Yamaha Star XVS13CAC Owner's Manual

Motorcycle
Table of Contents

Advertisement

Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
XVS13CA(C)
LIT-11626-24-50
27D-28199-10

Advertisement

Table of Contents
loading

Summary of Contents for Yamaha Star XVS13CAC

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL XVS13CA(C) LIT-11626-24-50 27D-28199-10...
  • Page 2 EAU10042 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 Yamaha has met these standards without reducing the performance or economy of operation of the motorcycle. To maintain these high standards, it is important that you and your Yamaha dealer pay close attention to the recommended maintenance schedules and operating instructions contained within this manual.
  • Page 4: Important Manual Information

    IMPORTANT MANUAL INFORMATION EAU10132 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 IMPORTANT MANUAL INFORMATION EAU10193 XVS13CA(C) OWNER’S MANUAL ©2010 by Yamaha Motor Corporation, U.S.A. 1st edition, July 2010 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A. is expressly prohibited. Printed in Japan.
  • Page 6: Table Of Contents

    TABLE OF CONTENTS LOCATION OF IMPORTANT Ignition circuit cut-off system ..4-16 Adjusting the clutch lever free LABELS ..........1-1 play ........... 7-19 FOR YOUR SAFETY – Checking the brake lever free SAFETY INFORMATION ....2-1 PRE-OPERATION CHECKS ..... 5-1 play ........... 7-20 Brake light switches .....
  • Page 7 Matte color caution ......8-1 Care ..........8-1 Storage ...........8-3 SPECIFICATIONS ......9-1 CONSUMER INFORMATION...10-1 Identification numbers ....10-1 Reporting safety defects ....10-3 Motorcycle noise regulation ..10-4 Maintenance record ......10-5 YAMAHA MOTOR CORPORATION, U.S.A. STREET AND ENDURO MOTORCYCLE LIMITED WARRANTY ....10-7 YAMAHA EXTENDED SERVICE (Y.E.S.) ........10-9...
  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 9 LOCATION OF IMPORTANT LABELS 2 California only TIRE INFORMATION Cold tire normal pressure should be set as follows. • Up to 90 kg (198 lbs) load FRONT : 250 kPa, (2.50 kgf/cm²), 36 psi REAR : 280 kPa, (2.80 kgf/cm²), 41 psi •...
  • Page 10: Safety Information

    SAFETY INFORMATION EAU10287 Safe Riding • Ride where other motorists can Perform the pre-operation checks each see you. Avoid riding in another time you use the vehicle to make sure it motorist’s blind spot. Be a Responsible Owner is in safe operating condition. Failure to Many accidents involve inexperi- As the vehicle’s owner, you are respon- inspect or maintain the vehicle properly...
  • Page 11 SAFETY INFORMATION due to excessive speed or under- This motorcycle is designed for on- A passenger should also observe cornering (insufficient lean angle road use only. It is not suitable for the above precautions. for the speed). off-road use. • Always obey the speed limit and Avoid Carbon Monoxide Poisoning never travel faster than warrant- Protective Apparel...
  • Page 12 Yamaha accessories, which are avail- of the motorcycle is changed. To avoid to minimize imbalance or instabili- able only from a Yamaha dealer, have the possibility of an accident, use ex- been designed, tested, and approved treme caution when adding cargo or Shifting weights can create a sud- by Yamaha for use on your vehicle.
  • Page 13 • Accessories fitted to the handle- Use caution when adding electri- genuine Yamaha accessories, recog- bar or the front fork area can cal accessories. If electrical acces- nize that some aftermarket accessories...
  • Page 14 SAFETY INFORMATION Check that the fuel cock (if equipped) is in the “OFF” position and that there are no fuel leaks. Point the front wheel straight ahead on the trailer or in the truck bed, and choke it in a rail to pre- vent movement.
  • Page 15: Description

    DESCRIPTION EAU10410 Left view 3,4,5 1. Spark plug (page 7-9) 9. Shift pedal (page 4-9) 2. Seat lock (page 4-13) 10.Engine oil filler cap (page 7-11) 3. Fuel injection system fuse (page 7-29) 4. Fuse box (page 7-29) 5. Main fuse (page 7-29) 6.
  • Page 16: Right View

    DESCRIPTION EAU10420 Right view 1. Rear brake fluid reservoir (page 7-21) 9. Engine oil filter cartridge (page 7-11) 2. Owner’s tool kit (page 7-2) 10.Brake pedal (page 4-9) 3. Battery (page 7-28) 11.Coolant reservoir (page 7-14) 4. Shock absorber assembly spring preload adjusting ring (page 4-14) 5.
  • Page 17: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 4-8) 2. Left handlebar switches (page 4-7) 3. Multi-function meter unit (page 4-4) 4. Main switch/steering lock (page 4-1) 5. Front brake fluid reservoir (page 7-21) 6. Right handlebar switches (page 4-7) 7.
  • Page 18: Instrument And Control Functions

    INSTRUMENT AND CONTROL FUNCTIONS EAU10460 EAU10661 To lock the steering Main switch/steering lock All electrical systems are off. The key can be removed. EWA10061 WARNING Never turn the key to “OFF” or “LOCK” while the vehicle is moving. Otherwise the electrical systems will be switched off, which may result in loss of control or an accident.
  • Page 19: Indicator Lights And Warning Lights

    4. High beam indicator light “ ” 5. Turn signal indicator light “ ” a Yamaha dealer check the electrical 6. Oil level warning light “ ” circuit. 7. Fuel level warning light “...
  • Page 20 3.0 seconds. If this oc- cles, the radiator fan(s) automati- light will flash ten times, then go off curs, have a Yamaha dealer check the cally switch on or off according to for 2.5 seconds. If this occurs, vehicle.
  • Page 21: Multi-Function Meter Unit

    INSTRUMENT AND CONTROL FUNCTIONS EAU50692 two tripmeters (which show the Speedometer Multi-function meter unit distance traveled since they were last set to zero) a fuel reserve tripmeter (which shows the distance traveled on the fuel reserve) a fuel meter a clock a self-diagnosis device a brightness control mode 1.
  • Page 22 INSTRUMENT AND CONTROL FUNCTIONS Odometer, tripmeters, fuel reserve If the fuel level warning light comes on Fuel meter tripmeter, fuel meter and clock (see page 4-2), the display will auto- matically change to the fuel reserve tripmeter mode “Trip F” and start count- ing the distance traveled from that point.
  • Page 23 “SELECT” switch to set note the code number, and then have a 1. Turn the key to “OFF”. the hours. Yamaha dealer check the vehicle. 2. Push and hold the “SELECT” 4. Push the “RESET” switch, and the switch.
  • Page 24: Handlebar Switches

    INSTRUMENT AND CONTROL FUNCTIONS 3. Turn the key to “ON”, and then re- EAU12348 Right Handlebar switches lease the “SELECT” switch after five seconds. Left 4. Adjust the multi-function meter unit panel brightness level by pushing the “SELECT” switch. 5. Push the “RESET” switch. The display will change to the prior mode.
  • Page 25: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS has traveled both about 150 m (490 ft) EAU12711 EAU12820 Start switch “ ” Clutch lever and for approximately 15 seconds. Push this switch to crank the engine However, the turn signal lights can also with the starter. See page 6-1 for start- be canceled manually by pushing the ing instructions prior to starting the en- switch in after it has returned to the cen-...
  • Page 26: Shift Pedal

    INSTRUMENT AND CONTROL FUNCTIONS EAU12871 EAU12890 EAU12941 Shift pedal Brake lever Brake pedal 1. Shift pedal 1. Brake lever 1. Brake pedal The shift pedal is located on the left The brake lever is located at the right The brake pedal is on the right side of side of the motorcycle and is used in handlebar grip.
  • Page 27: Fuel Tank Cap

    INSTRUMENT AND CONTROL FUNCTIONS EAU13121 2. Turn the key counterclockwise to EAU13221 Fuel tank cap Fuel the original position, remove it, and Make sure there is sufficient gasoline in then close the lock cover. the tank. EWA10881 WARNING The fuel tank cap cannot be installed unless the key is in the lock.
  • Page 28 WARNING as well as to the exhaust system. Gasoline is poisonous and can Your Yamaha engine has been de- cause injury or death. Handle gaso- signed to use regular unleaded gaso- line with care. Never siphon gaso- line with a pump octane number line by mouth.
  • Page 29: Fuel Tank Breather/Overflow Hose

    INSTRUMENT AND CONTROL FUNCTIONS EAU48760 EAU13433 ECA10701 Fuel tank breather/overflow Catalytic converter NOTICE hose This model is equipped with a catalytic Use only unleaded gasoline. The use converter in the exhaust system. of leaded gasoline will cause unre- EWA10862 pairable damage to the catalytic WARNING converter.
  • Page 30: Seat

    INSTRUMENT AND CONTROL FUNCTIONS EAU50680 2. Slide the seat rearward to fit the Seat slot in its bottom over the center seat holder. To remove the seat 3. Push the front of the seat down to 1. Insert the key into the seat lock, lock it in place.
  • Page 31: Helmet Holder

    It is recommended to have a Yamaha dealer adjust the spring preload. Should you choose to make the adjustment, special 1.
  • Page 32: Sidestand

    Take the shock Maximum (hard): Yamaha’s ignition circuit cut-off absorber assembly to a Yamaha system has been designed to assist dealer for any service. the operator in fulfilling the respon- sibility of raising the sidestand be- fore starting off.
  • Page 33: Ignition Circuit Cut-Off System

    INSTRUMENT AND CONTROL FUNCTIONS this system regularly and have a EAU44892 Ignition circuit cut-off system Yamaha dealer repair it if it does not The ignition circuit cut-off system (com- function properly. prising the sidestand switch, clutch switch and neutral switch) has the fol- lowing functions.
  • Page 34 INSTRUMENT AND CONTROL FUNCTIONS WARNING With the engine turned off: 1. Move the sidestand down. If a malfunction is noted, have a Yamaha 2. Make sure that the engine stop switch is set to “ ”. dealer check the system before riding.
  • Page 35: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 7-14 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 36 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 7-16, 7-24 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 7-24 •...
  • Page 37 FOR YOUR SAFETY – PRE-OPERATION CHECKS ITEM CHECKS PAGE • Check operation of ignition circuit cut-off system. Sidestand switch 4-15 • If system is not working correctly, have Yamaha dealer check vehicle.
  • Page 38: Operation And Important Riding Points

    Yamaha dealer. The transmission is in the neutral gine in case of a turnover. In this position.
  • Page 39: Shifting

    The neutral indicator the engine is running. Inade- light should come on. If not, ask a quate lubrication may damage Yamaha dealer to check the elec- the transmission. 1. Shift pedal trical circuit. 2. Neutral position Always use the clutch while 3.
  • Page 40: Engine Break-In

    OPERATION AND IMPORTANT RIDING POINTS 4. At the recommended shift points 3. Shift the transmission into the neu- EAU16841 Engine break-in shown in the following table, close tral position when the motorcycle There is never a more important period the throttle, and at the same time, is almost completely stopped.
  • Page 41: Parking

    If any engine trouble should occur WARNING during the engine break-in period, Since the engine and exhaust immediately have a Yamaha dealer system can become very hot, check the vehicle. park in a place where pedestri- ans or children are not likely to touch them and be burned.
  • Page 42: Periodic Maintenance And Adjustment

    – possibly leading to pending on the weather, terrain, geo- that is certified (if applicable). Yamaha death. See page 2-1 for more in- graphical location, and individual use, dealers are trained and equipped to...
  • Page 43: Owner's Tool Kit

    If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.
  • Page 44: Periodic Maintenance Chart For The Emission Control System

    From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi (13000 km) or 12 months. Items marked with an asterisk require special tools, data and technical skills, have a Yamaha dealer perform the service. EAU17601...
  • Page 45 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months Evaporative emis-...
  • Page 46: General Maintenance And Lubrication Chart

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU32186 General maintenance and lubrication chart INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months...
  • Page 47 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...
  • Page 48 24 months. Front and rear brake √ √ √ √ √ √ 25 * • Check operation. switches • Apply Yamaha chain and cable √ √ √ √ √ √ 26 * Control cables lube or engine oil thoroughly.
  • Page 49 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...
  • Page 50: Removing And Installing The Panel

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU18751 EAU42431 Removing and installing the Checking the spark plugs panel The spark plugs are important engine components, which are easy to check. The panel shown needs to be removed Since heat and deposits will cause any to perform some of the maintenance spark plug to slowly erode, the spark jobs described in this chapter.
  • Page 51 0.8–0.9 mm (0.031–0.035 in) diagnose such problems yourself. In- ed in the additional tool kit, which stead, have a Yamaha dealer check was handed out separately at the To install a spark plug the vehicle.
  • Page 52: Canister (For California Only)

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU19681 EAU42599 Canister (for California only) Engine oil and oil filter car- If a torque wrench is not available when tridge installing a spark plug, a good estimate The engine oil level should be checked of the correct torque is 1/4–1/2 turn before each ride.
  • Page 53 4. Minimum level mark An oil filter wrench is available at a 1. Engine oil drain bolt 4. If the engine oil is below the mini- Yamaha dealer. 2. Gasket mum level mark, add sufficient oil of the recommended type to raise 6.
  • Page 54 PERIODIC MAINTENANCE AND ADJUSTMENT Recommended engine oil: See page 9-1. Oil quantity: Without oil filter cartridge replace- ment: 3.20 L (3.38 US qt, 2.82 Imp.qt) With oil filter cartridge replacement: 3.40 L (3.59 US qt, 2.99 Imp.qt) 1. O-ring 1. Torque wrench Be sure to wipe off spilled oil on any parts after the engine and exhaust sys- Tightening torque:...
  • Page 55: Coolant

    A. (See page 7-9.) off and have a Yamaha dealer check 4. Remove the coolant reservoir cap, varies with engine temperature. the vehicle.
  • Page 56: Replacing The Air Filter Element

    Replace the air filter element added to the coolant, have a more frequently if you are riding in un- Yamaha dealer check the anti- usually wet or dusty areas. freeze content of the coolant as 1. Remove the air filter case cover by soon as possible, otherwise the removing the bolts.
  • Page 57: Checking The Throttle Grip Free Play

    The valve clearance changes with use, resulting in improper air-fuel mixture and/or engine noise. To prevent this from occurring, the valve clearance must be adjusted by a Yamaha dealer at the intervals specified in the periodic maintenance and lubrication chart. 1. Air filter element 3.
  • Page 58: Tires

    Yamaha dealer immediately and tires (i.e., when the temperature cause an accident. of the tires equals the ambient have the tire replaced.
  • Page 59: Cast Wheels

    BRIDGESTONE/EXEDRA G721 er damage before each ride. If any should also be left to a Yamaha damage is found, have a Yamaha Rear tire: dealer. dealer replace the wheel. Do not...
  • Page 60: Adjusting The Clutch Lever Free Play

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU50700 6. Tighten the locknut at the clutch Adjusting the clutch lever free cable, and then slide the rubber If the specified clutch lever free play play covers to their original positions. could be obtained as described above, 7.
  • Page 61: Checking The Brake Lever Free Play

    If there is free play, come on just before braking takes ef- have a Yamaha dealer inspect the fect. If necessary, adjust the rear brake brake system. light switch as follows, but the front...
  • Page 62: Checking The Front And Rear Brake Pads

    EAU22580 Checking the front and rear Checking the brake fluid level peared, have a Yamaha dealer replace brake pads the brake pads as a set. Front brake The front and rear brake pads must be...
  • Page 63: Changing The Brake Fluid

    Changing the brake fluid is above the minimum level mark and ter the brake fluid reservoir when Have a Yamaha dealer change the replenish if necessary. A low brake fluid refilling. Water will significantly brake fluid at the intervals specified in...
  • Page 64: Drive Belt Slack

    5. If the drive belt slack is incorrect, Drive belt slack with a force of 45 N (4.5 kgf, 10 lbf) have a Yamaha dealer adjust it. The drive belt slack should be checked applied to the belt with a belt ten- and adjusted at the intervals specified sion gauge as shown.
  • Page 65: Checking And Lubricating The Cables

    Yamaha dealer at the intervals speci- ed if necessary. If a cable is damaged fied in the periodic maintenance chart.
  • Page 66: Checking And Lubricating The Brake And Clutch Levers

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU23142 Recommended lubricant: Recommended lubricants: Checking and lubricating the Lithium-soap-based grease Brake lever: brake and clutch levers Silicone grease Clutch lever: Brake lever Lithium-soap-based grease Clutch lever The operation of the brake and clutch levers should be checked before each ride, and the lever pivots should be lu- bricated if necessary.
  • Page 67: Checking And Lubricating The Sidestand

    The swingarm pivots must be lubricat- The pivoting points of the rear suspen- be checked before each ride, and the ed by a Yamaha dealer at the intervals sion must be lubricated by a Yamaha sidestand pivot and metal-to-metal specified in the periodic maintenance...
  • Page 68: Checking The Front Fork

    WARNING! To avoid injury, of it falling over. have a Yamaha dealer check or re- [EWA10751] securely support the vehicle so 2. Hold the lower ends of the front pair it.
  • Page 69: Checking The Wheel Bearings

    (See page 4-13.) hub or if the wheel does not turn away from the battery and pro- This model is equipped with a VRLA smoothly, have a Yamaha dealer check vide sufficient ventilation when (Valve Regulated Lead Acid) battery. the wheel bearings.
  • Page 70: Replacing The Fuses

    2. If the battery will be stored for more EAU50810 Replacing the fuses Have a Yamaha dealer charge the bat- than two months, check it at least The main fuse, the fuel injection system tery as soon as possible if it seems to...
  • Page 71 To access the fuel injection system 4. If the fuse immediately blows use a fuse of a higher amperage fuse, remove the starter relay cover by again, have a Yamaha dealer rating than recommended to pulling it upward. check the electrical system.
  • Page 72: Replacing The Headlight Bulb

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU48511 Replacing the headlight bulb This model is equipped with a quartz bulb headlight. If the headlight bulb burns out, replace it as follows. ECA10650 NOTICE Take care not to damage the follow- ing parts: Headlight bulb 1.
  • Page 73: Tail/Brake Light

    2. Screw 2. Remove the burnt-out bulb by pushing it in and turning it counter- clockwise. 1. “TOP” mark 6. Install the headlight unit by install- ing the screws. 7. Have a Yamaha dealer adjust the headlight beam if necessary. 7-32...
  • Page 74: License Plate Light

    Supporting the motorcycle If the license plate light does not come Since this model is not equipped with a on, have a Yamaha dealer check the centerstand, follow these precautions electrical circuit or replace the bulb. when removing the front and rear...
  • Page 75: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.
  • Page 76: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.
  • Page 77 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.
  • Page 78: Motorcycle Care And Storage

    Be ble. Rust and corrosion can develop Cleaning even if high-quality components are sure to consult a Yamaha dealer for ECA10772 used. A rusty exhaust pipe may go un- advice on what products to use be- NOTICE fore cleaning the vehicle.
  • Page 79 MOTORCYCLE CARE AND STORAGE off any detergent residue using Test the product on a small hid- plenty of water, as it is harmful den part of the windshield to Salt sprayed on roads in the winter may to plastic parts. make sure that it does not leave remain well into spring.
  • Page 80: Storage

    Contaminants on the brakes or tires of the presence of ammonia) can cause loss of control. Consult a Yamaha dealer for ad- and areas where strong chemi- Make sure that there is no oil or vice on what products to use.
  • Page 81 MOTORCYCLE CARE AND STORAGE 2. Fill up the fuel tank and add fuel e. Remove the spark plug caps stabilizer (if available) to prevent from the spark plugs, and then Make any necessary repairs before the fuel tank from rusting and the install the spark plugs and the storing the motorcycle.
  • Page 82: Specifications

    SPECIFICATIONS Dimensions: Engine oil: Fuel: Overall length: Recommended brand: Recommended fuel: 2530 mm (99.6 in) YAMALUBE Unleaded gasoline only Overall width: Type: Fuel tank capacity: 860 mm (33.9 in) SAE 10W-30, 10W-40, 10W-50, 15W-40, 15.0 L (3.96 US gal, 3.30 Imp.gal) Overall height: 20W-40 or 20W-50 Fuel reserve amount:...
  • Page 83 SPECIFICATIONS 2nd: (Total weight of rider, passenger, cargo and Rear brake: 1.778 (32/18) accessories) Type: 3rd: Tire air pressure (measured on cold Single disc brake 1.381 (29/21) tires): Operation: 4th: Right foot operation Loading condition: 1.115 (29/26) Recommended fluid: 0–90 kg (0–198 lb) 5th: DOT 4 Front:...
  • Page 84 SPECIFICATIONS Bulb voltage, wattage × quantity: Signaling system fuse: 10.0 A Headlight: 12 V, 60 W/55 W × 1 Ignition fuse: 15.0 A Tail/brake light: Radiator fan fuse: 20.0 A Front turn signal/position light: 12 V, 23 W/8.0 W × 2 Fuel injection system fuse: 10.0 A Rear turn signal light:...
  • Page 85: Consumer Information

    Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: 1.
  • Page 86 This information illustration. This label shows specifica- will be needed when ordering spare tions related to exhaust emissions as parts from a Yamaha dealer. required by federal law, state law and Environment Canada. 10-2...
  • Page 87: Reporting Safety Defects

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Yamaha Motor Corporation, U.S.A. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
  • Page 88: Motorcycle Noise Regulation

    CONSUMER INFORMATION EAU26560 Motorcycle noise regulation TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new ve- hicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.
  • Page 89: Maintenance Record

    CONSUMER INFORMATION EAU26632 Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your vehicle will be required to document that maintenance has been completed in accordance with the emissions warranty. The chart below is printed only as a reminder that maintenance work is required.
  • Page 90 CONSUMER INFORMATION Maintenance Date of Servicing dealer Mileage Remarks interval service name and address 36000 mi (55000 km) or 54 months 40000 mi (61000 km) or 60 months 10-6...
  • Page 91: Yamaha Motor

    CONSUMER INFORMATION EAU26663 YAMAHA MOTOR CORPORATION, U.S.A. STREET AND ENDURO MOTORCYCLE LIMITED WARRANTY Yamaha Motor Corporation, U.S.A. hereby warrants that CUSTOMER’S RESPONSIBILITY under this Engine new Yamaha motorcycles will be free from defects in warranty shall be to: Displacement Period...
  • Page 92 CUSTOMER SERVICE What costs are my responsibility during the warranty period? If your machine requires warranty service, you must take it to any authorized Yamaha The customer’s responsibility includes all costs of normal maintenance services, motorcycle dealer within the continental United States. Be sure to bring your warranty non-warranty repairs, accident and collision damages, and oil, oil filters, air filters, registration card or other valid proof of the original date of purchase.
  • Page 93: Yamaha Extended Service (Y.e.s.)

    This excellent Y.E.S. plan coverage is only available to dealer to see how comforting uninterrupted factory- Yamaha owners like you, and only while your Yamaha is still backed protection can be. within the Yamaha Limited Warranty period. So visit your authorized Yamaha dealer to get all the facts.
  • Page 94 Yamaha Limited Warranty expires. A special note: If visiting your dealer isn’t convenient, contact Yamaha with your Primary ID number (your frame number). We’ll be happy to help you get the Y.E.S. coverage you need.
  • Page 95 INDEX Fuel ............4-10 Fuel level warning light......4-3 Air filter element, replacing ....7-15 Panel, removing and installing....7-9 Fuel tank breather/overflow hose..4-12 Parking............ 6-4 Fuel tank cap.........4-10 Part locations .......... 3-1 Battery ..........7-28 Fuses, replacing........7-29 Brake and clutch levers, checking and lubricating.....
  • Page 96 INDEX Turn signal indicator light ......4-2 Turn signal light bulb, replacing .... 7-32 Turn signal switch ........4-7 Valve clearance ........7-16 Vehicle Emission Control Information label ............ 10-2 Vehicle identification number ....10-1 Warranty, extended....... 10-9 Warranty, limited ........10-7 Wheel bearings, checking.....
  • Page 98 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2010.07-1.5×1 CR...
