Citizen 0S60 Instruction Manual

Citizen 0S60 Instruction Manual

13-1/2 linge, 3 eyes chronograph analogue quartz, 0 jewel
Hide thumbs Also See for 0S60:
1
2
3
4
5

Advertisement

Quick Links

Download this manual See also: Instruction Manual
1. BASIC SPECIFICATIONS
(1) Cal. No.
(2) Time standard
Type of quartz : Tuning fork type quartz crystal
Frequency
: 32,768Hz
Accuracy
: +/-20 s/month worn under normal circumstances
(3) Balanceable weight of hand
Minute hand Max. 0.4 μN.m
Center Chrono Second hand Max. 0.11 μN.m
Other small hands Max. 0.02 μN.m
(4) Function
Chronograph 1/20 sec. basis
(Up to 11 hour 59 min. 59 sec.)
Powercell Saving Reset Mechanism(PSRM)
Over-loading Compensation Device(OLCD)
Digital Frequency Control(DFC) for time adjustment
Chronograph
minute hand
Hour hand
Chronograph
hour hand
13-1/2 LINGE, 3 EYES CHRONOGRAPH
ANALOGUE QUARTZ, 0 JEWEL
BY CITIZEN WATCH CO., LTD. JAPAN
CALIBRE
Ligne
Size*mm
Date
Total height
Battery life
Battery
SILVER OXIDE SR927W or equivalent
(* 60 minutes chronograph operation per day)
Second hand
or 1/20 sec
chronograph hand
MOVEMENT SPECIFICATIONS
CAL.0S60
MANUFACTURED IN JAPAN
*TO CONFIRM WITH MOV'T DRAWING ATTACHED
0S60
13-1/2
Φ30.80mm
O
4.13MM
Approx. 2 years*
Chronograph
second hand
Button A
Button B
Minute hand
Normal crown
position
Calendar

Advertisement

loading

Related Manuals for Citizen 0S60

Summary of Contents for Citizen 0S60

  • Page 1 MOVEMENT SPECIFICATIONS CAL.0S60 13-1/2 LINGE, 3 EYES CHRONOGRAPH ANALOGUE QUARTZ, 0 JEWEL BY CITIZEN WATCH CO., LTD. JAPAN MANUFACTURED IN JAPAN 1. BASIC SPECIFICATIONS (1) Cal. No. *TO CONFIRM WITH MOV'T DRAWING ATTACHED 0S60 CALIBRE 13-1/2 Ligne Size*mm Φ30.80mm Date Total height 4.13MM...
  • Page 2 The unit(gate) time of measurement must be set at "10 sec." or integer fold value of 10 sec. owing to the DFC system, and the measurement must be performed in the form of complete watch. * Marking on movement JAPAN MIYOTA CO. (CAL. NO.) NO JEWELS * Typical clearance Mov't - Caseback...

  • Page 3: Setting The Time

    4. INSTRUCTION MANUAL A) DISPLAYS AND BUTTONS Chronograph Chronograph minute hand second hand Button A Hour hand Minute hand Chronograph hour hand Normal crown position Calendar Button B Second hand or 1/20 sec chronograph hand B) SETTING THE TIME 1. Pull the crown out to the 2nd position so that the second hand stops at (0) position. 2.

  • Page 4: Time Measurement

    Chronograph Chronograph minute hand second hand Button A Hour hand Minute hand Chronograph hour hand Normal crown position Calendar Button B Second hand or 1/20 sec chronograph hand "A" RESET "A" TIME MEASUREMENT STOP "B" "A" "B" E) CHRONOGRAPH RESET (INCL. AFTER REPLACING BATTERY) This procedure should be performed when the chronograph second hand and chronograph 1/20 second hand do not return to the 0 second position after the chronograph has been reset, and including after the battery has been replaced.
  • Page 5 F) FITTING METHOD OF HANDS Place the module on case back shown in the figure and position the reference hand, then fit the hands according to the following procedure. Chronograph Chronograph minute hand second hand Button A Hour hand Minute hand Chronograph hour hand Normal crown...
