLE WARNING! • Do not let children play with the sunroof. Never leave children unattended in a vehicle, or with access to an unlocked vehicle. Do not leave the key fob in or near the vehicle, and do not leave the ignition of a vehicle equipped with Keyless Enter-N-Go™...
  • Page 50: Electronics

    ELECTRONICS YOUR VEHICLE'S SOUND SYSTEM 1. Uconnect ® Phone Button pg. 108 2. Uconnect ® Voice Command Button pg. 111 3. Steering Wheel Audio Controls (Left) pg. 116 4. Steering Wheel Audio Controls (Right) pg. 116 5. Volume Knob / Audio Mute Button 6.
  • Page 51 ELECTRONICS 7. 9-1-1 Button pg. 58 8. Uconnect ® 8.4 Radio pg. 76 9. Screen Off Button 10. Back Button 11. Tune / Scroll Knob / Browse / Enter Button 12. Media Hub: Audio Jack, USB Port, and SD Card Slot (located center console) pg.
  • Page 52: Identifying Your Radio

    ELECTRONICS IDENTIFYING YOUR RADIO Uconnect® 3.0 • Two hard-keys on either side of the display Uconnect® 3.0 Uconnect® 5.0 • 5” Touchscreen • Three hard-keys on either side of the display Uconnect® 5.0 Uconnect® 8.4A • 8.4” Touchscreen • Climate soft key in lower menu bar •...
  • Page 53: Uconnect Access (Available On Uconnect 8.4A And Uconnect 8.4An) (If Equipped)

    ELECTRONICS Uconnect® 8.4AN • 8.4” Touchscreen • Climate soft key in lower menu bar • HD Button will be visible on right side of screen when viewing AM or FM • SiriusXM Travel Link feature listed within Apps Uconnect® 8.4AN Uconnect®...
  • Page 54 ELECTRONICS 3. The Uconnect ® Voice Command and Uconnect ® Phone buttons are located on the left side of your steering wheel. These buttons allow you to use your voice to make phone calls, send and receive text messages, control your media, enter navigation destinations and more all without taking your hands off the steering wheel.
  • Page 55 ELECTRONICS 6. A final message will display on the touchscreen allowing you to check on the status of your email submission. To exit the registration, press the X in the upper right corner. NOTE: For security reasons, this link is valid for 24 hours from the time you submit your email address into the radio touchscreen.
  • Page 56 ELECTRONICS Set Up Your Via Mobile Profile NOTE: Complete your Via Mobile Profile online during registration of your Uconnect Access system. You can come back to this page by logging into your Mopar Owner Connect account (www.moparownerconnect.com), going to Edit Profile, then Via Mobile Profile.
  • Page 57 ELECTRONICS Purchasing Apps and WiFi NOTE: Apps and WiFi can be purchased from the Uconnect Store within your vehicle, and ® online at Mopar Owner Connect. You must first register and set up a Uconnect ® Payment account. Purchasing Apps and WiFi for your vehicle 1.
  • Page 58 ELECTRONICS Using Uconnect® Access Getting Started with Apps • Built-In Features– use the built-in 3G Cellular Network on your Uconnect® radio. • Uconnect ® Access via Mobile – Uconnect ® Access via Mobile uses your smart- phone’s existing data plan to access Uconnect System-enabled apps, which you can control both using your touchscreen and steering wheel controls.
  • Page 59 ELECTRONICS Maintaining Your Uconnect® Access Account Reinstalling an App • You can easily correct many Application related issues you may be experiencing by resetting the App back to the factory setting. From the vehicle’s radio touchscreen, complete the following steps: 1.
  • Page 60 ELECTRONICS Built-In Features 1. Assist Call – The rear view mirror contains an ASSIST push button which (once registered) automatically connects the vehicle occupants to one of these pre- defined destinations for immediate support: • Roadside Assistance Call – If you get a flat tire, or need a tow, you’ll be con- nected to someone who can help any- time.
  • Page 61 ELECTRONICS 4. Yelp® - Customers have the ability to search for nearby destinations or a point of interest (POI) either by category or custom search by using keywords (for example, “Italian restaurant”). Searching can be done by voice or using the touchscreen keypad.
  • Page 62 ELECTRONICS Uconnect® Access Remote Features • If you own a compatible iPhone or Android powered device, the Uconnect Access ® ® App allows you to remotely lock or unlock your doors, start your engine or activate your horn and lights from virtually anywhere (Vehicle must be within the United States, have network coverage and must be registered with Uconnect ®...
  • Page 63 ELECTRONICS 3. Remote Horn and Lights – It’s easy to locate a vehicle in a dark, crowded or noisy parking area by activating the horn and lights. It may also help if you need to draw attention to your vehicle for any reason. You can send a request to your vehicle in one of three ways: •...
  • Page 64 ELECTRONICS To send a text message: a. Press the Uconnect ® Phone button. b. Wait for the beep. c. Say “Text.” d. Uconnect will prompt you “Say the phone number, or full name and phone ® type of the contact you want to send a message to.” e.
  • Page 65 ELECTRONICS WARNING! • ALWAYS drive safely with your hands on the steering wheel. You have full responsibility and assume all risks related to the use of the Uconnect ® features and applications in this vehicle. Only use Uconnect when it is safe to do so. ®...
  • Page 66 ELECTRONICS • Launch the Uconnect ® Access App on your smartphone, and log in with your username and password that was set up during registration. Accept the Terms and Conditions. • Ensure that Via Mobile data has been turned on under “Settings” in the Uconnect ®...
  • Page 67 ELECTRONICS • If equipped, the Via Mobile apps can be found by selecting the “Apps” soft-key in the lower right corner of the radio touchscreen. Via Mobile apps are listed under the “All Apps” tab. The words “Via Mobile” will appear after the app name indicating it is a Via Mobile app.
  • Page 68 ELECTRONICS Via Mobile Apps (If Equipped) • Aha • Easily access and organize your favorite content from the web into personalized, live and on-demand stations. Choose from stations spanning Internet radio, personalized music, hotels, weather, audiobooks, Facebook , Twitter ® ®...
  • Page 69: Uconnect ® 3.0

    ELECTRONICS Uconnect® 3.0 Clock Setting 1. Press the Menu button at the bottom of the radio, and push the Enter/Browse button for System Settings. Next, select the Time and Format setting and then select Set Time by pushing the Enter/Browse button. 2.
  • Page 70 ELECTRONICS Radio Operation Seek Up/Down Buttons • Press to seek through radio stations in AM, FM or SXM bands. • Hold either button to bypass stations without stopping. Store Radio Presets • The Presets are available for all Radio Modes, and are activated by touching any of the six Preset buttons.
  • Page 71 ELECTRONICS USB/Audio Jack (AUX) Operation USB/iPod® • USB/iPod Mode is entered by either inserting a USB Jump Drive or iPod cable ® ® into the USB port or by touching the Media button located left of the display. Once in Media Mode, select USB/iPod ®...
  • Page 72: Uconnect ® 5.0

    ELECTRONICS Uconnect® 5.0 Clock Setting 1. To start the clock setting procedure, perform either of the following: • Press the More hard-key on the right side of the display, next press the Time soft-key and then press the Set soft-key. •...
  • Page 73 ELECTRONICS Equalizer • Touch the Equalizer soft-key to adjust the Bass, Mid and Treble. Use the + or - soft-key to adjust the equalizer to your desired settings. Press the back arrow soft-key when done. Balance/Fade • Touch the Balance/Fade soft-key to adjust the sound from the speakers. Use the arrow soft-key to adjust the sound level from the front and rear or right and left side speakers.
  • Page 74 ELECTRONICS • SiriusXM services require subscriptions, sold separately after the 12-month trial included with the new vehicle purchase. If you decide to continue your service at the end of your trial subscription, the plan you choose will automatically renew and bill at then-current rates until you call SiriusXM at 1-866-635-2349 for U.S.
  • Page 75 ELECTRONICS Audio Jack (AUX) • The AUX allows a portable device, such as an MP3 player or an iPod ® , to be plugged into the radio and utilize the vehicle’s audio system, using a 3.5 mm audio cable, to amplify the source and play through the vehicle speakers. •...
  • Page 76 ELECTRONICS Voice Command (VR) User TIPs • To hear available commands, press the Uconnect ® Voice Command button and say “Help”. You will hear available commands for the menu displayed. • At any time, you can say the words “Cancel” or “Help”. These commands are universal and can be used from virtually any menu.
  • Page 77 ELECTRONICS Voice Command Examples – Uconnect® 5.0 GENERAL Anytime “Go to Radio” (Media, Phone) – Compass, Settings, and More functions are not Voice Command accessible “Cancel” “Help” (to listen to suggested commands specific to current need “Repeat” RADIO AM/FM “Tune to AM950”, “Tune to 95.5FM (preset 5) Satellite Band Control “Tune to Satellite Channel 80's on 8”, Tune to Satellite Channel 32 (preset 4)
  • Page 78: Uconnect® 8.4A

    ELECTRONICS Uconnect® 8.4A Uconnect® 8.4A AT A GLANCE Displaying the Time • If the time is not currently displayed on the radio or player main page, touch the Settings soft-key or the Apps soft-key and then the Settings soft-key. In the Settings list, touch the Clock soft-key then touch the check box next to Show Time in Status Bar.
  • Page 79 ELECTRONICS Audio Settings • Touch the Audio soft-key to activate the Audio settings screen to adjust Balance\Fade, Equalizer, and Speed Adjusted Volume. • You can return to the Radio screen by touching the X located at the top right. Balance/Fade •...
  • Page 80 ELECTRONICS Selecting Radio Stations • Touch the desired radio band (AM, FM or SXM) soft-key. Seek Up/Seek Down • Touch the Seek arrow soft-keys for less than two seconds to seek through radio stations. • Touch and hold either arrow soft-key for more than two seconds to bypass stations without stopping.
  • Page 81 ELECTRONICS Jump • Automatically tells you when Traffic & Weather for a favorite city is available, and gives you the option to switch to that channel. Touch Jump to activate the feature. After listening to Traffic and Weather, touch Jump again to return to the previous channel.
  • Page 82 ELECTRONICS Replay • Lets you replay up to 44 minutes of the content of the current SiriusXM channel. Replay Option Description Option Play/Pause Touch to Pause content playback. Touch Pause/Play again to resume playback. Rewind/RW Rewinds the channel content in steps of five seconds. Touch and hold to rewind continuously, then release to begin playing content at that point.
  • Page 83 ELECTRONICS MEDIA HUB – PLAYING iPod/USB/MP3 DEVICES • There are many ways to play music from iPod /MP3 players or USB devices ® through your vehicle's sound system. Touch your Media soft-key to begin. Audio Jack (AUX) • The AUX allows a portable device, such as an MP3 player or an iPod ®...
  • Page 84 ELECTRONICS NOTE: When connecting your iPod device for the first time, the system may take several ® minutes to read your music, depending on the number of files. For example, the system will take approximately five minutes for every 1000 songs loaded on the device.
  • Page 85 ELECTRONICS iPod®/CD/AUX CONTROLS • The iPod ® /CD/AUX controls are accessed by touching the desired soft-key dis- played on the side of the screen and choosing between Disc, AUX, iPod ® Bluetooth or SD Card. NOTE: Uconnect will usually automatically switch to the appropriate mode when some- ®...
  • Page 86 ELECTRONICS Changing the Navigation Voice Prompt Volume 1. Touch the Settings soft-key. 2. In the Settings menu, touch the Guidance soft-key. 3. In the Guidance menu, adjust the Nav Volume by touching the + or – Nav Volume Adjustment soft-keys. Finding Points of Interest (POI) •...
  • Page 87 ELECTRONICS Finding a Place by Spelling the Name • From the Main Navigation Menu touch the Where to? soft-key, touch the Points of Interest soft-key and then touch the Spell Name soft-key. • Enter the name of your destination. • Touch the List soft-key. •...
  • Page 88 ELECTRONICS Go Home • A Home location must be saved in the system. From the Main Navigation menu, touch the Where To? soft-key, then touch the Go Home soft-key. • Your route is marked with a blue line on the map. If you depart from the original route, your route is recalculated.
  • Page 89 ELECTRONICS Uconnect® Phone (Bluetooth® HANDS FREE CALLING) • If the Uconnect Phone Button exists on your steering wheel, then you have ® the Uconnect Phone features. ® • The Uconnect ® Phone is a voice-activated, hands-free, in-vehicle communica- tions system with Voice Command Capability (see Voice Command section). •...
  • Page 90 ELECTRONICS Select the mobile phone's priority level • When the pairing process has successfully completed, the system will prompt you to choose whether or not this is your favorite phone. Selecting Yes will make this phone the highest priority. This phone will take precedence over other paired phones within range.
  • Page 91 ELECTRONICS Voice Command Tips (8.4 and 8.4N ONLY) • Using complete names (i.e; Call John Doe vs. Call John) will result in greater system accuracy. • You can “chain” commands together for faster results. Say “Call John Doe, mobile”, for example. •...
  • Page 92 ELECTRONICS VOICE COMMAND QUICK REFERENCE Uconnect® 8.4A Voice Command Quick Reference • If the Uconnect ® Voice Command button exists on your steering wheel, you have the Voice Command feature, which is optimized for the driver. The Voice Command feature lets you keep your hands on the wheel, your eyes on the road, and control navigation and media sources.
  • Page 93 ELECTRONICS • Always wait for the beep before speaking. • Speak normally, without pausing, just as you would speak to a person sitting a few feet/meters away from you. • Make sure that no one other than you is speaking during a Voice Command period. Steering Wheel Buttons •...
  • Page 94 ELECTRONICS...
  • Page 95 ELECTRONICS Voice Command Examples – Uconnect® 8.4A GENERAL Anytime “Go to Radio” (Media, Climate, Navigation, Phone, Apps) – Settings, and Controls are not Voice Command accessible “Cancel” “Help” (to listen to suggested commands specific to current need “Repeat” “Launch Yelp ”...
  • Page 96 ELECTRONICS PHONE Voice Texting (Requires Create a text message using Voice Command Capability “Send a message to John Smith (123-456-7890)” registration with “Show Messages” Uconnect ® Access and a “Listen to” (view) “number 4” current subscription.) “Reply” NOTE: Requires a compat- “Forward text”...
  • Page 97: Uconnect® 8.4An

    ELECTRONICS Uconnect® 8.4AN Uconnect® 8.4AN AT A GLANCE Displaying the Time • If the time is not currently displayed on the radio or player main page, touch the Controls soft-key or the Apps soft-key and then the Settings soft-key. In the Settings list, touch the Clock soft-key then touch the check box next to Sync Time.
  • Page 98 ELECTRONICS Audio Settings • Touch of the Audio soft-key to activate the Audio settings screen to adjust Balance\Fade, Equalizer, and Speed Adjusted Volume. • You can return to the Radio screen by touching the X located at the top right. Balance/Fade •...
  • Page 99 ELECTRONICS Selecting Radio Stations • Touch the desired radio band (AM, FM or SXM) soft-key. Seek Up/Seek Down • Touch the Seek arrow soft-keys for less than two seconds to seek through radio stations. • Touch and hold either arrow soft-key for more than two seconds to bypass stations without stopping.
  • Page 100 ELECTRONICS Seek Up/Seek Down • Touch the Seek arrow soft-keys for less than two seconds to seek through channels in SXM mode. • Touch and hold either arrow soft-key for more than two seconds to bypass channels without stopping. The radio will stop at the next listenable channel once the arrow soft-key is released.
  • Page 101 ELECTRONICS Browse • Lets you browse the SiriusXM channel listing or Genre listing. Favorites, Game Zone, Weather and Jump settings also provide a way to browse the SiriusXM channel list. Browse Sub-Menu Description Sub-Menu Shows the channel listing. Genre Provides a list of all genres, and lets you jump to a channel within the selected genre.
  • Page 102 ELECTRONICS • SiriusXM services require subscriptions, sold separately after the 12-month trial included with the new vehicle purchase. If you decide to continue your service at the end of your trial subscription, the plan you choose will automatically renew and bill at then-current rates until you call SiriusXM at 1-866-635-2349 for U.S.
  • Page 103 ELECTRONICS MEDIA HUB – PLAYING iPod/USB/MP3 DEVICES • There are many ways to play music from iPod /MP3 players or USB devices ® through your vehicle's sound system. Touch your Media soft-key to begin. Audio Jack (AUX) • The AUX allows a portable device, such as an MP3 player or an iPod ®...
  • Page 104 ELECTRONICS NOTE: When connecting your iPod device for the first time, the system may take several ® minutes to read your music, depending on the number of files. For example, the system will take approximately five minutes for every 1000 songs loaded on the device.
  • Page 105 ELECTRONICS iPod®/CD/AUX CONTROLS • The iPod ® /CD/AUX controls are accessed by touching the desired soft-key dis- played on the side of the screen and choosing between Disc, AUX, iPod ® Bluetooth or SD Card. NOTE: Uconnect will usually automatically switch to the appropriate mode when some- ®...
  • Page 106 ELECTRONICS NAVIGATION • Touch the Nav soft-key in the menu bar to access the Navigation system. Changing the Navigation Voice Prompt Volume 1. Touch the View Map soft-key from the Nav Main Menu. 2. With the map displayed, touch the Settings soft-key in the lower right area of the screen.
  • Page 107 ELECTRONICS Finding a Place by Spelling the Name • From the Main Navigation Menu touch the Where to? soft-key, touch the Points of Interest soft-key, then touch the Spell Name soft-key. • Enter the name of your destination. • Touch the Done soft-key. •...
  • Page 108 ELECTRONICS Go Home • A Home location must be saved in the system. From the Main Navigation menu, touch the Where To? soft-key, then touch the Go Home soft-key. • Your route is marked with a blue line on the map. If you depart from the original route, your route is recalculated.
  • Page 109 ELECTRONICS Taking a Detour • To take a detour you must be navigating a route. • Touch the Detour soft-key. NOTE: If the route you are currently taking is the only reasonable option, the device may not calculate a detour. For more information, see your Uconnect ®...
  • Page 110 ELECTRONICS NOTE: SiriusXM Travel Link requires a subscription, sold separately after the 1 year trial subscription included with your vehicle purchase. • SiriusXM Travel Link is only available in the United States. Fuel Prices Check local gas and diesel prices in your area and route to the station of your choice.
  • Page 111 ELECTRONICS Start pairing procedure on mobile phone • Search for available devices on your Bluetooth ® enabled mobile phone. This is usually within Settings or Options under “Bluetooth”. See your mobile phone’s manual for details. • When your phone finds the system, select “Uconnect” as the paired device. You may be prompted by your phone to download the phonebook.
  • Page 112 ELECTRONICS Common Phone Commands (Examples) • “Call John Smith” • “Call John Smith mobile” • “Dial 1 248 555 1212” • “Call Emergency” • “Call Towing Assistance” • “Redial” Phonebook • Uconnect ® radios will automatically download your phonebook from your paired phone, if this feature is supported by your phone.
  • Page 113 ELECTRONICS Voice Text Reply • Uconnect Phone can read or send new text messages on your mobile phone. ® • Your mobile phone must be MAP (Message Access Profile) compatible to support SMS via Bluetooth ® to use this feature. If the Uconnect ®...
  • Page 114 ELECTRONICS Voice Command (VR) User TIPs • To hear available commands, press the Uconnect ® Voice Command button and say “Help”. You will hear available commands for the menu displayed. • At any time, you can say the words “Cancel” or “Help”. These commands are universal and can be used from virtually any menu.
  • Page 115 ELECTRONICS...
  • Page 116 ELECTRONICS Voice Command Examples – Uconnect® 8.4AN GENERAL Anytime “Go to Radio” (Media, Climate, Navigation, Phone, Apps) – Settings, and Controls are not Voice Command accessible “Cancel” “Help” (to listen to suggested commands specific to current need) “Repeat” “Launch Yelp ”...
  • Page 117 ELECTRONICS PHONE Voice Texting (Requires Create a text message using Voice Command Capability “Send a message to John Smith (123-456-7890)” registration with “Show Messages” Uconnect ® Access and a “Listen to” (view) “number 4” current subscription) “Reply” NOTE: Requires a compat- “Forward text”...
  • Page 118: Steering Wheel Audio Controls

    ELECTRONICS APPS SiriusXM Travel Link (Traffic “Show Fuel prices” “Show Current Weather” – provides access to function is not voice com- Forecast as well mand accessible within “Show Weather map” – multiple map formats available SiriusXM Travel Link) “Show Sports” “Show Movie listings”...
  • Page 119: Electronic Vehicle Information Center (Evic)

    ELECTRONICS ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) • The EVIC features a driver interactive display that is located in the instrument cluster. Pressing the controls on the left side of the steering wheel allows the driver to select vehicle information and Personal Settings.
  • Page 120 ELECTRONICS Uconnect® Customer Programmable Features • The Uconnect system allows you to access Customer Programmable feature ® settings such as Display, Clock, Safety/Assistance, Lights, Doors & Locks, Auto-On Comfort & Remote Start, Engine Off Operation, Compass Settings, Audio, Trailer Brake, Phone/Bluetooth ®...
  • Page 121: Universal Garage Door Opener (Homelink )

    ELECTRONICS Trip B • Press and release the UP or DOWN arrow button until the Trip B icon is highlighted in the EVIC. Press and release the RIGHT arrow button to display the Trip B information. Fuel Economy • Press and release the UP or DOWN arrow button until the Fuel Economy icon is highlighted.
  • Page 122 ELECTRONICS Before You Begin Programming HomeLink® • Ensure that your vehicle is parked out- side of the garage before you begin programming. • For efficient programming and accurate transmission of the radio-frequency sig- nal, it is recommended that a new bat- tery be placed in the hand-held trans- mitter of the device that is being programmed to the HomeLink...
  • Page 123 ELECTRONICS NOTE: If the EVIC displays “DID NOT TRAIN” repeat from Step 2. 5. At the garage door opener motor (in the garage), locate the “LEARN” or “TRAINING” button. This can usually be found where the hanging antenna wire is attached to the garage door opener motor. Firmly press and release the “LEARN”...
  • Page 124: Power Inverter

    ELECTRONICS Using HomeLink® • To operate, press and release the programmed HomeLink ® button. Activation will now occur for the programmed device (i.e., garage door opener, gate operator, security system, entry door lock, home/office lighting, etc.,). The hand-held transmitter of the device may also be used at any time. WARNING! •...
  • Page 125: Power Outlets

    ELECTRONICS POWER OUTLETS • The auxiliary 12 Volt (13 Amp) power outlets can provide power for in-cab accessories designed for use with the standard “cigar lighter” plug. The 12 Volt power outlets have a cap attached to the outlet indicating “12V DC”, together with either a key symbol or a battery symbol.
  • Page 126 ELECTRONICS • The rear center console power outlet can be switched to “battery” powered all the time by switching the power outlet right rear quarter panel fuse in the fuse panel.
  • Page 127: Off-Road Capabilities

    OFF-ROAD CAPABILITIES FOUR WHEEL DRIVE OPERATION FOUR-POSITION/PART TIME TRANSFER CASE • The transfer case provides four mode positions: • Two-wheel drive high range (2WD) • Four-wheel drive high range (4WD LOCK) • NEUTRAL (N) • Four-wheel drive low range (4WD LOW) •...
  • Page 128 OFF-ROAD CAPABILITIES FIVE-POSITION/ON-DEMAND TRANSFER CASE • This electronically shifted transfer case provides five mode positions: • Two-wheel drive high range (2WD) • Four-wheel drive automatic range (4WD AUTO) • Four-wheel drive lock range (4WD LOCK) • Four-wheel drive low range (4WD LOW) •...
  • Page 129 OFF-ROAD CAPABILITIES FIVE-POSITION/ON-DEMAND TRANSFER CASE • This electronically shifted transfer case provides five mode positions: • Two-wheel drive high range (2WD) • Four-wheel drive automatic range (4WD AUTO) • Four-wheel drive lock range (4WD LOCK) • Four-wheel drive low range (4WD LOW) •...
  • Page 130: Utility

    UTILITY TONNEAU COVER • The Tonneau Cover can be removed and reinstalled by using the locking clamps located underneath the Tonneau Cover. NOTE: Be sure that the Tonneau Cover is secured before driving. EASY-OFF TAILGATE • To simplify mounting of a camper unit with an overhang, the tailgate can be removed.
  • Page 131: Pickup Box

    UTILITY PICKUP BOX • You can carry wide building materials (sheets of plywood, etc.) by building a raised load floor. Place lumber across the box in the indentations provided above the wheel housings and in the bulkhead dividers to form the floor. •...
  • Page 132: Rambox

    UTILITY RAMBOX® • The RamBox system is an integrated pickup box storage and cargo management ® system consisting of three features: • Integrated box side storage bins • Cargo extender/divider • Bed rail tie-down system RamBox® Integrated Box Side Storage Bins •...
  • Page 133 UTILITY • Storage bins feature two removable drain plugs (to allow water to drain from bins). To remove plug, pull up on the edge. To install, push plug downward into drain hole. • The RamBox storage bins can be locked and unlocked using the vehicle key or ®...
  • Page 134 UTILITY Divider Position • There are 11 divider slots along the bed inner panels which allow for various positions to assist in managing your cargo. • To install the bed extender into a divider position perform the following: • Make sure the center handle is unlocked using the vehicle key and rotate the center handle vertically to release the extender side gates.
  • Page 135 UTILITY CAUTION! • Failure to follow the following items could cause damage to the vehicle: • Assure that all cargo inside the storage bins is properly secured. • Do not exceed cargo weight rating of 150 lb (68 kg) per bin. •...
  • Page 136: Towing & Payload

    UTILITY...
  • Page 137 UTILITY...
  • Page 138 UTILITY...
  • Page 139: Tow/Haul Mode

    UTILITY TOW/HAUL MODE • When driving in hilly areas, towing a trailer, carrying a heavy load, etc., and frequent transmission shifting occurs, press the TOW/HAUL switch to select TOW/HAUL mode. This will improve performance and reduce the potential for transmission overheating or failure due to excessive shifting. When operating in TOW/HAUL mode, transmission upshifts are delayed, and the transmission will automatically downshift (for engine braking) during steady braking maneuvers.
  • Page 140 UTILITY • Setting with a 3.5” EVIC Press the RIGHT arrow on the steering wheel to enter “VEHICLE SETTINGS.” • Press the UP or DOWN buttons until Trailer Brake Type appears on the screen. • Press the RIGHT arrow and then press the UP or DOWN buttons until the proper Trailer Brake Type appears on the screen.
  • Page 141: Recreational Towing (Behind Motorhome, Etc.)

    UTILITY RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Wheels OFF The Two-Wheel Four-Wheel Drive Models Condition Ground Drive Models See Instructions: • Automatic transmission in PARK • Manual transmission in gear Flat Tow NONE NOT ALLOWED (NOT in NEUTRAL) •...
  • Page 142 UTILITY Recreational Towing – Four-Wheel Drive Models NOTE: Both the manual shift and electronic shift transfer cases must be shifted into NEUTRAL (N) for recreational towing. Automatic transmissions must be shifted into PARK for recreational towing. Manual transmissions must be placed in gear (NOT in NEUTRAL) for recreational towing.
  • Page 143 UTILITY Shifting Into NEUTRAL (N) Use the following procedure to prepare your vehicle for recreational towing. WARNING! You or others could be injured or killed if you leave the vehicle unattended with the transfer case in the NEUTRAL (N) position without first fully engaging the parking brake.
  • Page 144 UTILITY 11. Shift the transmission into PARK or place manual transmission in gear (NOT in Neutral). On 8-speed transmissions the shifter will automatically select PARK when the engine is turned off. 12. Turn the ignition switch to the OFF position, then cycle the key or the Keyless Enter-N-Go™...
  • Page 145 UTILITY NOTE: When shifting out of transfer case NEUTRAL (N), turning the engine OFF is not required, but may be helpful to avoid gear clash. With the 8-speed automatic transmission, the engine must remain running, since turning the engine OFF will shift the transmission to PARK (and the transmission must be in NEUTRAL for the transfer case to shift out of NEUTRAL).
  • Page 146: 1500 3.0L Diesel

    1500 3.0L DIESEL DIESEL ENGINE BREAK-IN RECOMMENDATIONS • The 3.0 turbocharged diesel engine does not require a break-in period due to its construction. Normal operation is allowed, providing the following recommenda- tions are followed: • Warm up the engine before placing it under load. •...
  • Page 147: Diesel Fuel Filter/Water Separator

    1500 3.0L DIESEL CAUTION! If the “Water in Fuel Indicator Light” remains on, DO NOT START the engine before you drain the water from the fuel filters to avoid engine damage. Refer to “Maintenance Procedures/Draining Fuel/Water Separator Filter” in “Maintaining Your Vehicle”...
  • Page 148: Exhaust Regeneration

    1500 3.0L DIESEL Fuel Filter Replacement 1. Ensure engine is turned off. 2. Place drain pan under the fuel filter assembly. 3. Open the water drain valve, and let any accumulated water drain. 4. Close the water drain valve. 5. Remove bottom cover using a strap wrench. Rotate counterclockwise for removal. Remove the used o-ring and discard it.
  • Page 149 1500 3.0L DIESEL Perform Service • Your vehicle will require emissions maintenance at a set interval. To help remind you when this maintenance is due, the Electronic Vehicle Information Center (EVIC) will display “Perform Service”. • When the “Perform Service” message is displayed on the EVIC it is necessary to have the emissions maintenance performed.
  • Page 150 1500 3.0L DIESEL COOL-DOWN IDLE CHART TURBO "COOL DOWN" CHART Idle Time (in minutes) Driving Conditions Load Turbo Temp Before Shut Down Stop and Go Empty Cool Less than 1 Stop and Go Medium Warm Highway Speeds Medium Warm City Traffic Max.
  • Page 151: Diesel Exhaust Fluid

    1500 3.0L DIESEL DIESEL EXHAUST FLUID • Diesel Exhaust Fluid (DEF) sometimes known simply by the name of its active component, UREA—is a key component of selective catalytic reduction (SCR) systems, which help diesel vehicles meet stringent emission regulations. DEF is a liquid reducing agent that reacts with engine exhaust in the presence of a catalyst to convert smog-forming nitrogen oxides (NOx) into harmless nitrogen and water vapor.
  • Page 152 1500 3.0L DIESEL Adding Diesel Exhaust Fluid • The DEF gauge (located in the instrument panel) will display the level of DEF remaining in the tank. • Completely fill the DEF tank through the diesel exhaust fluid fill location (located behind the fuel door) at every maintenance interval or before if prompted by the Electronic Vehicle Information Center (EVIC).
  • Page 153 1500 3.0L DIESEL CAUTION! • To avoid DEF spillage and overfilling, do not “top off” the DEF tank after filling. • When DEF is spilled, clean the area immediately with water or a mild solvent. • DO NOT OVERFILL. DEF will freeze below 12 degrees F (-11 degrees C). The DEF system is designed to work in temperatures below the DEF freezing point, however, if the tank is overfilled and freezes, the system could be damaged.
  • Page 154 1500 3.0L DIESEL Diesel Exhaust Fluid (DEF) Fault Warning Messages • There are different messages which are displayed if the vehicle detects that the DEF system has been filled with a fluid other than DEF, has experienced component failures, or when tampering has been detected. •...
  • Page 155: Diesel Engine Starting Procedures

    6.7L CUMMINS® DIESEL DIESEL ENGINE BREAK-IN RECOMMENDATIONS • The Cummins ® turbocharged diesel engine does not require a break-in period due to its construction. Normal operation is allowed, providing the following recom- mendations are followed: • Warm up the engine before placing it under load. •...
  • Page 156: Diesel Exhaust Brake (Engine Braking)

    6.7L CUMMINS® DIESEL Cold Start Procedure • Turn the ignition switch to the ON position. If the Wait To Start light appears in the cluster, wait for the light to turn off before starting. • In extremely cold weather below 0°F (-18°C) it may be beneficial to cycle the manifold heaters twice before attempting to start the engine.
  • Page 157: Idle-Up Feature (Automatic Transmission Only)

    6.7L CUMMINS® DIESEL CAUTION! Use of aftermarket exhaust brakes is not recommended and could lead to engine damage. WARNING! Do not use the exhaust brake feature when driving in icy or slippery conditions as the increased engine braking can cause the rear wheels to slide and the vehicle to swing around with the possible loss of vehicle control, which may cause a collision possibly resulting in personal injury or death.
  • Page 158: Engine Mounted Fuel Filter/Water Separator

    6.7L CUMMINS® DIESEL ENGINE MOUNTED FUEL FILTER/WATER SEPARATOR Draining Fuel/Water Separator • If the “Water in Fuel” indicator light is illuminated and an audible chime is heard five times, you should stop the engine and drain the water from the separator.
  • Page 159: Underbody Mounted Fuel Filter/Water Separator

    6.7L CUMMINS® DIESEL CAUTION! • Diesel fuel will damage blacktop paving surfaces. Drain the filter into an appropriate container. • Do not prefill the fuel filter when installing a new fuel filter. There is a possibility debris could be introduced into the fuel filter during this action. It is best to install the filter dry and allow the in-tank lift pump to prime the fuel system.
  • Page 160: Exhaust Regeneration

    6.7L CUMMINS® DIESEL The underbody mounted filter housing will cause the engine not to run if: 1. No filter is installed. NOTE: • Using a fuel filter that does not meet the manufacturer's filtration and water separating requirements can severely impact fuel system life and reliability. •...
  • Page 161: Cool-Down Idle Chart

    6.7L CUMMINS® DIESEL Exhaust System — Regeneration Required Now • “Exhaust System—Regeneration Required Now” will be displayed on the EVIC if the exhaust particulate filter reaches 80% of its maximum storage capacity. Exhaust Filter XX% Full • Indicates that the Diesel Particulate Filter (DPF) is approaching full. Exhaust System —...
  • Page 162: Adding Fuel - Diesel Engine Only

    6.7L CUMMINS® DIESEL ADDING FUEL – DIESEL ENGINE ONLY • Your vehicle is equipped with a cap-less fuel system. • Most fuel cans will not open the flapper door. • A funnel is provided to open the flap- per door to allow emergency refueling with a fuel can.
  • Page 163: Diesel Exhaust Fluid

    6.7L CUMMINS® DIESEL DIESEL EXHAUST FLUID • Diesel Exhaust Fluid (DEF) sometimes known simply by the name of its active component, UREA—is a key component of selective catalytic reduction (SCR) systems, which help diesel vehicles meet stringent emission regulations. DEF is a liquid reducing agent that reacts with engine exhaust in the presence of a catalyst to convert smog-forming nitrogen oxides (NOx) into harmless nitrogen and water vapor.
  • Page 164 6.7L CUMMINS® DIESEL Diesel Exhaust Fluid Storage • Diesel Exhaust Fluid (DEF) is considered a very stable product with a long shelf life. If DEF is kept in temperatures between 10° to 90°F (-12° to 32°C), it will last a minimum of one year. •...
  • Page 165: Diesel Exhaust Fluid Warning Messages

    6.7L CUMMINS® DIESEL DEF Fill Procedure • Remove cap from DEF tank (located behind the fuel door on drivers side of the vehicle). • Insert DEF container or fill nozzle into DEF fill location and fill DEF tank. • Reinstall cap onto DEF tank. •...
  • Page 166: Diesel Exhaust Fluid Fault Warning Messages

    6.7L CUMMINS® DIESEL • 5 MPH Max Speed on Restart, Long Idle or Refuel Refill DEF – This message will continuously display when the counter reaches zero, and will be accompanied by a periodic chime. The vehicle will only be capable of a maximum speed of 5 MPH upon the first of the following conditions to occur: •...
  • Page 167 6.7L CUMMINS® DIESEL NOTE: Under some circumstances this mileage counter may start with a value of less than 150 miles (241 km). For example, if recurring faults are detected in a time interval of less than 40 hours, the counter may restart at the value where it stopped when a previous fault was temporarily remedied, or at a minimum of 50 miles (80 km).
  • Page 168: What To Do In Emergencies

    WHAT TO DO IN EMERGENCIES ROADSIDE ASSISTANCE • Dial toll-free 1-800-521-2779 for U.S. Residents or 1-800-363-4869 for Cana- dian Residents. • Provide your name, vehicle identification number, license plate number, and your location, including the telephone number from which you are calling. •...
  • Page 169 WHAT TO DO IN EMERGENCIES • Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly. The TPMS malfunction indicator is combined with the low tire pressure telltale. When the system detects a malfunction, the telltale will flash for approximately one minute and then remain continuously illuminated.
  • Page 170 WHAT TO DO IN EMERGENCIES BRAKE - Brake Warning Light • This light monitors various brake functions, including brake fluid level and parking brake application. If the brake light turns on it may indicate that the parking brake is applied, that the brake fluid level is low, or that there is a problem with the anti-lock brake system reservoir.
  • Page 171 WHAT TO DO IN EMERGENCIES - Malfunction Indicator Light (MIL) • The Malfunction Indicator Light (MIL) is part of an onboard diagnostic system called OBD II that monitors engine and automatic transmission control systems. The light will illuminate when the key is in the ON/RUN position before engine start.
  • Page 172 WHAT TO DO IN EMERGENCIES - Anti-Lock Brake (ABS) Light • This light monitors the Anti-Lock Brake System (ABS). The light will turn on when the ignition switch is turned to the ON/RUN position and may stay on for as long as four seconds.
  • Page 173 WHAT TO DO IN EMERGENCIES - Transmission Temperature Warning Light • This light indicates that there is excessive transmission fluid temperature that might occur with severe usage such as trailer towing. If this light turns on, stop the vehicle and run the engine at idle, with the transmission in NEUTRAL, until the light turns off.
  • Page 174: If Your Engine Overheats

    WHAT TO DO IN EMERGENCIES IF YOUR ENGINE OVERHEATS • In any of the following situations, you can reduce the potential for overheating by taking the appropriate action. • On the highways — slow down. • In city traffic — while stopped, shift the transmission to NEUTRAL, but do not increase engine idle speed.
  • Page 175: Jacking And Tire Changing

    WHAT TO DO IN EMERGENCIES JACKING AND TIRE CHANGING Jack Location • The jack and jack tools are stored under the front passenger seat. Removal Of Jack And Tools • To access the jack and jack tools you must remove the plastic access cover, located on the side of the seat.
  • Page 176 WHAT TO DO IN EMERGENCIES 2500/3500 Series Trucks • Remove the jack and tool bracket assembly by removing the wing bolt and sliding the jack and tool bracket assembly from under the seat. Removing The Spare Tire • Remove the spare tire before attempting to jack up the truck. Attach the wheel wrench to the jack extension tube.
  • Page 177 WHAT TO DO IN EMERGENCIES Preparations 1. Park the vehicle on a firm, level surface. Avoid ice or slippery areas. 2. Turn on the Hazard Warning flasher. 3. Set the parking brake. 4. Place the shift lever into PARK. On four-wheel drive vehicles, shift the transfer case to the 4L position.
  • Page 178 WHAT TO DO IN EMERGENCIES 3. Placement of the jack: 1500 Series Trucks • When changing a front wheel, place the scissors jack under the rear portion of the lower control arm as shown below.
  • Page 179 WHAT TO DO IN EMERGENCIES • Operate the jack using the jack drive tube and the wheel wrench. The tube extension may be used but is not required. • For 4x2 and 4x4 trucks, when changing a rear wheel, assemble the jack drive tube to the jack and connect the drive tube to the extension tube.
  • Page 180 WHAT TO DO IN EMERGENCIES 2500/3500 Series Trucks • For 2500/3500 4x2 series trucks, when changing a front wheel, place the bottle jack under the frame rail behind the wheel. Locate the jack as far forward as possible on the straight part of the frame. •...
  • Page 181 WHAT TO DO IN EMERGENCIES • For 4x2 and 4x4 trucks, when changing a rear wheel, assemble the jack drive tube to the jack and connect the drive tube to the extension tube. Place the jack under the axle between the spring and the shock absorber with the drive tubes extending to the rear.
  • Page 182 WHAT TO DO IN EMERGENCIES Reinstalling The Jack And Tools 1500 Series Trucks 1. Tighten the jack all the way down by turning the jack turn-screw clockwise until the jack is snug. 2. Position the jack and tool bag. Make sure the lug wrench is under the jack near the jack turn-screw.
  • Page 183 WHAT TO DO IN EMERGENCIES 5. Turn the wing bolt clockwise to secure to the floor pan. Reinstall the plastic cover. 2500/3500 Series Trucks 1. Tighten the jack all the way down by turning the jack turn-screw clockwise until the jack is snug. 2.
  • Page 184 WHAT TO DO IN EMERGENCIES Hub Caps/Wheel Covers • The hub caps must be removed before raising the vehicle off the ground. • For single rear-wheel (SRW) models, use the blade on the end of the lug wrench to pry the hub cap off. Insert the blade end into the pry-off notch and carefully pop off the hub cap with a back-and-forth motion.
  • Page 185 WHAT TO DO IN EMERGENCIES 8-Stud — Dual Rear Wheels • Dual wheels are flat-mounted and center-piloted. The lug nuts are a two-piece assembly. When the tires are being rotated or replaced, clean these lug nuts and add two drops of oil at the interface between the hex and the washer. •...
  • Page 186 WHAT TO DO IN EMERGENCIES To Stow The Flat Or Spare NOTE: RAM 1500 vehicles equipped with aluminum wheels cannot be stored under the vehicle because the wheel retainer will not fit through the wheel pilot hole. Secure the flat tire in the bed of the truck. Have the flat tire repaired or replaced immediately.
  • Page 187 WHAT TO DO IN EMERGENCIES WARNING! • Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel. •...
  • Page 188: Jump-Starting

    WHAT TO DO IN EMERGENCIES JUMP-STARTING • If your vehicle has a discharged bat- tery it can be jump-started using a set of jumper cables and a battery in an- other vehicle or by using a portable battery booster pack. •...
  • Page 189 WHAT TO DO IN EMERGENCIES Once the engine is started, remove the jumper cables in the reverse sequence: 1. Disconnect the negative (-) jumper cable from the engine ground of the vehicle with the discharged battery. 2. Disconnect the negative end (-) of the jumper cable from the negative (-) post of the booster battery.
  • Page 190: Emergency Tow Hooks

    WHAT TO DO IN EMERGENCIES WARNING! • When temperatures are below the freezing point, electrolyte in a discharged battery may freeze. Do not attempt jump-starting because the battery could rupture or explode and cause personal injury. Battery temperature must be brought above the freezing point before attempting a jump-start.
  • Page 191: Shift Lever Override

    WHAT TO DO IN EMERGENCIES SHIFT LEVER OVERRIDE • If a malfunction occurs and the shift lever cannot be moved out of the PARK position, you can use the following procedure to temporarily move the shift lever. • Have your vehicle inspected by your local authorized dealer immediately if the shift lever override has been used.
  • Page 192 WHAT TO DO IN EMERGENCIES MANUAL PARK RELEASE — EIGHT SPEED TRANSMISSION • In order to push or tow the vehicle in cases where the transmission will not shift out of PARK (such as a dead battery), a Manual Park Release is available. •...
  • Page 193 WHAT TO DO IN EMERGENCIES • While holding the locking tab in the disengaged position, pull the tether strap to rotate the lever rearward, until it locks in place pointing towards the driver's seat. Release the locking tab and verify that the Manual Park Release lever is locked in the released position.
  • Page 194: Towing A Disabled Vehicle

    WHAT TO DO IN EMERGENCIES...
  • Page 195: Freeing A Stuck Vehicle

    WHAT TO DO IN EMERGENCIES FREEING A STUCK VEHICLE • If your vehicle becomes stuck in mud, sand or snow, it can often be moved by a rocking motion. Turn your steering wheel right and left to clear the area around the front wheels.
  • Page 196: Event Data Recorder (Edr)

    WHAT TO DO IN EMERGENCIES EVENT DATA RECORDER (EDR) • This vehicle is equipped with an Event Data Recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.
  • Page 197: Maintaining Your Vehicle

    MAINTAINING YOUR VEHICLE OPENING THE HOOD • Pull the hood release lever located below the steering wheel at the base of the instrument panel. • Reach into the opening beneath the center of the hood and move the safety latch lever while lifting the hood at the same time.
  • Page 198: Engine Compartment

    MAINTAINING YOUR VEHICLE...
  • Page 199 MAINTAINING YOUR VEHICLE...
  • Page 200 MAINTAINING YOUR VEHICLE...
  • Page 201 MAINTAINING YOUR VEHICLE...
  • Page 202 MAINTAINING YOUR VEHICLE...
  • Page 203 MAINTAINING YOUR VEHICLE...
  • Page 204: Fluids And Capacities

    MAINTAINING YOUR VEHICLE FLUIDS AND CAPACITIES Gasoline Versions Component Fluid, Lubricant, or Genuine Part Capacities We recommend you use MOPAR ® Engine Coolant Antifreeze/Coolant 10 Year/150,000 Mile 14 Quarts 3.6L Engine Formula OAT (Organic Additive (13 Liters) Technology). We recommend you use MOPAR ®...
  • Page 205 MAINTAINING YOUR VEHICLE Component Fluid, Lubricant, or Genuine Part Capacities For best performance and maximum pro- tection under all types of operating condi- tions, the manufacturer only recommends full synthetic engine oils that meet the American Petroleum Institute (API) cat- Engine Oil with 6.4L Engine - egories of SN.
  • Page 206 MAINTAINING YOUR VEHICLE Component Fluid, Lubricant, or Genuine Part Capacities Power Steering We recommend you use MOPAR ® Power Reservoir – 2500/ Steering Fluid +4 or MOPAR ATF+4 — ® ® 3500 Models Automatic Transmission Fluid. 1500 Regular Cab Shortbed/Crew Quad Cab - 26 Gal- lons (98 Liters) (Approximate)
  • Page 207 MAINTAINING YOUR VEHICLE Diesel Versions Component Fluid, Lubricant, or Genuine Part Capacities Engine Coolant We recommend you use MOPAR ® Antifreeze/ 3.0 L Turbo Diesel 11.6 Quarts Coolant Ten Year/150,000 Mile Formula OAT Engine – 1500 (11 Liters) (Organic Additive Technology). Models Only Engine Coolant We recommend you use MOPAR...
  • Page 208 MAINTAINING YOUR VEHICLE Component Fluid, Lubricant, or Genuine Part Capacities Use good quality diesel fuel from a repu- table supplier in your vehicle. Federal law requires that you must fuel this vehicle with Ultra Low Sulfur Highway Diesel fuel (15 ppm Sulfur maximum) and prohibits the use of Low Sulfur Highway Diesel fuel (500 ppm Sulfur maximum) to avoid damage to the emissions control system.
  • Page 209 MAINTAINING YOUR VEHICLE Component Fluid, Lubricant, or Genuine Part Capacities Use good quality diesel fuel from a repu- table supplier in your vehicle. Federal law requires that you must fuel this vehicle with Ultra Low Sulfur Highway Diesel fuel (15 ppm Sulfur maximum) and prohibits the use of Low Sulfur Highway Diesel fuel (500 ppm Sulfur maximum) to avoid damage to the emissions control system.
  • Page 210 MAINTAINING YOUR VEHICLE Component Fluid, Lubricant, or Genuine Part Capacities Automatic Trans- mission – Eight- We recommend you use MOPAR ZF 8&9 ® Speed Automatic Speed ATF™ Automatic Transmission — 3.0 Turbo Diesel – Fluid. 1500 Models Only Automatic Transmission – We recommend you use MOPAR ATF+4 ®...
  • Page 211: Maintenance Schedule - Gasoline Engine

    MAINTAINING YOUR VEHICLE CAUTION! • Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion protection. Organic Additive Technology (OAT) engine coolant is different and should not be mixed with Hybrid Organic Additive Technology (HOAT) engine coolant (antifreeze) or any “globally compatible”...
  • Page 212 MAINTAINING YOUR VEHICLE NOTE: 1500 Models Only • Under no circumstances should oil change intervals exceed 10,000 miles (16,000 km) or twelve months on 1500 trucks, whichever comes first. 2500 – 3500 Models • Under no circumstances should oil change intervals exceed 8,000 miles (13,000 km) or twelve months on 2500 –...
  • Page 213 MAINTAINING YOUR VEHICLE...
  • Page 214 MAINTAINING YOUR VEHICLE...
  • Page 215 MAINTAINING YOUR VEHICLE...
  • Page 216: Maintenance Schedule - 1500 3.0L Diesel Engine

    MAINTAINING YOUR VEHICLE MAINTENANCE SCHEDULE — 1500 3.0L DIESEL ENGINE Your vehicle is equipped with an automatic oil change indicator system. The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance.
  • Page 217 MAINTAINING YOUR VEHICLE...
  • Page 218 MAINTAINING YOUR VEHICLE...
  • Page 219 MAINTAINING YOUR VEHICLE MAINTENANCE SCHEDULE — B6 TO B20 BIODIESEL (1500 DIESEL) NOTE: • Under no circumstances should oil change intervals exceed 8,000 miles (12 875 km) or six months, whichever comes first when using Biodiesel blends greater than 5% (B5).
  • Page 220 MAINTAINING YOUR VEHICLE...
  • Page 221 MAINTAINING YOUR VEHICLE...
  • Page 222: Maintenance Schedule - 6.7L Cummins® Diesel Engine

    MAINTAINING YOUR VEHICLE MAINTENANCE SCHEDULE — 6.7L CUMMINS® DIESEL ENGINE CAUTION! Failure to perform the required maintenance items may result in damage to the vehicle. At Each Stop For Fuel • Check the engine oil level at least 30 minutes after a fully warmed engine is shut off.
  • Page 223 MAINTAINING YOUR VEHICLE For information on resetting the Oil Change Indicator message, refer to “Oil Change Due” under “Electronic Vehicle Information Center (EVIC)/EVIC Warning Lights” in “Understanding Your Instrument Panel” for further information. Replace the engine oil and oil filter every 15,000 miles (24 000 km) or six months, or sooner if prompted by the oil change indicator system.
  • Page 224 MAINTAINING YOUR VEHICLE...
  • Page 225 MAINTAINING YOUR VEHICLE...
  • Page 226 MAINTAINING YOUR VEHICLE...
  • Page 227: Fuses

    MAINTAINING YOUR VEHICLE FUSES POWER DISTRIBUTION CENTER (FUSES) • The Power Distribution Center is lo- cated in the engine compartment near the battery. This center contains car- tridge fuses and mini fuses. A descrip- tion of each fuse and component may be stamped on the inside cover, other- wise the cavity number of each fuse is stamped on the inside cover that cor-...
  • Page 228 MAINTAINING YOUR VEHICLE Cavity Cartridge Fuse Micro Fuse Description 30 Amp Pink Electric Park Brake Right Side – If Equipped 30 Amp Pink SCR – If Equipped 30 Amp Pink Passenger Door Module 30 Amp Pink Drive Train Control Module 20 Amp Yellow Engine Control Module 30 Amp Pink...
  • Page 229 MAINTAINING YOUR VEHICLE Cavity Cartridge Fuse Micro Fuse Description 10 Amp Red Ignition Node Module / Keyless Ignition 5 Amp Tan Battery Sensor 20 Amp Yellow Trailer Tow – Left Turn/Stop Lights 20 Amp Yellow Adjustable Pedals 20 Amp Yellow E38 Radio –...
  • Page 230 MAINTAINING YOUR VEHICLE Cavity Cartridge Fuse Micro Fuse Description 15 Amp Blue Clearance Lights 10 Amp Red Universal Garage Door Opener / Compass 20 Amp Yellow Trailer Tow Right Turn/Stop Lights 10 Amp Red Steering Column Control Module/ Cruise Control 15 Amp Blue Switch Bank/Instrument Cluster 10 Amp Red...
  • Page 231: Tire Pressures

    MAINTAINING YOUR VEHICLE TIRE PRESSURES • Check the inflation pressure of each tire, including the spare tire, at least monthly and inflate to the recommended pressure for your vehicle. • The tire pressures recommended for your vehicle are found on the “Tire and Loading Information”...
  • Page 232: Wheel And Wheel Trim Care

    MAINTAINING YOUR VEHICLE WHEEL AND WHEEL TRIM CARE • All wheels and wheel trim, especially aluminum and chrome plated wheels, should be cleaned regularly with a mild soap and water to prevent corrosion. • To remove heavy soil and/or excessive brake dust, use MOPAR ®...
  • Page 233: Customer Assistance

    CUSTOMER ASSISTANCE CHRYSLER GROUP LLC CUSTOMER CENTER P.O. Box 21–8004 Auburn Hills, MI 48321–8004 Phone: 1–866–726–4636 CHRYSLER CANADA INC. CUSTOMER CENTER P.O. Box 1621 Windsor, Ontario N9A 4H6 Phone: 1–800–465–2001 (English) Phone: 1–800–387–9983 (French) ASSISTANCE FOR THE HEARING IMPAIRED • To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommunication Devices for the Deaf) equipment at its customer center.
  • Page 234: Reporting Safety Defects In The United States

    • A street address is required when ordering manuals (no P.O. Boxes). • The Owner's Manual and User Guide electronic files are also available on the Chrysler, Jeep, Ram Truck, Dodge and SRT websites. • Click on the “For Owners” tab, select “Owner/Service Manuals”, then select your desired model year and vehicle from the drop down lists.
  • Page 235: Mopar Accessories

    MOPAR ACCESSORIES AUTHENTIC ACCESSORIES BY MOPAR® The following highlights just some of the many Authentic Ram Truck Accessories by Mopar ® featuring a fit, finish, and functionality specifically for your Ram Truck. In choosing Authentic Accessories you gain far more than expressive style, premium protection, or extreme entertainment, you also benefit from enhancing your vehicle with accessories that have been thoroughly tested and factory-approved.
  • Page 236: Index

    INDEX Adjustable Pedals ...29 Dimmer Control... . .32 Airbag ....16 Disarming, Security System .
  • Page 237 INDEX High Beam ... . .31 New Vehicle Break-In Switch ....32 Period ..30, 144, 153 Heated Steering Wheel .
  • Page 238 INDEX Schedule, Maintenance ..209, 214 Tow/Haul ....137 Seat Belts ....15 Tow Hooks, Emergency .
  • Page 239: Faq (How To?)

    FAQ (How To?) FREQUENTLY ASKED QUESTIONS GETTING STARTED How do I install my LATCH Equipped Child Seat? pg. 17 How do I program my Front Seat Memory? pg. 25 OPERATING YOUR VEHICLE How does the Electronic Range Select (ERS) operate? pg. 35 ELECTRONICS Which radio is in my vehicle? •...
  • Page 240 FAQ (How To?) OFF-ROAD CAPABILITIES How do I shift into different four-wheel drive selections? pg. 125 UTILITY How do I know how much I can tow with my Ram Truck? pg. 134 How do I adjust the gain on the Integrated Trailer Brake Module? pg. 137 WHAT TO DO IN EMERGENCIES How do I change a flat tire? pg.
  • Page 241 NOTES...
  • Page 242 NOTES...
  • Page 243: Driving And Alcohol

    This guide has been prepared to help you get quickly acquainted with your new RAM and to provide a convenient reference source for common questions. However, it is not a substitute for your Owner’s Manual. For complete operational instructions, maintenance procedures and important safety messages, please consult your Owner’s Manual, Navigation/Uconnect Manuals and other Warning Labels in your vehicle.
  • Page 244 Download a free electronic copy of the Owner’s Manual or Warranty Booklet by visiting the Owners tab at www.ramtrucks.com (U.S.) or www.ramtruck.ca (Canada). 14D241-926-AA RAM Trucks 1500/2500/3500 Second Edition User Guide...

This manual is also suitable for:

Ram 3500Ram 25002014 ram 35002014 ram 2500

Table of Contents

Save PDF
