Video Settings And Audio Settings - digital rapids TouchStream User Manual

•
RTP Projects (included with the TS model): Each RTP project has both a
Push and a Pull version. (You cannot use RTP push and pull
simultaneously.) When you are selecting a project be sure to choose the
correct broadcast type, Push or Pull.
The push projects can multicast the stream or they can send the stream
to an external media server that can use an SDP file, such as a Darwin
Media Server.
The multicast option uses the IP address you provide and also creates
an SDP file at the default location (
Users\Documents\Digital Rapids\Stream\SDP)
The external option sends the stream to the server at the IP address and
port specified, and creates an SDP file on the media server. For media
servers that need authorization you can specify the username and
password.
The Pull projects make the stream available over the specified port.
The RTP projects installed with your TouchStream unit have not been set
up to create an archive file while broadcasting. If you require this option
you will have to create new projects specifically for that purpose.
•
TS Projects: These projects send the stream to the specified IP address
and port. They can use UDP or RTP with RTSP. As well, some of the
projects are preset to use the H264 video codec and AAC audio codec
and some have been preset to use the MPEG2 video codec and MPEG
audio. When you are selecting a project be sure to choose the correct
broadcast type, RTP/RTSP or UDP, and the correct codecs.

Video Settings and Audio Settings

The Video Settings and Audio Settings are available from both the Setup screen
and from the Main screen. Please see the following sections for detailed
information.
Digital Rapids TouchStream
C:\Documents and Settings\All
.
Page 17
