Audio Pass-Through for Monitoring

If you connect speakers or headphones to the audio output on the back of the
TouchStream unit you will be able to monitor the audio input. The stereo pair that
you are monitoring will be the pair that is selected on the TouchStream screen
(selection indicated by a blue highlight at the bottom of the audio slider).

Info

When you press the Info button you will see information about the currently
loaded project on the left side and information about the hardware and status on
the right hand side.
There are also buttons for additional functions.
•
Email Config can be used to send information about your unit to Digital
Rapids Support should you need assistance.
•
Network Settings button can be used to select between automatic and
manual network configuration.
•
Broadcast Mgr Ctrl can be used to set up the TouchStream unit as a
resource that will be controlled by Digital Rapids Broadcast Manager.
•
Reset will reset all user settings for audio, video, trigger and output
settings to their default values. After pressing this button you can select
Cancel if you want to retain your current settings.
•
Security will give you options to Lock all controls on the TouchStream
interface. It also gives you access to the Restrictions options, which
allows you to hide only the functions you specify.
•
Device Settings can be used by newer TouchStream units to adjust the
brightness of the blue ring, the backlight and the DR logo on the front left
corner of the unit.
