UNIVERSAL MASTERPIECE BORN IN JAPAN
INSTRUCTION MANUAL FOR MIYOTA WATCH MOVEMENT
CALIBER NO. 0S60
CHRONOGRAPH FUNCTION: CENTER SECOND HAND CHRONOGRAPH 1/20 sec. Timing
up to 11 hours 59 minutes 59 seconds 95
BATTERY: SR927W
A) DISPLAYS AND BUTTONS
B) SETTING THE TIME
C) SETTING THE DATE
D) USING THE CHRONOGRAPH
E) CHRONOGRAPH RESET (INCL. AFTER REPLACING BATTERY)
Chronograph
minute hand
Hour hand
Chronograph
hour hand
B) SETTING THE TIME
1. Pull the crown out to the 2nd position.
2. Turn the crown to set hour and minute hands.
3. When the crown is pushed back to the normal position, small second hand begins to run.
C) SETTING THE DATE
1. Pull the crown out to the 1st position.
2. Turn the crown counter-clockwise to set the date.
*If the date is set between the hours of around 9:00 PM and 1:00 AM, the date may not change on the
following day.
3. After the date has been set, push the crown back to the normal position.
D) USING THE CHRONOGRAPH
This chronograph is able to measure and display time in 1/20 second timing up to maxinum of 11 hours 59
minutes 59 seconds 95.
Measuring time with the chronograph
1. Press button "B" to change the watch to the chroonograph mode.
The second hand stops at zero position, and changes to the chronograph 1/20 second hand.
2. The chronograph can be started and stopped each time button "A" is pressed.
The chronograph 1/20 second hand stops at zero position 30 seconds after starting.
When button "A" is pressed to stop the chronograph, the chronograph 1/20 second hand advances
rapidly to display the measured time.
3. Pressing button "B" resets the chronograph and all chronograph hands return to zero position.
RESET
E) CHRONOGRAPH RESET (INCL. AFTER REPLACING BATTERY)
This procedure shoud be performed when the chronograph second hand and the chronograph 1/20
second hand do not return to zero position after the chronograph has been reset, and including after the
battery has been replaced.
1. Pull the crown out to the 2nd position.
2. Press button "A" to set the chronograph second hand to zero position.
3. Press button "B" to set the chronograph 1/20 second hand to zero position.
The chronograph hand can be advanced rapidly by continuously pressing button "A" or "B".
4. Once the hand have been zeroed, return the crown to the normal position.
5. Press button "B" to check that the chronograph hands are reset to zero position.
* Do not push the crown to the normal position while the chronograph second hand and the chronograph
1/20 second hand return to zero postion. Each hands stop on the way when crown are returned to normal
position and these positions are recognized as zero position.
MIYOTA
MADE IN JAPAN
METAL MOVEMENT
Chronograph
second hand
Button A
Button B
Small Second hand or Chronograph 1/20 second hand
" A "
TIME MEASUREMENT
Minute hand
1st position
2nd position
Normal crown position
Calendar
" A "
STOP
" A "
" B"
" B "
