Summary of Contents for GRASS VALLEY PDR 200

  • Page 1: Installation Manual

    P D R 2 0 0 , P D R 3 0 0 , & P D R 4 0 0 Installation Manual 0 71 - 80 0 5 -0 0 M A R C H 2 3 , 2 0 0 0 PR OFI LE FA M I LY V I D E O F I L E S E R V E R S...
  • Page 2 Copyright Copyright © 2000 Grass Valley Group Inc. All rights reserved. Printed in the United States of America. This document may not be copied in whole or in part, or otherwise reproduced except as specifically permitted under U.S. copyright law, without the prior written consent of Grass Valley Group Inc., P.O.
  • Page 3 Grass Valley Group Product Support You can get technical assistance, check on the status of problems, or report new problems by contacting our Product Support Group. United States and Canada Monday–Friday 5:30AM–5:00PM Pacific Time (800) 547-8949 Europe Monday–Friday 9:00AM–5:30PM France...
  • Page 4 Grass Valley Group Product Support Profile Video File Server Installation...
  • Page 5: Table Of Contents

    Contents Grass Valley Group Product Support ..................iii Chapter 1 Introduction Scope............................. 1-1 Related Documentation ......................1-2 Organization of the Manual....................1-2 Product Description ....................... 1-3 Product Features ......................1-4 Front Panel Controls and Indicators ................. 1-5 Accessories ........................... 1-6 Standard Accessories .......................
  • Page 6 Contents Chapter 3 Starting Your Profile System Power On/Off ......................... 3-1 Logging On ........................3-1 Automatic Logon ......................3-1 Logon as Administrator ....................3-2 Logon as Profile ......................3-2 Turning Power On ......................3-2 Turning Power Off ......................3-4 System Set-up ........................3-5 Configuring Your Profile System ..................
  • Page 7 Contents Figures The Profile Video File Server ....................1-1 Profile Video File Server Front Panel ................... 1-5 Configuration Labels Locations .................... 1-14 Rack Slide Set for Right Side of Profile Chassis and Rack ..........2-2 Spacing Specification for Mounting Holes in a Rack ............2-3 Front Rail Mounting Detail ....................
  • Page 8 Contents Tables Profile Video File Server Model Descriptions ..............1-8 PDR202 and PDR204 Factory Standard Configurations with Installable Options ..1-9 PDR304 and PDR308 Factory Standard Configurations with Installable Options ..1-10 PDR312 and PDR316 Factory Standard Configurations with Installable Options ..1-11 PDR324 Factory Standard Configurations with Installable Options .......1-12 PDR404 Factory Standard Configurations with Installable Options ........1-13 Maximum Video Data Rates Per Channel With Non-RAID Storage ........1-15 Maximum Video Data Rates Per Channel With PRS255 RAID Storage Chassis ...1-15...
  • Page 9: Safety Summaries

    Safety Summaries General Safety Summary Review the following safety precautions to avoid injury and prevent damage to this product or any products connected to it. Only qualified personnel should perform service procedures. While using this product, you may need to access other parts of the system. Read the General Safety summary in other system manuals for warnings and cautions related to operating the system.
  • Page 10: Safety Terms And Symbols

    Safety Summaries Safety Terms and Symbols Terms in This These terms may appear in this manual: Manual WARNING: Warning statements identify conditions or practices that can result in personal injury or loss of life. CAUTION: Caution statements identify conditions or practices that can result in damage to the equipment or other property.
  • Page 11: Laser Compliance

    Changes or modifications not expressly approved by Grass Valley Group can affect emission compliance and could void the user’s authority to operate this equipment.
  • Page 12 Safety Summaries Laser Safety Laser safety in the United States is regulated by the Center for Devices and Radiological Health (CDRH). The laser safety regulations are published in the “Laser Product Performance Standard,” Code of Federal Regulation (CFR), Title 21, Subchapter J. The International Electrotechnical Commission (IEC) Standard 825, “Radiation of Laser Products, Equipment Classification, Requirements and User’s Guide,”...
  • Page 13: Chapter 1 Introduction

    Introduction Scope This is the Installation manual for the Grass Valley Group Profile Family of Video File Servers. The Profile family of products includes the PDR200 JPEG Video File Server, the PDR300 MPEG Video File Server, and the PDR400 DVCPRO Video File Server.
  • Page 14: Related Documentation

    Chapter 1 Introduction Related Documentation Profile Family User Manual PDR 200 Service Manual Profile System Software Release Notes PDX 218 Disk Expansion Chassis Instruction Manual Windows NT Instruction Manual Organization of the Manual The Installation manual is divided into the chapters identified and described below.
  • Page 15: Product Description

    Each configuration is then tailored, through factory installed options, to meet your site-specific needs. Many options may be easily added to your PDR 200 as your needs change and expand. For information on adding options, contact your Grass Valley Group representative.
  • Page 16: Product Features

    Chapter 1 Introduction Product Features Record/playback and storage/retrieval applications for the Profile Video File Server run in the Windows NT environment. The Windows NT operating software is loaded on the dedicated system hard disk, which is also used for application storage. Control is via an internal Pentium-based CPU board.
  • Page 17: Front Panel Controls And Indicators

    Front Panel Controls and Indicators Front Panel Controls and Indicators The Profile Video File Server front panel, shown in Figure 1-2, consists of the controls and indicators keyed to Figure 1-2 and briefly described below. Ê Floppy Disk Drive access for loading operating system software or specific application software.
  • Page 18: Accessories

    • 1 Keyboard (Grass Valley Group part number 119-4899-XX) • 1 Mouse (Grass Valley Group part number 119-4330-XX) • EMI Suppression Gaskets for BNC Connectors (Grass Valley Group part number 016-1448-XX) • Cable Assemblies, Power (161-0123-00 for US and Japan; 161-0066-09 for Europe;...
  • Page 19: Optional Accessories

    • Eight-connector DB25-XLR breakout cable for longitudinal time code I/O, 6 ft. (Grass Valley Group part number 174-3249-XX) • Eight-connector breakout cable, with DB25 connector, 24 ft. (Grass Valley Group part number 174-3481-XX) • External CD ROM drive (Grass Valley Group part number PDRFCD) •...
  • Page 20: Configurations

    Chapter 1 Introduction Configurations The Profile Video File Server is available in several factory installed configurations. Table 1-1 lists the available JPEG codecs, MPEG encoders, MPEG decoders and DVCPRO25 codecs that are available on each model. Table 1-1. Profile Video File Server Model Descriptions Model Number Number of...
  • Page 21: Pdr202 And Pdr204 Factory Standard Configurations With Installable Options

    Configurations Table 1-2. PDR202 and PDR204 Factory Standard Configurations with Installable Options Slot PDR202A PDR202D PDR204A PDR204D System CPU System CPU System CPU System CPU Parallel Port Parallel Port Parallel Port Parallel Port System SCSI System SCSI System SCSI System SCSI Audio I/O Audio I/O Audio I/O...
  • Page 22: Pdr304 And Pdr308 Factory Standard Configurations With Installable Options

    Chapter 1 Introduction Table 1-3. PDR304 and PDR308 Factory Standard Configurations with Installable Options Slot PDR304A PDR304D PDR308A PDR308D System CPU System CPU System CPU System CPU Parallel Port Parallel Port Parallel Port Parallel Port System SCSI System SCSI System SCSI System SCSI Audio I/O Audio I/O...
  • Page 23: Pdr312 And Pdr316 Factory Standard Configurations With Installable Options

    Configurations Table 1-4. PDR312 and PDR316 Factory Standard Configurations with Installable Options Slot PDR312A PDR312D PDR316A PDR316D System CPU System CPU System CPU System CPU Parallel Port Parallel Port Parallel Port Parallel Port System SCSI System SCSI System SCSI System SCSI Audio I/O Audio I/O Audio I/O...
  • Page 24: Pdr324 Factory Standard Configurations With Installable Options

    Chapter 1 Introduction Table 1-5. PDR324 Factory Standard Configurations with Installable Options Slot PDR324A PDR324D System CPU System CPU Parallel Port Parallel Port System SCSI System SCSI Audio I/O Audio I/O Digital AES/EBU Digital AES/EBU Video Mixer Video Mixer Video Out Video Out Picture Monitor (Analog) Picture Monitor (Analog)
  • Page 25: Pdr404 Factory Standard Configurations With Installable Options

    Configurations Table 1-6. PDR404 Factory Standard Configurations with Installable Options Slot PDR404A PDR404D PDR406A PDR406D System CPU System CPU System CPU System CPU Parallel Port Parallel Port Parallel Port Parallel Port System SCSI System SCSI System SCSI System SCSI Audio I/O Audio I/O Audio I/O Audio I/O...
  • Page 26: Configuration Labels

    Chapter 1 Introduction Configuration Labels You may check/identify your configuration, including factory installed options, by looking at the bottom panel just below the rear panel board connectors. A configuration label, which identifies the board installed in the slot above the label, has been attached to assist you in making connections to your Profile system.
  • Page 27: Maximum Video Data Rates

    Maximum Video Data Rates Maximum Video Data Rates This section describes the maximum video data rate available per channel on the Profile Video File Server when all channels are in use. The maximum video data rate per channel depends on the Profile model, the type of storage, and the number of storage disk drives in the system.
  • Page 28: Storage Capacity Estimates

    Chapter 1 Introduction You can select the video data rate the Profile system uses to record the video signal, unless you are using DVCPRO25 codecs which operate at a fixed 25Mb/s. When selecting video data rates, be sure not to exceed the total Profile system bandwidth. Fibre channel transfers, archive operations, and high bandwidth recording or playout may require that you reduce the data rate on other channels or operate fewer channels at one time.
  • Page 29: Dvcpro System Timing Considerations

    DVCPRO System Timing Considerations DVCPRO System Timing Considerations The DVCPRO codecs used in Profile systems are actually pairs of codecs. Because of this paired codec architecture, some restrictions apply to the DVCPRO codecs which require the following system timing limitations: 1.
  • Page 30 Chapter 1 Introduction 1-18 Profile Video File Server Installation...
  • Page 31: Chapter 2 Mechanical Installation

    Chapter Mechanical Installation This chapter describes the mechanical installation of your Profile Video File Server into an equipment rack and the connection of cables to the rear panel. The chapter includes examples of connections to peripheral equipment such as the PDX 218 storage expansion chassis, the PRS 255 RAID Storage chassis.
  • Page 32: Mounting The Slide Tracks In The Rack

    Chapter 2 Mechanical Installation Mounting the Slide Tracks in the Rack Figure 2-1 shows the components of a right-hand rack slide set. Note that the chassis sections are already attached to the Profile Video File Server and PAC208/216. When mounting rack slides in the equipment rack, bear the following in mind: •...
  • Page 33: Spacing Specification For Mounting Holes In A Rack

    Mounting the Slide Tracks in the Rack From Figure 2-2, choose the proper set of rail mounting holes on the rack. Notice that the hole spacing can vary with the rack type. When mounting the slides in racks with EIA spacing, make sure that the slides are attached to the 0.5-inch spaced holes. “UNIVERSAL”...
  • Page 34: Front Rail Mounting Detail

    Chapter 2 Mechanical Installation Figure 2-3 and Figure 2-4 show front and rear rail mounting details for both deep and shallow racks. Mount the rails using the enclosed hardware. Make sure the stationary sections are horizontally aligned and are level, as well as parallel to each other. BAR NUT (Use if the front rail is not tapped) Figure 2-3.
  • Page 35: Mounting The Profile Video File Server

    Mounting the Profile Video File Server Mounting the Profile Video File Server In addition to room to make cable connections, the Profile Video File Server requires six inches (15.25 cm) of clearance behind the rear panel for connectors and cable bends.
  • Page 36: Making Rack Slide Adjustments

    Chapter 2 Mechanical Installation Making Rack Slide Adjustments After installation, binding may occur if the slide tracks are not properly adjusted. To adjust the tracks: 1. Slide the chassis out approximately 10 inches. 2. Slightly loosen the mounting screws holding the tracks to the front of the rails and allow the tracks to seek an unbound position.
  • Page 37: Making Rear Panel Connections

    Making Rear Panel Connections Making Rear Panel Connections Because of the flexible configurations of the Profile Video File Server, not all of the rear panel connections described here may apply to your Profile system. The connections are described as though all factory installable options were in fact installed.
  • Page 38: Connecting The Mouse And Keyboard

    Chapter 2 Mechanical Installation Connecting the Mouse and Keyboard The Profile system mouse and keyboard connectors are located on the rear panel as shown in Figure 2-7. Connect the mouse and keyboard as shown in Figure 2-7. J12 J11 J9 J8 J4 J3 Mouse Keyboard...
  • Page 39: Connecting The Reference Genlock

    Connecting the Reference Genlock Connecting the Reference Genlock The Profile Video File Server provides a Reference Genlock board, standard on all configurations, with two BNC connectors and a 25-pin DIN connector. The BNC connectors form a bridging, high impedance loop-through for the analog black burst house reference signal.
  • Page 40: Connecting Video

    Chapter 2 Mechanical Installation Connecting Video The Profile Video File Server supports Serial Digital I/O, Analog Composite I/O, and Analog Component Inputs. The video connections you make depends on your Profile Video File Server configuration. Connecting Serial Digital Video The Profile Video File Server allows Serial Digital Video I/O board installations for two channels of serial digital input and output per board.
  • Page 41: Connecting Analog Composite Video I/O

    Connecting Video Connecting Analog Composite Video I/O The Profile Video File Server may include one or more an Analog Composite Video In/Output boards. Figure 2-11 shows analog composite video cable connections for a typical location, slot J14. Refer to the rear panel labels or Tables 1-2 through 1-6 in Chapter 1, pages 1-9 through 1-13, to determine the slot location of this board in your system.
  • Page 42: Connecting Analog Composite Monitor

    Chapter 2 Mechanical Installation Connecting Analog Composite Monitor The Profile Video File Server may include an Analog Composite Monitor board which provides four channels of analog composite video output with time code burn-in and text overlay. With this board you can simultaneously display independent time code of each playback channel on a picture monitor display.
  • Page 43: Connecting Analog Composite Video Out

    Connecting Video Connecting Analog Composite Video Out The Profile Video File Server may include an Analog Composite Video Out board which provides up to four channels of analog composite video output. The board also has a Monitor D connector which is the Out D video with time code burn-in available. Figure 2-13 shows analog composite video out cable connections for a typical location, slot J6.
  • Page 44: Connecting Component Analog Video

    Chapter 2 Mechanical Installation Connecting Component Analog Video The Profile Video File Server may include an Component Analog Video In board which accepts a single source of component analog video input. Figure 2-14 shows component analog video in cable connections for a typical location, slot J13.
  • Page 45: Connecting Audio

    Connecting Audio Connecting Audio Your Profile Video File Server can have one or two Audio I/O boards installed. All units have at least one Audio I/O board, called Audio Signal Processor Board (or ASPB), which provides 16 channels of audio I/O. A second ASPB can be installed, adding 16 more channels for a total of 32 channels of audio I/O.
  • Page 46: Connecting 16 Channels Aes/Ebu Digital Audio (Xlr216 Or Bnc216)

    Chapter 2 Mechanical Installation The 16 channels supported by the ASPB are divided into four audio groups with four audio channels in each group. The first group consists of channels 1 to 4. The second group consists of channels 5 to 8, and so on up to the fourth group. Audio channels are typically assigned by groups to video channels.
  • Page 47: Aspb Connections For 16 Channels Of Aes/Ebu Digital Audio

    Connecting Audio ASPB J12 J11 J9 J8 J16 J15 J14 J4 J3 J2 Digital (AES/EBU) AES/EBU 1-16 Channels Monitor Spares XLR216 Audio Panel PROFILE Digital (AES/EBU) 1-16 Channels BNC216 Audio Panel 9676-49 . . . In Out Figure 2-15. ASPB Connections for 16 Channels of AES/EBU Digital Audio Profile Video File Server Installation 2-17...
  • Page 48: Connecting 32 Channels Aes/Ebu Digital Audio (Xlr216 Or Bnc216)

    Chapter 2 Mechanical Installation Connecting 32 Channels AES/EBU Digital Audio (XLR 216 or BNC 216) Figure 2-16 shows AES/EBU digital audio interface connections for a 32 audio channel Profile Video File Server. The 32 channel Profile system has two Audio I/O boards: ASPB1 and ASPB2.
  • Page 49: Aspb Connections For 32 Channels Of Aes/Ebu Digital Audio

    Connecting Audio ASPB2 ASPB1 (Channels 17-32) (Channels 1-16) J16 J15 J14 J12 J11 J9 J8 J4 J3 J2 Digital (AES/EBU) AES/EBU 1-16 Channels Spares Monitor ASPB1 XLR216 Breakout Panel PROFILE Digital (AES/EBU) AES/EBU 17-32 Channels Spares Monitor ASPB2 XLR216 Breakout Panel PROFILE To ASPB1 Digital (AES/EBU)
  • Page 50: Connecting 8 Analog And 8 Digital Channels (Pac208)

    Chapter 2 Mechanical Installation Connecting 8 Analog and 8 Digital Channels (PAC 208) Figure 2-17 shows analog/digital audio connections for a 16 audio channel Profile Video File Server using the PAC 208 version of the PAC 200 Profile Audio Chassis. The PAC 208 chassis allows you to connect eight analog and eight digital (four pairs) audio I/Os to the Profile Video File Server.
  • Page 51: Aspb Connections For 8 Analog And 8 Digital Audio Channels

    Connecting Audio ASPB J12 J11 J9 J8 J16 J15 J14 J4 J3 J2 Analog Digital (AES/EBU) 9-16 Channels Channels Ref Monitor PAC208 Audio Chassis 9676-50 Figure 2-17. ASPB Connections for 8 Analog and 8 Digital Audio Channels Profile Video File Server Installation 2-21...
  • Page 52: Connecting 16 Analog/Digital Channels (Pac216)

    Chapter 2 Mechanical Installation Connecting 16 Analog/Digital Channels (PAC 216) Figure 2-18 shows analog/digital audio connections for a 16 audio channel Profile Video File Server using the PAC 216 version of the PAC 200 Profile Audio Chassis. This Profile system has one ASPB (Audio Signal Processor Board) which provides 16 channels of audio I/O.
  • Page 53: Aspb Connections For 16 Analog And 16 Digital Audio Channels

    Connecting Audio ASPB J12 J11 J9 J8 J16 J15 J14 J4 J3 J2 Analog Digital (AES/EBU) 9-16 Channels Channels Ref Monitor PAC216 Audio Chassis Analog Digital (AES/EBU) 9-16 Channels Channels Ref Monitor PACXLR Audio Breakout Panel PROFILE 9676-51 Figure 2-18. ASPB Connections for 16 Analog and 16 Digital Audio Channels Profile Video File Server Installation 2-23...
  • Page 54: Connecting 32 Analog/Digital Channels (Pac216)

    Chapter 2 Mechanical Installation Connecting 32 Analog/Digital Channels (PAC 216) Figure 2-19 shows analog/digital interface connections for a 32 audio channel Profile Video File Server. The 32 channel Profile system has two Audio I/O boards: ASPB1 and ASPB2. ASPB1 is in the lower numbered slot, and ASPB2 is in the higher numbered slot.
  • Page 55: Aspb Connections For 32 Analog And 32 Digital Audio Channels

    Connecting Audio • Connections on the PAC XLR Audio Breakout Panel are provide for analog audio channels 25-32, each with an In and Out. • Connections on the PAC XLR Audio Breakout Panel are for four pairs of digital audio channels: 25/26, 27/28, 29/30, and 31/32 where each pair has an In and Out. •...
  • Page 56: Connecting Scsi Devices

    Chapter 2 Mechanical Installation Connecting SCSI Devices The Profile Video File Server has a number of connectors for attaching SCSI devices. There are SCSI connectors on the Master and Slave Enhanced Disk Recorder boards, on the System SCSI board, and along the top of the rear panel (see Figure 2-20). Beyond the Master Enhanced Disk Recorder board, standard on all configurations, the number of SCSI connectors available depends on your configuration.
  • Page 57: Example 1: Connecting A Pdx218 Disk Expansion Chassis

    See “Using the Profile Disk Utility” in the Profile Family User Manual. See Figure 2-21 through Figure 2-25 for examples of Grass Valley Group SCSI devices that can be connected to the SCSI connectors on the Master and Slave EDR boards.
  • Page 58: Example 2: Connecting Two Pdx218 Disk Expansion Chassis

    Chapter 2 Mechanical Installation Disk Disk Recorder Recorder Slave Master Profile Video File Server Note: Disk recorder board locations may be different than shown. See rear panel labels for actual locations. First PDX218 Second PDX218 SCSI Cable Terminator 9687-24 Figure 2-22. Example 2: Connecting two PDX218 Disk Expansion Chassis Example 2 (Figure 2-22) shows disk expansion of a Profile system equipped with Master and Slave EDR boards.
  • Page 59: Example 3: Profile Video File Server To Pls 200 Connections

    Connecting SCSI Devices SCSI SCSI Profile Video File Server Note: Disk recorder board locations may be different than shown. See rear panel labels for actual locations. PLS200 SCSI Cable Terminator SCSI Jumper 9676-44 Figure 2-23. Example 3: Profile Video File Server to PLS 200 Connections Example 3 (Figure 2-23) shows connection of a Profile Library System (PLS200) to a Profile Video File Server equipped with a Slave EDR.
  • Page 60: Example 4: Profile Video File Server To Pdx 218 And Pls 200 Connections

    Chapter 2 Mechanical Installation SCSI SCSI Profile Video File Server J11 J10 Note: Disk recorder board locations may be different than shown. See rear panel labels for actual locations. PDX218 PLS200 SCSI Cable Terminator SCSI Jumper 9676-66 Figure 2-24. Example 4: Profile Video File Server to PDX 218 and PLS 200 Connections Example 4 (Figure 2-24) shows disk expansion of a Slave EDR-equipped Profile system and connection to a Profile Library System (PLS200).
  • Page 61 Connecting SCSI Devices SCSI SCSI Profile Note: Video J11J10 Disk recorder board locations File may be different than shown. Server See rear panel labels for actual locations. Additional PRS250 PRS250 PLS200 SCSI Cable Terminator SCSI Jumper 9676-41 Figure 2-25. Example 5: Profile Video File Server to Multiple RAIDs and PLS 200 Connections Example 5 (Figure 2-25) shows connection of the Profile Video File Server to two RAID Storage chassis (PRS250) and to a Profile Library System (PLS 200).
  • Page 62: Connecting Rs-422 Devices

    Chapter 2 Mechanical Installation Connecting RS-422 Devices The Profile Video File Server provides eight RS-422 interface ports through a single connector on the RS-422 Interface board. Attaching the RS-422 Connector Panel to the RS-422 interface board provides eight standard DB9 RS-422 connectors as shown in Figure 2-26.
  • Page 63: Connecting Network Devices

    Connecting Network Devices Connecting Network Devices The Profile Video File Server supports connection to Ethernet and Fibre Channel networks. Connecting Fibre Channel If the Fibre Channel board is installed, there are a number of ways it may be connected for networking. Profile Video Networking requires both a Fibre Channel network and an Ethernet network.
  • Page 64: Making Power Connections

    Chapter 2 Mechanical Installation Making Power Connections Power Source The Profile Video File Server and PAC 208/216 operate from a single-phase power source having one of its current-carrying conductors at or near earth ground (the neutral conductor). Only the line conductor is fused for over-current protection. Grass Valley Group does not recommend connection to systems that have both current carrying conductors live with respect to ground as power sources, such as phase-to-phase in multi-phase systems.
  • Page 65: Power Cord Connector

    Making Power Connections Table 2-3. Power Cords for the Profile Video File Server and PAC 208 Power Plug Description Standard 120 V, 3-prong power plug on a 2.5 meter long power cord. For use with common ground systems in North America. Universal European 230V/10A power plug on a 2.5 meter long power cord.
  • Page 66 Chapter 2 Mechanical Installation 2-36 Profile Video File Server Installation...
  • Page 67: Chapter 3 Starting Your Profile System

    Chapter Starting Your Profile System This chapter contains information to get you up and running with your Profile Video File Server. The tasks you will perform are: • Turning Profile system and peripheral equipment On. • Logging On • Configuring your Profile system. •...
  • Page 68: Logon As Administrator

    Chapter 3 Starting Your Profile System Logon as Administrator When the Profile system is powered On, you may interrupt automatic logon and logon as Administrator. It is not necessary to logon as administrator to configure Profile System software. However, you must logon as Administrator for Windows NT administration and to: - Configure Ethernet network settings (see Chapter 4, “Networking Your Profile System”).
  • Page 69: Rear Panel Main Power Switch

    Turning Power On 5. Wait approximately 1 to 2 minutes. 6. On the rear panel of the Profile Video File Server (see Figure 3-1), turn the main power switch to (On). 7. On the front panel of the Profile Video File Server (see Figure 3-2), turn the power switch to On.
  • Page 70: Turning Power Off

    Chapter 3 Starting Your Profile System Turning Power Off To turn your Profile system Off without loss of data, you must: 1. Quit all Profile System Software by selecting Quit Exit from the File menu. 2. Exit or Quit any other processes which may be running in the same way. 3.
  • Page 71: System Set-Up

    System Set-up System Set-up If you have not interrupted the automatic logon sequence (see “Logging On” on page 3-1), your Profile system will go through its normal self-check and initialization sequence. When completed, the VdrPanel, shown in Figure 3-3, appears on the monitor.
  • Page 72: Configuring Your Profile System

    Chapter 3 Starting Your Profile System Configuring Your Profile System Before you can use your Profile system to record and playback clips, you must perform the tasks listed below. • If your system includes one or more disk based external storage devices, you must use the Profile Disk Utility to make a file system.
  • Page 73: Installation Verification

    Steps 1 and 2 above. • For other errors, see “Initial Power On Checks”. • If errors persist, check the Profile Error Log and contact your Grass Valley Group representative. (See the Profile Family User Manual, “Using Profile Utilities” to access the Profile Error Log.)
  • Page 74: Rear Panel Board Indicators

    Red LED should be off. (On at power up and then off after a few minutes.) Analog Video If all LEDs are as indicated in Table 3-1, run the diagnostics below. If board LEDs are not as indicated, contact your Grass Valley Group representative. Profile Video File Server Installation...
  • Page 75: System Board Diagnostics

    System Board Diagnostics System Board Diagnostics Run system board diagnostics if you have a problem and the rear panel LEDs are not as indicated in Table 3-1. To run system board diagnostics: 1. Quit all Profile System Software by selecting from the File menu.
  • Page 76 Main Diagnostics window. If you have any board failures or any other unresolved installation problems, contact your Grass Valley Group representative. See “Grass Valley Group Product Support” at the front of this manual. 12.Once you have checked all the boards, shutdown and restart Windows NT and then perform “Installation Verification”...
  • Page 77: Chapter 4 Networking Your Profile System

    Building a network of more than two Profile systems requires an Ethernet hub (or connections to an existing Ethernet network) and a Fibre Channel hub. In this network configuration, Grass Valley Group recommends that you begin by configuring and testing the network with only two Profile Systems connected to the Ethernet and Fibre Channel hubs.
  • Page 78: Networking Several Profile Systems

    Chapter 4 Networking Your Profile System Networking Several Profile Systems If you want to connect more than two Profile systems together for video networking, you will need to connect each system to an Ethernet hub or an existing Ethernet network and a Fibre Channel hub.
  • Page 79: Point To Point Network Connection

    Point to Point Network Connection Profile1 Ethernet Hub 1 Fibre Channel Hub 1 Profile2 Profile3 Profile4 Ethernet Hub 2 Fibre Channel Hub 2 Profile5 Profile6 0033-10 Figure 4-2. Cascading Several Hubs Point to Point Network Connection The simplest network connection is the point-to-point connection shown in Figure 4-3. This method allows you to connect two Profile systems together.
  • Page 80: Connecting Ethernet

    Network Speed drop-down list box. NOTE: The speed setting may not work correctly with some Ethernet hubs and Auto switches. Grass Valley Group does not recommend the use of the setting. Auto 6. Click to close all of the open dialog boxes, and reboot your system.
  • Page 81: Configuring Ethernet For Tcp/Ip

    Configuring Ethernet for TCP/IP Configuring Ethernet for TCP/IP NOTE: If you are connecting to an existing TCP/IP network, you must contact your network administrator before proceeding with TCP/IP configuration. Please review this procedure with your network administrator before performing it. The following steps assume that you are not connecting to an existing TCP/IP network.
  • Page 82: Connecting Fibre Channel

    Chapter 4 Networking Your Profile System Connecting Fibre Channel Figure 4-5 shows the connection of several Profile systems to a Fibre Channel Hub using fibre channel cables. See Appendix B for fibre channel board connector pin-out information. Recommended Maximum Fibre Channel cable lengths are: •...
  • Page 83: Fibre Channel Board And Hub Connection

    Connecting Fibre Channel J16 J15 J14 J12 J11 J4 J3 J2 9676-53 Fibre Channel board Fibre Channel Hub Figure 4-6. Fibre Channel Board and Hub Connection 3. Turn Profile system power On. 4. You must now configure the Fibre Channel board for use in your video network environment.
  • Page 84 Chapter 4 Networking Your Profile System Profile Video File Server Installation...
  • Page 85: Appendix A Specifications

    These are not considered to be statements of guaranteed performance and are not ordinarily supported by a performance check procedure. Test Equipment Grass Valley Group uses the following test equipment to verify the performance requirements listed in this chapter. • VM700A •...
  • Page 86: Electrical Specifications

    Appendix A Electrical Specifications The Performance Requirements listed in the Electrical Specifications apply over an ambient temperature range of +20.5 C to +30.5 C. The Performance Requirement tolerances listed in the Electrical Specification are doubled over the temperature range of 0 to +40.5 C, unless there is a specific exception. Table A-1.
  • Page 87 Electrical Specifications Table A-2. Analog Composite Video Output Characteristics Description 1 ±1% Program Gain Requirement: 500 kHz to 5.8 MHz ±2% Frequency Response Requirement: Supplemental Data:-3 dB Nominally 6.25 MHz Signal-to-Noise Ratio Requirement: > 50 dB ≤10 ns NTSC Chrominance-to-Luminance Delay Requirement: ≤15 ns PAL Error...
  • Page 88 Appendix A Table A-3. Analog Composite Video I/O Characteristics Description Inputs (without TBC) ≥40 dB to 5MHz Return Loss Genlock Locks to (and remain locked) to incoming Black Burst -3 dB to +6 dB from nominal. PAL nominal - Sync @ 300mV; Burst @ 300mV NTSC nominal - Sync @ 40 IRE;...
  • Page 89 Electrical Specifications Table A-4. Component Analog Video Input Characteristic Specification Input connectors: BNCx (3) terminating Impedance: 75 ohms ≤ -40dB to 5.0MHz Return loss: Input formats Betacam supported (525/60): Betacam without setup Betacam (non-EBU) MII without setup (SMPTE/EBU-N10) GBR (700mv no setup) Input formats SMPTE/EBU-N 10 supported (625/50):...
  • Page 90 Appendix A Table A-6. Format Voltage Level Definitions for CAVmtrxN Colorbar Matrix Test Clip Format White Yellow Cyan Green Magenta Blue Black SMPTE/EBU-N10 (MII w/o setup) 465.2 308.2 216.8 157.0 59.9 -262.5 88.6 -173.9 173.9 -88.6 262.5 42.7 -262.5 -219.8 219.8 262.5 -42.7...
  • Page 91 Electrical Specifications Table A-7. Format Voltage Level Definitions for CAVmtrxP Colorbar Matrix Test Clip Format White Yellow Cyan Green Magenta Blue Black SMPTE/EBU-N10 (MII w/o setup) 465.2 308.2 216.8 157.0 59.9 -262.5 88.6 -173.9 173.9 -88.6 262.5 42.7 -262.5 -219.8 219.8 262.5 -42.7...
  • Page 92: Program Input Genlock

    Appendix A Table A-8. Program Input Genlock Characteristics Description ±50 Hz at subcarrier Burst Frequency Lock Range Requirement: Supplemental Data:Remains locked or initial lock Signal Amplitude Lock Requirement: Stays locked to +6 dB and -3 dB Range ≤1° Phase Jitter (Analog Input and Requirement: Analog Output) ≤0.5°...
  • Page 93: Profile Video File Server Power Source

    Electrical Specifications Table A-11. Analog Audio Characteristics Description 1 ±1 dB Through Gain Requirement: Supplemental Data:Non-mix mode each of four channels Frequency Response Requirement: 20 Hz to 20 kHz, with between +0.5 dB, -2 dB maximum deviation from flatness at 48 kHz sample rate Supplemental Data:600 Ω...
  • Page 94: Environmental Criteria

    Appendix A Table A-14. Profile Video File Server Power Supply Specifications (from Manufacturer) Characteristics Description Output voltages Supplemental Data:+5Vdc @ 70 A max. -5Vdc @ 5 A max. +12Vdc @ 10 A max. +12Vdc @ 6 A max. -12Vdc @ 6A max. Total wattage Supplemental Data:1000 W maximum Supplemental Data:200 mV p-p on + 5V supply...
  • Page 95: Mechanical Specifications

    Mechanical Specifications Mechanical Specifications Table A-16 lists the dimensions for the Profile Video File Server chassis, the PAC 208/216 chassis, the XLR panels, and the BNC panel. Table A-16. Profile Video File Server Mechanical Specifications Item Dimensions PDR200/PDR300 Height: 8.720 inches (22.149 centimeters) Width: 19.000 inches (48.260 centimeters) Depth: 24.150 inches (61.341 centimeters) PAC208/216...
  • Page 96 Appendix A A-12 Profile Video File Server Installation...
  • Page 97: S-Vga Connector

    Appendix Connector Pin-outs This appendix contains the pin-outs for the connectors at the rear panel of the Profile Video File Server. S-VGA Connector The S-VGA monitor connector on the System CPU board in slot J1 is a high density 15-pin female connector. Figure B-1 shows the S-VGA Monitor connector and Table B-1 lists the pin-outs.
  • Page 98: Ethernet Connector

    Appendix B Ethernet Connector The Ethernet connector located on the System CPU board in slot J1 is an 8-pin RJ-45 snap-in telephone-type connector which supports Category 5 unshielded twisted pair cable. Figure B-2 shows the RJ-45 connector and Table B-2 lists the pin-outs. Pin 8 9676-18 Pin 1...
  • Page 99: Parallel Port Connector

    Parallel Port Connector Parallel Port Connector Figure B-3. shows the parallel port connector in slot J2 and Table B-3 lists the pin-outs. 9676-61 Figure B-3. Parallel Port Connector Table B-3. Parallel Port Connector Pin-outs Signal Signal STROBE/ AUTO FEED PD(0) ERROR PD(1) INIT...
  • Page 100: Rs-232 Connectors

    Appendix B RS-232 Connectors The Profile Video File Server has two RS-232 interface connectors on the rear panel. Figure B-4 shows a 9-pin RS-232 rear panel connector (both are male) and Table B-4 lists the pin-outs. Figure B-4. RS-232 Connector Pin-outs Table B-4.
  • Page 101: Scsi Connector

    SCSI Connector SCSI Connector The Profile Video File Server provides a number of 68-pin SCSI interface connectors at the rear panel, including the one on the SCSI board which is reserved for the PLS200 Library System. For a 2-channel Profile, SCSI interfaces are identified as: SCSI A - Master EDR board rear panel connector SCSI B - Rear Panel connector For a 4-channel Profile, SCSI interfaces are identified as:...
  • Page 102 Appendix B Table B-5. 68 pin SCSI Connector Pin-outs Pin # Mnemonic Signal Description Pin # Mnemonic Signal Description DB12 Data Bus bit 12 -DB12 Data Bus bit 12 DB13 Data Bus bit 13 -DB13 Data Bus bit 13 DB14 Data Bus bit 14 -DB14 Data Bus bit 14...
  • Page 103: Fibre Channel Connector

    Fibre Channel Connector Fibre Channel Connector The Fibre Channel board uses a 9-pin subminiature D-type connector. Figure B-6 shows the connector and Table B-6 lists the pin-outs. Figure B-6. Fibre Channel Connector Table B-6. Fibre Channel Connector Pin-outs Pin # Mnemonic Description Differential Transmit Data IN...
  • Page 104: Reference Genlock D-Connector

    Appendix B Reference Genlock D-Connector The 25-pin male D connector on the Reference Genlock board provides eight Longitudinal Time Code (LTC) interfaces (four input channels and four output channels). The LTC Breakout cable with a DB25 connector on one end and eight XLR connectors on the other can then be connected to the Reference Genlock 25-pin D connector at the rear panel of the Profile.
  • Page 105: Audio Signal Processing Board Connector

    Audio Signal Processing Board Connector Audio Signal Processing Board Connector The Audio digital Signal Processor board (ASPB) accepts 16 channels of digital audio input and provides 16 channels of digital audio output via a 80-pin connector on the rear panel. The cable to this connector is from the Profile Audio Chassis or from the XLR/BNC 216 Digital Breakout Box.
  • Page 106 Appendix B Table B-8. ASPB Connector Pin-outs Signal Description Signal Description Signal Description Ch 1-2 AES Out (P) Ch 15-16 AES Out (P) Ch 1-2 AES Out (N) Ch 13-14 AES In (P) Ch 15-16 AES Out (N) Chassis Ground Ch 13-14 AES In(N) Ch 1-4 ADC Clock Out (P) Chassis Ground...
  • Page 107 Index Index Configuring Your Profile 3-6 Connecting AES/EBU Digital Audio 2-16, 2-18 Connecting Analog Composite Monitor 2-12 Connecting Analog Composite Video I/O 2-11 Accessories 1-6 Connecting Analog Composite Video Out Optional 1-7 2-13 Standard 1-6 Connecting Audio AES/EBU Audio Breakout Panel 2-15 16 Channel Analog and/or Digital 2-22 Analog Audio 16 Channels AES/EBU Digital Only 2-16...
  • Page 108 Index General Safety Summary ix Data Rates 1-15 Diagnostics 3-9 house reference signal, connecting 2-9 Digital Audio, connecting 2-16, 2-18, 2-20, 2-22, 2-24 DVCPRO 1-3, 1-8, 1-13, 1-16 Indicators, Front Panel 1-5 DVCPRO Restrictions Initial Power On Checks 3-7 system timing 1-17 Injury Precautions ix when used with JPEG 1-17 Installation Verification 3-7...
  • Page 109 Serial Digital Video I/O PAC208 Profile Audio Chassis 2-15 Connecting 2-10 PAC216 Profile Audio Chassis 2-15, 2-24 Specifications A-2 PDR 200, Description 1-3 Slave Enhanced Disk Recorder Board 2-26 PDR 300, Description 1-3 Slave Enhanced Disk Recorder Connection PDR 400, Description 1-3...
  • Page 110 Index Starting Your Profile See also Automatic Logon 3-1 Storage Capacity 1-16 S-VGA Connector B-1 System Bandwidth 1-16 System Board Diagnostics 3-9 System Set-up 3-5 Test Equipment A-1 Testing Your Ethernet Connection 4-5 Time Code Specification A-8 Turning Power Off 3-4 Turning Power On 3-2 Updating an Emergency Repair Disk 3-6 video clock reference 2-9...

This manual is also suitable for:

Pdr 300Pdr 400

Table of Contents
