Summary of Contents for digital rapids TouchStream

  • Page 2 The exclusion of implied warranties is not permitted by some jurisdictions. The above exclusion may not apply to you. In no event will Digital Rapids Corporation be liable to you for any consequential, incidental or indirect damages (including damages for loss of business profits,...

  • Page 3: Table Of Contents

    Connecting to the Network ................5 Connecting an External Hard Drive..............6 Connecting a Monitor, Keyboard, Mouse ............6 TouchStream Software Operation ................ 7 Overview ......................7 Getting Started – Using a previous configuration .......... 7 Getting Started – Setting up a new configuration .......... 8 Setup .......................
  • Page 4 DRC- 5650 .......................33 Regulatory Certifications and Compliance ............35 WARNING: English (USA) ................38 AVERTISSEMENT: Français ................40 Warranty ......................42 Limited Warranty for Digital Rapids TouchStream ........42 Extent of Limited Warranty ................42 Warranty Limitations and Exclusions ............43 Limitations of Liability ...................43 Contact Information .....................44...

  • Page 5: Safety Instructions

    Digital Rapids TouchStream Safety Instructions Before you operate this product you will need to make sure you follow certain basic safety precautions. CAUTION Servicing of a chassis sub-assembly shall be performed only by technically qualified persons. Follow these guidelines to meet and maintain safety and product regulatory requirements.

  • Page 6: Checking The Power Cord

    Digital Rapids TouchStream Checking the Power Cord WARNING Do not attempt to modify or use the supplied AC power cord if it is not the exact type required. The power supply cord is the main disconnect to AC power. The socket outlet must be installed near the equipment and be readily accessible.
  • Page 7 Digital Rapids TouchStream 4. Provide some electrostatic discharge (ESD) protection by wearing an antistatic wrist strap attached to building ground—any unpainted metal surface on a chassis that is still plugged in—when handling components. WARNING The power button on the front panel DOES NOT turn off the AC power.

  • Page 8: Touchstream Connections

    Digital Rapids TouchStream TouchStream Connections Connecting Video and Audio Inputs Your TouchStream unit will have one of three sets of connections available, depending on which model you purchased. Option 1: Analog only Video: One standard definition video channel selected from Composite (yellow) and S-video (black) inputs.

  • Page 9: Connecting To The Network

    The TouchStream unit includes a Gigabit Ethernet controller with a standard 8P8C (8 Position 8 Contact) connection, often referred to as an RJ45 connection. Once you have physically connected the TouchStream unit to the network with a cable, you may have to configure the network settings using the TouchStream software.

  • Page 10: Connecting An External Hard Drive

    Digital Rapids TouchStream Connecting an External Hard Drive If you plan to create archive files with your TouchStream unit you must have either purchased the internal storage option for your TouchStream unit or you must connect an external drive to your unit. You cannot write archive files to the internal “C”...

  • Page 11: Touchstream Software Operation

    If the TouchStream unit was shut down in an unarmed state, then simply press the Trigger button, choose your trigger type, press Arm, and you are ready to start streaming. If TouchStream was shut down in an “unarmed”...

  • Page 12: Getting Started - Setting Up A New Configuration

    In that case you will need to set up the unit. Getting Started – Setting up a new configuration If you are setting up the TouchStream software for the first time, or you want to set up a new configuration, there are a few basic steps.
  • Page 13 10. The Info button on the main screen provides you with information about your unit. If you are having an issue with your unit and you contact Digital Rapids Support for assistance they may direct you to use the Email option on this Info screen.

  • Page 14: Setup

    GPI Trigger TouchStream can monitor the serial communication port on the back of the unit for a GPI signal, and it can use that signal to start the encoding. For more information about making GPI cables please see...

  • Page 15: Pause/Resume

    If you want to exit the trigger screen without changing any settings, press the Cancel button. Pause/Resume While the TouchStream unit is encoding the Pause button will be available. If you press the Pause button it will change to a Resume button. Page 11...

  • Page 16: Project

    For some codecs transport stream muxer settings will be included in the project; these project names start with “TS_” Installed TouchStream Projects TouchStream has 4 basic models, with 3 input options. The projects that are available are the ones that can be used by your model and input option. •...

  • Page 17: Input

    TouchStream unit then please contact Digital Rapids support for an updated key. Use a firewire cable to connect the DV camera to TouchStream and turn on the DV camera. Go to the Input screen (or if you are currently on the Input screen, go to any other screen then go back to the Input screen to refresh the screen.) Your...
  • Page 18 Archive File Output You can use your TouchStream unit to create an archive file. If you plan to create archive files you must have purchased the internal storage option for your TouchStream unit or you must connect an external drive to your unit. You cannot write archive files to the internal “C”...
  • Page 19 These %text% strings are “system tags” or wildcard values that are understood by the TouchStream software. There are many additional system tags that you may find useful (e.g. %R% is output resolution). You can modify the file name by pressing in the name field to open a keyboard panel.
  • Page 20 Note that the Dicas projects that have been installed on your TouchStream unit include 3 output streams in each project. Be sure to configure the output for all 3 output streams. •...

  • Page 21: Video Settings And Audio Settings

    The Pull projects make the stream available over the specified port. The RTP projects installed with your TouchStream unit have not been set up to create an archive file while broadcasting. If you require this option you will have to create new projects specifically for that purpose.

  • Page 22: Video Settings

    Done button and return to the main screen. That is, the settings are not saved with any individual project, they are saved and applied to all projects on the TouchStream unit and to all output streams in the loaded project (if your project includes more than one output stream).

  • Page 23: Picture Controls

    Removing noise from the video will improve the quality of the encoded video by allowing the codec to allocate bits to real picture data. There are two types of noise reduction that can be adjusted in the TouchStream interface. Page 19...
  • Page 24 (trails) artifact in the processed frame. TouchStream uses a very advanced form of temporal noise processing called motion adaptive 3D noise reduction. Motion adaptive 3D noise reduction...

  • Page 25: Cropping

    Done button and return to the main screen. That is, the settings are not saved with any individual project, they are saved and applied to all projects on the TouchStream unit and to all output streams in the loaded project (if your project includes more than one output stream).

  • Page 26: Audio Pass-Through For Monitoring

    If you connect speakers or headphones to the audio output on the back of the TouchStream unit you will be able to monitor the audio input. The stereo pair that you are monitoring will be the pair that is selected on the TouchStream screen (selection indicated by a blue highlight at the bottom of the audio slider).

  • Page 27: Email Config

    Digital Rapids Support for assistance they may direct you to use the Email option on this Info screen. This will email the unit’s information, along with the project and input settings in use at the time, directly to Digital Rapids Support. Network Settings...

  • Page 28: Reset

    From the main Security screen you must enter the Lock Settings password to enable the Lock button. By default the password is touchstream. If you want to change this password touch the Change Password button, enter the current password, enter a new password and touch Set.
  • Page 29 Once this function is restricted the Trigger button will be shown on the main screen but hidden on the Setup screen. In addition, when the TouchStream unit is not currently encoding the Trigger button will always be armed. The trigger will be armed each time you power on the system as well.

  • Page 30: Broadcast Manager Control

    Restrictions interface. Broadcast Manager Control This function can be used if you own Digital Rapids Broadcast Manager, and you want your TouchStream unit to be controlled by Broadcast Manager. Press the Broadcast Mgr Ctrl button and enter your Media Manager Domain (the domain you set up for your Media Manager resources, not your Windows domain) and your Media Manager Server IP address or Host Name.

  • Page 31: Customizing Touchstream Projects

    Manager Console when you are setting up Broadcast Manager jobs. If a job is currently being run by Broadcast Manager the preview window on the TouchStream will show the active video and the VU meters will show the audio levels.
  • Page 32 (800x480), and once it has been changed it is not easy to reset the resolution. When using updated versions of the TouchStream OS you will not be able to change the screen resolution on the TouchStream unit.

  • Page 33: Gpi - General Purpose Interface

    Digital Rapids TouchStream GPI - General Purpose Interface GPI triggers are physical connections between two pieces of equipment. GPI triggers are typically based on a change of state on a monitored pin of the serial port. For instance you could create a GPI trigger which was operated by a toggle switch, by the alarm closure of an alarm system, or a port on a piece of broadcast equipment.

  • Page 34: Touchstream System Specifications

    Touch Screen panel on front of unit, resolution 800 x 480 On board graphics Window XP Embedded OS Ports on a TouchStream system: USB - 2 ports or 4 ports, depending on the motherboard Ethernet - 1 port (RJ-45) Fire Wire - 2 ports...

  • Page 35: Drc-Stream Pci Card Specifications

    Digital Rapids TouchStream DRC-Stream PCI Card Specifications DRC-500 Form Factor Half Length, Full Height PCI 64 bit /66Mhz (32bit /33Mhz compatible) Total power consumption: typical 6.25W; maximum 10W 3.3V 0.9A 0.6A 0.02A 0.25W Video and Audio Inputs Supports NTSC and PAL video standards...

  • Page 36: Drc-1600

    Digital Rapids TouchStream DRC-1600 Form Factor Full Length, Full Height PCI 64 bit /66Mhz (32bit /33Mhz compatible) Power Requirements ~ 25 Watts +3.3V - 3.5A +5V - 1.5A -5V - 0A +12V - 0.5A -12V - 0.1A General NTSC or PAL inputs (user-selectable) One video processing channel Up to 8 mono channels of audio processing.

  • Page 37: Drc- 5650

    Digital Rapids TouchStream Optional Analog Video inputs (requires breakout cable or breakout box): Composite (BNC) 1V p-p, 75 Ohm S-Video: (4-Pin Mini-DIN) Y Signal 1V p-p, 75 Ohm C Signal 286mV p-p (NTSC) 300mv p-p (PAL) Component Betacam (BNC's): Y Signal...
  • Page 38 Digital Rapids TouchStream Proc Amp controls Gamma correction Filtering and noise reduction Graphics Overlay High speed graphics buffer with alpha channel Overlay graphics during record or playback Video Input (on PCI board or Breakout Box) 1 x BNC multi-format HD-SDI and SD-SDI Audio Inputs (on PCI board or Breakout Box) Embedded SDI audio (16 channels, 24-bit, 32/44.1/48 kHz)

  • Page 39: Regulatory Certifications And Compliance

    Digital Rapids TouchStream Regulatory Certifications and Compliance The TouchStream chassis complies with the following safety regulations. Safety U.S., Canada UL60950-1– CSA C22.2 no. 60950-1-07 950 (UL and cUL) Europe, CE Mark IEC EN60950-1:2005 International IEC60950 (CB Report and Certificate) Electromagnetic Capability (EMC) U.S.
  • Page 40 Digital Rapids TouchStream FCC Rules This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 41 European Union Restriction on Hazardous Substances, or RoHS), California substance restriction requirements, and other international initiatives. Digital Rapids’ current family of hardware cards – including the DRC-500, DRC- 1000, DRC-1400, DRC-1600, DRC-2000, DRC-2400, DRC-2600 and DRC-5650 boards – are compliant with the RoHS initiative. Our compliant products bear our RoHS compliant symbol on our packaging.

  • Page 42: Warning: English (Usa)

    Digital Rapids TouchStream WARNING: English (USA) The power supply in this product contains no user-serviceable parts. Refer servicing only to qualified personnel. Do not attempt to modify or use the supplied AC power cord if it is not the exact type required.
  • Page 43 Digital Rapids TouchStream 3. Attach the cover to the chassis with the screws removed earlier, and tighten them firmly. 4. Connect all external cables and the AC power cord(s) to the system. A microprocessor and heat sink may be hot if the system has been running. Also, there may be sharp pins and edges on some board and chassis parts.

  • Page 44: Avertissement: Français

    Digital Rapids TouchStream AVERTISSEMENT: Français Le bloc d'alimentation de ce produit ne contient aucune pièce pouvant être réparée par l'utilisateur. Ce produit peut contenir plus d'un bloc d'alimentation. Veuillez contacter un technicien qualifié en cas de problème. Ne pas essayer d'utiliser ni modifier le câble d'alimentation CA fourni, s'il ne correspond pas exactement au type requis.
  • Page 45 Digital Rapids TouchStream fonctionnement du système en l’absence des panneaux risque d’endommager ses pièces. Pour installer les panneaux, procédez comme suit: 1. Assurez-vous de ne pas avoir oublié d’outils ou de pièces démontées dans le système. 2. Assurez-vous que les câbles, les cartes d’extension et les autres composants sont bien installés.

  • Page 46: Warranty

    If any Product furnished by Digital Rapids which is the subject of this Limited Warranty fails during the warranty period for reasons covered by this Limited Warranty, Digital Rapids, at its option, will: •...

  • Page 47: Warranty Limitations And Exclusions

    Digital Rapids responsibility under this, or any other warranty, implied or expressed, is limited to repair or replacement as set forth above. These remedies are the sole and exclusive remedies for any breach of warranty. Digital Rapids is not responsible for direct, special, incidental, or consequential damages resulting...

  • Page 48: Contact Information

    Digital Rapids TouchStream Contact Information North and South America Digital Rapids Corporation 90 Allstate Parkway, Suite 700 Markham, Ontario L3R 6H3 Canada 905-946-9666 voice 416-352-0716 fax Sales: sales.na@digital-rapids.com; 905-946-9666 x 212 (North America) sales.la@digital-rapids.com; +54-11-3221-4202 (Latin America) Technical Support: support.na@digital-rapids.com...
  • Page 49 1.1 to 1.2), not including new chargeable options. Standard Support is telephone and email support during regular business days from 10am to 6pm based on the time zone of the regional Digital Rapids Support Office. Maintenance and Standard Support must be renewed annually; please contact your Digital Rapids representative for pricing or more information.
