TDK-Lambda CSS65 Product Handbook page 14

CSS65 Product HANDBOOK
Input Parameters:
Standard
Nominal input voltage
Input voltage range
Input frequency range
Maximum input current
Input Connections: Input connector 3 pin header (center pin removed) 5A/250V MAX, mates with Molex
Housing 09-50-3031
Output Parameters:
Output channel
CSS65-5
CSS65-12
CSS65-15
CSS65-19
CSS65-24
CSS65-36
CSS65-48
Output Connections: output connector 4 pin header, mates with Molex Housing 09-50-3041
All individual outputs are SELV.
Note:
If the total voltage of outputs connected in series exceed the 60Vdc SELV limit then all outputs must be
considered non-SELV.
Non-SELV outputs are hazardous and must not be made user accessible. They must be guarded or a
deflector fitted during installation to avoid a service engineer making inadvertent contact with the output
terminals, or dropping a tool onto them.
All outputs have operational spacings to earth, and due consideration must be given to this in the end product
design.
Safety Approvals:
IEC/EN/60601-1 CB Report and Certificate.
UL/CSA 60601-1 - UL + C -UL approval
nd
IEC / EN60950-1(2 Edition)
CE mark.
CE marking when applied to any CSS65-xx product, indicates compliance with the Low Voltage Directive
(2006/95/EC) in that it complies with EN60950-1, 2
60601-1
100-240VAC
90-264VAC
47-63Hz
2A
Vout (V) Adjustment
range (V)
5
12
15
All
19
Factory set
24
36
48
nd
60950-1
100-240VAC
90-264VAC
47-63Hz
2A
Output Maximum
current (A) power (W)
8.0A 40
5.0 60
4.0 60
3.43 65
2.71 65
1.81 65
1.36 65
Edition
