1 DATECS
DPP-255 User Manual
Version
Data
Range
Change description
Author
Viktor
1.0.0
20.01.2016
All document
First release
Kochev

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DPP-255 and is the answer not in the manual?

Questions and answers

Related Manuals for Datecs DPP-255

Summary of Contents for Datecs DPP-255

  • Page 1 1 DATECS DPP-255 User Manual Version Data Range Change description Author Viktor 1.0.0 20.01.2016 All document First release Kochev...
  • Page 2 Decree № 82 of 10.04.2006) THE INFORMATION IN THIS DOCUMENT CANNOT BE REPRODUCES IN ANY MECHANICAL, ELECTRICAL OR ELECTRONIC WAY AND UNDER ANY CIRCUMSTANCES WITHOUT THE WRITTEN CONSENT FROM DATECS LTD. UM 07.01.01/v1.0.0...
  • Page 3 1 DATECS DPP-255 User’s Manual Legal Notice “Made for iPod,” “Made for iPhone,” and Made for iPad” mean that an electronic accesory has been designed to connect specifically to iPod, iPhone, or iPad, respectively, and has been certified by the developer to meet Apple performance standards.
  • Page 4 1 DATECS DPP-255 User’s Manual This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 5: Table Of Contents

    CONTENTS 1. INTRODUCTION ............................ 6 2. FEATURES ............................. 6 3. TECHNICAL SPECIFICATION ........................7 4. GENERAL VIEW............................. 8 5. GETTING STARTED..........................9 5.1. C DPP-255 ..........................9 HARGE 5.2. D ........................ 10 IAGNOSTIC INFORMATION 5.4. L ..........................10 OADING PAPER 5.5 R...

  • Page 6: Introduction

    User’s Manual 1. Introduction Datecs DPP-250 is a mobile ESC/POS and LABEL thermal printer. It can be used in dynamic working conditions and its abundant built-in features allow it to be widely used for different applications. Printer can quickly and easily print text and/or graphics, depending on customer needs –...

  • Page 7: Technical Specification

    1 DATECS DPP-255 User’s Manual 3. Technical specification DPP-255 Specification Printing Method Direct line thermal printer Total Dots 384 dots / line Dot Density 8 dots / mm (203 dpi) Print Speed 100 mm / sec Print Width 48 mm...

  • Page 8: General View

    Because of the continually evolving Driver and SDK to support new mobile devices, Drivers and SKDs are distributed online and is available for download at our website. For details on using the DPP-255 Drivers and SKDs, please refer to the SKD’s documentation.

  • Page 9: Getting Started

    User’s Manual 5. Getting started The DPP-255 allows you to print information from your PDA and Smart phone. Before using the DPP-255 thermal printer, the battery should be properly charged. The following Quick Start guide will help to get your DPP-255 ready for use.

  • Page 10: Diagnostic Information

    1 DATECS DPP-255 User’s Manual 5.2. Diagnostic information  Holding FEED button while power on for ~ 0.5 sec (STATUS LED lights) – short self test  Holding FEED button while power on for ~2.5 sec (one beep and POWER LED turns green) –...
  • Page 11 1 DATECS DPP-255 User’s Manual  Load the paper roll. Move paper guide to fit paper width  Fixing peeler unit (if loading a thermal label roll)  Removing peeler unit UM 07.01.01/v1.0.0...

  • Page 12: Replace Battery

    1 DATECS DPP-255 User’s Manual 5.5 Replace battery  Open battery cover.  Eject battery.  Put new battery pack in battery holder and close battery cover. Battery pack no longer required mustn’t be waste but be brought it to nearest electric store to recycle 5.6.

  • Page 13: Functions

    6. Functions 6.1. Self test The DPP-255 has a built-in test pattern that shows the printer’s current configuration as well as the various resident printer fonts. The self-test can also be used as a troubleshooting tool to determinate problems or battery level.

  • Page 14: Page Mode

    1 DATECS DPP-255 User’s Manual 6.2. Page mode In page mode the result the result of incoming commands is forwarded to a reserved memory area (page). The page place and size is defined using commands ESC W. Command GS T selects the print direction in this page.

  • Page 15: Hardware Setup

    1 DATECS DPP-255 User’s Manual 6.5. Hardware setup Hardware setup allows you to switch register functions in the memory manually. Function are called up by the POWER and FEED buttons and the printer prints registered functions.  Hold POWER button while power on for more than 6 sec(printer prints) Content of memory switch is printed by pressing FEED button ...
  • Page 16 1 DATECS DPP-255 User’s Manual Follow the flow chart to change the parameter. As the setting parameter is printed, choose the right parameter by manipulating the FEED and POWER buttons. After completing the parameters set up, data are stored and the printer turn off.
  • Page 17 1 DATECS DPP-255 User’s Manual Setting Memory switches (Default settings)  RESTORE FACTORY DEFAULTS? Select reset memory switches as factory default. YES: Returns to the default memory NO: No action  CHANGE MEMORY SWITCHES? SWITCH NO NO (Value: 0) YES (Value: 1)

  • Page 18: Dip Switches

    1 DATECS DPP-255 User’s Manual  CHANGE PAIRING INFO? Select the setting for Bluetooth Pairing key After selected “YES” key, goes to the settings items “SAVE PAIRING INFO”. There is a possible to set up this item when “DISABLE AUTHENTICATION” is set “NO”.

  • Page 19: Led Display

    1 DATECS DPP-255 User’s Manual 6.7. LED display  No error signal Is detected Standby – It is possible to print and the printer waits for printing data Initialization – Initialize printer memories. The printer goes OFFLINE during initialization. After completing initialization, the printer goes stanby.

  • Page 20: Interfaces

    1 DATECS DPP-255 User’s Manual 7. Interfaces 7.1. USB The DPP-255 is equipped with USB version 2.0 for high speed data transfer. The device class is “Printing Device Class” Signal Direction Function VBUS Detect connect/disconnect of USB USB data (-) USB (+) 7.2.

  • Page 21: Wi-Fi

    1 DATECS DPP-255 User’s Manual 7.4. Wi-Fi Contents Items Wi-Fi standard IEEE 802.11b Speed rate Max. 11Mbps Hardware Chanel CH 1 to 13 Security 64/128 WEP, WPA-PSK, WPA2-PSK Wi-Fi protocol TCP, IP, SOCKET, ARP, RAPP Port 1 to 9999(default 9100)

  • Page 22: Maintains

    Do not use volatile chemical agents, such as thinner and benzene. Do not get moisture or spill liquids inside of the printer. Turn ON printer only after alcohol is completely dried. For maintenance and service, please contact you Datecs local distributor. UM 07.01.01/v1.0.0...
