Page 1: Introduction
TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 3: Table Of Contents
CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .
Page 4: Introduction
4 INTRODUCTION INTRODUCTION This manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your new vehicle. It is supplemented by a Warranty Information Booklet and various customer oriented documents. You are urged to read these publications carefully.
Page 5 INTRODUCTION 5...
Page 6: Van Conversions/Campers
6 INTRODUCTION WARNINGS AND CAUTIONS This manual contains WARNINGS against operating procedures which could result in an accident or bodily injury. It also contains CAUTIONS against procedures which could result in damage to your vehicle. If you do not read this entire manual you may miss important information.
Page 7: Vehicle Identification Number
VEHICLE IDENTIFICATION NUMBER The vehicle identification number (VIN) is found on the left front corner of the instrument panel, visible through the windshield. This number also appears on the Auto- mobile Information Disclosure Label affixed to a window on your vehicle, the vehicle registration and title. Vehicle Identification Number NOTE: It is illegal to remove the VIN.
Page 9 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS Power Wagon: Things To Know Before Starting Your Vehicle ......12 Features .
Page 10 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Security Alarm System — If Equipped ..19 Rearming Of The System ....20 To Set The Alarm .
Page 11 Enhanced Seat Belt Reminder System (BeltAlert) ......45 Seat Belts And Pregnant Women ... .46 Seat Belt Extender .
Page 12: Power Wagon: Things To Know Before Starting Your Vehicle
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE POWER WAGON: THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Your Power Wagon is a specialty vehicle, equipped with several features not available on other production trucks. It is very important that you read the following sections of the owner’s manual before operation.
Page 13: Ignition Key Removal
Ignition Key Removal Automatic Transmission Place the shift lever in PARK. Turn the ignition switch to the LOCK position, and remove the key. Ignition Switch Positions THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 NOTE: If you try to remove the key before you place the lever in PARK, the key may become trapped temporarily in the ignition cylinder.
Page 14 14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Never leave children alone in a vehicle. Leaving children in a vehicle unattended is dangerous for a number of reasons. A child or others could be seri- ously or fatally injured. Don’t leave the keys in the ignition.
Page 15: Locking Doors With The Key
Ignition Key Release Button Locking Doors With The Key You can insert the key with either side up. To lock the door, turn the key rearward, to unlock the door, turn the key forward. See Section 7 of this manual for door lock lubrication.
Page 16: Replacement Keys
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE turn on for three (3) seconds for a bulb check. If the light remains on after the bulb check, it indicates that there is a problem with the electronics. In addition, if the light begins to flash after the bulb check, it indicates that someone used an invalid key to start the engine.
Page 17: Customer Key Programming
CAUTION! Always remove Sentry Keys from the vehicle and lock all doors when leaving the vehicle unattended. At the time of purchase, the original owner is provided with a four-digit PIN number. Keep the PIN in a secure location. This number is required for dealer replacement of keys.
Page 18: General Information
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Insert a blank Sentry Key into the ignition switch. Turn the ignition switch to the “ON” position within 60 seconds. After 10 seconds, a single chime will sound. In addition, the Vehicle Security Alarm Indicator Light will stop flashing.
Page 19: Steering Wheel Lock - If Equipped
STEERING WHEEL LOCK — IF EQUIPPED Your vehicle may be equipped with a passive steering wheel lock. This lock prevents steering the vehicle with- out the ignition key. If the steering wheel is moved no more than 1/2 turn in either direction and the key is not in the ignition switch, the steering wheel will lock.
Page 20: Rearming Of The System
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Rearming of the System: The security system will rearm itself after the 15 addi- tional minutes of headlights and security telltale flashing, if the system has not been disabled. If the condition which initiated the alarm is still present, the system will ignore that condition and monitor the remaining doors and ignition.
Page 21: Illuminated Entry System - If Equipped
The Security Alarm System is designed to protect your vehicle; however, you can create conditions where the system will arm unexpectedly. If you remain in the vehicle and lock the doors with the transmitter, the alarm will sound when you pull the door handle to exit. The door will be locked but the Security Alarm will not arm.
Page 22: To Unlock The Doors
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE This system allows you to lock or unlock the doors from distances up to about 23 feet (7 meters) using a hand held radio transmitter. The transmitter need not be pointed at the vehicle to activate the system.
Page 23: Using The Panic Alarm
1. Perform this operation while standing outside the vehicle. 2. Press and hold the LOCK button on a programmed (i.e. functional) key fob. 3. Continue to hold the LOCK button, wait at least 4 seconds, but no longer than 10 seconds, then press and hold the PANIC button.
Page 24: General Information
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE General Information This device complies with part 15 of FCC rules and with RS-210 of Industry Canada. Operation is subject to the following conditions: 1. This device may not cause harmful interference. 2.
Page 25: Remote Starting System - If Equipped
NOTE: Perchlorate Material – special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate The recommended replacement battery is CR2032. NOTE: Do not touch the battery terminals that are on the back housing or the printed circuit board. 1. With transmitter buttons facing down, use a flat blade or dime to pry the two halves of the transmitter apart.
Page 26 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To remote start your vehicle, press the REMOTE START button on the key fob twice within three seconds. To indicate that the vehicle is about to start, the parking lights will flash and the horn will sound briefly. Remote Start Transmitter Once the vehicle has started, the engine will run for 15 minutes.
Page 27: Door Locks
Remote start will also cancel if any of the following occur: • If the engine stalls or RPM exceeds 2500 • Any engine warning lamps come on • The hood is opened • The hazard switch is pressed • The transmission is moved out of park •...
Page 28: Power Door Locks - If Equipped
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • For personal security and safety in the event of an accident, lock the vehicle doors when you drive as well as when you park and leave the vehicle. • Never leave children alone in a vehicle. Leaving children in a vehicle unattended is dangerous for a number of reasons.
Page 29 chime will sound if the key is in the ignition switch and a door is open, as a reminder to remove the key. Automatic Door Locks – If Equipped If this feature is enabled, your door locks will lock automatically when the vehicle’s speed exceeds 15 mph. Automatic Door Lock Programming This feature is enabled when your vehicle is shipped from the assembly plant and can be disabled by using the...
Page 30 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Auto Unlock On Exit — If Equipped This feature unlocks all of the doors of the vehicle when any door is opened. This will occur only after the vehicle has been shifted into the Park position after the vehicle has been driven (shifted out of Park and all doors closed).
Page 31: Child Protection Door Lock
Child Protection Door Lock To provide a safer environment for children riding in the rear seat, the rear doors of your vehicle have the child- protection door lock system. Child Protection Door Lock Location THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 To use the system, open each rear door, slide the lever UP to engage the locks and DOWN to disengage the child- protection locks.
Page 32: Windows
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Avoid trapping anyone in a vehicle in a collision. Remember that the rear doors can only be opened from the outside when the child protection locks are engaged. NOTE: After setting the child protection door lock system, always test the door from the inside to make certain it is in the desired position.
Page 33 The control on the left front door panel has up-down switches that give you fingertip control of all power windows. There is a single opening and closing switch on the front passenger door for passenger window control and on the rear doors of Quad Cab and Mega Cab models.
Page 34: Wind Buffeting
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Window Lockout Switch (4 Door Models Only) The window lockout switch on the driver’s door allows you to disable the window control on the other doors. To disable the window controls on the other doors, press the window lock button.
Page 35: Lap/Shoulder Belts
Please pay close attention to the information in this section. It tells you how to use your restraint system properly to keep you and your passengers as safe as possible. WARNING! In a collision, you and your passengers can suffer much greater injuries if you are not properly buckled up.
Page 36 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and seat belts.
Page 37 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the seat. 2. The seat belt latch plate is above the back of the front seat, next to your arm in the rear seat. Grasp the latch plate and pull out the belt.
Page 38 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Latch Plate To Buckle WARNING! • A belt buckled into the wrong buckle will not protect you properly.
Page 39 4. Position the lap belt across your thighs, below your abdomen. To remove slack in the lap belt portion, pull up on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt. A snug belt reduces the risk of sliding under the belt in a collision.
Page 40 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. To release the belt, push the red button on the buckle. The belt will automatically retract to its stowed position. If necessary, slide the latch plate down the webbing to allow the belt to retract fully. WARNING! A frayed or torn belt could rip apart in a collision and leave you with no protection.
Page 41 Detaching Buckle with Key 2. To reattach the seat belt to the front center seat, pull the black buckle latch plate forward from the cab back panel and insert it into the black keyed buckle until there is an audible click. Refer to the previous section for the proper seat belt usage.
Page 42 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Inserting Latch Plate In Use Position WARNING! If the black latch and buckle are not connected when the seat belt is used by an occupant, the seat belt will not restrain you properly.
Page 43: Adjustable Upper Shoulder Belt Anchorage
Adjustable Upper Shoulder Belt Anchorage In the front row outboard seats, the shoulder belt can be adjusted upward or downward to help position the belt away from your neck. Press the button located on the upper belt guide, and then move it up or down to the position that serves you best.
Page 44: Center Lap Belts
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How To Use The Automatic Locking Mode 1. Buckle the combination lap/shoulder belt. 2. Grasp the shoulder portion and pull downward until the entire belt is extracted. 3. Allow the belt to retract. As the belt retracts, you will hear a clicking sound.
Page 45: Seat Belt Pretensioners - If Equipped
Seat Belt Pretensioners — If Equipped The seat belts for both front seating positions are equipped with pretensioning devices that are designed to remove slack from the seat belt system in the event of a collision. These devices improve the performance of the seat belt by assuring that the belt is tight about the occupant early in a collision.
Page 46: Seat Belts And Pregnant Women
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The following steps must occur within the first 60 seconds of the ignition switch being turned to the ON or START position. DaimlerChrysler does not recom- mend deactivating the Enhanced Warning System (BeltAlert).
Page 47: Seat Belt Extender
Seat Belt Extender If a seat belt is too short, even when fully extended, your dealer can provide you with a seat belt extender. This extender should be used only if the existing belt is not long enough. When it is not required, remove the ex- tender and store it.
Page 48 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the instrument panel, above the glove compartment. The words SRS/AIRBAG are embossed on the airbag covers. NOTE: The front airbags are certified to the Federal regulations that allow less forceful deployment. The front airbags have a multistage inflator design. This may allow the airbag to have different rates of inflation that are based on collision severity and occupant size.
Page 49 NOTE: Do not use a clothing bar mounted to the coat hooks in this vehicle. A clothing bar will impede the proper performance of the window bags. Along with the seat belts, front airbags work with the instrument panel knee bolsters to provide improved protection for the driver and front passenger.
Page 50 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Children that are not big enough to properly wear the vehicle seat belt (see section on Child Restraints) should be secured in the rear seat in child restraints or belt- positioning booster seats. Older children who do not use child restraints or belt-positioning booster seats should ride properly buckled up in the rear seat.
Page 51 WARNING! • Relying on the airbags alone could lead to more severe injuries in a collision. The airbags work with your seat belt to restrain you properly. In some collisions the airbags won’t deploy at all. Always wear your seat belts even though you have airbags.
Page 52 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Driver and Front Passenger Seat Belt Pretensioners (If Equipped) • Driver Seat Track Position Sensor (If Equipped) • Passenger Side Frontal Airbag ON/OFF Switch (2500/ 3500 Standard Cab Vehicles Only) • Passenger Airbag Disable (PAD) Indicator Light (2500/3500 Standard Cab Vehicles Only) How the Airbag System Works •...
Page 53 WARNING! Ignoring the AIRBAG warning light in your instru- ment panel could mean you won’t have the airbags to protect you in a collision. If the light does not come on, stays on after you start the vehicle, or if it comes on as you drive, have the airbag system checked right away.
Page 54 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE collision requiring the airbags, it signals the inflator units. A large quantity of nontoxic gas is generated to inflate the front airbags. Different airbag inflation rates may be possible based on collision severity and occu- pant size.
Page 55 • The Knee Impact Bolsters help protect the knees of the driver and the front passenger, and position every- one for the best interaction with the front airbag. Passenger Airbag On/Off Switch – (2500/3500 Standard Cab Vehicles Only) THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 The passenger front airbag is to be turned off only if the passenger: •...
Page 56 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Whenever an airbag is turned off, even a lap/ shoulder belted passenger may hit their head, neck, or chest on the dashboard (instrument panel) or windshield in a crash. This may result in serious injury or death.
Page 57 If you do have a collision which deploys the airbags, any or all of the following may occur: • The nylon airbag material may sometimes cause abra- sions and/or skin reddening to the driver and front passenger as the airbags deploy and unfold. The abrasions are similar to friction rope burns or those you might get sliding along a carpet or gymnasium floor.
Page 58 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Maintaining Your Airbag System WARNING! • Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured if the airbag system is not there to protect you.
Page 59: Event Data Recorder (Edr)
• The airbag light does not come on or flickers during the 6 to 8 seconds when the ignition switch is first turned on. • The light remains on or flickers after the 6 to 8 second interval. • The light flickers or comes on and remains on while driving.
Page 60 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE be requested by customers, insurance carriers, govern- ment officials, and professional crash researchers, such as those associated with universities, and with hospital and insurance organizations. In the event that an investigation is undertaken by DaimlerChrysler Corporation (regardless of initiative), the company or its designated representative will first obtain permission of the appropriate custodial entity for...
Page 61: Child Restraint
• Time of airbag deployment (in terms of ignition cycles and vehicle mileage) • Airbag deployment level (if applicable) • Impact acceleration and angle • Seatbelt status • Brake status (service and parking brakes) • Accelerator status (including vehicle speed) •...
Page 62 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! In a collision, an unrestrained child, even a tiny baby, can become a missile inside the vehicle. The force required to hold even an infant on your lap can become so great that you could not hold the child, no matter how strong you are.
Page 63 unless the airbag is turned off. An airbag deployment could cause severe injury or death to infants in this position. • Children who weigh more than 20 lbs (9 kg) and who are older than one year can ride forward-facing in the vehicle.
Page 64 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Here are some tips for getting the most out of your child restraint: • Before buying any restraint system, make sure that it has a label certifying that it meets all applicable Safety Standards.
Page 65 around, and insert the latch plate into the buckle again. If you still can’t make the child restraint secure, try a different seating position. • Buckle the child into the seat according to the child restraint manufacturer’s directions. • When your child restraint is not in use, secure it in the vehicle with the seat belt or remove it from the vehicle.
Page 66 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: For children riding in the front seat of a Stan- dard Cab model refer to the “Passenger Airbag On/Off Switch” located in this section. Standard Cab Passenger Seat Quad Cab Rear Outboard Seats...
Page 67 Mega Cab Rear Seats Child restraint systems having attachments designed to connect to the lower anchorages are now available. Child restraints having tether straps and hooks for connection to the seatback tether anchorage have been available for THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 some time.
Page 68 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE restraint installation, instead of tucking the seat belt behind the child restraint, route the seat belt through the child restraint belt path and then buckle it. This should stow the seat belt out of the reach of an inquisitive child. Remind all children in the vehicle that the seat belts are not toys and should not be played with, and never leave your child unattended in the vehicle.
Page 69 rearward-facing infant restraints will also be equipped with a tether strap, a hook and means for adjusting the tension in the strap. In general, you will first loosen the adjusters on the lower straps and tether straps so that you can more easily attach the hook or connector to the lower anchorages and tether anchorages.
Page 70 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! An incorrectly anchored tether strap could lead to seat failure and injury to the child. In a collision, the seat could come loose and allow the child to crash into the inside of the vehicle or other passengers, or even be thrown from the vehicle.
Page 71 Multiple Child Restraint Installation Sequence - (Quad Cab Rear Seats) 1. Obtain tether straps by raising the head restraints and reaching between the rear glass and rear seat. The tether strap may be retained with an elastic band. Accessibility to the tether strap is greatly improved by raising the seat cushion to the “up”...
Page 72 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Multiple Child Restraints...
Page 73: Children Too Large For Booster Seats
Tether Anchorage Points at All Three Seating Positions (Mega Cab) 1. Place the child restraint on the seat and adjust the tether strap so that it will reach over the seat back under the head restraint to the tether anchor directly behind the seat.
Page 74: Engine Break-In Recommendations
74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Make sure that the child is upright in the seat. • The lap portion should be low on the hips and as snug as possible. • Check belt fit periodically. A child’s squirming or slouching can move the belt out of position.
Page 75: Safety Tips
A new engine may consume some oil during its first few thousand miles of operation. This is a normal part of the break-in and is not an indication of difficulty. CAUTION! • During the first 500 miles (805 km) your new vehicle is driven, do not tow a trailer.
Page 76: Lock Your Vehicle
76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lock Your Vehicle Always remove the keys from the ignition and lock all doors when leaving the vehicle unattended, even in your own driveway or garage. Try to park your vehicle in a well-lighted area and never invite theft by leaving ar- ticles of value exposed.
Page 77: Safety Checks You Should Make Inside The Vehicle
Safety Checks You Should Make Inside The Vehicle Heater Defroster Ducts Inspect the heater defroster ducts for proper operation. Check for proper air flow through all defroster ducts. If there are any question regarding the operation of your heater defroster ducts, have the system checked by an authorized dealer Seat Belts Inspect the belt system periodically, checking for cuts,...
Page 78: Safety Checks You Should Make Outside The Vehicle
78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Safety Checks You Should Make Outside The Vehicle Tires Examine tires for tread wear or uneven wear patterns. Check for stones, nails, glass or other objects lodged in the tread. Inspect for tread cuts or sidewall cracks. Check wheel nuts for tightness and tires for proper pressure.
Page 79 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Power Wagon Features ....84 Locking Front And Rear Differentials ..84 4.56:1 Gears .
Page 80 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Exterior Mirrors Folding Feature ...90 Electronic Power Mirrors – If Equipped ..91 Electric Rear Window Defroster And Heated Sideview Mirrors –...
Page 81 Headlights, Parking Lights, Panel Lights ..130 Daytime Running Lights (Canada Only And Fleet Vehicles) ......131 Lights-On Reminder .
Page 82 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Average Fuel Economy (AVG ECO) ..145 Distance To Empty (DTE) ....145 Trip Odometer (ODO) .
Page 83 Sunroof Maintenance ....159 Sunroof Fully Closed ....159 Electrical Power Outlets .
Page 84: Power Wagon Features
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE POWER WAGON FEATURES Locking Front and Rear Differentials Most 4WD trucks are equipped with open differentials front and rear. This design is used because it allows each wheel to turn independently helping to eliminate bind- ing when cornering.
Page 85: Electronically Disconnecting Stabilizer/Sway Bar
Electronically Disconnecting Stabilizer/Sway Bar Stabilizer bars are used to help distribute load force from one side of the vehicle to the other. This helps to reduce body roll and create a smoother ride during on-road driving. However, this becomes a disadvantage when the vehicle is driven off-road when a higher level of suspen- sion articulation is needed.
Page 86: High-Pressure Monotube Shocks/New Front And Rear Springs
86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE High-Pressure Monotube Shocks/New Front and Rear Springs The new variable-rate shocks and revised springs help to create a suitable on-road ride without compromising off-road competency. The shocks are designed to provide improved stability, durability, and suspension articula- tion.
Page 87: Wheels
Wheels Stylish forged aluminum 17 wheels give the Power Wagon a powerful stance. Forging a wheel from alumi- num produces a stronger, lighter weight wheel than machining or casting the wheel out of the same material. Standard package features: • Fuel Tank Skid Plate - protects the fuel tank from impingement damage.
Page 88: Mopar Options
88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Off-Road Tuned Suspension And Shocks - improves mobility, ground clearance and ride comfort. • Heavy Duty Thermally Protected and Sealed Electric Winch with Roller Fairlead - Useful for work and vehicle recovery. •...
Page 89: Automatic Dimming Mirror - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89 Automatic Dimming Mirror – If Equipped This mirror automatically adjusts for annoying headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light in the button will indicate when the dimming feature is activated.
Page 90: Outside Mirrors
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! To avoid damage to the mirror during cleaning, never spray any cleaning solution directly onto the mirror. Apply the solution onto a clean cloth and wipe the mirror clean. Outside Mirrors To receive maximum benefit, adjust the outside mirror(s) to center on the adjacent lane of traffic with a slight overlap of the view obtained on the inside mirror.
Page 91: Electronic Power Mirrors - If Equipped
Electronic Power Mirrors – If Equipped Power Mirror Movement The controls for the power mirrors are located on the driver’s door trim panel. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91 Power Mirror Switches Set the top switch to the left or right for the left or right mirror, and set it to the center off position to prevent accidentally moving a mirror when you are finished adjusting the mirror.
Page 92: Electric Rear Window Defroster And Heated Sideview Mirrors - If Equipped
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Electric Rear Window Defroster and Heated Sideview Mirrors – If Equipped The Electric Rear Window Defroster and Heated side view mirrors are activated by pressing the heated grid button, located on the Climate Control panel, with the ignition On.
Page 93: Hands-Free Communication (Uconnect ) - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93 HANDS–FREE COMMUNICATION (UConnect ) — IF EQUIPPED NOTE: The sales code RER radio contains an inte- grated Hands-Free Communication (UConnect ) sys- tem. Refer to your “Navigation User’s Manual” for UConnect system operating instructions for this radio. UConnect is a voice-activated, hands-free, in- vehicle communications system.
Page 94 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: For UConnect customer support, visit the following web sites: • www.chrysler.com/uconnect • www.dodge.com/uconnect • www.jeep.com/uconnect • or call 1–877–855–8400 UConnect allows you to transfer calls between the system and your cellular phone as you enter or exit your vehicle, and enables you to mute the system’s micro-...
Page 95: Operation
Voice Recognition Button Actual button location may vary with radio. The individual buttons are described in the “Operation” section. The UConnect system can be used with any Hands-Free Profile certified Bluetooth™ cellular UConnect website for supported phones. If your cellu- lar phone supports a different profile (e.g., Headset Profile) you may not be able to use any UConnect features.
Page 96 96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • For each feature explanation in this section, only the combined form of the voice command is given. You can also break the commands into parts and say each part of the command, when you are asked for it. For example, you can use the combined form voice com- mand Phonebook New Entry, or you can break the combined form command into two voice commands:...
Page 97 The following are general phone to UConnect System pairing instructions: • Press the “Phone” button to begin. • After the Ready prompt and the following beep, say Setup Phone Pairing. • When prompted, after the beep, say Pair a Phone and follow the audible prompts.
Page 98 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • System will prompt you to say the number you want call. • For example, you can say 234-567-8901. The phone number that you enter must be of valid length and combination. Based on the country in which the ve- hicle was purchased, the UConnect limits the user from dialing invalid combination of numbers.
Page 99 • After the Ready prompt and the following beep, say Phonebook New Entry. • When prompted, say the name of the new entry. Use of long names helps the voice recognition and it is recommended. For example, say Robert Smith or Robert instead of Bob.
Page 100 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Some phones cannot send phonebook entries if they are already connected to any system via Bluetooth, and you may see a message on the phone display that the Bluetooth link is busy. In this case, the user must first disconnect or drop the Bluetooth connection to the UConnect and then send the address book entry via Bluetooth.
Page 101 Delete Entries in the UConnect Phonebook NOTE: Editing phone book entries is recommended when vehicle is not in motion. • Press the “Phone” button to begin. • After the Ready prompt and the following beep, say Phonebook Delete. • After you enter the Phonebook Delete menu, you will then be asked for the name of the entry that you wish to delete.
Page 102: Phone Call Features
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE List All Names in the UConnect Phonebook • Press the “Phone” button to begin. • After the Ready prompt and the following beep, say Phonebook List Names. • The UConnect system will play the names of all the phone book entries.
Page 103 Answer or Reject an Incoming Call - Call Currently in Progress If a call is currently in progress and you have another incoming call, you will hear the same network tones for call waiting that you normally hear when using your cell phone.
Page 104 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Conference Call When two calls are in progress (one active and one on hold), press and hold the “Phone” button until you hear a double beep indicating that the two calls have been joined into one conference call.
Page 105: Uconnect System Features
Call Continuation Call continuation is progression of a phone call on UConnect system after the vehicle ignition key has been switched to off. Call continuation functionality available on the vehicle can be any one of three types: • After ignition key is switched off, a call can continue on the UConnect system either until the call ends or until the vehicle battery condition dictates cessation of the call on the UConnect system and transfer of the...
Page 106 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Emergency Assistance If you are in an emergency and the mobile phone is reachable: • Pick up the phone and manually dial the emergency number for your area. If the phone is not reachable and the UConnect system is operational, you may reach the emergency number as follows: •...
Page 107 Please refer to the 24-Hour “Towing Assistance” cover- age details in the Warranty information booklet and on the 24–Hour Towing Assistance Card. Paging To learn how to page refer to Working with Automated Systems. Paging works properly except for pagers of certain companies which time-out a little too soon to work properly with the UConnect system.
Page 108 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE say “Send.” The system will prompt you to enter the name or number, say the name of the phonebook entry you wish to send. The UConnect will then send the corresponding phone number associated with the phone- book entry as tones over the phone.
Page 109 status when you are attempting to make a phone call using UConnect . The status is given for roaming, net- work signal strength, phone battery strength, etc. Dialing Using the Cellular Phone Keypad You can dial a phone number with your cellular phone keypad and still use the UConnect system (while dial- ing via the cell phone keypad, the user must exercise caution and take precautionary safety measures).
Page 110: Advanced Phone Connectivity
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Advanced Phone Connectivity Transfer Call to and from Cellular Phone The UConnect system allows on going calls to be transferred from your cellular phone to the UConnect system without terminating the call. To transfer an ongo- ing call from your UConnect paired cellular phone to the UConnect system or vice-versa, press the “Voice Recognition”...
Page 111: Things You Should Know About Your Uconnect System
• After the Ready prompt and the following beep, say Setup Select Phone and follow the prompts. • You can also press the “Voice Recognition” button anytime while the list is being played, and then choose the phone that you wish to select. •...
Page 112 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Press the “Voice Recognition” button and say Setup, Voice Training command. Repeat the words and phrases when prompted by the UConnect system. For best results, the Voice Training session should be completed when the vehicle is parked, engine running, all windows closed, and the blower fan switched off.
Page 113 • Even though the system is designed for users speaking in North American English, French, and Spanish ac- cents, the system may not always work for some. • When navigating through an automated system, such as voice mail, or when sending a page, at the end of speaking the digit string, make sure to say Send.
Page 114 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Performance, such as audio clarity, echo, and loudness to a large degree rely on the phone and network, and not the UConnect system. • Echo at far end can sometime be reduced by lowering the in-vehicle audio volume.
Page 115 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115...
Page 116 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 117 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117...
Page 118 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Primary Alternate(s) zero three four five seven eight nine star (*) plus (+) pound (#) add location Voice Commands Primary Alternate(s) call cancel confirmation prompts. continue delete dial download edit emergency English erase all Espanol...
Page 119 Voice Commands Primary Alternate(s) language list names list phones mobile mute mute off new entry pager pair a phone phone pairing pairing phonebook phone book previous record again redial UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 Voice Commands Primary Alternate(s) return to main menu return or main menu select phone...
Page 120: General Information
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information This device complies with part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. •...
Page 121: 40-20-40 Front Seat
40-20-40 Front Seat As the name implies, the seat is divided into 3 segments. The outboard seat portions are each 40% of the total width of the seat. The back of the center portion (20%) easily folds down to provide an armrest/center storage compartment (if equipped).
Page 122: Reclining Seats
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Reclining Seats The recliner handle is on the outside of the seat cushion. Pull up on the handle to release the seat back and adjust for comfort. WARNING! You can be seriously, even fatally injured riding in a seat with the seatback reclined.
Page 123: Manual Rotary Lumbar Support Adjustment - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 Manual Rotary Lumbar Support Adjustment — If Equipped Rotating the lumbar control knob on the left side of the driver’s seatback and on the right side of the passenger’s seatback increases or decreases the lumbar support. Manual Lumbar Adjustment...
Page 124: Power Seats - If Equipped
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Seats — If Equipped CAUTION! Don’t put anything under a power seat. It may cause damage to the seat controls. Up, Down, Forward, and Rearward The power seat controls are on the outboard side of the front seat cushions.
Page 125: Heated Seats - If Equipped
control seat height. Change the seat angle by using the two toggle switches, tilting it up or down. Tilt Adjustment UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 Heated Seats — If Equipped The heated seat switches are located in the instrument panel under the climate controls.
Page 126 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Each heated seat switch has two settings (HI and LOW). Press the switch once to obtain High heat level, then press the switch again to obtain Low heat level. Pressing the switch a third time will turn the heated seats OFF. If you do not purposefully turn the switch OFF, the seat heating level will automatically change to the next lower level, or OFF.
Page 127: To Open And Close The Hood
TO OPEN AND CLOSE THE HOOD Hood Release Lever To open the hood, two latches must be released. First pull the hood release lever located below the steering wheel at the base of the instrument panel. Once the hood is UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 released you must reach into the opening beneath the center of the grille and push up the latch to release the...
Page 128: Lights
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LIGHTS WARNING! If the hood is not fully latched, it could fly up when the vehicle is moving and block your forward vision. Be sure all hood latches are latched fully before driving. Headlight Switch Location...
Page 129: Interior Lights
Interior Lights Dimmer Control Courtesy and dome lights are turned on when the front doors are opened, when the dimmer control (rotating wheel on the right side of the switch) is rotated to the upward detent position, or if equipped, when the UN- LOCK button is pressed on the key fob.
Page 130: Battery Saver
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Battery Saver To protect the life of your vehicle’s battery, Load Shed- ding is provided for both the interior and exterior lights. If the ignition is off and any door is left ajar for 10 minutes or the dimmer control is rotated upwards for 10 minutes, the interior lights will automatically turn off.
Page 131: Daytime Running Lights (Canada Only And Fleet Vehicles)
Light Switch Rotation Your vehicle is equipped with plastic headlight lenses that are lighter and less susceptible to stone breakage than glass headlights. Plastic is not as scratch resistant as glass and therefore different lens cleaning procedures must be followed. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 To minimize the possibility of scratching the lenses and reducing light output, avoid wiping with a dry cloth.
Page 132: Lights-On Reminder
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lights-on Reminder If the headlights, parking lights, or cargo lights are left on, after the ignition is turned off, a chime will sound when the driver’s door is opened. Fog Lights — If Equipped The foglights are turned ON by placing the head- light rotary control in the parking light or head- light position and pushing in the headlight rotary...
Page 133: Multifunction Control Lever
Multifunction Control Lever The multifunction control lever is located on the left side of the steering column. Turn Signals Move the lever up or down to signal a right-hand or left-hand turn. The arrow on either side of the instrument cluster flashes to indicate the direction of the turn, and proper operation of the front and rear turn signal lights.
Page 134 134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Passing Light You can signal another vehicle with your headlights by partially pulling the multifunction lever toward the steer- ing wheel. This will cause the high beam headlights to turn on until the lever is released. High Beam / Low Beam Select Switch Pull the multifunction control lever fully toward the steering wheel to switch the headlights from HIGH or...
Page 135: Windshield Wipers And Washers
WINDSHIELD WIPERS AND WASHERS Windshield Wipers Windshield Wiper / Washer Switch UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 The wipers and washers are operated by a switch in the multifunction control lever. Turn the end of the handle to select the desired wiper speed. Intermittent Wiper System The intermittent feature of this system was designed for use when weather conditions make a single wiping cycle,...
Page 136: Windshield Washers
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Sudden loss of visibility through the windshield could lead to an accident. You might not see other vehicles or other obstacles. To avoid sudden icing of the windshield during freezing weather, warm the windshield with defroster before and during wind- shield washer use.
Page 137: Tilt Steering Column
TILT STEERING COLUMN To tilt the column, pull rearward on the lever below the turn signal control and move the wheel up or down, as desired. Push the lever forward to lock the column firmly in place. Tilt Steering Control Lever UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 WARNING! Tilting the steering column while the vehicle is...
Page 138: Electronic Speed Control - If Equipped
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ELECTRONIC SPEED CONTROL — IF EQUIPPED When engaged, this device takes over accelerator opera- tion at speeds greater than (refer to the table below for the speed for your specific engine). The controls are mounted on the steering wheel.
Page 139: To Deactivate
To Deactivate A soft tap on the brake pedal, normal braking, clutch pressure while slowing the vehicle, or pressing the CAN- CEL button will deactivate speed control without erasing the memory. Pushing the ON/OFF button to the OFF position or turning off the ignition erases the memory. WARNING! Leaving the Speed Control ON when not in use is dangerous.
Page 140 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Tapping the DECEL button once will result in a speed decrease (refer to the table below for the speed for your specific engine). Each time the button is tapped, speed will decrease. For example, tapping the button 3 times will decrease the speed by 3 times the speed listed in the table below (refer to the table below for the speed for your specific engine).
Page 141: To Accelerate For Passing
To Accelerate For Passing Depress the accelerator as you would normally. When the pedal is released, the vehicle will return to the set speed. NOTE: When driving uphill, at elevations above 2,000 feet (610 meters), or when the vehicle is heavily loaded (especially when towing) the vehicle may slow below the SET speed.
Page 142: Overhead Console - If Equipped
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE OVERHEAD CONSOLE — IF EQUIPPED The two optional overhead consoles may consist of the following features: Overhead Console Features • Courtesy/Reading Lights • Compass/Temperature Mini-Trip Computer (CMTC) — If Equipped • Universal Garage Door Opener — If Equipped Courtesy/Reading Lights In the middle of the console are two courtesy/reading lights.
Page 143: Overhead Console With Compass/Temperature Mini-Trip Computer - If Equipped
OVERHEAD CONSOLE WITH COMPASS/TEMPERATURE MINI-TRIP COMPUTER — IF EQUIPPED This optional overhead console consists of the following: • Courtesy Lights • Compass/Temperature Mini-Trip Computer (CMTC) UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 This overhead console allows you to choose between a compass/temperature display and one of four trip con- ditions being monitored.
Page 144: Reset Button
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE RESET Button Use this button to reset the following displays: Average Fuel Economy (AVG ECO) Trip Odometer (ODO) Elapsed time (ET) Global Reset If the RESET button is pressed twice within 2 seconds while in any of the 3 resettable displays (AVG ECO, ODO, ET), the Global Reset will reset all 3 displays.
Page 145: Average Fuel Economy (Avg Eco)
Average Fuel Economy (AVG ECO) Shows the average fuel economy since the last reset. Average fuel economy is a running average of the amount of fuel used and the distance the vehicle has traveled. When the fuel economy is reset, the display will momen- tarily blank.
Page 146: Trip Odometer (Odo)
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: It is possible for DTE to display “LO FUEL” before the low fuel warning light turns on in the instru- ment cluster. This could occur because low fuel warning is set to a specified fuel tank volume and DTE is an estimated distance calculation based on fuel economy and remaining fuel tank volume.
Page 147: C/T Button
C/T Button Use this button to select a readout of the outside tem- perature and one of eight compass headings that indicate the direction in which the vehicle is facing. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 WARNING! Even if the display still reads a few degrees above 32°F ( 0°C), the road surface may be icy, particularly in woods or on bridges.
Page 148: Manual Compass Calibration
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Compass Calibration NOTE: To ensure proper compass calibration, make sure the compass variance is properly set before manu- ally calibrating the compass. If the compass appears erratic and the CAL symbol does not appear, you must manually put the compass into the “Calibration”...
Page 149: Outside Temperature
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 NOTE: The default for the compass variance is zone 8. To set the variance: Turn the ignition ON and set the display to “Compass/Temperature.” Press and hold the RESET button approximately five seconds. The last vari- ance zone number will be displayed.
Page 150: Garage Door Opener - If Equipped
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE GARAGE DOOR OPENER — IF EQUIPPED HomeLink replaces up to three remote controls (hand held transmitters) that operate devices such as garage door openers, motorized gates, lighting, or home security systems. The HomeLink unit operates off of your vehi- cle’s battery.
Page 151: Programming Homelink
WARNING! Your motorized door or gate will open and close while you are training the Universal Transceiver. Do not train the transceiver if people or pets are in the path of the door or gate. Only use this transceiver with a garage door opener that has a “stop and reverse”...
Page 152 152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To do this, press and hold the two outside buttons for 20 seconds. Release the buttons when the indicators start to flash. It is recommended that a new battery be placed in the hand-held transmitter of the device being programmed to HomeLink for more efficient training and accurate transmission of the radio-frequency signal.
Page 153 4. Press and hold the just-trained HomeLink button. If the indicator(s) blink rapidly for two seconds and then remains constant, continue with next section: Program- ming A Rolling Code System. NOTE: After training a HomeLink garage door does not operate with HomeLink and the garage door opener was manufactured after 1995, the garage door opener may have rolling code.
Page 154: Gate Operator/Canadian Programming
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 7. Return to the vehicle and press the programmed HomeLink button twice (holding the button for 2 sec- onds each time). If the device is plugged in and activates, programming is complete. If the device does not activate, press the button a third time (for 2 seconds) to complete the training.
Page 155: Using Homelink
Then proceed with Step 4 under “Programming HomeLink.” earlier in this section. Using HomeLink To operate, simply press and release the programmed HomeLink button. Activation will now occur for the trained device (i.e. garage door opener, gate operator, security system, entry door lock, home/office lighting, etc.
Page 156: General Information
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Press the Learn Button on the Garage Door Opener to complete the training for Rolling Code. • Did you unplug the device for training, and remember to plug it back in? If you are have any problems, or require assistance, please call toll-free 1–800–355–3515 or, on the Internet at www.HomeLink.com for information or assistance.
Page 157: Open Sunroof - Express Mode
WARNING! • Never leave children alone in a vehicle. Leaving children in a vehicle unattended is dangerous for a number of reasons. A child or others could be seriously or fatally injured. Don’t leave the keys in the ignition. A child could operate power win- dows, other controls, or move the vehicle.
Page 158: Closing Sunroof - Express
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Closing Sunroof - Express Press the switch forward and release, and the sunroof will close automatically from any position. The sunroof will close fully and stop automatically. This is called Express Close. During Express Close operation, any movement of the switch will stop the sunroof.
Page 159: Wind Buffeting
Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down, or the sunroof (if equipped) in certain open or partially open positions.
Page 160 160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE All accessories connected to this/these outlet(s) should be removed or turned OFF when the vehicle is not in use to protect the battery against discharge. NOTE: If desired, all of the power outlets can be converted by your authorized dealer to provide power with the ignition switch in the ON position only.
Page 161: Cigar Lighter And Ash Receiver
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 CIGAR LIGHTER AND ASH RECEIVER The removable ash receiver is located in the instrument panel cup holder tray. The cigar lighter is located on the instrument panel, above and to the left of the ash receiver. As a child safety precaution, the lighter only operates with the ignition switch ON.
Page 162: Cupholders
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CUPHOLDERS Front Instrument Panel Cupholders To secure the cup, place the cup to be held into one of the cup wells and then push the cupholder arm toward the cup until it is held stable. Rear Cupholder —...
Page 163: Storage
STORAGE Center Storage Compartment — If Equipped The center portion of the seat folds down to provide an armrest with unique storage compartments under the lid. Push the button on the front of the armrest to raise the cover. Inside there is a power outlet (if equipped), removable coin holder (if equipped), and two dividers to UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 configure the storage area into compartments.
Page 164: Storage And Seats - If Equipped
164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Storage and Seats — If Equipped Located in the center of the front 40/20/40 seat cushion there is a storage compartment. Standard cab models also have storage behind the seat. The Quad Cab models provide additional storage under the rear seat.
Page 165: Rear Window Features
REAR WINDOW FEATURES Electric Rear Window Defroster and Heated Side view Mirrors — If Equipped The Electric Rear Window Defroster and Heated side view mirrors are activated by pressing the heated grid button, located on the Climate Control panel, with the ignition On. Turning Off the ignition will deactivate the Electric Rear Window Defroster and Heated side view mirrors feature.
Page 166: Sliding Rear Window - If Equipped
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sliding Rear Window — If Equipped A locking device in the center of the window helps to prevent entry from the rear of the vehicle. Squeeze the lock to release the window. FOLD FLAT LOAD FLOOR — IF EQUIPPED Quad Cab models with a 60/40 rear seat, may be equipped with a folding load floor.
Page 167 WARNING! Do not operate the vehicle with loose items stored on the load floor. While driving or in an accident you may experience, abrupt stopping, rapid acceleration, or sharp turns. Loose objects stored on the load floor may move around with force and strike occupants, resulting in serious or fatal injury.
Page 168 168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Grasp the knob on the load floor and lift the knob until the load floor unfolds into position. Load Floor In Open Position 3. Reverse the procedure to store the load floor. Positioning the Load Floor for Storage Access Under the Seat 1.
Page 169: Pickup Box
Load Floor Securing Straps 4. Reverse the procedure to put the load floor back in the secured down position before you operate the vehicle. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 PICKUP BOX Pickup Box Features The pickup box on your new Ram has many features designed for utility and convenience.
Page 170 170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE You can carry wide building materials (sheets of ply- wood, etc.) by building a raised load floor. Place lumber across the box in the indentations provided above the wheel housings and in the bulkhead dividers to form the floor.
Page 171: Slide-In Campers
There are stampings in the sheet metal on the inner side bulkheads of the box in front of and behind both wheel housings. Place wooden boards across the box from side to side to create separate load compartments in the pickup box.
Page 172 172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Dual rear wheel pickup models require properly spaced rear clearance lights. If such a vehicle is operated without a tailgate, suitable lights must be installed.
Page 173 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instruments And Controls ....177 Instrument Cluster ..... . 178 Instrument Cluster Description .
Page 174 174 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions - Satellite Radio — If Equipped ......199 Sales Code RAQ – AM/FM/CD (6-Disc) Radio With Optional Satellite Radio, Hands Free Phone, And Vehicle Entertainment Systems (VES) Capabilities .
Page 175 Operation Instructions - (CD Mode For CD Audio Play) ......219 Load/Eject Button (CD Mode For CD Audio Play) .
Page 176 176 UNDERSTANDING YOUR INSTRUMENT PANEL Remote Sound System Controls — If Equipped . . 235 Radio Operation ..... . 236 Tape Player .
Page 177: Instruments And Controls
INSTRUMENTS AND CONTROLS 1 — Headlight Switch 6 — Passenger Airbag* 2 — Air Outlets 7 — Glove Box 3 — Instrument Cluster 8 — Power Outlet 4 — Climate Controls 9 — Heated Seat Switch 5 — Radio 10 — TPMS “Light Load” Reset Switch* * If Equipped UNDERSTANDING YOUR INSTRUMENT PANEL 177 11 —...
Page 178: Instrument Cluster
178 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER...
Page 179: Instrument Cluster Description
INSTRUMENT CLUSTER DESCRIPTION 1. Check Gages This light illuminates when the Voltmeter, Engine Oil Pressure or Engine Coolant Temperature gages indicate a reading either too high or too low. Examine the gages carefully, and follow the instructions above for each indicated problem. NOTE: When the ignition switch is turned to OFF, the Fuel Gage, Voltmeter, Oil Pressure and Engine Coolant Temperature gages may not show accurate readings.
Page 180 180 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! Do not operate the engine with the tachometer pointer at high rpm for extended periods. Engine damage may occur. 5. Airbag Indicator Light The indicator lights and remains lit for 6 to 8 seconds when the ignition is first turned on.
Page 181 NOTE: If the gauge pointer moves to either extreme of the gauge, the “Check Gages” indicator will illuminate and a single chime will sound. 10. Transfer Case Position (See page 271 for more information.) 11. TOW HAUL The TOW HAUL button is located at the end of the gear shift lever.
Page 182 182 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! Do not leave your vehicle unattended with the en- gine running as you would not be able to react to the temperature indicator if the engine overheats. NOTE: Engine idle speed will automatically increase to 1000 rpm at elevated coolant temperatures to improve engine cooling.
Page 183 To reset a trip odometer, display the desired trip odom- eter to be reset then push and hold the button until the display resets (approximately 2 seconds). Vehicle Warning Messages When the appropriate conditions exist, messages such as “door” (indicates that a door(s) may be ajar), “hood” (if the hood is open or ajar, on vehicles with remote start), “gASCAP”...
Page 184 184 UNDERSTANDING YOUR INSTRUMENT PANEL cluster. To reset the oil change indicator system (after performing the scheduled maintenance) refer to the fol- lowing procedure. 1. Turn the ignition switch to the ON position (Do not start the engine). 2. Fully depress the accelerator pedal slowly three times within 10 seconds.
Page 185 CAUTION! Prolonged driving with the MIL on could cause damage to the engine control system. It also could affect fuel economy and driveability. If the MIL is flashing, severe catalytic converter damage and power loss will soon occur. Immediate service is required. 19.
Page 186 186 UNDERSTANDING YOUR INSTRUMENT PANEL that the anti-lock portion of the brake system is not functioning and that service is required. See your autho- rized dealer immediately. The ABS light could also illuminate during loss of traction and remain illuminated until the brake pedal is pressed.
Page 187 24. Tire Pressure Monitoring Telltale Light — If Equipped Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those...
Page 188 188 UNDERSTANDING YOUR INSTRUMENT PANEL When the malfunction indicator is illuminated, the sys- tem may not be able to detect or signal low tire pressure as intended. TPMS malfunctions may occur for a variety of reasons, including the installation of replacement or alternate tires or wheels on the vehicle that prevent the TPMS from functioning properly.
Page 189 TPMS “Light Load” Reset Switch – If Equipped The TPMS ”Light Load” reset switch allows you to choose between Light Load vehicle conditions and Max Load vehicle conditions tire pressures and related TPMS warning levels. The switch is located in the instrument panel, below the climate control panel.
Page 190: Electronic Digital Clock
190 UNDERSTANDING YOUR INSTRUMENT PANEL fuel warning is set to a specified fuel tank volume and DTE is an estimated distance calculation based on vehicle fuel economy and remaining fuel tank volume. Ram fuel tank volumes are as follows: • 34 gallons - short box models •...
Page 191: Radio General Information
RADIO GENERAL INFORMATION Radio Broadcast Signals Your new radio will provide excellent reception under most operating conditions. Like any system, however, car radios have performance limitations, due to mobile opera- tion and natural phenomena, which might lead you to believe your sound system is malfunctioning. To help you understand and save you concern about these “apparent”...
Page 192: Sales Code Ref - Am/Fm/Cd (Single Disc) Radio With Optional Satellite Radio And Hands Free Phone Capability
192 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: The radio, steering wheel radio controls (if equipped), and 6 disc CD/DVD changer (if equipped) will remain active for up to 10 minutes after the ignition switch has been turned off. Opening a vehicle front door will cancel this feature.
Page 193 Power Switch/Volume Control (Rotary) Press the ON/VOL control to turn the radio ON. Press the ON/VOL a second time to turn OFF the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction without stopping. Turning the volume control to the right increases the volume and to the left decreases it.
Page 194 194 UNDERSTANDING YOUR INSTRUMENT PANEL SCAN Button (Radio Mode) Pressing the SCAN button causes the tuner to search for the next listenable station in either, AM, FM, or Satellite (if equipped) frequencies, pausing for 5 seconds at each listenable station before continuing to the next. To stop the search, press SCAN a second time.
Page 195 AM/FM Button (Radio Mode) Press the button to select AM or FM Modes. Setting the Tone, Balance, and Fade Press the rotary TUNE control and BASS will display. Turn the TUNE control to the right or left to increase or decrease the Bass tones.
Page 196: Operation Instructions - Cd Mode
196 UNDERSTANDING YOUR INSTRUMENT PANEL You may add a second station to each push-button by repeating the above procedure with this exception: Press the SET button twice and SET 2 will show in the display window. Each button can be set for SET 1 and SET 2 in both AM and FM.
Page 197 • If you insert a disc with the ignition ON and the radio OFF, the CD will automatically be pulled into the CD Player. • This radio does not play discs with MP3 tracks. SEEK Button (CD Mode) Press the right side of the SEEK button for the next track on the CD.
Page 198: Operation Instructions - Auxiliary Mode
198 UNDERSTANDING YOUR INSTRUMENT PANEL RND/SET Button (Random Play Button) (CD Mode) Press this button while the CD is playing to activate Random Play. This feature plays the selections on the compact disc in random order to provide an interesting change of pace.
Page 199: Operating Instructions - Hands Free Phone - If Equipped
MUTE Button (Auxiliary Mode) Press the MUTE button to cancel the sound from the speakers. MUTE will display. Press the MUTE button a second time and the sound from the speakers will return. Rotating the volume control or turning OFF the ignition will also return the sound from the speakers.
Page 200: Sales Code Raq - Am/Fm/Cd (6-Disc) Radio With Optional Satellite Radio, Hands Free Phone, And Vehicle Entertainment Systems (Ves) Capabilities
200 UNDERSTANDING YOUR INSTRUMENT PANEL SALES CODE RAQ – AM/FM/CD (6-DISC) RADIO WITH OPTIONAL SATELLITE RADIO, HANDS FREE PHONE, AND VEHICLE ENTERTAINMENT SYSTEMS (VES) CAPABILITIES NOTE: The radio sales code is located on the lower right side of your radio faceplate. RAQ Radio Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC...
Page 201 Mode Button (Radio Mode) Press the mode button repeatedly to select between the CD player, Satellite Radio, or Vehicle Entertainment System (VES) (if equipped). SEEK Button (Radio Mode) Press and release the SEEK button to search for the next listenable station in either AM/FM or Satellite (if equipped) mode.
Page 202 202 UNDERSTANDING YOUR INSTRUMENT PANEL Time Button Press the time button and the time of day will be displayed for 5 seconds. Clock Setting Procedure 1. Press and hold the time button until the hours blink. 2. Adjust the hours by turning the right side Tune / Audio control.
Page 203 Press the rotary TUNE control a third time and TREBLE will display. Turn the TUNE control to the right or left to increase or decrease the Treble tones. Press the rotary TUNE control a fourth time and BAL- ANCE will display. Turn the TUNE control to the right or left to adjust the sound level from the right or left side speakers.
Page 204 204 UNDERSTANDING YOUR INSTRUMENT PANEL Jazz News Nostalgia Oldies Personality Public Rhythm and Blues Rhythm_and_Blues Religious Music Religious Talk Rock Soft Soft Rock Soft Rhythm and Blues Sports Talk Top 40 Weather By pressing the SEEK button when the PTY icon is Jazz displayed, the radio will be tuned to the next frequency News...
Page 205: Operation Instructions - (Cd Mode For Cd Audio Play)
You may add a second station to each push-button by repeating the above procedure with this exception: Press the SET/DIR button twice and SET 2 will show in the display window. Each button can be set for SET 1 and SET 2 in both AM and FM.
Page 206 206 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! This CD player will accept 4 3/4 inch (12 cm) discs only. The use of other sized discs may damage the CD player mechanism. You may eject a disc with the radio OFF. If you insert a disc with the ignition ON and the radio ON, the unit will switch from radio to CD mode and begin to play when you insert the disc.
Page 207: Load/Eject Button (Cd Mode For Cd Audio Play)
LOAD/EJECT Button (CD Mode for CD Audio Play) LOAD/ EJECT - Load Press the LOAD/ EJECT button and the push- button with the corresponding number where the CD is being loaded. The radio will display PLEASE WAIT and prompt when to INSERT DISC.
Page 208: Notes On Playing Mp3 Files
208 UNDERSTANDING YOUR INSTRUMENT PANEL RW/FF (CD MODE for CD Audio Play) Press and hold FF (Fast Forward) and the CD player will begin to fast forward until FF is released or RW or another CD button is pressed. The RW (Reverse) button works in a similar manner.
Page 209 Supported Medium Formats (File Systems) The medium formats supported by the radio are ISO 9660 Level 1 and Level 2 and includes the Joliet extension. When reading discs recorded using formats other than ISO 9660 Level 1 and Level 2, the radio may fail to read files properly and may be unable to play the file nor- mally.
Page 210 210 UNDERSTANDING YOUR INSTRUMENT PANEL rates (VBR) are also supported. The majority of MP3 files use a 44.1 kHz sampling rate and a 192, 160, 128, 96 or VBR bit rates. MPEG Specifi- Sampling Fre- cation quency (kHz) MPEG-1 Audio 48, 44.1, 32 Layer 3 MPEG-2 Audio...
Page 211: Operation Instructions - (Cd Mode For Mp3 Audio Play)
Operation Instructions - (CD Mode for MP3 Audio Play) SEEK Button (CD Mode for MP3 Play) Pressing the right side of the SEEK button plays the next MP3 File. Pressing the left side of the SEEK button plays the beginning of the MP3 file. Pressing the button within the first ten seconds plays the previous file.
Page 212 212 UNDERSTANDING YOUR INSTRUMENT PANEL MSG or INFO Button (CD Mode for MP3 Play) Press and MSG or INFO button while playing MP3 disc. The radio scrolls through the following TAG information: Song Title, Artist, File Name, and Folder Name (if avail- able).
Page 213: Sales Code Rak - Am/Fm/Cassette/Cd (6-Disc) Radio With Optional Satellite Radio, Hands Free Phone, Video, Mp3, And Wma Capabilities
Operating Instructions - Satellite Radio Mode (If Equipped) Refer to the Satellite Radio section of the Owner’s Manual. Operating Instructions - Video Entertainment System (VES ) (If Equipped) Refer to separate Video Entertainment System (VES ) Guide. SALES CODE RAK – AM/FM/CASSETTE/CD (6-DISC) RADIO WITH OPTIONAL SATELLITE RADIO, HANDS FREE PHONE, VIDEO, MP3, and WMA CAPABILITIES...
Page 214 214 UNDERSTANDING YOUR INSTRUMENT PANEL Power Switch/Volume Control (Rotary) Press the ON/VOL control to turn the radio ON. Press the ON/VOL a second time to turn OFF the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction without stopping. Turning the volume control to the right increases the volume and to the left decreases it.
Page 215 Clock Setting Procedure 1. Press and hold the time button until the hours blink. 2. Adjust the hours by turning the right side Tune/ Audio control. 3. After the hours are adjusted, press the right side Tune/Audio control to set the minutes. The minutes will begin to blink.
Page 216 216 UNDERSTANDING YOUR INSTRUMENT PANEL Press the rotary TUNE control a third time and TREBLE will display. Turn the TUNE control to the right or left to increase or decrease the Treble tones. Press the rotary TUNE control a fourth time and BAL will display.
Page 217 Oldies Oldies Soft Soft Nostalgia Nostalgia Jazz Jazz Classical Classical Rhythm and Blues Rhythm_and_Blues Soft Rhythm and Blues Soft_R_&_B Foreign Language Foreign_Language Religious Music Religious_Music Religious Talk Religious_Talk Personality Personality Public Public College College Unassigned Weather Weather UNDERSTANDING YOUR INSTRUMENT PANEL 217 By pressing the SEEK button when the PTY icon is displayed, the radio will be tuned to the next frequency station with the same selected PTY name.
Page 218: Operating Instructions - Tape Player
218 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions — Tape Player Insert the cassette with the exposed tape side toward the left and the mechanical action of the player will gently pull the cassette into the play position. NOTE: When subjected to extremely cold temperatures, the tape mechanism may require a few minutes to warm up for proper operation.
Page 219: Scan Button
Scan Button Press this button to play 10 seconds of each selection. Press the scan button a second time to cancel the feature. Changing Tape Direction If you wish to change the direction of tape travel (side being played), press Preset 6. The lighted arrow in the display window will show the new direction.
Page 220: Load/Eject Button (Cd Mode For Cd Audio Play)
220 UNDERSTANDING YOUR INSTRUMENT PANEL compact discs (CD-RW) compact discs with MP3 tracks and multisession compact discs with CD and MP3 tracks and WMA. Inserting Compact Disc(s) CAUTION! This CD player will accept 4 3/4 inch (12 cm) discs only. The use of other sized discs may damage the CD player mechanism.
Page 221 Radio display will show LOADING DISC when the disc is loading and “READING DISC” when the radio is reading the disc. LOAD/EJT - Eject Press the LOAD/EJT button and the push- button with the corresponding number where the CD was loaded and the disc will unload and move to the entrance for easy removal.
Page 222: Notes On Playing Mp3 Files
222 UNDERSTANDING YOUR INSTRUMENT PANEL RND/PTY Button (Random Play Button) (CD MODE for CD Audio Play) Press this button while the CD is playing to activate Random Play. This feature plays the selections on the compact disc in random order to provide an interesting change of pace.
Page 223 The radio uses the following limits for file systems: • Maximum number of directory levels: 15 • Maximum number of files: 255 • Maximum number of folders: 100 • Maximum number of characters in file/folder names: • Level 1: 12 (including a separator 3-character extension) •...
Page 224 224 UNDERSTANDING YOUR INSTRUMENT PANEL MPEG Specifi- Sampling Fre- cation quency (kHz) MPEG-1 Audio 48, 44.1, 32 Layer 3 MPEG-2 Audio 24, 22.05, 16 Layer 3 ID3 Tag information for artist, song title, and album title are supported for version 1 ID3 tags. ID3 version 2 is not supported by the radios.
Page 225: Operation Instructions - (Cd Mode For Mp3 And Wma Audio Play)
Operation Instructions - (CD Mode for MP3 and WMA Audio Play) SEEK Button (CD Mode for MP3 and WMA Play) Pressing the right side of the SEEK button plays the next file. Pressing the left side of the SEEK button plays the beginning of the file.
Page 226 226 UNDERSTANDING YOUR INSTRUMENT PANEL INFO Button (CD Mode for MP3 Play) Press and INFO button while playing MP3 or WMA disc. The radio scrolls through the following TAG information: Song Title, Artist, File Name, and Folder Name (if avail- able).
Page 227: Sales Code Rec - Am/Fm/Cd (6-Disc) Radio With Navigation System
Operating Instructions - Satellite Radio Mode (If Equipped) Refer to the “Satellite Radio” section of the Owner’s Manual. Operating Instructions - Video Entertainment System (VES) (If Equipped) Refer to separate “Video Entertainment System (VES) Guide.” UNDERSTANDING YOUR INSTRUMENT PANEL 227 SALES CODE REC —...
Page 228: Operating Instructions - Satellite Radio (If Equipped)
228 UNDERSTANDING YOUR INSTRUMENT PANEL menus and instructions for selecting a variety of destina- tions and routes, AM/FM stereo radio and six-disc CD changer with MP3 capability. Mapping information for navigation is supplied on a DVD that is loaded into the unit. One map DVD covers all of North America.
Page 229 2. To show the GPS clock, select “Displayed Clock: GPS Clock” and press ENTER. 3. To adjust the time zone, Select “Time Zone” and press ENTER. Select the appropriate time zone and press ENTER. 4. To turn daylight savings on or off, select “Daylight Savings”...
Page 230: Audio Clock Display
230 UNDERSTANDING YOUR INSTRUMENT PANEL 3. To decrease the clock by one hour, use the Select Encoder to highlight the “-” sign. Press ENTER. Press ENTER again to decrease the clock by another hour. 4. To increase the clock by minutes, make sure “MIN +” is highlighted and press ENTER.
Page 231: Satellite Radio - If Equipped
3. To switch the clock to the small clock, quickly press TIME again. 4. To toggle back to the large clock, simply press TIME. UNDERSTANDING YOUR INSTRUMENT PANEL 231 SATELLITE RADIO — IF EQUIPPED Satellite radio uses direct satellite to receiver broadcast- ing technology to provide clear digital sound, coast to coast.
Page 232: Electronic Serial Number/Sirius Identification Number (Esn/Sid)
232 UNDERSTANDING YOUR INSTRUMENT PANEL 1. The Electronic Serial Number/Sirius Identification Number (ESN/SID). 2. Your Vehicle Identification Number. Electronic Serial Number/Sirius Identification Number (ESN/SID) The Electronic Serial Number/Sirius Identification Num- ber is needed to activate your Sirius Satellite Radio system. To access the ESN/SID, refer to the following steps: ESN/SID Access with REF Radios With the ignition switch in the ACCESSORY position and...
Page 233: Selecting Satellite Mode In Ref, Raq, And Rak Radios
Selecting Satellite Mode in REF, RAQ, and RAK Radios Selecting Satellite Mode — REF Radio Press the MODE button repeatedly until the word SAT appears in the display. A CD may remain in the radio while in the Satellite radio mode.
Page 234: Storing And Selecting Pre-Set Channels
234 UNDERSTANDING YOUR INSTRUMENT PANEL Storing and Selecting Pre-Set Channels In addition to the 12 AM and 12 FM pre-set stations, you may also commit 12 satellite stations to push button memory. These satellite channel pre-set stations will not erase any AM or FM pre-set memory stations. Follow the memory pre-set procedures that apply to your radio.
Page 235: Reception Quality
Reception Quality Satellite reception may be interrupted due to one of the following reasons. • The vehicle is parked in an underground parking structure or under a physical obstacle. • Dense tree coverage may interrupt reception. • Driving under wide bridges or along tall buildings can cause intermittent reception.
Page 236: Radio Operation
236 UNDERSTANDING YOUR INSTRUMENT PANEL The left hand control is a rocker type switch with a push button in the center. The function of the left hand control is different depending on which mode you are in. The following describes the left hand control operation in each mode.
Page 237: Cassette Tape And Player Maintenance
CASSETTE TAPE AND PLAYER MAINTENANCE To keep the cassette tapes and player in good condition, take the following precautions: 1. Do not use cassette tapes longer than C-90; otherwise, sound quality and tape durability will be greatly dimin- ished. 2. Keep the cassette tape in its case to protect from slackness and dust when it is not in use.
Page 238: Compact Disc Maintenance
238 UNDERSTANDING YOUR INSTRUMENT PANEL COMPACT DISC MAINTENANCE To keep the compact discs in good condition, take the following precautions: 1. Handle the disc by its edge; avoid touching the surface. 2. If the disc is stained, clean the surface with a soft cloth, wiping from center to edge.
Page 239: Climate Controls
UNDERSTANDING YOUR INSTRUMENT PANEL 239 CLIMATE CONTROLS Heater Only — Fleet Vehicles The controls for the heating and ventilation system in this vehicle consist of a series of rotary knobs. These comfort controls can be set to obtain desired interior conditions. Manual Heating Controls Climate Control Location...
Page 240 240 UNDERSTANDING YOUR INSTRUMENT PANEL The mode control (at the right of the control panel) can be set in any of the following positions: NOTE: To improve your selection choices, the system allows you to operate at intermediate positions between the major modes.
Page 241 Defrost Outside air is primarily directed to the windshield through the defroster outlets located at the base of the windshield, and the demister outlets located at the edge of each side of the instrument panel. Blower Control The rotary knob on the left of the control panel is the blower control.
Page 242: Air Conditioning And Heating
242 UNDERSTANDING YOUR INSTRUMENT PANEL Air Conditioning and Heating — If Equipped Air Conditioning And Heating Air Conditioning Operation To turn on the Air Conditioning, set the fan control at any speed and press the snowflake button located at the right of the control panel. Conditioned air will be directed through the outlets selected by the mode control.
Page 243 NOTE: To improve your selection choices, the system allows you to operate at intermediate positions between the major modes. These intermediate positions are iden- tified by the small dots. Recirculation Modes (Panel or Bi-Level) Select the recirculation modes when the outside air contains smoke, odors, high humidity, or if rapid cooling is desired.
Page 244 244 UNDERSTANDING YOUR INSTRUMENT PANEL Blower Control The rotary knob on the left of the control panel is the blower control. Turn the knob clockwise to one of the four positions to obtain the blower speed you desire. To turn the blower off, turn the knob to the far left posi- tion.
Page 245: Air Conditioning With Dual Zone Temperature Control - If Equipped
Air Conditioning with Dual Zone Temperature Control — If Equipped With the Dual Zone Temperature Control System, each front seat occupant can independently control the tem- perature of air coming from the outlets on their side of the vehicle. Dual Zone Control Head UNDERSTANDING YOUR INSTRUMENT PANEL 245 Air Conditioning and Heating Operation To turn on the Air Conditioning, set the fan control at any...
Page 246 246 UNDERSTANDING YOUR INSTRUMENT PANEL Recirculation Pushbutton Pushing the Recirculation button al- lows interior air to recirculate continu- ously in any position except defrost and defrost/floor mode for rapid cool down of the interior. See “Fast Cooldown” later in this section. Mode Control The mode control allows you to choose from several patterns of air...
Page 247 Outside air flows in equal proportions through the floor and defroster outlets. Defrost Outside air is primarily directed to the windshield through the defroster outlets located at the base of the windshield and side window demist outlets. NOTE: The air conditioning compressor operates in both Mix and Defrost or a blend of these modes, even if the A/C button has not been pressed.
Page 248 248 UNDERSTANDING YOUR INSTRUMENT PANEL Dual Zone Temperature Control Dual Zone Temperature Control Use this control to regulate the temperature of the air inside the passenger compartment. This is accomplished by having separate temperature control slides for both the driver and front passenger. The blue area of the scale indicates cooler temperatures while the red area indicates warmer temperatures.
Page 249: Operating Tips
NOTE: When you turn off the engine you may hear a hissing sound from under the hood for a short period of time. This is a normal condition that occurs if the air conditioning system has been on. It is not an indication of a problem with the air conditioning system.
Page 250 250 UNDERSTANDING YOUR INSTRUMENT PANEL Regular cleaning of the inside of the windows with a non-filming cleaning solution (vinegar and water works very well) will help prevent contaminates (cigarette smoke, perfumes, etc.) from sticking to the windows. Contaminates increase the rate of window fogging. Summer Operation Air conditioned vehicles must be protected with a high quality antifreeze coolant during summer to provide...
Page 251: Operating Tips Chart
UNDERSTANDING YOUR INSTRUMENT PANEL 251 Operating Tips Chart...
Page 253 STARTING AND OPERATING CONTENTS Starting Procedures – Gas Engines ... 258 Manual Transmission – If Equipped ..258 Automatic Transmission – If Equipped ..258 Normal Starting .
Page 254 254 STARTING AND OPERATING Limited-Slip Differential — If Equipped ..275 Driving On Slippery Surfaces ....276 Axle Locker System ..... 276 Stabilizer/Sway Bar System .
Page 255 Multi Displacement System (MDS) — 5.7L Engine Only ....... . 326 Tire Safety Information .
Page 256 256 STARTING AND OPERATING Tire Pressure Monitor System Components . . . 355 General Information ....357 Fuel Requirements ..... . 357 Reformulated Gasoline .
Page 257 STARTING AND OPERATING 257 Recreational Towing Procedure — Manual Equipment Identification Plate ... . . 387 Shift Transfer Case — If Equipped ..384 Returning To Normal Operation —...
Page 258: Starting Procedures - Gas Engines
258 STARTING AND OPERATING STARTING PROCEDURES – GAS ENGINES Before starting your vehicle, adjust your seat, adjust both inside and outside mirrors, and fasten your seat belts. The starter should not be operated for more than 15- second intervals. Waiting a few seconds between such intervals will protect the starter from overheating.
Page 259: Normal Starting
Normal Starting Normal starting of either a warm or cold engine is obtained without pumping or depressing the accelerator pedal. Turn the key to the START position and release when the engine starts. If the engine fails to start within 10 seconds, turn the key to the OFF position, wait 5 seconds, then repeat the starting procedure.
Page 260 260 STARTING AND OPERATING CAUTION! To prevent damage to the starter, do not crank the engine for more than 15 seconds at a time. Wait 10 to 15 seconds before trying again. WARNING! Never pour fuel or other flammable liquids into the throttle body air inlet opening in an attempt to start the vehicle.
Page 261: After Starting
If the engine has been flooded, it may start to run, but not have enough power to continue running when the key is released. If this occurs, continue cranking with the accel- erator pedal pushed all the way to the floor. Release the accelerator pedal and the key once the engine is running smoothly.
Page 262: Automatic Transmission
262 STARTING AND OPERATING AUTOMATIC TRANSMISSION CAUTION! Damage to the transmission may occur if the follow- ing precautions are not observed: • Shift into PARK only after the vehicle has come to a complete stop. • Shift into or out of REVERSE only after the vehicle has come to a complete stop and the engine is at idle speed.
Page 263 drive, move the selector lever from Park or Neutral to the desired drive position. Pull the selector lever toward you when shifting into Reverse, Second, First or Park, or when shifting out of Park. Gear Ranges DO NOT race the engine when shifting from Park or Neutral position into another gear range.
Page 264 264 STARTING AND OPERATING WARNING! It is dangerous to shift the selector lever out of “P” or “N” if the engine speed is higher than idle speed. If your foot is not firmly on the brake pedal, the vehicle could accelerate quickly forward or in reverse. You could lose control of the vehicle and hit someone or something.
Page 265 “2” Second Use this position for driving slowly in heavy city traffic or on mountain roads where more precise speed control is desirable. Use it also when climbing long grades, and for engine braking when descending moderately steep grades. NOTE: Do not exceed maximum engine speed. “1”...
Page 266 266 STARTING AND OPERATING If the transmission temperature gets extremely hot, the transmission will automatically select the most desirable gear for operation at this temperature. If the transmission temperature becomes hot enough the TRANS TEMP light may illuminate and the transmission may downshift out of Overdrive until the transmission cools down.
Page 267 reduce the potential for transmission overheating or failure due to excessive shifting. When operating in “TOW HAUL” mode, 5th gear (if equipped) is disabled and 2-3 and 3-4 shift patterns are modified. Shifts into Overdrive (4th gear) are allowed during steady cruise (for improved fuel economy) and automatic closed- throttle downshifts to 3rd gear are performed (for im- proved braking) when driving conditions warrant.
Page 268: Manual Transmission
268 STARTING AND OPERATING NOTE: If the vehicle has not been driven in several days, the first few seconds of operation after shifting the transmission into gear may seem sluggish. This is due to the fluid partially draining from the torque converter into the transmission.
Page 269: Manual Transmission - 6 Speed (G56)
Manual Transmission — 6 Speed (G56) The Power Wagon may be equipped with the G56 manual transmission. This transmission has a “creeper” 1st gear which should be used to start from a standing position when carrying a payload or towing a trailer. Damage to the clutch can result from starting in 2nd or 3rd gear with a loaded vehicle.
Page 270: Downshifting - All Manual Transmissions
270 STARTING AND OPERATING Downshifting – All Manual Transmissions Moving from a high gear down to a lower gear is recommended to preserve brakes when driving down steep hills. In addition, downshifting at the right time provides better acceleration when you desire to resume speed.
Page 271: Four-Wheel- Drive Operation
FOUR-WHEEL- DRIVE OPERATION Manually Shifted Transfer Case Operating Information/Precautions The transfer case provides 4 mode positions - 2 (rear)- wheel-drive high range, 4-wheel-drive high range, neu- tral, and 4-wheel-drive low range. This transfer case is intended to be driven in the 2-wheel- drive position (2H) for normal street and highway con- ditions such as dry hard surfaced roads.
Page 272 272 STARTING AND OPERATING place. Shifting while only the front or rear wheels are spinning can cause damage to the transfer case. Because 4-wheel drive provides improved traction, there is a tendency to exceed safe turning and stopping speeds. Do not go faster than road conditions permit. NOTE: Delayed shifts out of four-wheel drive may be experienced due to uneven tire wear, low or uneven tire pressures, excessive vehicle loading, or cold tempera-...
Page 273: Shifting Procedure - Manually Shifted Transfer Case
4-Wheel-Drive High Range - Locks the front and rear driveshafts together. Forces the front and rear wheels to rotate at the same speed. Additional traction for loose, slippery road surfaces only. Neutral - Disengages both the front and rear driveshafts from the powertrain.
Page 274: Transfer Case Reminder Light
274 STARTING AND OPERATING vehicle in motion, the transfer case will engage / disen- gage faster if you momentarily release the accelerator pedal after completing the shift. Apply a constant force when shifting the transfer case lever. 2H or 4H ⇔ 4L With the vehicle rolling at 2 to 3 mph (3 to 5 km/h), shift an automatic transmission to N (Neutral) or depress the clutch on a manual transmission.
Page 275: Limited-Slip Differential - If Equipped
LIMITED-SLIP DIFFERENTIAL — IF EQUIPPED The limited-slip differential provides additional traction on snow, ice, mud, sand and gravel, particularly when there is a difference between the traction characteristics of the surface under the right and left rear wheels. During normal driving and cornering, the limited-slip unit per- forms similarly to a conventional differential.
Page 276: Driving On Slippery Surfaces
Axle Locker System Dodge Power Wagons are equipped with electronically locking front and rear axles. Locking the axles provides greater traction in severe low traction conditions or in rock climbing environments where one wheel is likely to not be in contact with the ground.
Page 277 CAUTION! Do not try to lock the rear axle if the vehicle is stuck and the tires are spinning. You can damage drivetrain components. Lock the rear axle before attempting situations or navigating terrain, which could possi- bly cause the vehicle to become stuck. The locking axles are controlled by the axle locker switch located on the center console.
Page 278 278 STARTING AND OPERATING rear axles are unlocked. In the REAR LOCK position, the rear axle is locked. In the FRONT/REAR position, the front and rear axles are locked. NOTE: Even when the axles are in the AXLE UNLOCK position, the limited slip differential in the rear axle still provides torque biasing capability for moderate low traction environments.
Page 279: Stabilizer/Sway Bar System
NOTE: The rear axle must be locked before the front axle will lock. To unlock the front axle move the axle locker switch to REAR LOCK. The FRONT/REAR indicator light will go out when the axle is unlocked. NOTE: The axle lockers could be torque locked due to side to side loads on the axle.
Page 280 280 STARTING AND OPERATING The switch has two positions, on-road and off-road. The system is normally in on-road mode, indicated by a solid green light. The stabilizer/sway bar should remain in on-road mode during normal driving conditions. WARNING! Do not disconnect the stabilizer bar and drive on hard surfaced roads or at speeds above 18 MPH, you may lose control of the vehicle, which could result in serious injury.
Page 281: Power Wagon - Safe Off-Road Driving
WARNING! If stabilizer/sway bar will not return to on-road mode, vehicle stability is greatly reduced. Do not attempt to drive vehicle over 18 mph (29 km/h). Driving faster than 18 mph (29 km/h) may cause loss of control of the vehicle, which could result in serious injury.
Page 282 282 STARTING AND OPERATING Ramp Travel Index (RTI) The ramp travel index is the distance, in inches, that you can drive your vehicle with one wheel on a 20-degree ramp without lifting any other wheel off the ground. This distance up the ramp divided by the wheelbase of the vehicle and multiplied by 1000 is the RTI.
Page 283 STARTING AND OPERATING 283 Angles A, B, C, and D...
Page 284 284 STARTING AND OPERATING Water Fording Water Fording Characteristics Water fording characteristic is the vehicle’s ability to cross a body of still water, where the powertrain and drivetrain are safe from water ingestion. The Power Wagon has high water fording characteristics with the ability to cross a pool of water, without stopping, 24 inches deep at a maximum speed of 10 mph and a pool of Front and Rear (Shown) Differential Height E...
Page 285 water 30 inches deep at a maximum speed of 5 mph, both with an entrance ramp angle of 1.3 degrees. CAUTION! The door sill height is 25 inches. Water may intrude into the interior of the vehicle at greater depths. Simultaneous Brake And Throttle Operation Many off-road driving conditions require the simulta- neous use of the brake and throttle (two footed driving).
Page 286: Driving In Snow, Mud And Sand
286 STARTING AND OPERATING CAUTION! Never park your vehicle over dry grass or other combustible materials. The heat from your vehicle exhaust system could cause a fire. WARNING! Always wear your seat belt and firmly tie down cargo. Unsecured cargo can become projectiles in an off-road situation.
Page 287 the wheels and traction will be lost. If you start to slow to a stop, try turning your steering wheel no more than ⁄ turn quickly back and forth, while still applying throttle. This will allow the tires to get a fresh bite and help maintain your momentum.
Page 288: Crossing Obstacles (Rocks And Other High Points)
288 STARTING AND OPERATING air pressure before driving on pavement or other hard surfaces. Be sure you have a way to air the tires back up prior to reducing the pressure. CAUTION! Reduced tire pressures may cause tire unseating and total loss of air pressure.
Page 289 stand a safe distance in front of you where they can see the obstacle, watch your tires and undercarriage, and guide you through. Crossing Large Rocks When approaching large rocks, choose a path which ensures you drive over the largest of them with your tires.
Page 290 290 STARTING AND OPERATING dirt to fill the rut ahead of the turnout you just created. You should now be able to drive out following the trench you just created at a 45-degree angle. WARNING! There is an increased risk of roll over when crossing an obstacle, at any angle, with steep sides.
Page 291: Hill Climbing
CAUTION! Winching or rocking the vehicle off hard objects increases the risk of underbody damage. Hill Climbing Hill climbing requires good judgment and a good under- standing of your abilities and your vehicle’s limitations. Hills can cause serious problems. Some are just too steep to climb and should not be attempted.
Page 292 292 STARTING AND OPERATING ⁄ turn quickly back and forth. This will provide a fresh bite into the surface and will usually provide enough traction to complete the climb. If you do not make it to the top, place the vehicle in reverse and back straight down the grade using engine resistance along with the vehicle brakes.
Page 293 more weight on the down hill wheels, which increases the possibilities of a down hill slide or roll over. Make sure the surface has good traction with firm and stable soils. If possible transverse the incline at an angle heading slightly up or down. WARNING! Driving across an incline increases the risk of a roll over, which may result in severe injury.
Page 294: Driving Through Water
294 STARTING AND OPERATING Driving Through Water Extreme care should be taken crossing any type of water. Water crossings should be avoided if possible and only be attempted when necessary, in a safe responsible manner. You should only drive through areas which are designated and approved.
Page 295 muddy waters, check for hidden obstacles. Make sure you will not be intruding on any wildlife and you can recover the vehicle if necessary. The key to a safe crossing is the water depth, current and bottom con- ditions. On soft bottoms the vehicle will sink in, effectively increasing the water level on the vehicle.
Page 296: Airing Down For Off-Road Driving
296 STARTING AND OPERATING Even the slowest current can push the heaviest vehicle downstream out of control if the water is deep enough to push on the large surface area of the vehicle’s body. Before you proceed determine the speed of the current, the water’s depth, approach angle, bottom condition and if there are any obstacles, then cross at an angle heading slightly upstream using the low and slow...
Page 297: Vehicle Recovery
CAUTION! Reduced tire pressure increases the risk of tire dam- age and may cause tire unseating with total loss of air pressure. To reduce the risk of tire unseating, while at a reduced tire pressure, drive at slower speeds and avoid sharp turns or abrupt maneuvers.
Page 298 298 STARTING AND OPERATING CAUTION! Pulling the vehicle off an obstacle, without first clearing the object, may result in additional under- body damage. • Rock Cycling Your Vehicle – Rock cycling your ve- hicle is one of the easiest, fastest and most commonly used methods.
Page 299 point. Using tow straps requires coordination between the two drivers. Good communication and line of sight are required for a safe recovery. First connect the tow strap to the correct attachment points on both vehicles. There should be a least 20 to 30 feet between the vehicles to allow for a safe recovery.
Page 300 300 STARTING AND OPERATING • Winching (see the section on “Winch Operation” for additional information on the Power Wagon’s winch) – Winching is most commonly used in the following situations: there is no support vehicle available, a high controlled force is required to recover the vehicle, there is a high risk of environmental or vehicle dam- age, or where nothing else seemed to work.
Page 301: After Driving Off-Road
WARNING! Winch cables are under high tension when in use and can become a projectile if they fail. Never stand over or straddle the winch cable. Never jerk or overload the winch cable. Never stand in front of the vehicle while winching.
Page 302: Winch Usage - If Equipped
302 STARTING AND OPERATING WARNING! Abrasive material in any part of the brakes may cause excessive wear or unpredictable braking. You might not have full braking power when you need it to prevent an accident. If you have been operating your vehicle in dirty conditions, get your brakes checked and cleaned as necessary.
Page 303 3. Apply at least 500 lbs. of tension to the rope while winding the rope in. Always use care to ensure the rope does not pile up on one side of the drum and is neatly wound onto the drum. CAUTION! Wire rope must spool on the winch drum in the direction indicated on the drum rotation decal on the...
Page 304: Understanding The Features Of Your Winch
304 STARTING AND OPERATING UNDERSTANDING THE FEATURES OF YOUR WINCH Winch Components...
Page 305 1. Motor: The winch motor is powered by the vehicle charging system and features a thermal protection switch that automatically stops motor function in the power-in direction if the motor gets too hot. 2. Remote Socket: The remote socket allows the remote control to be attached to the control pack to allow the winch to function.
Page 306: Winch Accessories
306 STARTING AND OPERATING WINCH ACCESSORIES The following accessories are necessary to attach the winch to anchors, change direction of pull, and for safe winching. Gloves: Wire rope, through use, will develop which can slice skin. It is ex- tremely important to wear protective gloves while oper- ating the winch or handling the wire rope.
Page 307: Operating Your Winch
Clevis/D-Shackles: OPERATING YOUR WINCH D-Shackle is a safe means of connecting the looped ends of • Always use supplied hook strap to hold hook when spooling wire rope in or out. cables, straps and snatch • Never use as a hoist. blocks.
Page 308 308 STARTING AND OPERATING General Information Practice using your winch before you get stuck. Some key points to remember when using your winch are: 1. Always take your time to assess the situation and plan your pull carefully. 2. Always take your time when using a winch. 3.
Page 309 CAUTION! Be careful not to pull the Winch Cable Collar through the rollers. Watch and listen to Winch for proper snugness. STARTING AND OPERATING 309 1. Inspect the winch, winch mount, and wire rope for damage. Do not use the winch if the mount is loose or rope shows excessive wear or damage.
Page 310 310 STARTING AND OPERATING 3. Disengage clutch to allow free spooling of the winch drum, rotate the clutch lever on the winch to disengage. Freespooling conserves battery power. Free Spool 4. Free the winch hook and attach hook strap. Free the winch hook from its anchor point.
Page 311 6. Secure to the anchor point. Once you’ve established your anchor point, secure the tree-trunk protector or choker-chain around the object. STARTING AND OPERATING 311 Tree Trunk Protector CAUTION! Always be certain the anchor you select will with- stand the load.
Page 312 312 STARTING AND OPERATING NOTE: How to choose an anchor point: A secure anchor is critical to winching operations. An anchor must be strong enough to hold while winching. Natural an- chors include trees, stumps and rocks. Hook the cable as low as possible.
Page 313 9. Connect the remote control to the winch control box, located behind the front bumper. Be careful not to let the remote control cord dangle in front of the winch. If you choose to control the winch from inside your vehicle, always pass the remote through a window to avoid pinching the cord in the door.
Page 314 314 STARTING AND OPERATING 12. Check wire rope. The wire rope should be neatly wound around the spooling drum. Improper winding can cause damage to the wire rope. 13. In certain situations you may decide to throw a heavy blanket or similar object over the wire rope.
Page 315 the vehicle and never near the wire rope or snatch block. Your situation may have other no people zones. No People Zones 15. Begin winching. With the winching vehicles engine on and light tension already on the wire rope, begin winching slowly and steadily.
Page 316 316 STARTING AND OPERATING NOTE: Avoid overheating the winch motor. For ex- tended winching, stop at reasonable intervals to allow the winch motor to cool down. NOTE: What to look for under load: The wire rope must always spool onto the drum as indicated by the drum rotation decal on the winch.
Page 317 WARNING! To prevent serious injury, NEVER put your fingers inside the hook area as you are powering-in. STARTING AND OPERATING 317 NOTE: How to spool under no load: Arrange the remote control lead so it cannot be caught in the winch. Arrange the wire rope so it will not kink or tangle when spooled.
Page 318: Rigging Techniques
318 STARTING AND OPERATING 19. Store the hook on the most outboard loop of the tow hook. 20. Disconnect remote control. Disconnect the remote control cord from the control box and store in a clean and dry place. Winching operations are now complete. Put the cap on the solenoid plug-in.
Page 319 STARTING AND OPERATING 319 How to change the pulling direction: All winching operations should have a straight line from the winch to the object being pulled. This minimizes the wire rope collecting on one side of the drum affecting pulling efficiency and damaging wire rope. A snatch block, secured to a point directly in front of the vehicle will enable you to change your pulling direction while still allowing the wire rope to be at 90°...
Page 320 320 STARTING AND OPERATING Increasing pulling power: Increase Pulling Power In some cases, you may find yourself needing more pulling power. The use of snatch blocks increases me- chanical advantage and that increases your pulling power: Double Line: Because pulling power decreases with the number of layers of wire rope on the winch drum, you can use a snatch block to double line out more wire rope.
Page 321: Parking Brake
vehicle’s frame/tow hook and run the wire rope through a snatch block. Disengage the clutch and, using the snatch block, pull out enough wire to reach your anchor point. Do not attach hook to mounting kit. Secure to the anchor point with a tree trunk protector or choker chain. Attach the clevis/shackle.
Page 322: Brake System
322 STARTING AND OPERATING WARNING! • Always fully apply the parking brake when leav- ing your vehicle, or it may roll and cause damage or injury. Also be certain to leave an automatic transmission in Park, a manual transmission in Reverse or First gear.
Page 323: Brake Noise
Brake Noise During normal operation of the brake system certain noises may be present from time to time. Occasional groan or squeal noises may occur during normal operation of the brake system which may not be indica- tive of a problem. These noises may be heard at any time the brakes are applied but may be more noticeable during the first few brake applications in the morning.
Page 324 324 STARTING AND OPERATING WARNING! Pumping of the anti-lock brakes will diminish their effectiveness and may lead to an accident. Pumping makes the stopping distance longer. Just press firmly on your brake pedal when you need to slow down or stop.
Page 325: Power Steering
POWER STEERING The standard power steering system will give you good vehicle response and increased ease of maneuverability in tight spaces. The system will provide mechanical steering capability if power assist is lost. If for some reason, the power assist is interrupted, it will still be possible to steer your vehicle.
Page 326: Multi Displacement System (Mds) - 5.7L Engine Only
326 STARTING AND OPERATING MULTI DISPLACEMENT SYSTEM (MDS) — 5.7L Engine Only This feature offers improved fuel economy by shutting off four of the engine’s eight cylinders during light load and cruise conditions. The system is automatic with no driver inputs or additional driving skills required. NOTE: The MDS system may take some time to return to full functionality after a battery disconnect.
Page 327 • European Metric tire sizing is based on European design standards. Tires designed to this standard have the tire size molded into the sidewall beginning with the section width. The letter P is absent from this tire size designation. Example: 215/65R15 96H •...
Page 328 328 STARTING AND OPERATING Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light Truck tire based on U.S. design standards T = Temporary Spare tire 31 = Overall Diameter in Inches (in) 215 = Section Width in Millimeters (mm)
Page 329 Service Description: 95 = Load Index —A numerical code associated with the maximum load a tire can carry. H = Speed Symbol —A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions. —The maximum speed corresponding to the Speed Symbol should only be achieved un- der specified operating conditions (i.e.
Page 330: Tire Identification Number (Tin)
330 STARTING AND OPERATING Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire; however, the date code may only be on one side. Tires with white sidewalls will have the full TIN including date code DOT = Department of Transportation —This symbol certifies that the tire is in compliance with the U.S.
Page 331: Tire Loading And Tire Pressure
Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on either the face of the driver’s door or the driver’s side “B” pillar. Tire Placard Location STARTING AND OPERATING 331 Tire and Loading Information Placard Tire and Loading Information This placard tells you important information about the: 1) number of people that can be carried in the vehicle...
Page 332 332 STARTING AND OPERATING Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the “Tire and Loading Information”...
Page 333 5. Determine the combined weight of luggage and cargo being loaded on the vehicle. That weight may not safely exceed the available cargo and luggage load capacity calculated in Step 4. 6. If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle.
Page 334 334 STARTING AND OPERATING...
Page 335: Tires - General Information
WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 336: Tire Inflation Pressures
336 STARTING AND OPERATING 2. Economy— Improper inflation pressures can cause uneven wear patterns to develop across the tire tread. These abnormal wear patterns will reduce tread life resulting in a need for earlier tire replacement. Under inflation, also increases tire rolling resistance and results in higher fuel consump- tion.
Page 337 check tire pressure. Do not make a visual judgement when determining proper inflation. Radial tires may look properly inflated even when they are under inflated. CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap (if equipped). This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem.
Page 338: Radial-Ply Tires
338 STARTING AND OPERATING Tire Pressures for High Speed Operation The manufacturer advocates driving at safe speeds within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high speeds, maintaining correct tire inflation pressure is very important.
Page 339: Compact Spare Tire - If Equipped
Compact Spare Tire — If Equipped The compact spare is for temporary emergency use with radial tires. It is engineered to be used on your style vehicle only. Since this tire has limited tread life, the original tire should be repaired (or replaced) and rein- stalled at the first opportunity.
Page 340: Tire Spinning
340 STARTING AND OPERATING original equipped tire on the front or rear axle of your vehicle, but it is not. Installation of this limited use spare tire affects vehicle handling. Since it is not the same tire, replace (or repair) the original tire and reinstall on the vehicle at the first opportunity.
Page 341: Tread Wear Indicators
Tread Wear Indicators Tread wear indicators are in the original equipment tires to help you in determining when your tires should be replaced. STARTING AND OPERATING 341 These indicators are molded into the bottom of the tread grooves. They will appear as bands when the tread depth becomes 1/16 inch (2 mm).
Page 342: Replacement Tires
342 STARTING AND OPERATING WARNING! Tires and spare tire should be replaced after six years, regardless of the remaining tread. Failure to follow this warning can result in sudden tire failure. You could lose control and have an accident resulting in serious injury or death.
Page 343: Alignment And Balance
WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change suspension dimensions and performance characteristics, result- ing in changes to steering, handling, and braking of your vehicle.
Page 344: Supplemental Tire Pressure Information - If Equipped
344 STARTING AND OPERATING Improper alignment will not cause vehicle vibration. Vibration may be a result of tire and wheel out-of- balance. Proper balancing will reduce vibration and avoid tire cupping and spotty wear. SUPPLEMENTAL TIRE PRESSURE INFORMATION — IF EQUIPPED A light load vehicle condition is defined as two passen- gers {150 lbs (68 kg) each} plus 200 lbs (91kg) of cargo.
Page 345: Snow Tires
These cautions apply to all chain traction devices, includ- ing link and cable (radial) chains. NOTE: On 4x4 Power Wagon models, class “U” snow chains are permitted on the rear wheels only of vehicles equipped with LT285/70R17D. CAUTION! Do not use tire chains on the 4X4 front wheels of Ram Trucks equipped with LT285/70R17D.
Page 346: Tire Rotation Recommendations
346 STARTING AND OPERATING TIRE ROTATION RECOMMENDATIONS Tires on the front and rear axles of vehicles operate at different loads and perform different steering, driving, and braking functions. For these reasons, they wear at unequal rates, and develop irregular wear patterns. These effects can be reduced by timely rotation of tires.
Page 347: Tire Pressure Monitor System (Tpms) - If Equipped
TIRE PRESSURE MONITOR SYSTEM (TPMS) — IF EQUIPPED The Tire Pressure Monitoring System (TPMS) will warn the driver of a low tire pressure based on the vehicle recommended cold tire inflation placard pressure. The placard pressure is defined on the Tire and Loading Information label.
Page 348 348 STARTING AND OPERATING The TPM System will continue to warn the driver of low tire pressure as long as the condition exists, and will not turn off until the tire pressure is at or above recom- mended cold placard pressure. Once the low tire pressure warning has been illuminated, the tire pressure must be increased to the recommended cold placard pressure in order for the TPMS warning lamp to be turned off.
Page 349 CAUTION! After inspecting or adjusting the tire pressure always reinstall the valve stem cap. This will prevent mois- ture and dirt from entering the valve stem, which could damage the Tire Pressure Monitoring Sensor. NOTE: • The TPMS is not intended to replace normal tire care and maintenance, nor to provide warning of a tire failure or condition.
Page 350: Tire Pressure Monitor System (Tpms) "Light Load" Reset Switch Description - If Equipped
350 STARTING AND OPERATING Tire Pressure Monitor System (TPMS) “Light Load” Reset Switch Description – If Equipped WARNING! Never operate your vehicle with the TPMS and tire pressures set to the Light Load Inflation Pressure settings if carrying more than two occupants ( 150 lbs each) plus 200 pounds of cargo.
Page 351 Light Load Reset Switch STARTING AND OPERATING 351 “Light Load” Reset Switch Operation – If Equipped • This vehicle may have different recommended tire pressure values between the front and rear tires as shown in both the Tire Loading Information Label and the Supplemental Tire Pressure Information Label (located on the rear face of the driver door).
Page 352 352 STARTING AND OPERATING • The TPMS system will always reset to the max load inflation pressure (cold) low pressure warning thresh- old condition when the system experiences a loss of electrical power. For example, by momentarily discon- necting the battery or IOD fuse. Example Supplemental Tire Pressure Label To switch from the max load inflation pressure (cold) low pressure warning threshold to the light load inflation...
Page 353 25% or more below the light load inflation pressure (cold) tire pressure values. The light load inflation pressure (cold) tire pressure values are defined in the Supplemen- tal Tire Pressure Information label located on the rear face of the driver door. If the switch LED did not turn ON, you may need to drive the vehicle for one minute above 15 mph (25 km/h) and then press the “Light Load”...
Page 354 354 STARTING AND OPERATING WARNING! It is the driver’s responsibility to change to the max load inflation pressure (cold) low pressure warning threshold condition when not driving in the light load condition as defined as two occupants ( 150 lbs each) plus 200 pounds of cargo.
Page 355: Tire Pressure Monitor System Components
Tire Pressure Monitor System Components The Tire Pressure Monitor System (TPMS) uses wireless technology with wheel rim mounted electronic sensors to monitor tire pressure levels. Sensors, mounted to each wheel as part of the valve stem, transmit tire pressure readings to the Receiver Module. NOTE: It is particularly important, for you to check the tire pressure in all of your tires regularly and to maintain the proper pressure.
Page 356 356 STARTING AND OPERATING the ignition key is cycled, this sequence will repeat, providing the system fault still exists. A system fault can occur by any of the following scenarios: 1. Signal interference due to electronic devices or driving next to facilities emitting the same Radio Frequencies as the TPM sensors.
Page 357: General Information
Light will turn OFF, as long as no tire pressure is below the low-pressure warning limit in any of the four active road tires. The vehicle may need to be driven for up to 10 minutes above 15 mph (25 km/h) in order for the TPMS to receive this information.
Page 358: Reformulated Gasoline
358 STARTING AND OPERATING Poor quality gasoline can cause problems such as hard starting, stalling and hesitations. If you experience these symptoms, try another brand of “regular” gasoline be- fore considering service for the vehicle. Over 40 auto manufacturers world-wide have issued and endorsed consistent gasoline specifications (the World- wide Fuel Charter, WWFC) to define fuel properties necessary to deliver enhanced emissions, performance...
Page 359: Mmt In Gasoline
MMT In Gasoline MMT is a manganese-containing metallic additive that is blended into some gasoline to increase octane. Gasolines blended with MMT provide no performance advantage beyond gasolines of the same octane number without MMT. Gasolines blended with MMT reduce spark plug life and reduce emission system performance.
Page 360: Materials Added To Fuel
360 STARTING AND OPERATING CAUTION! If the Check Engine or Service Engine Soon light is flashing, immediate service is required; see onboard diagnostics system section. Materials Added To Fuel All gasolines sold in the United States are required to contain effective detergent additives. Use of additional detergents or other additives is not needed under normal conditions and would result in unnecessary cost.
Page 361: Carbon Monoxide Warnings
• The use of fuel additives which are now being sold as octane enhancers is not recommended. Many of these products contain high concentrations of methanol. Fuel system damage or vehicle performance problems resulting from the use of such fuels or additives is not the responsibility of the manufacturer.
Page 362: Adding Fuel
362 STARTING AND OPERATING ADDING FUEL Adding Fuel (Gas Engines) The fuel tank filler tube has a restricting door about 2 inches (50 mm) inside the opening. If using a portable fuel container, it should have a flexible nozzle long enough to force open the restricting door.
Page 363 WARNING! • Never have any smoking materials lit in or near the vehicle when the gas cap is removed or the tank filled. • Never add fuel to the vehicle when the engine is running. This is in violation of most state and federal fire regulations and will cause the Mal- function Indicator Light to turn on.
Page 364: Vehicle Loading
364 STARTING AND OPERATING in a row, the system will turn on the Malfunction Indicator Light (MIL). Resolving the problem will turn the MIL light off. VEHICLE LOADING Certification Label As required by National Highway Traffic Safety Admin- istration Regulations, your vehicle has a certification label affixed to the driver’s side door or pillar.
Page 365 Each axle GAWR is determined by the components in the system with the lowest load carrying capacity (axle, springs, tires or wheels). Heavier axles or suspension components sometimes specified by purchasers for in- creased durability does not necessarily increase the vehi- cle’s GVWR.
Page 366 366 STARTING AND OPERATING or rear axles has been exceeded but the total load is within the specified GVWR. If so, weight must be shifted from front to rear or rear to front as appropriate until the specified weight limitations are met. Store the heavier items down low and be sure that the weight is distributed equally.
Page 367: Trailer Towing
STARTING AND OPERATING 367 Gross Vehicle Weight Rating (GVWR) 6500 LBS. TRAILER TOWING In this section you will find safety tips and information on limits to the type of towing you can reasonably do with your vehicle. Before towing a trailer carefully re- view this information to tow your load as efficiently and safely as possible.
Page 368 368 STARTING AND OPERATING Gross Trailer Weight (GTW) The gross trailer weight (GTW) is the weight of the trailer plus the weight of all cargo, consumables and equipment (permanent or temporary) loaded in or on the trailer in its loaded and ready for operation condition. The recom- mended way to measure GTW is to put your fully loaded trailer on a vehicle scale.
Page 369 Frontal Area The maximum height and maximum width of the front of a trailer. Trailer Sway Control The trailer sway control is a telescoping link that can be installed between the hitch receiver and the trailer tongue that typically provides adjustable friction associated with the telescoping motion to dampen any unwanted trailer swaying motions while traveling.
Page 370 370 STARTING AND OPERATING WARNING! An improperly adjusted Weight Distributing Hitch system may reduce handling, stability, braking per- formance, and could result in an accident. Weight Distributing Systems may not be compatible with Surge Brake Couplers. Consult with your hitch and trailer manufacturer or a reputable Recreational Vehicle dealer for additional information.
Page 371: Trailer Hitch Classification
Improper Adjustment of Weight Distributing System Fifth-Wheel Hitch A special high platform with a coupling that mounts over the rear axle of the tow vehicle in the truck bed. Connects a vehicle and fifth-wheel trailer with a coupling king pin. STARTING AND OPERATING 371 Gooseneck Hitch The gooseneck hitch employs a pivoted coupling arm...
Page 372: Trailer Towing Weights (Maximum Trailer Weight Ratings)
• http:// www.dodge.com/towing. • http:// www.dodge.ca (Canada). Trailer and Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the...
Page 373: Towing Requirements
Never exceed the maximum tongue weight stamped on your bumper or trailer hitch. Consider the following items when computing the weight on the rear axle of the vehicle: • The tongue weight of the trailer. STARTING AND OPERATING 373 • The weight of any other type of cargo or equipment put in or on your vehicle.
Page 374 374 STARTING AND OPERATING CAUTION! • Avoid towing a trailer for the first 500 miles (805 km) of vehicle operation. Doing so may damage your axles, driveline and vehicle. • During the first 500 miles (805 km) of trailer towing, limit your speed to 50 mph (80 km/h). Perform the maintenance listed in Section 8 of this manual.
Page 375 • Safety chains must always be used between your vehicle and trailer. Always connect the chains to the frame or hook retainers of the vehicle hitch. Cross the chains under the trailer tongue and allow enough slack for turning corners. •...
Page 376 376 STARTING AND OPERATING − Check for signs of tire wear or visible tire damage before towing a trailer. Refer to the Tires–General Information section of this manual on Tread Wear Indicators for the proper inspection procedure. − When replacing tires refer to the Tires–General Infor- mation section of this manual on Replacement Tires for proper tire replacement procedures.
Page 377 WARNING! Do not connect trailer brakes to your vehicle’s hy- draulic brake lines. It can overload your brake sys- tem and cause it to fail. You might not have brakes when you need them and could have an accident. Towing any trailer will increase your stopping dis- tance.
Page 378 378 STARTING AND OPERATING The electrical connections are all complete to the vehicle but you must mate the harness to a trailer connector. Refer to the following illustrations. 7- Pin Connector 4 - Pin Connector...
Page 379 WARNING! Any work done to the vehicles electrical system, or wiring, should be performed by a qualified automo- tive technician, if done improperly it may cause damage to the electrical system wiring and could result in serious or fatal injury. The following chart identifies the maximum electrical loads that the trailer tow output circuits are capable of supporting.
Page 380: Towing Tips
380 STARTING AND OPERATING Towing Tips Before setting out on a trip, practice turning, stopping and backing the trailer in an area away from heavy traffic. If using a manual transmission vehicle for trailer towing, all starts must be in FIRST gear to avoid excessive clutch slippage.
Page 381: Trailer Towing Mirrors - If Equipped
Towing Tips — Electronic Speed Control (If Equipped) − Don’t use in hilly terrain or with heavy loads. − When using the speed control, if you experience speed drops greater than 10 mph (16 km/h), disengage until you can get back to cruising speed. −...
Page 382 382 STARTING AND OPERATING CAUTION! Do not attempt to fold the 7 x 10 inch trailer towing mirrors forward. The 7 x 10 inch trailer towing mirrors are not designed to be folded forward and doing so will damage the mirrors and/or vehicle. Blindspot Mirror...
Page 383: Snowplow
Trailer Towing Position SNOWPLOW NOTE: Do not use this model vehicle for snowplow applications. STARTING AND OPERATING 383 WARNING! Snowplows and other aftermarket equipment should not be added to the front end or your vehicle. The airbag crash sensors may be affected by the change in the front end structure.
Page 384: Recreational Towing - 4-Wheel Drive Vehicles (Behind Motorhome, Etc.)
384 STARTING AND OPERATING WARNING! Attaching a snowplow to this vehicle could adversely affect performance of the airbag system in an acci- dent. Do not expect that the airbag will perform as described earlier in this manual RECREATIONAL TOWING — 4–WHEEL DRIVE VEHICLES (BEHIND MOTORHOME, ETC.) CAUTION! Internal damage to the transfer case will occur if a...
Page 385 1. Bring the vehicle to a complete stop. 2. Shut OFF the engine. 3. Depress the brake pedal. 4. Shift automatic transmission to N (NEUTRAL), or depress the clutch on manual transmissions. 5. Shift transfer case lever into N (NEUTRAL). 6.
Page 386 386 STARTING AND OPERATING Returning to Normal Operation — Manual Shift Transfer Case Use the following procedure to prepare your vehicle for normal usage: 1. Bring the vehicle to a complete stop. 2. Shut OFF the engine. 3. Depress the brake pedal. 4.
Page 387 CAUTION! • Do not use a bumper mounted clamp-on tow bar on your vehicle. The bumper face bar will be damaged. • Do not disconnect the rear driveshaft because fluid will leak from the transfer case and damage the internal parts. STARTING AND OPERATING 387 EQUIPMENT IDENTIFICATION PLATE The equipment Identification Plate is located on the hood...
Page 389: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....390 Jacking And Tire Changing ....391 All Models –...
Page 390: Hazard Warning Flasher
390 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The Hazard Warning switch is mounted on the top of the steering column as shown in the illustration. Hazard Light Warning Switch To engage the Hazard Warning lights, depress the button on the top of the steering column.
Page 391: Jacking And Tire Changing
JACKING AND TIRE CHANGING WARNING! • Being under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you. You could be crushed. Never put any part of your body under a vehicle that is on a jack. Never start or run the engine while the vehicle is on a jack.
Page 392: Jacking Instructions
392 WHAT TO DO IN EMERGENCIES WARNING! After using the jack and tools, always reinstall them in the original carrier and location. While driving you may experience, abrupt stopping, rapid accelera- tion, or sharp turns. A loose jack, tools, bracket or other objects in the vehicle may move around with force, resulting in serious injury.
Page 393: Tire Changing Procedure
NOTE: The winch mechanism is designed for use with the jack extension tube only. Use of an air wrench or other power tools is not recommended and can damage the winch. Tire Changing Procedure WARNING! Getting under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you.
Page 394 394 WHAT TO DO IN EMERGENCIES • Block both the front and rear of the wheel diagonally oppo- site the jacking position. For example, if the right front wheel is being changed, block the left rear wheel. • Passengers should not remain in the vehicle when the vehicle is being jacked.
Page 395 1. Remove the spare wheel, jack, and tools from storage. 2. Using the wheel wrench, loosen, but do not remove, the wheel nuts by turning them counterclockwise one turn while the wheel is still on the ground. 3. For Power Wagon, when changing the front wheel, assemble the jack drive tube to the jack and connect the drive tube to the extension tube.
Page 396 396 WHAT TO DO IN EMERGENCIES 4. By rotating the wheel wrench clockwise, raise the vehicle until the wheel just clears the surface. WARNING! Raising the vehicle higher than necessary can make the vehicle unstable and cause an accident. It could slip off the jack and hurt someone near it.
Page 397 WARNING! A loose tire or jack thrown forward in a collision or hard stop could injure someone in the vehicle. Al- ways stow the jack parts and the extra tire and wheel in the places provided. 7. Remove wheel blocks. Do not install chrome or alu- minum wheel center caps on the spare wheel.
Page 398 398 WHAT TO DO IN EMERGENCIES Wheel Nuts All wheel nuts should be tightened occasionally to elimi- nate the possibility of wheel studs being sheared or the bolt holes in the wheels becoming elongated. This is especially important during the first few hundred miles of operation to allow the wheel nuts to become properly set.
Page 399: Hoisting
HOISTING A conventional floor jack may be used at the jacking locations, refer to the graphics that show jacking loca- tions. However, a floor jack or frame hoist must never be used on any other parts or the underbody. CAUTION! Never use a floor jack directly under the differential housing of a loaded truck or damage to your vehicle may result.
Page 400 400 WHAT TO DO IN EMERGENCIES WARNING! Battery fluid is a corrosive acid solution; do not allow battery fluid to contact eyes, skin or clothing. Don’t lean over battery when attaching clamps or allow the clamps to touch each other. If acid splashes in eyes or on skin, flush contaminated area immediately with large quantities of water.
Page 401 5. Connect the other cable, first to the negative terminal of the booster battery and then to the engine of the vehicle with the discharged battery. Make sure you have a good contact on the engine. WHAT TO DO IN EMERGENCIES 401 WARNING! •...
Page 402: Freeing A Stuck Vehicle
402 WHAT TO DO IN EMERGENCIES WARNING! Any procedure other than above could result in: 1. Personal injury caused by electrolyte squirting out the battery vent; 2. Personal injury or property damage due to battery explosion; 3. Damage to charging system of booster vehicle or of immobilized vehicle.
Page 403: Towing A Disabled Vehicle
WARNING! Chains are not recommended for freeing a stuck vehicle. Chains may break, causing serious injury or death. WARNING! Stand clear of vehicles when pulling with tow hooks. Tow straps and chains may break, causing serious injury. WHAT TO DO IN EMERGENCIES 403 CAUTION! Tow hooks are for emergency use only, to rescue a vehicle stranded off road.
Page 404: 4-Wheel-Drive Vehicles
404 WHAT TO DO IN EMERGENCIES 4-Wheel-Drive Vehicles CAUTION! To avoid damage to the transfer case while towing, always use the following method. The manufacturer recommends towing with all wheels off the ground. Acceptable methods are to tow vehicle on a flatbed or with one end of vehicle raised and the opposite end on a towing dolly.
Page 405: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment— 5.7L Gas Engine ..408 Onboard Diagnostic System (OBD II) ..409 Loose Fuel Filler Cap Message ... . 409 Emissions Inspection And Maintenance Programs .
Page 406 406 MAINTAINING YOUR VEHICLE Power Steering — Fluid Check ... . 421 Front Suspension Ball Joints ....422 Steering Linkage —...
Page 407 Bulb Replacement ..... . 453 Headlight (Halogen)/Front Park And Turn Lights ......453 Tail, Stop, Turn And Backup Lights .
Page 408: Engine Compartment- 5.7L Gas Engine
408 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT— 5.7L GAS ENGINE...
Page 409: Onboard Diagnostic System (Obd Ii)
ONBOARD DIAGNOSTIC SYSTEM (OBD II) Your vehicle is equipped with a sophisticated onboard diagnostic system called OBDII. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 410: Emissions Inspection And Maintenance Programs
410 MAINTAINING YOUR VEHICLE tightened. Press the odometer reset button to turn the message off. If the problem persists, the message will appear the next time the vehicle is started. This might indicate a damaged cap. If the problem is detected twice in a row, the system will turn on the Malfunction Indicator Light (MIL).
Page 411: Replacement Parts
5. Approximately 15 seconds later, one of two things will happen: a. The MIL light will blink for approximately 5 sec- onds and then remain on until the first engine crank or the key is turned off. This means that your vehicle’s OBD system is not ready and you should not proceed to the I/M station.
Page 412: Dealer Service
412 MAINTAINING YOUR VEHICLE DEALER SERVICE Your dealer has the qualified service personnel, special tools and equipment to perform all service operations in an expert manner. Service manuals are available which include detailed service information for your vehicle. Refer to these manuals before attempting any procedure yourself.
Page 413: Engine Oil
These items should be inspected if a malfunction is observed or suspected. Engine Oil Checking Oil Level To assure proper lubrication of your vehicle’s engine, the engine oil must be maintained at the correct level. The best time to check the engine oil level is about 5 minutes after a fully warmed up engine is shut off or before starting the engine after it has sat overnight.
Page 414 414 MAINTAINING YOUR VEHICLE Change Engine Oil Follow the Maintenance Schedule for recommended en- gine oil change intervals. Engine Oil Selection For best performance and maximum protection under all types of operating conditions, the manufacture only recommends engine oils that are API certified and meet the requirements of DaimlerChrysler Material Standard MS-6395.
Page 415: Engine Oil Filter
For information on engine oil filler cap location, see the Engine Compartment illustration in this section. Lubricants which do not have both, the engine oil certi- fication mark and the correct SAE viscosity grade num- ber should not be used. Synthetic Engine Oils You may use synthetic engine oils provided the recom- mended oil quality requirements are met, and the recom-...
Page 416: Drive Belts - Check Condition And Tension
416 MAINTAINING YOUR VEHICLE Drive Belts — Check Condition and Tension Belt tension is controlled by means of an automatic tensioner. No belt tension adjustments are required. However, belt and belt tensioner condition should be inspected at the specified intervals and replaced if re- quired.
Page 417: Engine Fuel Filter
WARNING! The air induction system (air cleaner, hoses, etc) can provide a measure of protection in the case of engine backfire. Do not remove the air induction system (air cleaner, hoses, etc) unless such removal is necessary for repair or maintenance. Make sure that no one is near the engine compartment before starting the vehicle with the air induction system (air cleaner, hoses, etc) removed.
Page 418 418 MAINTAINING YOUR VEHICLE CAUTION! Damage to the catalytic converter can result if your vehicle is not kept in proper operating condition. In the event of engine malfunction, particularly involv- ing engine misfire or other apparent loss of perfor- mance, have your vehicle serviced promptly. Contin- ued operation of your vehicle with a severe malfunction could cause the converter to overheat, resulting in possible damage to the converter and the...
Page 419: Emission-Related Components
To minimize the possibility of catalyst damage: • Do not shut off the engine or interrupt the ignition when the transmission is in gear and the vehicle is in motion. • Do not try to start engine by pushing or towing the vehicle.
Page 420: Air Conditioner Maintenance
420 MAINTAINING YOUR VEHICLE WARNING! Battery fluid is a corrosive acid solution and can burn or even blind you. Don’t allow battery fluid to contact your eyes, skin or clothing. Don’t lean over a battery when attaching clamps. If acid splashes in eyes or on skin, flush the area immediately with large amounts of water.
Page 421: Power Steering - Fluid Check
include cleaning of the condenser fins and a performance test. Drive belt tension should also be checked at this time. WARNING! • Use only refrigerants and compressor lubricants approved by the manufacturer for your air condi- tioning system. Some unapproved refrigerants are flammable and can explode, injuring you.
Page 422: Front Suspension Ball Joints
422 MAINTAINING YOUR VEHICLE WARNING! Fluid level should be checked on a level surface and with the engine off to prevent injury from moving parts and to insure accurate fluid level reading. Do not overfill. Use only manufacturers recommended power steering fluid. If necessary, add fluid to restore to the proper indicated level.
Page 423: Steering Linkage - Inspection
Front suspension ball joints should be replaced only by a qualified service technician using tools specially de- signed for this purpose. Damage to the joints and/or suspension components may result if improper replace- ment procedures are used. If seals are damaged the ball joints should be replaced to prevent leakage or contamination of the grease.
Page 424: Body Lubrication
424 MAINTAINING YOUR VEHICLE Body Lubrication Locks and all body pivot points, including such items as seat tracks, doors, tailgate and hood hinges, should be lubricated periodically to assure quiet, easy operation and to protect against rust and wear. Prior to the appli- cation of any lubricant, the parts concerned should be wiped clean to remove dust and grit;...
Page 425: Exhaust System
To prevent freeze-up of your windshield washer system in cold weather, select a solution or mixture that meets or exceeds the temperature range of your climate. This rating information can be found on most washer fluid containers. WARNING! Commercially available windshield washer solvents are flammable.
Page 426: Cooling System
426 MAINTAINING YOUR VEHICLE WARNING! Exhaust gases can injure or kill. They contain carbon monoxide (CO) which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing CO, fol- low the preceding safety tips. Exhaust System Rubber Isolator and Loop-Type Hanger —...
Page 427 accumulation of bugs, leaves, etc. If dirty, clean by gently spraying water from a garden hose vertically down the face of the condenser. Check the coolant recovery bottle tubing for brittle rub- ber, cracking, tears, cuts and tightness of the connection at the bottle and radiator.
Page 428 428 MAINTAINING YOUR VEHICLE CAUTION! Mixing of coolants other than specified HOAT en- gine coolants, may result in engine damage and may decrease corrosion protection. If a non-HOAT coolant is introduced into the cooling system in an emer- gency, it should be replaced with the specified cool- ant as soon as possible.
Page 429 The use of lower quality water will reduce the amount of corrosion protection in the engine cooling system. Please note that it is the owner’s responsibility to main- tain the proper level of protection against freezing ac- cording to the temperatures occurring in the area where the vehicle is operated.
Page 430 430 MAINTAINING YOUR VEHICLE community. To prevent ingestion by animals or children do not store ethylene glycol based engine coolant in open containers or allow it to remain in puddles on the ground. If ingested by a child, contact a physician immediately.
Page 431: Hoses And Vacuum/Vapor Harnesses
• Check coolant freeze point in the radiator and in the coolant recovery bottle. If antifreeze needs to be added, contents of coolant recovery bottle must also be protected against freezing. • If frequent coolant additions are required, or if the level in the coolant recovery bottle does not drop when the engine cools, the cooling system should be pres- sure tested for leaks.
Page 432: Brake System
432 MAINTAINING YOUR VEHICLE Inspect all hose connections such as clamps and cou- plings to make sure they are secure and no leaks are present. Components should be replaced immediately if there is any evidence of wear or damage that could cause failure. Brake System Power Disc Brakes (front and rear) Disc brakes do not require adjustment;...
Page 433: Clutch Hydraulic System
WARNING! Overfilling the brake fluid reservoir can result in spilling brake fluid on hot engine parts and the brake fluid catching fire. Use only brake fluid that has been in a tightly closed container to avoid contamination from foreign matter or moisture.
Page 434: Rear Axle And 4X4 Front Driving Axle Fluid Level
434 MAINTAINING YOUR VEHICLE Rear Axle And 4x4 Front Driving Axle Fluid Level Refer to Fluids, Lubricants and Genuine Parts for the correct Fluid type. For normal service, periodic fluid level checks are not required. When the vehicle is serviced for other reasons the exterior surfaces of the axle assembly should be inspected.
Page 435: Transfer Case
Transfer Case Fluid Level Check This fluid level can be checked by removing the filler plug. The fluid level should be to the bottom edge of the filler plug hole with the vehicle in a level position. Drain And Refill Follow the Maintenance Schedule for recommended transfer case fluid change intervals.
Page 436: Automatic Transmission
436 MAINTAINING YOUR VEHICLE Automatic Transmission Fluid Level Check The fluid level should be checked when the engine is fully warmed up and the fluid in the transmission is at normal operating temperature. Operation of the trans- mission with an improper fluid level will greatly reduce the life of the transmission and of the fluid.
Page 437 a minimum of two (2) minutes for the oil to fully drain into the transmission before rechecking the fluid level. NOTE: If it is necessary to check the transmission below the operating temperature, the fluid level should be between the two “COLD” (lower) holes on the dipstick with the fluid at approximately 70°F (21°C) (room tem- perature).
Page 438 To obtain best performance and long life for automatic transmissions, the manufacturer recommends that they be given regular maintenance service by an Authorized Dodge Dealer or Service Center. It is important that proper lubricant is used in the transmission. Refer to Fluids, Lubricants and Genuine Parts for correct fluid type.
Page 439: Front Wheel Bearings
Front Wheel Bearings Front wheel bearings for all Dodge Ram Trucks are sealed-for-life. They do not require greasing or seal replacement. In some instances, these bearings will “purge” excess grease and the bearing will look slightly wet. This is normal. Periodic inspection for excess play is recommended.
Page 440 440 MAINTAINING YOUR VEHICLE Required Maintenance for Noise Control Systems The following maintenance services must be performed every 6 months or 6,000 miles (9 600 km), whichever comes first, to assure proper operation of the noise control systems. In addition, inspection and service should be performed anytime a malfunction is observed or suspected.
Page 441 EXHAUST SYSTEM • Removal or rendering inoperative exhaust system components including the muffler or tailpipe. ENGINE COOLING SYSTEM • Removal or rendering inoperative the fan clutch. • Removal of the fan shroud. Noise Emission Warranty The manufacturer warrants that this vehicle as manufac- tured by the manufacturer, was designed, built and equipped to conform at the time it left the manufacturers control with all applicable U.S.
Page 442 442 MAINTAINING YOUR VEHICLE Noise Systems Maintenance Chart and Service Log Insert Month, Day, Year under column mileage closest to the mileage at which service was performed. MILES KILOMETERS Exhaust system-inspect Air cleaner assembly-inspect ODOMETER READING PERFORMED BY PERFORMED AT MILES KILOMETERS Exhaust system-inspect...
Page 443: Appearance Care And Protection From Corrosion
Appearance Care and Protection from Corrosion Protection of Body and Paint from Corrosion Vehicle body care requirements vary according to geo- graphic locations and usage. Chemicals that make roads passable in snow and ice, and those that are sprayed on trees and road surfaces during other seasons, are highly corrosive to the metal in your vehicle.
Page 444 444 MAINTAINING YOUR VEHICLE • Avoid using abrasive compounds and power buffing that may diminish the gloss or thin out the paint finish. CAUTION! Do not use abrasive or strong cleaning materials such as steel wool or scouring powder, which will scratch metal and painted surfaces.
Page 445 Wheel and Wheel Trim Care All wheels and wheel trim, especially aluminum and chrome plated wheels should be cleaned regularly with a mild soap and water to prevent corrosion. To remove heavy soil, use Mopar Wheel Cleaner or select a non- abrasive, non-acidic cleaner.
Page 446 446 MAINTAINING YOUR VEHICLE can act as an abrasive and damage the leather upholstery and should be removed promptly with a damp cloth. Stubborn soils can be removed easily with a soft cloth and Mopar Total Clean. Care should be taken to avoid soaking your leather upholstery with any liquid.
Page 447: Fuses (Integrated Power Module)
Seat Belt Maintenance Do not bleach, dye or clean the belts with chemical solvents or abrasive cleaners. This will weaken the fabric. Sun damage can also weaken the fabric. If the belts need cleaning, use a mild soap solution or lukewarm water.
Page 448 448 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Fuse Fuse 20 Amp Power Outlet Console Yellow 20 Amp Cabin Compartment Yellow Node (CCN) Door Locks — — 15 Amp Aisin Transmission Blue Controls (Diesel Only) 20 Amp Power Sunroof Yellow 10 Amp Vistronic Fan/ Wastegate Solenoid —...
Page 449 Cavity Cartridge Mini Description Fuse Fuse 30 Amp Electric Brake Pink 25 Amp Power-Battery Natural RWAL/ABS Module Feed 15 Amp Park Lamps Left Blue 20 Amp Trailer Park Lamps Yellow 15 Amp Park Lamps Right Blue — — 40 Amp ABS Pump Green 30 Amp...
Page 450 450 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Fuse Fuse 40 Amp Power Seats Green 10 Amp Power Run/Start- PCM/Steering Angle Sensor 10 Amp 4X4 Switch/Pass Dr Switch/EC Mirror 15 Amp Power Run/Start- Blue ABS/RWAL/Smart Bar/YAW Sensor/ Universal Exhaust Gas Oxygen (Uego) Sensor Controller 10 Amp PCM (Gas)/TCM...
Page 451 Cavity Cartridge Mini Description Fuse Fuse 10 Amp Seatbelt Tension Reducer/Power IGN Run/Acc 20 Amp Power IGN Run/Acc Yellow — Cigar Lighter/Rear Power Point — — 30 Amp Diesel PCM (Diesel Pink Only) MAINTAINING YOUR VEHICLE CAUTION! • When installing the Integrated Power Module cover, it is important to ensure the cover is prop- erly positioned and fully latched.
Page 452: Vehicle Storage
452 MAINTAINING YOUR VEHICLE VEHICLE STORAGE If you are storing your vehicle for more than 21 days, we recommend that you take the following steps to mini- mize the drain on your vehicle’s battery: • Disconnect the Ignition-Off Draw fuse (I.O.D.) fuse located in the Integrated Power Module, located in the engine compartment.
Page 453: Replacement Light Bulbs
EPLACEMENT LIGHT BULBS LIGHT BULBS — Inside Overhead Console Lights ....TS 212-2 Dome Light......7679 All of the inside bulbs are brass or glass wedge base.
Page 454 454 MAINTAINING YOUR VEHICLE 2. Remove the two (2) bolts from the front of the head- light housing. Front Headlight Housing Bolts 3. Remove the plug from the inner fender well and remove through Inner Fender Plug access hole.
Page 455 MAINTAINING YOUR VEHICLE 4. Pull the housing out from the fender to allow room to disconnect the electrical connectors. NOTE: For easier removal, pull the headlight assembly straight forward, applying the greatest amount of force to the outer edge of the headlight assembly. Rear Headlight Housing Nut Access Headlight Removal...
Page 456 456 MAINTAINING YOUR VEHICLE 5. Unlock and pull connector straight from the base of the headlight halogen bulb. 6. Twist connector on the side marker/turn signal/park light bulb ⁄ turn and remove connector and bulb from housing. 7. Remove housing from vehicle with headlight halogen bulb in housing.
Page 457: Tail, Stop, Turn And Backup Lights
Tail, Stop, Turn and Backup Lights 1. Remove the two (2) screws that pass through the bed sheetmetal. Removing the Two (2) Screws MAINTAINING YOUR VEHICLE 2. Pull the housing straight out from the body, with a quick motion, to separate the housing from the body. If not pulled straight, locators may be damaged.
Page 458 458 MAINTAINING YOUR VEHICLE 3. Rotate the bulb socket counterclockwise to remove 4. Pull bulb straight out of socket. from the housing. Pulling Bulb From Socket Rotating Bulb Socket From Housing...
Page 459: Center High-Mounted Stoplight With Cargo Light
5. Reverse Procedure to install bulb and housing. Place the two raised blocks passed the body. Sliding Raised Blocks Past Body MAINTAINING YOUR VEHICLE Center High-Mounted Stoplight With Cargo Light 1. Remove the two (2) screws holding the housing/lens to the body as shown.
Page 460 460 MAINTAINING YOUR VEHICLE 2. Separate the connector holding the housing and wir- ing harness to the body. 3. Turn desired bulb socket ⁄ turn and remove socket and bulb from housing. 4. Pull desired bulb straight from the socket.
Page 461: Cab Top Clearance Lights - If Equipped
• Outside Bulbs: Cargo Lamps • Inside Bulb: Center High Mount Stop Lamp 5. Reverse procedure for installation of bulbs and hous- ing. MAINTAINING YOUR VEHICLE Cab Top Clearance Lights — If Equipped 1. Remove the two screws from the top of the light.
Page 462 462 MAINTAINING YOUR VEHICLE 2. Rotate the socket ⁄ turn and pull it from the light 3. Pull the bulb straight from it’s socket and replace. assembly.
Page 463: Fog Lights
Fog Lights 1. Reach under the vehicle, unlock and twist connector counterclockwise ⁄ turn and remove connector and bulb from housing. MAINTAINING YOUR VEHICLE 2. Pull bulb straight from the connector. 3. Reverse procedure for installation of bulbs and hous- ing.
Page 464: Fluids And Capacities
464 MAINTAINING YOUR VEHICLE FLUIDS AND CAPACITIES Fuel 5.7L, 89 Octane 2500 Shortbed Models 2500 Longbed Models Engine Oil (with filter) 5.7L Engine V-8 (SAE 5W-20, API Certified). For trucks operating under a gross combined weight rating less than 14,000 lbs. 5.7L Engine V-8 (SAE 5W-30, API Certified).
Page 465: Fluids, Lubricants And Genuine Parts
FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Engine Coolant Engine Oil (For trucks operating under a gross combined weight rating less than 14,000 lbs.) 5.7L Engine Oil (For trucks operating under a gross combined weight rating greater than 14,000 lbs.) Engine Oil Filter Spark Plugs (5.7L Engine) Fuel Selection (5.7L)
Page 466: Chassis
466 MAINTAINING YOUR VEHICLE Chassis Component Automatic Transmission Transfer Case Manual Transmission Fluid (G-56) Front Driveshaft Grease Fitting. Clutch Linkage Front and Rear Axle Brake Master Cylinder Power Steering Reservoir Fluids, Lubricants and Genuine Parts. Mopar ATF+4, Automatic Transmission Fluid Mopar ATF+4, Automatic Transmission Fluid Mopar ATF+4, Automatic Transmission Fluid Use Mopar type MS-6560 (lithium based grease), or equivalent.
Page 467 MAINTENANCE SCHEDULES CONTENTS Emission Control System Maintenance ..468 Maintenance Schedule ....468 Required Maintenance Intervals ... 471...
Page 468 468 MAINTENANCE SCHEDULES EMISSION CONTROL SYSTEM MAINTENANCE The “Scheduled” maintenance services, listed in bold type in this section (Section 8) must be done at the times or mileages specified to assure the continued proper functioning of the emission control system. These, and all other maintenance services included in this manual, should be done to provide best vehicle performance and reliability.
Page 469 • Change your engine oil more often if you drive your vehicle off-road for an extended period of time. • Under no circumstances should oil change intervals exceed 6,000 miles (10,000 km) or 6 months, whichever comes first. Your dealer will reset the oil change indicator message after completing the scheduled oil change.
Page 470 470 MAINTENANCE SCHEDULES At Each Oil Change • Change the engine oil filter. • Inspect the brake hoses and lines. • Check the Manual Transmission fluid level. CAUTION! Failure to perform the required maintenance items may result in damage to the vehicle.
Page 471 Required Maintenance Intervals Maintenance Items Change the engine oil and engine oil filter. Rotate Tires. Lubricate outer tie rod ends. Lube Front Drive Shaft Fitting. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter, replace if necessary.
Page 472 472 MAINTENANCE SCHEDULES Maintenance Items Inspect Exhaust System. Perform the first inspection at 12,000 miles (20 000 km) or 12 months. Inspect the front suspension, tie rod ends and boot seals, replace if necessary. Replace the engine air cleaner filter. Inspect the transfer case fluid.
Page 473 Maintenance Items Change the manual transmission fluid if using your vehicle for any of the following: trailer towing, snow plowing, heavy loading, taxi, police, delivery service (commercial service), off-road, desert operation or more then 50% of your driving is at sustained high speeds during hot weather, above 90F°...
Page 474 474 MAINTENANCE SCHEDULES WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.
Page 475: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......476 Prepare For The Appointment .
Page 476: Suggestions For Obtaining Service For Your Vehicle
We want you to be happy with our products and services. Warranty service must be done by an authorized Chrysler, Dodge, or Jeep dealer. We strongly recommend that you take your vehicle to your selling dealer. They know you and your vehicle best, and are most concerned that you get prompt and high quality service.
Page 477 technicians, special tools, and the latest information to assure your vehicle is fixed correctly and in a timely manner. This is why you should always talk to your dealer’s service manager first. Most matters can be resolved with this process. •...
Page 478 478 IF YOU NEED CONSUMER ASSISTANCE Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its Customer Center. Any hearing or speech impaired customer who has access to a TDD or a conventional teletypewriter (TTY) in the United States can communicate with the manufacturer by dialing 1–800–380–CHRY.
Page 479: Warranty Information (U.s. Vehicles Only)
WARNING! Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain prod- ucts of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Page 480: In Canada
480 IF YOU NEED CONSUMER ASSISTANCE To contact NHTSA, you may either call the Auto Safety Hotline toll free at 1–888–327–4236 (TTY: 1–800–424– 9153), or go to http://www.safercar.gov; or write to: Administrator, NHTSA, 400 Seventh Street, SW., Wash- ington, DC 20590. You can also obtain other information about motor vehicle...
Page 481 • Diagnostic Procedure Manuals. Filled with diagrams, charts and detailed illustrations, these practical manuals make it easy for students and technicians to find and fix problems on computer- controlled vehicle systems and features. They show exactly how to find and correct problems the first time, using step-by-step troubleshooting and driveability procedures, proven diagnostic tests and a complete list of all tools and equipment.
Page 482: Department Of Transportation Uniform Tire Quality Grades
482 IF YOU NEED CONSUMER ASSISTANCE DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following describes the tire grading categories estab- lished by the National highway Traffic Safety Adminis- tration. The specific grade rating assigned by the tire’s manufacturer in each category is shown on the sidewall of the tires on your car.
Page 483: Temperature Grades
Temperature Grades The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature can lead to sudden tire failure.
Page 485 INDEX...
Page 486 486 INDEX Adding Fuel ......362 Air Cleaner, Engine (Engine Air Cleaner Filter) ......416,440 Air Conditioner Maintenance .
Page 487 Ball Joints ......422 Bar, Stabilizer/Sway System ....279 Battery .
Page 488 488 INDEX Center High Mounted Stop Light ... . 459 Center Lap Belts ......44 Center Seat Storage Compartment .
Page 489 Cruise Control (Speed Control) ....138 Cup Holder ......162 Customer Assistance .
Page 490 490 INDEX Emission Control System Maintenance ..468 Emission Related Components ....419 Engine ....... 408 Air Cleaner .
Page 491 Fluids, Lubricants and Genuine Parts ..465 Fog Lights ..... . . 132,184,463 Fold Flat Load Floor .
Page 492 492 INDEX Hands-Free Phone (UConnect™) ....93 Hazard Warning Flasher ....390 Head Restraints .
Page 493 Jack Location ......391 Jack Operation ......393 Jump Starting .
Page 494 494 INDEX Intensity Control ..... . . 129 Interior ......129,142 Lights On Reminder .
Page 495 Electric Powered ..... . . 91 Outside ......90 Rearview .
Page 496 496 INDEX Onboard Diagnostic System ....409,410 Opener, Garage Door (HomeLink ) ... 150 Operating Precautions ....409 Outside Rearview Mirrors .
Page 497 Radial Ply Tires ......338 Radiator Cap (Coolant Pressure Cap) ..427,429 Radio Broadcast Signals .
Page 498 498 INDEX Safety Defects, Reporting ....479 Safety Information, Tire ....326 Safety Tips .
Page 499 Transfer Case, Shifting into Transfer Case Neutral (N) ......384 Transfer Case, Shifting out of Transfer Case Neutral (N) .
Page 500 500 INDEX Supplemental Tire Pressure Information ..344 Synthetic Engine Oil ..... . 415 System, Navigation .
Page 501 Snow Tires ......345 Spare Tire ......392 Spinning .
Page 502 502 INDEX Trip Odometer ..... . . 182,189 Turn Signals ....133,179,453,457 UConnect™...
Page 503 Rear Sliding ......166 Windshield Defroster ....240,243 Windshield Washers .
