- Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL XV19CSA(C) XV19CA(C) LIT-11626-24-09 29S-28199-13...
- Page 2 EAU10042 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
- Page 3 Yamaha has met these standards without reducing the performance or economy of operation of the motorcycle. To maintain these high standards, it is important that you and your Yamaha dealer pay close attention to the recommended maintenance schedules and operating instructions contained within this manual.
-
Page 4: Important Manual Information
IMPORTANT MANUAL INFORMATION EAU10132 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. - Page 5 IMPORTANT MANUAL INFORMATION EAU10193 XV19CSA(C)/XV19CA(C) OWNER’S MANUAL ©2010 by Yamaha Motor Corporation, U.S.A. 1st edition, April 2010 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A. is expressly prohibited. Printed in Japan.
-
Page 6: Table Of Contents
TABLE OF CONTENTS LOCATION OF IMPORTANT EXUP system ....... 4-15 Cast wheels ......... 7-16 LABELS ..........1-1 Sidestand ........4-16 Clutch lever ........7-17 Ignition circuit cut-off system ..4-16 Checking the brake lever free SAFETY INFORMATION ....2-1 Auxiliary DC connector ....4-18 play ........... - Page 7 Matte color caution ......8-1 Care ..........8-1 Storage ...........8-3 SPECIFICATIONS ......9-1 CONSUMER INFORMATION...10-1 Identification numbers ....10-1 Reporting safety defects ....10-3 Motorcycle noise regulation ..10-4 Maintenance record ......10-5 YAMAHA MOTOR CORPORATION, U.S.A. STREET AND ENDURO MOTORCYCLE LIMITED WARRANTY ....10-7 YAMAHA EXTENDED SERVICE (Y.E.S.) ........10-9...
-
Page 8: Location Of Important Labels
Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer. - Page 9 LOCATION OF IMPORTANT LABELS California only WARNING BEFORE YOU OPERATE THIS VEHICLE, READ THE OWNER’S MANUAL AND ALL LABELS. ALWAYS WEAR AN APPROVED MOTORCYCLE HELMET, eye protection, and protective clothing. PREMIUM UNLEADED GASOLINE ONLY 91 Min. Pump Octane (R+M)/2 4C8-2118K-00...
-
Page 10: Safety Information
SAFETY INFORMATION EAU10287 Safe Riding • Ride where other motorists can Perform the pre-operation checks each see you. Avoid riding in another time you use the vehicle to make sure it motorist’s blind spot. Be a Responsible Owner is in safe operating condition. Failure to Many accidents involve inexperi- As the vehicle’s owner, you are respon- inspect or maintain the vehicle properly... - Page 11 SAFETY INFORMATION due to excessive speed or under- This motorcycle is designed for on- A passenger should also observe cornering (insufficient lean angle road use only. It is not suitable for the above precautions. for the speed). off-road use. • Always obey the speed limit and Avoid Carbon Monoxide Poisoning never travel faster than warrant- Protective Apparel...
- Page 12 Yamaha accessories, which are avail- of the motorcycle is changed. To avoid to minimize imbalance or instabili- able only from a Yamaha dealer, have the possibility of an accident, use ex- been designed, tested, and approved treme caution when adding cargo or Shifting weights can create a sud- by Yamaha for use on your vehicle.
-
Page 13: Specifications
• Accessories fitted to the handle- Use caution when adding electri- genuine Yamaha accessories, recog- bar or the front fork area can cal accessories. If electrical acces- nize that some aftermarket accessories... - Page 14 SAFETY INFORMATION Check that the fuel cock (if equipped) is in the “OFF” position and that there are no fuel leaks. Point the front wheel straight ahead on the trailer or in the truck bed, and choke it in a rail to pre- vent movement.
-
Page 15: Description
DESCRIPTION EAU10410 Left view 1. Headlight (page 7-28) 9. Engine oil drain bolt A (crankcase) (page 7-10) 2. Seat lock (page 4-12) 10.Engine oil filter cartridge (page 7-10) 3. Main fuse (page 7-26) 11.Shift pedal (page 4-7) 4. Battery (page 7-25) 5. -
Page 16: Right View
DESCRIPTION EAU10420 Right view 2,3,4 10,11 1. Helmet holder (page 4-13) 9. Rear brake light switch (page 7-18) 2. Rear brake fluid reservoir (page 7-19) 10.Engine oil drain bolt (oil tank) (page 7-10) 3. Fuel injection system fuse (page 7-26) 11.Shock absorber assembly spring preload adjusting nut (page 4-14) 4. -
Page 17: Controls And Instruments
DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 4-7) 9. Brake lever (page 4-8) 2. Left handlebar switches (page 4-5) 3. Clutch fluid reservoir (page 7-19) 4. Multi-function meter unit (page 4-2) 5. Main switch (page 4-1) 6. Front brake fluid reservoir (page 7-19) 7. -
Page 18: Instrument And Control Functions
INSTRUMENT AND CONTROL FUNCTIONS EAU10450 EAU45751 EAU49391 Main switch Indicator lights and warning All electrical systems are off. The key lights can be removed. EWA10072 WARNING Never turn the key to “OFF” while the vehicle is moving, otherwise the electrical systems will be switched off, which may result in loss of con- trol or an accident. -
Page 19: Multi-Function Meter Unit
3.0 seconds. If this oc- EAU44598 High beam indicator light “ ” Multi-function meter unit curs, have a Yamaha dealer check the This indicator light comes on when the vehicle. high beam of the headlight is switched EAU11534 Engine trouble warning light “... - Page 20 INSTRUMENT AND CONTROL FUNCTIONS two tripmeters (which show the Fuel gauge distance traveled since they were 120 20 100 00 140 40 80 80 last set to zero) 160 60 60 60 180 80 a fuel reserve tripmeter (which 40 40 shows the distance traveled on the 20 20 fuel reserve)
- Page 21 INSTRUMENT AND CONTROL FUNCTIONS F-TRIP → TRIP A → TRIP B → ODO Odometer, tripmeters, fuel reserve 3. Push the “SELECT” switch, and → F-TRIP tripmeter and clock the minute digits will start flashing. To reset a tripmeter, select it by push- 4.
-
Page 22: Handlebar Switches
If the odometer/tripmeter/clock display To set the brightness EAU12348 Handlebar switches indicates any error codes, note the 1. Turn the key to “OFF”. code number, and then have a Yamaha 2. Push and hold the “SELECT” Left dealer check the vehicle. switch. ECA11590 3. - Page 23 This model can be equipped with op- control mode of the multi-function lights will self-cancel after the vehicle tional lights available at a Yamaha meter unit. has traveled both about 150 m (490 ft) dealer.
-
Page 24: Clutch Lever
INSTRUMENT AND CONTROL FUNCTIONS See “Multi-function meter unit” on page EAU12820 EAU12871 Clutch lever Shift pedal 4-2 for detailed information. 1. Clutch lever 1. Shift pedal The clutch lever is located at the left The shift pedal is located on the left handlebar grip. -
Page 25: Brake Lever
INSTRUMENT AND CONTROL FUNCTIONS EAU12890 EAU12941 EAU13121 Brake lever Brake pedal Fuel tank cap 1. Brake lever 1. Brake pedal 1. Fuel tank cap lock cover 2. “ ” mark The brake lever is located at the right The brake pedal is on the right side of 3. -
Page 26: Fuel
INSTRUMENT AND CONTROL FUNCTIONS 2. Turn the key counterclockwise to EAU13212 Fuel the original position, remove it, and Make sure there is sufficient gasoline in then close the lock cover. the tank. EWA10881 WARNING The fuel tank cap cannot be installed unless the key is in the lock. -
Page 27: Fuel Tank Breather/Overflow Hose
Check the fuel tank breather/over- as well as to the exhaust system. flow hose for cracks or damage, Your Yamaha engine has been de- and replace it if damaged. Make sure that the end of the fuel signed to use premium unleaded gaso-... -
Page 28: Catalytic Converters
INSTRUMENT AND CONTROL FUNCTIONS EAU13445 ECA10701 EAU44460 Catalytic converters Steering lock NOTICE This vehicle is equipped with catalytic Use only unleaded gasoline. The use converters in the exhaust system. of leaded gasoline will cause unre- EWA10862 pairable damage to the catalytic WARNING converter. -
Page 29: Rider Seat
INSTRUMENT AND CONTROL FUNCTIONS To unlock the steering EAU34042 Rider seat To remove the rider seat 1. Insert the key into the seat lock, and then turn it counterclockwise. 1. Projection 2. Seat holder 1. Unlock. 2. Push the front of the seat down to 1. -
Page 30: Helmet Holder
INSTRUMENT AND CONTROL FUNCTIONS EAU44441 To release the helmet from the hel- Helmet holder met holder Remove the rider seat, remove the hel- met holding cable from the helmet hold- er and the helmet, and then install the seat. 1. Helmet holding cable 2. -
Page 31: Adjusting The Shock Absorber Assembly
INSTRUMENT AND CONTROL FUNCTIONS EAU38405 load and thereby soften the sus- Adjusting the shock absorber pension, turn the adjusting nut in assembly direction (b). This shock absorber assembly is To make the adjustment, use equipped with a spring preload adjust- the special wrench and exten- ing nut. -
Page 32: Exup System
EAU15282 Spring preload: EXUP system sorber assembly to an open Minimum (soft): This model is equipped with Yamaha’s flame or other high heat source. Distance A = 172 mm (6.77 in) EXUP (EXhaust Ultimate Power valve) Standard: This may cause the unit to ex- system. -
Page 33: Sidestand
EAU44892 Sidestand Ignition circuit cut-off system Yamaha dealer repair it if it does not The sidestand is located on the left side The ignition circuit cut-off system (com- function properly. of the frame. Raise the sidestand or... - Page 34 INSTRUMENT AND CONTROL FUNCTIONS WARNING With the engine turned off: 1. Move the sidestand down. If a malfunction is noted, have a Yamaha 2. Make sure that the engine stop switch is set to “ ”. dealer check the system before riding.
-
Page 35: Auxiliary Dc Connector
INSTRUMENT AND CONTROL FUNCTIONS EAU44585 Auxiliary DC connector ECA15311 NOTICE The accessory connected to the auxiliary DC connector should not be used with the engine turned off, and the load must never exceed 36 W (3 A), otherwise the fuse may blow or the battery may discharge. -
Page 36: For Your Safety - Pre-Operation Checks
• Check vehicle for oil leakage. Transfer case oil • Check vehicle for oil leakage. 7-13 • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary. 7-18, 7-19 •... - Page 37 • Make sure that operation is smooth. • Check cable free play. Throttle grip 7-14, 7-21 • If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 7-21 •...
- Page 38 FOR YOUR SAFETY – PRE-OPERATION CHECKS ITEM CHECKS PAGE Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 4-16 • If system is not working correctly, have Yamaha dealer check vehicle.
-
Page 39: Operation And Important Riding Points
Yamaha dealer. The transmission is in the neutral gine in case of a turnover. In this position. -
Page 40: Shifting
NOTICE tral position. The neutral indicator light should come on. If not, ask a Even with the transmission in Yamaha dealer to check the elec- the neutral position, do not trical circuit. coast for long periods of time 3. Start the engine by pushing the with the engine off, and do not start switch. -
Page 41: Engine Break-In
OPERATION AND IMPORTANT RIDING POINTS 4. At the recommended shift points 3. Shift the transmission into the neu- EAU16841 Engine break-in shown in the following table, close tral position when the motorcycle There is never a more important period the throttle, and at the same time, is almost completely stopped. -
Page 42: Parking
If any engine trouble should occur ans or children are not likely to during the engine break-in period, touch them and be burned. immediately have a Yamaha dealer Do not park on a slope or on soft check the vehicle. ground, otherwise the vehicle may overturn, increasing the risk of a fuel leak and fire. -
Page 43: Periodic Maintenance And Adjustment
– possibly leading to pending on the weather, terrain, geo- that is certified (if applicable). Yamaha death. See page 2-1 for more in- graphical location, and individual use, dealers are trained and equipped to... -
Page 44: Owner's Tool Kit
If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you. -
Page 45: Periodic Maintenance Chart For The Emission Control System
From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi (13000 km) or 12 months. Items marked with an asterisk require special tools, data and technical skills, have a Yamaha dealer perform the service. EAU17601... - Page 46 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months Evaporative emis-...
-
Page 47: General Maintenance And Lubrication Chart
PERIODIC MAINTENANCE AND ADJUSTMENT EAU32186 General maintenance and lubrication chart INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months... - Page 48 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...
- Page 49 Front and rear brake √ √ √ √ √ √ 25 * • Check operation. switches • Apply Yamaha chain and cable √ √ √ √ √ √ 26 * Control cables lube or engine oil thoroughly. • Check operation and free play.
- Page 50 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months Lights, signals and...
-
Page 51: Checking The Spark Plugs
Do not attempt to diagnose 0.8–0.9 mm (0.031–0.035 in) such problems yourself. Instead, have a Yamaha dealer check the vehicle. Clean the surface of the spark plug If a spark plug shows signs of electrode gasket and its mating surface, and then... -
Page 52: Canister (For California Only)
PERIODIC MAINTENANCE AND ADJUSTMENT EAU19681 EAU3836A completely cooled down, and then Canister (for California only) Engine oil and oil filter car- warmed up again for several minutes to tridge normal operating temperature. The engine oil level should be checked 4. Wait a few minutes until the oil set- before each ride. - Page 53 PERIODIC MAINTENANCE AND ADJUSTMENT ECA10900 NOTICE Make sure that the oil filler cap is se- curely tightened, otherwise oil may seep out when the engine is run- ning. To change the engine oil (with or without oil filter cartridge replace- ment) 1.
- Page 54 An oil filter wrench is available at a Yamaha dealer. Tightening torques: Engine oil drain bolt A (crankcase): 9. Apply a thin coat of clean engine 32 Nm (3.2 m·kgf, 23 ft·lbf)
-
Page 55: Transfer Case Oil
“CD” or oils of a high- changed by a Yamaha dealer at the in- 14. Remove the engine oil filler cap, er quality than specified. In... -
Page 56: Air Filter Element
To prevent this Have a Yamaha dealer replace the air from occurring, the valve clearance filter element. must be adjusted by a Yamaha dealer at the intervals specified in the periodic maintenance and lubrication chart. -
Page 57: Tires
Yamaha dealer immediately and tires (i.e., when the temperature cause an accident. of the tires equals the ambient have the tire replaced. -
Page 58: Cast Wheels
Manufacturer/model: for cracks, bends or warpage be- related wheel parts replacement METZELER/880 MARATHON fore each ride. If any damage is should also be left to a Yamaha Rear tire: found, have a Yamaha dealer re- Size: dealer. place the wheel. Do not attempt... -
Page 59: Clutch Lever
If there is air 1. No brake lever free play in the hydraulic system, have a Yamaha dealer bleed the system be- There should be no free play at the fore operating the motorcycle. -
Page 60: Brake Light Switches
EAU22392 indicator grooves have almost disap- Brake light switches Checking the front and rear peared, have a Yamaha dealer replace brake pads the brake pads as a set. The front and rear brake pads must be checked for wear at the intervals spec-... -
Page 61: Checking The Brake And Clutch Fluid Levels
PERIODIC MAINTENANCE AND ADJUSTMENT EAU38630 Clutch Observe these precautions: Checking the brake and clutch When checking the brake and fluid levels clutch fluid levels, make sure that the top of each reservoir is level. Front brake Use only the recommended quality brake fluid, otherwise the rubber seals may deteriorate, causing leakage and poor braking or clutch... -
Page 62: Changing The Brake And Clutch Fluids
The drive belt slack should be checked ually go down. However, if the and adjusted at the intervals specified Have a Yamaha dealer change the brake fluid level goes down sud- in the periodic maintenance and lubri- brake and clutch fluids at the intervals denly, have a Yamaha dealer cation chart. -
Page 63: Checking And Lubricating The Cables
A belt tension gauge is available at a bles and cable ends should be lubricat- Yamaha dealer at the intervals speci- Yamaha dealer. ed if necessary. If a cable is damaged fied in the periodic maintenance chart. -
Page 64: Checking And Lubricating The Brake And Shift Pedals
PERIODIC MAINTENANCE AND ADJUSTMENT EAU44272 EAU43600 Recommended lubricant: Checking and lubricating the Checking and lubricating the Lithium-soap-based grease brake and shift pedals brake and clutch levers Brake pedal Brake lever Shift pedal Clutch lever The operation of the brake and shift The operation of the brake and clutch pedals should be checked before each levers should be checked before each... -
Page 65: Checking And Lubricating The Sidestand
The operation of the sidestand should The pivoting points of the rear suspen- be checked before each ride, and the sion must be lubricated by a Yamaha sidestand pivot and metal-to-metal dealer at the intervals specified in the contact surfaces should be lubricated if periodic maintenance and lubrication necessary. -
Page 66: Checking The Front Fork
WARNING! To avoid injury, of it falling over. have a Yamaha dealer check or re- [EWA10751] securely support the vehicle so 2. Hold the lower ends of the front pair it. -
Page 67: Checking The Wheel Bearings
EWA10760 WARNING To charge the battery Electrolyte is poisonous and Have a Yamaha dealer charge the bat- dangerous since it contains sul- tery as soon as possible if it seems to furic acid, which causes severe have discharged. Keep in mind that the burns. -
Page 68: Replacing The Fuses
PERIODIC MAINTENANCE AND ADJUSTMENT battery tends to discharge more quickly is turned to “OFF”, then con- EAU42584 Replacing the fuses if the vehicle is equipped with optional nect the positive lead before The main fuse, the fuel injection system electrical accessories. connecting the negative lead. - Page 69 8. Spare fuse the electrical circuit in question to check if the device operates. 5. If the fuse immediately blows again, have a Yamaha dealer check the electrical system. 6. Install the battery cover, and then hook the battery band onto the holder.
-
Page 70: Replacing The Headlight Bulb
PERIODIC MAINTENANCE AND ADJUSTMENT EAU23795 Replacing the headlight bulb This model is equipped with a quartz bulb headlight. If the headlight bulb burns out, replace it as follows. ECA10650 NOTICE Take care not to damage the follow- ing parts: Headlight bulb 1. -
Page 71: Tail/Brake Light
1. Remove the turn signal lens by re- ing the screws. If the tail/brake light does not come on, moving the screws. 7. Have a Yamaha dealer adjust the have a Yamaha dealer check it. headlight beam if necessary. 1. Screw 2. -
Page 72: Replacing A License Plate Light Bulb
PERIODIC MAINTENANCE AND ADJUSTMENT EAU24324 EAU24350 Replacing a license plate light Supporting the motorcycle bulb Since this model is not equipped with a centerstand, follow these precautions 1. Remove the license plate light unit when removing the front and rear by removing the nuts, washers and wheel or performing other maintenance rubber dampers. -
Page 73: Troubleshooting
However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly. -
Page 74: Troubleshooting Chart
Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good. -
Page 75: Motorcycle Care And Storage
Be ble. Rust and corrosion can develop Cleaning even if high-quality components are sure to consult a Yamaha dealer for ECA10772 used. A rusty exhaust pipe may go un- advice on what products to use be- NOTICE fore cleaning the vehicle. - Page 76 MOTORCYCLE CARE AND STORAGE off any detergent residue using Test the product on a small hid- plenty of water, as it is harmful den part of the windshield to Salt sprayed on roads in the winter may to plastic parts. make sure that it does not leave remain well into spring.
-
Page 77: Storage
Contaminants on the brakes or tires of the presence of ammonia) can cause loss of control. Consult a Yamaha dealer for ad- and areas where strong chemi- Make sure that there is no oil or vice on what products to use. - Page 78 MOTORCYCLE CARE AND STORAGE 2. Fill up the fuel tank and add fuel 4. Lubricate all control cables and the stabilizer (if available) to prevent pivoting points of all levers and the fuel tank from rusting and the pedals as well as of the side- fuel from deteriorating.
-
Page 79: Specifications
SAE 10W-40 1799 mm (70.8 in) XV19CA 5C71 00 Ground clearance: SAE 10W-50 XV19CAC 5C72 10 146 mm (5.75 in) XV19CSA 5C71 00 SAE 15W-40 Minimum turning radius: XV19CSAC 5C72 10 SAE 20W-40 3500 mm (137.8 in) Spark plug(s): SAE 20W-50... - Page 80 SPECIFICATIONS Transmission type: Manufacturer/model: Operation: Constant mesh 5-speed METZELER/880 MARATHON Right hand operation Operation: Loading: Recommended fluid: Left foot operation DOT 4 Maximum load: Gear ratio: Rear brake: 204 kg (450 lb) 1st: (Total weight of rider, passenger, cargo and Type: 38/16 (2.375) accessories)
- Page 81 SPECIFICATIONS Voltage, capacity: Taillight fuse: 12 V, 12.0 Ah 7.5 A Headlight: Signaling system fuse: 10.0 A Bulb type: Ignition fuse: Halogen bulb Bulb voltage, wattage × quantity: 25.0 A Fuel injection system fuse: Headlight: 15.0 A 12 V, 60 W/55 W × 1 Auxiliary DC connector fuse: Tail/brake light: 3.0 A...
-
Page 82: Consumer Information
Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: 1. - Page 83 This information illustration. This label shows specifica- will be needed when ordering spare tions related to exhaust emissions as parts from a Yamaha dealer. required by federal law, state law and Environment Canada. 10-2...
-
Page 84: Reporting Safety Defects
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Yamaha Motor Corporation, U.S.A. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. -
Page 85: Motorcycle Noise Regulation
CONSUMER INFORMATION EAU26560 Motorcycle noise regulation TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new ve- hicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person. -
Page 86: Maintenance Record
CONSUMER INFORMATION EAU26632 Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your vehicle will be required to document that maintenance has been completed in accordance with the emissions warranty. The chart below is printed only as a reminder that maintenance work is required. - Page 87 CONSUMER INFORMATION Maintenance Date of Servicing dealer Mileage Remarks interval service name and address 36000 mi (55000 km) or 54 months 40000 mi (61000 km) or 60 months 10-6...
-
Page 88: Yamaha Motor
CONSUMER INFORMATION EAU26663 YAMAHA MOTOR CORPORATION, U.S.A. STREET AND ENDURO MOTORCYCLE LIMITED WARRANTY Yamaha Motor Corporation, U.S.A. hereby warrants that CUSTOMER’S RESPONSIBILITY under this Engine new Yamaha motorcycles will be free from defects in warranty shall be to: Displacement Period... - Page 89 CUSTOMER SERVICE What costs are my responsibility during the warranty period? If your machine requires warranty service, you must take it to any authorized Yamaha The customer’s responsibility includes all costs of normal maintenance services, motorcycle dealer within the continental United States. Be sure to bring your warranty non-warranty repairs, accident and collision damages, and oil, oil filters, air filters, registration card or other valid proof of the original date of purchase.
-
Page 90: Yamaha Extended Service (Y.e.s.)
This excellent Y.E.S. plan coverage is only available to dealer to see how comforting uninterrupted factory- Yamaha owners like you, and only while your Yamaha is still backed protection can be. within the Yamaha Limited Warranty period. So visit your authorized Yamaha dealer to get all the facts. - Page 91 Yamaha Limited Warranty expires. A special note: If visiting your dealer isn’t convenient, contact Yamaha with your Primary ID number (your frame number). We’ll be happy to help you get the Y.E.S. coverage you need.
- Page 92 INDEX Fuel............4-9 Part locations .......... 3-1 Fuel level warning light ......4-2 Air filter element ........7-14 Fuel tank breather/overflow hose ..4-10 Auxiliary DC connector ......4-18 Rear suspension, lubricating....7-23 Fuel tank cap .......... 4-8 Rider seat..........4-12 Fuses, replacing ........
- Page 93 INDEX Valve clearance ........7-14 Vehicle Emission Control Information label............ 10-2 Vehicle identification number....10-1 Warranty, extended ......10-9 Warranty, limited........10-7 Wheel bearings, checking ....7-25 Wheels..........7-16...
- Page 96 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2010.05-0.5×1 CR...
