- Page 1 2.4GHz IEEE 802.11g 54/108Mbps Wireless LAN Access Point GW-AP54SGX Planex Communications Inc.
-
Page 2: Table Of Contents
CONTENTS Chapter 1 Introduction....................3 Features..................... 3 Package Contents..................3 Chapter 2 Product Overview ..................4 Front View ....................4 Rear View ....................4 System Requirements ................5 Chapter 3 Hardware Installation................5 Chapter 4 System Configuration ................6 Browser Configuration ................6 4.1.1 Disable Proxy Connection .............. -
Page 3: Chapter 1 Introduction
Chapter 1 Introduction The 2.4 GHz IEEE 802.11g 54Mbps Wireless LAN Access Point (GW-AP54SGX) offers fast, reliable wireless connectivity with considerable cost savings over wired LANs (eliminates long-term maintenance overhead for cabling). Just install enough wireless access points to cover your network area, plug wireless cards into your notebooks or install wireless adapters into your desktops, and start networking. -
Page 4: Chapter 2 Product Overview
IEEE 802.11b standard. 2.1 Front View Color Status Indicator Solid Flashing Power Green Turns solid green when The GW-AP54SGX is power is applied to this initializing or upgrading device. firmware. Green Valid Ethernet cable link. Receiving/Sending data WLAN Green Receiving/Sending data 2.2 Rear View... -
Page 5: System Requirements
Normally, the higher you place the antenna, the better performance. Position the antennas in the desired positions. The GW-AP54SGX can be wired to an Ethernet network through an Ethernet device such as a hub or a switch using category 3, 4, or 5 UTP Ethernet cable and an RJ-45 connector. -
Page 6: Chapter 4 System Configuration
Chapter 4 System Configuration The Access Point can be configured by any Java-supported browser, which is Internet Explorer 5.5 or above. Using the Web management interface, you can configure the Access Point and view statistics to monitor network activity. Before you attempt to log into the Access Point’s Web-based Administration, please verify the following. -
Page 7: Navigating The Web Browser Interface
4.2 Navigating the Web Browser Interface The Access Point’s management interface features a user-friendly setup interface. This configuration menu is divided into four categories: Status, Wireless, TCP/IP and Other. Note: To ensure proper screen refresh after a command entry, ensure that Internet Explorer 5.5 is configured as follows: Under the menu Tools Internet Options General... -
Page 8: Current Status
4.2.1 Current Status The Access Point Current Status page shows the current status and some basic settings of the device. 4.2.2 Setup Wizard (1) Setup Wireless Networks Use the Setup Wizard to quickly configure settings for wireless environments. Click Next to begin setup. - Page 9 (3) WEP Encryption for 802.11g If you wish to use encryption, enable it here and enter the encryption Key values. Click Next to continue. (4) Wireless Setup Complete The Setup Wizard has completed. Click Back to modify previous settings. Click Reboot to save the current settings and reboot the Wireless AP.
-
Page 10: Advanced Setup
4.2.3 Advanced Setup 4.2.3.1 Configuration (1) IP address Configuration Device IP Address The default settings of the GW-AP54SGX are displayed in the example below. The default IP address is 192.168.1.100 MAC Address (Media Access Control Address) - Page 11 (This is not advisable since it will be difficult to determine the dynamic IP address assigned to the GW-AP54SGX). Using DHCP automatically configures all IP settings upon restart, therefore the IP Address, Subnet Mask and Default Gateway will be read-only displays when the device is configured as a DHCP client.
- Page 12 (3) AP Mode Settings This device can work not only as an Access Point but also as a Point-to-Point Bridge (PtP Bridge), a Point-to- Multipoint Bridge (PtMP Bridge) or AP Repeater. Simply input the Root AP MAC Address of the other remote Conception 108Mbps Access point(s). Bridge Wireless Bridge can connect another Wireless Bridge and also connect wireless clients at the same time.
- Page 13 (4) WLAN Parameter Management In the WLAN Parameter Management screen, you can change the SSID and Channel for the IEEE wireless environment you are configuring. SSID (Service Set Identifier) default is the default setting. The SSID is a unique name that identifies a network.
- Page 14 Select the transmission rate for the network. Beacon Interval (20 – 1000) Beacons are packets sent by an Access Point to synchronize a wireless network. Specify a Beacon interval value. Default (100) is recommended. DTIM (1 - 255) Enter a value between 1 and 255 for the Delivery Traffic Indication Message (DTIM.) DTIM is a countdown informing clients of the next window for listening to broadcast and multicast messages.
- Page 15 Wireless devices can still send data to the Ethernet. (6) Access Control Settings MAC Address Control List Use MAC Filters to allow or deny wireless connection to the GW-AP54SGX. WLAN Partition is used to set up barriers between wireless devices or between wired and wireless interfaces.
- Page 16 MAC Address Filtering or Access Control is disabled by default. When this feature is enabled, you can select wireless devices that are allowed access or specify wireless devices that are denied access to the wireless interface through the Access Point. To turn MAC address filtering off, select Disabled for the Access Control drop-down menu.
- Page 17 Using an open system with WEP enabled means the access point and wireless stations encrypt only the data in each packet. WEP is not used for the purpose of authentication, that is, encryption does not prevent any station from associating with the access point. ‧...
-
Page 18: Management
4.2.3.2 Management (1) Administration Administration Management Change your password in this window. It can be up to 12 characters in length. Please keep a copy of your password in a safe place. This is the same password used for access by the Multiple AP Manager. -
Page 19: Maintenance
IMPORTANT! The Access Point must be manually reset after every firmware upgrade. After the GW-AP54SGX has been upgraded and reboots, hold down the reset button on the rear panel for a few seconds. The device will reset and reboot. Upon rebooting after this manual reset, the Access Point is ready to use. -
Page 20: Statistics
Click Restore from Restore to Factory Default Settings to return to factory default settings or click Restart from Apply Settings and Restart to apply new settings and restart your system (GW-AP54SGX). 4.2.4 Statistics Network traffic statistics for both received and transmitted communications through the Ethernet port and wireless connections associated with the Access Point are displayed here. - Page 21 (2) Transmitted Transmitted Frames Count Click Reload, shows the current status information. (3) Received Received Frame Count Click Reload, shows the current status information. (4) WEP Frame Error Wep Frame Error Count Click Reload, shows the current status information.
-
Page 23: Chapter 5 Specifications
Chapter 5 Specifications IEEE 802.11b Wireless LAN IEEE 802.11g Wireless LAN Standards IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Fast Ethernet Ports One 10/100Mbps Ethernet LAN ports 802.11b: 11, 5.5, 2, and 1Mbps Data Rates 802.11g: 108, 54, 48, 36, 24, 18, 12, 9 and 6Mbp 64/ 128/152 bit WEP encryption Security Encryption Media Access Control... -
Page 24: Chapter 6 Safety Statement
Chapter 6 Safety Statement CE Statements This device has bee tested and found to comply with the requirements set up in the council directive on the approximation of the law of member states relating to EMC Directive 89/336/EEC, Low Voltage Directive 73/23/EEC and R&TTE Directive 99/5/EC. - Page 25 Use only with supplied antenna. Unauthorized antenna, modification, or attachments could damage the transmitter and may violate FCC regulations. "PLANEX CMMUNICATIONS INC. declare that GW-US54MINI (54Mbps Wireless USB LAN Adapter) is limited in CH1~CH11 by specified firmware controlled in USA."...
