- Page 1 User Manual DPP-450 ESC/POS PRINTER...
-
Page 2: User Manual
1 DATECS DPP-450 User manual THE INFORMATION IN THIS DOCUMENT CANNOT BE REPRODUCED IN ANY MECHANICAL, ELECTRICAL OR ELECTRONIC WAY AND UNDER ANY CIRCUMSTANCES WITHOUT THE WRITTEN CONSENT FROM DATECS LTD. VERSION: September 2012... -
Page 3: Table Of Contents
4. General view......................6 4.1 Dimensions and outlook ................... 6 4.2 Box Contents....................7 5. Getting started ......................8 5.1 Charge DPP-450 ....................9 5.2 Diagnostic information ..................10 5.3 Loading paper ....................10 5.4 Mounting belt clip ................... 14 5.5 Self-Test ...................... -
Page 4: Introduction
User manual 1. Introduction DATECS DPP-450 is a mobile ESC/POS and LABEL thermal printer. It can be used in dynamic working conditions and its abundant built-in features allow it to be widely used for different applications. Printer can quickly and easily print text and/or graphics, depending on customer’s needs –... -
Page 5: Technical Specification
1 DATECS DPP-450 User manual 3. Technical specification DPP-450 Specification Line Thermal Dot Printing Printing Method 832 dots / line Total Dots Dot Density 8 dots / mm (203 dpi) Print Speed 150 mm / sec Print Width 104 mm... -
Page 6: General View
1 DATECS DPP-450 User manual 4. General view 4.1 Dimensions and outlook... -
Page 7: Box Contents
1 DATECS DPP-450 User manual 4.2 Box Contents... -
Page 8: Getting Started
Because of the continually evolving Driver & SDK to support new mobile devices, Drivers & SDK are distributed online and is available for download at our website indicated below. For details on using the DPP-450 Drivers & SDK, please refer to the SDK’s documentation. -
Page 9: Charge Dpp-450
AC Charger only. Charging time is 3 hours from empty to full charge. When the battery is fully charged the device can print 150m paper roll, this is 3.5 rolls standart for DPP-450. AC adapter and power cord Battery... -
Page 10: Diagnostic Information
1 DATECS DPP-450 User manual Insert cable to dc jack to start charging. When the device is turn on(holding turn on/off button), in display will show “CHG” text and greed led “CHARGE” is blink. ECS/POS Ready 5.2 Diagnostic information • Holding <LF> button while power on for ~ 0.5 sec (first sound signal) – short self- test. - Page 11 1 DATECS DPP-450 User manual When the paper cover is open drop the new roll of thermal media. With green lever can choose size of thermal paper. To choose paper size – pull up lever and push on right for small paper or left for big.
- Page 12 1 DATECS DPP-450 User manual Right paper position Close paper cover...
- Page 13 1 DATECS DPP-450 User manual Slide peeler Peeler setting for label paper. Peeler setting for paper roll.
-
Page 14: Mounting Belt Clip
5.5 Self-Test • Holding <LF> button while power on for ~ 0.5 sec (first sound signal) – short self- test. The DPP-450 has a built-in test pattern that shows the printer’s current configuration as well as the various resident printer fonts. The self-test can... - Page 15 1 DATECS DPP-450 User manual • Holding <LF> button while power on for ~ 5.5 sec (third sound signal) – self-test. Resident font sizes Characters per line Text formatting Resident character set Resident barcode symbols Printer’s configuration...
-
Page 16: Page Mode
1 DATECS DPP-450 User manual 5.6 Page Mode In page mode the result of incoming commands is forwarded to a reserved memory area (page). The page place and size is defined using command ESC W. Command GS T selects the print direction in this page. At the end the collected information is printed using one of the commands, provided for this. - Page 17 1 DATECS DPP-450 User manual Open channel (No action – all channels always open) Close channel (No action – all channels always open) Send data Request data >4: Application specific Status: One byte: Bit 0 No error Error occured Bit 1...
-
Page 18: Hardware Setup
1 DATECS DPP-450 User manual is received. The application must take care to get the data fast enough from the output buffer or the data may be corrupt. Command 4 Get printer status. 5 data bytes returned in response: BufferHi BufferLo PrStatus Volt Temperature... - Page 19 1 DATECS DPP-450 User manual Then press FEED button, to enter Hardware menu. Device will prining current settings. The LCD in hardware configuration menu: FACTORY DEFAULT MEM. SWITCHES: BAUD RATE: IrDA BAUD RATE: With button “PRINT” can move down and with “FEED” can enter in selected.
- Page 20 1 DATECS DPP-450 User manual FACTORY DEFAULT MEM. SWITCHES ENABLE SOUND Enable/Disable printer's buzzer EXECUTE <CR> AS <LF> Disable CR/CR is executed as LF DISABLE <LF> COMMAND Enable/Disable LF DISABLE<LF>AFTER Disable LF immediately after CR DEFAULT SMALL FONT Set the small font as default...
- Page 21 1 DATECS DPP-450 User manual • 2 min. • 5 min. PRINT DARKNESS Changing the printing darkness • 120 % • 140 % • 160 % • 60 % • 75 % • 90 % • 100 % CHARACTER TABLE Changing the printer's character table •...
-
Page 22: List Of Commands
1 DATECS DPP-450 User manual USB DEV. CLASS Changing the USB device class of the printer Printer/Serial • Printer • Serial SAVE & EXIT MENU 5.10 List of commands Sounds the buzzer Horizontal Tab command configuration flags 2, 3 and 4 Printing а... - Page 23 1 DATECS DPP-450 User manual ESC D Setting horizontal tab position ESC E Specifying/Canceling highlighting ESC F Filling or inverting the page area in page mode ESC G Specifying/Canceling highlighting ESC I Specifying/Canceling Italic print ESC J Printing and Paper feed n/203 inches...
-
Page 24: Connecting Device
5.11 Connecting Device The DPP-450 is designed to use different methods of communications. Care must be taken to ensure that the DPP-450 USB/RS 232 connector and PDA & Smartphone connector are not accidentally damaged. The figures below show how to attach the different device to the DPP-450. - Page 25 Start – LibraryDemo on iPad. Connect LineaTab to iPad(Figure 4). After this press settings button. Turn on DPP-450 Bluetooth printer. From setting menu press Discover printers, and wait to find printers. When is found press on selected printer and wait connect.
-
Page 26: Mount Strap
1 DATECS DPP-450 User manual On “Print” menu can printing via Bluetooth connection: Print Self-test Demo fonts Demo barcodes Demo graphics To terminate the BT connection, press settings menu and name of printer. When is close connection the “tick” will disappearing. - Page 27 1 DATECS DPP-450 User manual...
