  • Page 1 Vocia ® Paging Station Kit 1 (PSKIT-1) Manual December 2013 Biamp Systems, 9300 SW Gemini Drive, Beaverton, Oregon 97008 U.S.A. (503) 641-7287 www.biamp.com...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Important Safety Instructions 1) Read these instructions. 10) Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles and the point 2) Keep these instructions. where they exit from the product. 3) Heed all warnings. 11) Only use attachments/accessories specified by the 4) Follow all instructions.

  • Page 3: Table Of Contents

    VOCIA PAGING STATION KIT (PSKIT-1) . . . . . . . . . . . . . . . . . .

  • Page 4: Vocia Paging Station Kit (Pskit-1)

    Page routing. Thus all the processing, routing and storage functionality in a Vocia system remains decentralized. This eliminates a single point of system failure and permits redundancy to be built directly into the network. As part of a Vocia system, the PSKIT-1 meets paging requirements for facilities of all sizes.

  • Page 5: Front Panel

    The Vocia PSKIT-1 is capable of operation from both PoE and 24V DC power. If both are being used, PoE power is given priority. The Power Indicator LED behaves in the following manner:...

  • Page 6: Ptt Input

    General Purpose Inputs The PSKIT-1 supports 12 unmonitored Control Inputs for connection to a keypad interface numbered 0 through 9, as well as inputs for a Next and Previous scroll button. Each Control Input is activated with a momentary connection to Ground. Only one pin can be selected at once.

  • Page 7: Aux Port

    Network Connection The PSKIT-1 is a CobraNet device and uses the RJ-45 connector for communications with other Vocia devices. It is possible to use this network connection with an 802.3af or 802.3at (type 1) PoE switch or external PoE Supplies to provide power to the device. Alternatively, if the device is being powered using the Power Connector and an external 24V DC supply, a connection to the CobraNet network must still be available for the device communications.

  • Page 8: Pskit-1 Specifications

    VOCIA PAGING STATION KIT (PSKIT-1) SPECIFICATIONS Vocia Paging Station Kit Interface 1 SPECIFICATIONS Frequency Response: A/D Converters: 24-bit (48kHz sampling) +0, -1dB, 100Hz to 20kHz Effective Input Headroom: 30dB Connection: RJ-45 with shielded Ethernet (CAT5, CAT5e, CAT6 or CAT7) Gain:...

  • Page 9: Warranty

    WARRANTY BIAMP SYSTEMS IS PLEASED TO EXTEND THE FOLLOWING 5-YEAR LIMITED WARRANTY TO THE ORIGINAL PURCHASER OF THE PROFESSIONAL SOUND EQUIPMENT DESCRIBED IN THIS MANUAL 1. BIAMP Systems warrants to the original purchaser of new products that the product will be free from defects in material and workmanship for a period of 5 YEARS from the date of purchase from an authorized BIAMP Systems dealer, subject to the terms and conditions set forth below.

  • Page 10: Fcc Notice

    FCC COMPLIANCE FCC NOTICE - CLASS B DIGITAL DEVICE NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential as well as in a commercial installation.

  • Page 11: Ec Declaration Of Conformity

    Biamp Systems Corporation will invalidate this declaration. ® Brand Name: Vocia Product Description: Paging Station Control Interface Model: PSKIT-1 Applicable EC Directives: Applicable Harmonized Standards: LVD Directive (2006/95/EC) Safety EN 60065:2002, A1:2006, A11:2008, A2:2010, A12:2011...

  • Page 12: Rohs Compliance And Hazardous Substance Table

    This Biamp product, including all attendant cables and accessories supplied by Biamp, meets all requirements of EU Directives 2011/65/EU. The information below is presented in accordance with parallel requirements of Chinese law SJ/T11363-2006. Biamp Systems Corporation (Announcement Station) Vocia PSKIT-1 Cr+6 PBDE     ( Equipment Chassis)
