When geographic load balancing is enabled, incoming client requests are directed to one of
the sites in the geographic cluster based on the following criteria:
Availability—if a site is unavailable due to network outage, server failure, or any
other reason, Equalizer stops directing requests to that site.
Performance—Equalizer tracks the load and performance at each site and uses this
information to determine which site can process the request most efficiently.
Distance—Equalizer takes into account which site is closest to the client (in network
terms) and offers the least network latency.
Equalizer uses the domain name service (DNS) protocol
distribution. DNS is used to translate fully-qualified domain names such as
www.coyotepoint.com into the IP addresses used to identify hosts on the Internet. The
authoritative name server for the domain is configured to query the Equalizers in the
geographic cluster to resolve the domain name. When Equalizer receives a resolution
request, it uses the load-balancing algorithms configured for the geographic cluster to
determine which site is best able to process the request and then returns the address of the
selected site.
For example, there might be three sites in the geographic cluster www.coyotepoint.com,
one in the Eastern U.S., one in the Western U.S., and one in Europe. An Equalizer and a
cluster of servers resides at each of these sites.
Envoy Site 1: USA West
Figure 2 Three-site geographic cluster configuration
When a client in California attempts to connect to www.coyotepoint.com:
1. The client's local name server is queried to resolve the domain name. (Step 1 in Figure
3.)
2. The local name server queries the authoritative name server for coyotepoint.com.
(Step 2 in Figure 3.)
1. For more information about DNS, see Paul Albitz and Cricket Liu, DNS and BIND, 3rd ed. (O'Reilly & Associates, 1998).
Equalizer Installation and Administration Guide
Envoy Site 3: Europe
nternet
Envoy Site 2: USA East
Geographic Load Balancing
