Thelin PARLOUR 3000 Installation And Operating Instrictions

Direct vent gas heater
Hide thumbs Also See for PARLOUR 3000:
Table of Contents

Advertisement

Quick Links

PARLOUR 3000
DIRECT VENT GAS HEATER
Installation and Operating Instructions
Made in the USA by:
PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION.
SAVE THESE INSTRUCTIONS.
INSTALLER: PLEASE LEAVE THIS MANUAL WITH THE CUSTOMER!
CUSTOMER: PLEASE KEEP INSTRUCTIONS FOR FUTURE REFERENCE
TH-REF-SLS-233 Rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PARLOUR 3000 and is the answer not in the manual?

Questions and answers

Related Manuals for Thelin PARLOUR 3000

Summary of Contents for Thelin PARLOUR 3000

  • Page 1 PARLOUR 3000 DIRECT VENT GAS HEATER Installation and Operating Instructions Made in the USA by: PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION. SAVE THESE INSTRUCTIONS. INSTALLER: PLEASE LEAVE THIS MANUAL WITH THE CUSTOMER! CUSTOMER: PLEASE KEEP INSTRUCTIONS FOR FUTURE REFERENCE...
  • Page 2 PARLOUR 3000 DIRECT VENT GAS HEATER SAFETY NOTICES For Your Safety Installation Do not store or use gasoline or any other flammable PLEASE READ INSTRUCTIONS vapors or liquids in the vicinity of this or any other CAREFULLY BEFORE INSTALLING AND...
  • Page 3 PARLOUR 3000 DIRECT VENT GAS HEATER SAFETY NOTICES IF THIS APPLIANCE IS NOT PROPERLY INSTALLED, A HOUSE FIRE, OR EXPLOSION MAY RESULT. FOR YOUR SAFETY, FOLLOW THE INSTALLATION DIRECTIONS. CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION REQUIREMENTS IN YOUR AREA.
  • Page 4 PARLOUR 3000 DIRECT VENT GAS HEATER INSTALLATION INSTALLATION CHECKLIST  Dealer  Installer  Phone  Installation Date  Serial Number This appliance is suitable for installation in a Listing and Codes bedroom or bed sitting room. The Parlour is listed and certified for installation in This appliance may be installed in an aftermarket the U.S.A.
  • Page 5 PARLOUR 3000 DIRECT VENT GAS HEATER INDEX OF CONTENTS Airflow, 9 Glass Replacement, 26 Alcove Installation, 17 Gold Appendix A, 34 polishing, 26 Appendix B, 35 Hi/Lo Flame Adjust, 21 Appendix C, 36 Horizontal Installation, 14 Bedroom Installation, 14 Horizontal Termination, 14...

  • Page 6: Table Of Contents

    PARLOUR 3000 DIRECT VENT GAS HEATER FIGURES Figure 1 – Diagram of Dimensions ........................10 Figure 2 – Clearance to Combustibles ........................11 Figure 3 – Bottom View Showing Air Shutter and Location for Pressure Gauge Insertion ........ 13 Figure 4 – Vent Termination Locations ........................ 15 Figure 5 –...
  • Page 7 PARLOUR 3000 DIRECT VENT GAS HEATER WARNING Failure to follow the information in this manual exactly could result in a fire, explosion resulting in property damage, personal injury, and loss of life. Do not store or use gasoline or other flammable liquids in the vicinity of this or any other appliance.

  • Page 8: Listing Label

    PARLOUR 3000 DIRECT VENT GAS HEATER LABORATORY LISTING LABEL...

  • Page 9: Airflow

    INTRODUCTION AND SAFETY line (see Figure 1). INFORMATION Permit Thelin Hearth Products. would like to thank you for choosing our Parlour 3000 Direct Vent Gas Contact your local building officials and obtain a appliance. Whether using natural gas or liquid permit before beginning installation.

  • Page 10: Figure 1 - Diagram Of Dimensions

    PARLOUR 3000 DIRECT VENT GAS HEATER FIGURE 1 – DIAGRAM OF DIMENSIONS...

  • Page 11: Figure 2 - Clearance To Combustibles

    PARLOUR 3000 DIRECT VENT GAS HEATER FIGURE 2 – CLEARANCE TO COMBUSTIBLES 10” 16” Unit to corner ............ 10” Center of pipe to corner ........16” Use these diagrams to locate stove in the room. Note “Cornerwall” means from the back of the stove to the corner.

  • Page 12: Electrical Grounding Instructions

    Model: (Check one) Parlour 3000 Direct Vent Natural Gas Parlour 3000 Direct Vent LP (Liquid Propane) Gas Mail in your warranty card and save your bill of sale. You will need to show this evidence of date of purchase to receive full warranty coverage.

  • Page 13: Figure 3 - Bottom View Showing Air Shutter And Location For Pressure Gauge Insertion

    #39 (up to 4,500’ elevation) Natural Gas #53 (up to 4,500’ elevation) LP Gas Recommendation: If installing at higher altitudes, Thelin recommends, at the discretion of the installer: #40 (5,000’ to 7,000’ elevation) Natural Gas #54 (5,000’ to 7,000’ elevation) LP Gas REMEMBER! The size of the orifice hole should be reduced the higher the elevation.

  • Page 14: Bedroom Installation

    PARLOUR 3000 DIRECT VENT GAS HEATER Orifice Size Clearance to Combustibles (See Figure 2) The orifices are factory installed for altitudes up to See Listing Label for clearance to combustibles. 4,500 feet. If installing in a higher altitude check the Due to high temperatures, the room heater should orifice information (see Figure 3).

  • Page 15: Figure 4 - Vent Termination Locations

    PARLOUR 3000 DIRECT VENT GAS HEATER FIGURE 4 – VENT TERMINATION LOCATIONS...
  • Page 16 PARLOUR 3000 DIRECT VENT GAS HEATER B. Clearance to window or door that may be I. Clearance to service regulator vent outlet: opened: Canadian Installation: 3’ (91 cm) Canadian Installation: 6” minimum (15 cm) for U.S. Installation: Clearance in accordance with 10,000 Btuh (3 kW);...

  • Page 17: Horizontal Termination

    PARLOUR 3000 DIRECT VENT GAS HEATER Mobile Home Installation PLANNING THE INSTALLATION Direct Vent appliances installed in Mobile Homes There are two basic types of Direct Vent must be secured to the floor in a minimum of two installations: locations. Drill holes through the two back legs and ...

  • Page 18: Figure 5 - Diagram Of Venting Requirements

    PARLOUR 3000 DIRECT VENT GAS HEATER FIGURE 5 – DIAGRAM OF VENTING REQUIREMENTS...
  • Page 19 PARLOUR 3000 DIRECT VENT GAS HEATER restriction disks. (See Appendix A). Two 45- 3. Check for evidence of excessive condensation degree elbows to offset the vertical rise are such as water droplets forming on the inner liner permitted. Clearances to combustibles when passing or dripping from the pipe vent joints.

  • Page 20: Figure 6 - Vent Termination

    PARLOUR 3000 DIRECT VENT GAS HEATER FIGURE 6 – VENT TERMINATION Wind flow over roof structures can often cause localized pressure disturbances. Vent termination must take into account these disturbances and minimize them by using the following table to maintain the correct legal height of the vent.

  • Page 21: Burner On/Off Switch

    PARLOUR 3000 DIRECT VENT GAS HEATER Gas Line Installation Burner On/Off Switch The gas line must be installed in accordance with all This switch turns the burner on after the pilot is lit. local codes. See Figure 8 for location of gas hook- When the wall thermostat is hooked up, this switch will remain in the “On”...

  • Page 22: Figure 7 - Location Of Pilot, Burners, And Logs

    PARLOUR 3000 DIRECT VENT GAS HEATER FIGURE 7 – LOCATION OF PILOT, BURNERS, AND LOGS Note: Burner must be removed to access air shutter (See Appendix B) Burner and Pilot Checks A periodic check of the pilot and burner flames should be made. Check after the fire has been on for at least 30 minutes.

  • Page 23: Figure 8 - Diagram Of Control Components

    PARLOUR 3000 DIRECT VENT GAS HEATER FIGURE 8 – DIAGRAM OF CONTROL COMPONENTS...

  • Page 24: Door Gasket

    PARLOUR 3000 DIRECT VENT GAS HEATER LIGHTING THE PILOT MAINTENANCE Make sure that there is adequate clearance for STOP! Read the following safety information accessibility to service and operate the heater. before lighting. Always verify proper operation after servicing. This heater is equipped with an ignition device Every year inspect the fire box, burner, and glass which must be lighted by hand.

  • Page 25: Lighting Instructions

    PARLOUR 3000 DIRECT VENT GAS HEATER FOR YOUR SAFETY, READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot which is lit with a push-button piezo lighter. When lighting the pilot, follow these instructions exactly.

  • Page 26: Gold-Plated Parts

    Prior to the first burn it is furnished by Thelin Hearth Products. Do not important to use Kel Kem Spray Gold Cleaner substitute materials or try to cut glass that is not or Flitz Faucet &...

  • Page 27: Troubleshooting

    PARLOUR 3000 DIRECT VENT GAS HEATER TROUBLESHOOTING WARNING: All servicing and troubleshooting of gas controls and high voltage circuits should be done by a qualified service technician. As a guide to help you understand the functioning and potential problem areas in your heater, use the following chart.

  • Page 28: Replacement Parts List

    PARLOUR 3000 DIRECT VENT GAS HEATER REPLACEMENT PARTS LIST Replacement parts are available at your dealer. The parts listed below are the only parts that the consumer may replace. All other parts must be replaced by a qualified gas service person.

  • Page 29: Figure 9 - Wiring Diagram

    PARLOUR 3000 DIRECT VENT GAS HEATER FIGURE 9 – WIRING DIAGRAM...
  • Page 30 Division, 12400 Loma Rica Drive, Grass Valley, CA 95945. Returned part or product will be repaired or replaced at Thelin Hearth Products’ option and will be returned to you, freight prepaid, as soon as practical, but not later than 30 days after receipt.

  • Page 31: Figure 10 - Directions For Enabling Door Opening And Securing Door

    PARLOUR 3000 DIRECT VENT GAS HEATER FIGURE 10 – DIRECTIONS FOR ENABLING DOOR OPENING AND SECURING DOOR Cleaning Glass 1. Turn off stove and let cool down. 2. Open door and clean glass with glass cleaner (i.e., Windex or similar product) and wipe with soft cloth.

  • Page 32: Figure 11 - Delayed Ignition Safety Door

    PARLOUR 3000 DIRECT VENT GAS HEATER FIGURE 11 – DELAYED IGNITION SAFETY DOOR This unit is equipped with a safety door system that will prevent damage if the stove ignites with delayed combustion. If this happens, have a qualified service person determine the cause of the delayed ignition.

  • Page 33: Figure 12- Gas Valve And Pilot Assembly

    PARLOUR 3000 DIRECT VENT GAS HEATER FIGURE 12– GAS VALVE AND PILOT ASSEMBLY...

  • Page 34: Appendix A

    PARLOUR 3000 DIRECT VENT GAS HEATER APPENDIX A – VERTICAL PIPE INSTALLATION – AIR INTAKE RESTRICTOR DISKS...

  • Page 35: Appendix B

    PARLOUR 3000 DIRECT VENT GAS HEATER APPENDIX B – PARLOUR STOVE WITH BURNER...

  • Page 36: Appendix C

    PARLOUR 3000 DIRECT VENT GAS HEATER APPENDIX C – PYROTECH LOG PLACEMENT 1. Ember bed installed with brick panel. 2. Install rear log #2 against brick panel and center right to left. 4. Rest the “Y” log, #4, on top of the small log 3.
  • Page 37 PARLOUR 3000 DIRECT VENT GAS HEATER APPENDIX C – PYROTECH LOG PLACEMENT (CONTINUED) 5. Place the front log #5 against the “Y” log in the notch shown in the illustration with the bottom end up against the lip of the door opening. Note:...
  • Page 38 PARLOUR 3000 DIRECT VENT GAS HEATER...
