PSKIT-1

OPERATION MANUAL

May 2019

585.0404.90A

Table of Contents

Need help?

Do you have a question about the Vocia PSKIT-1 and is the answer not in the manual?

Page 1 PSKIT-1 OPERATION MANUAL May 2019 585.0404.90A...
Page 2 PSKIT-1 Product Description The PSKIT-1 is a standalone Paging Station Kit designed to allow for direct connection to third-party equipment such as fireman’s microphone stations or custom designed fire panels. The PSKIT-1 features embedded DSP and on-board memory to support standard and advanced public address and mass notification functionalities.
Page 3 PSKIT-1 Setup and Installation Setup and Use The Vocia software provides an intuitive interface for configuration, DSP equalization, and programming of the PSKIT-1. The information supplied by this manual relates to physical connections and assignment. For more details on software setup, please consult the Vocia Help File. Installation Install the unit away from heat sources, such as vents and radiators, and in rooms with adequate ventilation.
Page 4 Due to potential energy hazard, connections to the Auxiliary Power 24V DC inputs must be made by a qualified electrician or other qualified person The Vocia PSKIT-1 is capable of operation from both PoE and 24V DC power. If both are being used, PoE power is given priority. The Power Indicator LED behaves in the following manner:...
Page 5 Pin 5 GND / 0V Aux Port A RJ-45 connector is available internally for use with Biamp accessories. This port is not an Ethernet port and must not be connected to a switch, PoE supply, or other Ethernet network devices.
