Summary of Contents for Mobotix D12

Page 1: Live Viewing
CMOS www.mobotix.com > Services > Manuals without mechanical iris Wall bracket with cable cover for RJ45 wall outlet MOBOTIX AG • Security-Vision-Systems • Made in Germany Robust no moving parts www.mobotix.com • sales@mobotix.com • 23.11.2006 fiber glass housing...
Page 2: D12 Camera Manual Part 1
Admin Password: ISDN Dial-In Number: ISDN User Name: ISDN Password: Notes: Note: MOBOTIX offers inexpensive seminars that include a workshop and practical excercises: Basic Seminar 2 days, Advanced Seminar days. For more information, see www.mobotix.com © MOBOTIX AG • Security-Vision-Systems • Made in Germany...
Page 3: Table Of Contents
INSTALLING THE CAMERA & THE OUTDOOR WALL MOUNT 26 Quick Start Delivered Parts, Camera Components and Dimensions 2.2.1 Delivered Parts and Camera Components of the MOBOTIX D12D 2.2.2 Camera Casing and Connectors of the MOBOTIX D12D 2.2.3 Delivered Parts and Components of the Outdoor Wall Mount 2.2.4 Dimensions of the Outdoor Wall Mount...
Page 4 3.3.5 ISDN: Directly Supplying Power Using the External Power Supply 3.3.6 Ethernet and ISDN 3.3.7 Camera Startup Sequenze The First Image from the Camera 3.4.1 Preparing the Ethernet Connection 3.4.2 Preparing the ISDN Connection © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 5 The following chapters (4 and higher) are all part of the Camera Software Manual. The main headings are listed below to give you an overview of the Software Manual contents. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 6 Exposure Settings Day & Night Modes Managing Settings SOFTWARE UPDATES Overview Preparatory Steps Updating the Camera Software Update Checklist EVENTS, ACTIONS AND MESSAGES Overview Functional Overview © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 7 10.4 Configuring DynDNS 10.5 Updating Web Pages SOFTWARE INTERFACES 11.1 Overview 11.2 Accessing Live Images 11.3 Accessing the Second Image Channel 11.4 Video Streaming 11.5 The HTTP API © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 8 Technical information subject to change without notice! No part of this manual may be reproduced by any means without our written approval! Copyright © MOBOTIX AG, Kaiserslautern, Germany © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 9 D12 Camera Manual Part 1 Notes: © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 10: Introduction
BASIC models with differing software features. The WEB and BASIC mo- dels do not have a microphone. The D12 can be fitted with all MOBOTIX M14 high- performance lenses. Like all other MOBOTIX cameras, D12 models are more than "just a camera"; the...
Page 11: The Concept Behind The Mobotix D12
Low Bandwidth Requirements MOBOTIX' patent pending MxPEG streaming format allows fast live video with au- dio at extremely low network load (1 to 2 Mbps). Since the MOBOTIX camera itself detects movements in the image, video is only transmitted if movements occur, and when the video and audio data are stored.
Page 12 SD card can easily bridge longer network outages. 30 Live Cameras Using MxViewer The free MxViewer Windows client for viewing up to 30 MOBOTIX cameras with audio now features an integrated layout editor for quick assembly of building plans-using full drag&drop support for positioning the live camera images.
Page 13 PoE can be used for supplying power—unlike in other cameras. Weatherproof MOBOTIX D12 cameras are certified according to IP65 and are designed for out- door as well as indoor usage. As the cameras do not have any moving parts, they are extremely robust and resistant against heat or cold (-30°C to +60°C;...
Page 14 Logos, Animated or Freestyle The Logo generator of MOBOTIX cameras allows integrating different banners and Logo generator integrated graphics (including files loaded from any URL) into the current camera images—with optional scheduler control. MOBOTIX cameras are the only network IP cameras supporting animated and transparent graphics.
Page 15 D12 Camera Manual Part 1 Notes: © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 22.11.2006...
Page 16: Product Advantages Of The Mobotix D12
• Optional Wireless or UMTS/3G functionality thanks to CF cards (only instal- led by MOBOTIX; available in future versions). • High image quality with max. 1.3 M pixels resolution. The proven MOBOTIX software scaling delivers crisp images even for the smaller formats (PDA, CIF, VGA).
Page 17 (e.g. external sensors), three signal outputs (e.g. alarm systems), Line In, Line Out, USB devices, power backup. • Can be further expanded using MOBOTIX Cam-IO, which allows direct connection to door openers, lamps, sirens, an external microphone (with pre-amplifier), a loudspeaker, external sensors (e.g. light barrier). Hooks up directly to the mains and supplies power to the camera via the network cab- le to the camera (PoE).
Page 18: The Mobotix D12D-Fixdome Outdoor
After the position of the wall mount has been determined, the installer of the MOBOTIX camera system can connect the camera system to an installed network outlet, which has been properly tested and configured by the network installer.
Page 19 30% fiberglass). This material is used heavily in the automotive industry and is sturdy, resistant against high temperatures, environmental influences, chemicals, etc. Combined with the purely software-based design of the MOBOTIX D12D and the free software updates, the whole surveillance system has a long product life and thus provides a high return on investment (ROI).
Page 20: Product Advantages Of The Mobotix D12D-Outdoor
Outdoor Wall Mount with Corner and Pole Mount Corner and Pole Mount (rear view) 1.3.2 Product Advantages of the MOBOTIX D12D-Outdoor Besides the many product advantages inherent to the MOBOTIX D12, the MOBOTIX D12D-Outdoor offers these additional benefits: • Attractive design blends in well with building facades.
Page 21: Feature List
D12 Camera Manual Part 1 1.4 Feature List The MOBOTIX camera includes the following main features (some features are model-dependent): 1280 x 960 pixels • Live images of up to 1280 x 960 pixels resolution via network, ISDN, GSM, GPRS, UMTS, wireless up to 30 fps (at 640 x 480 resolution), also adapted for PDAs.
Page 22 • Multiple possibilities for connecting external devices, sensors and signal lines using the D Sub 15 HD socket of the camera or the MOBOTIX Cam-IO in- stallation box. • Speaker phone with talk, listen and intercom modes via Internet telephony (SIP) and ISDN using the integrated microphone and speaker.
Page 23: Hard- And Software Differences Of The Mobotix
The new hardware also brings new features, such as SIP video (Internet telephony with video) and new possibilities for extending the hardware (SD card, CF slots, MX Interface Connector, USB master pins for MOBOTIX expansion modules, etc.). The following table shows the most important differences in the hardware and...
Page 24: Important Notes
CAUTION: This deactivation is permanent and cannot be reversed even by MOBOTIX engineers. Deactivating the microphone will also deactivate all features that use the camera's microphone. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 22.11.2006...
Page 25: Starting The Camera Using The Factory Ip Address
MOBOTIX camera only displays the text WWW.MOBOTIX.COM, the to your liking time stamp and the MOBOTIX logo at the top of the image. Once the camera arming has been activated, the texts at the bottom of the live image (event, action and messaging symbols) will also appear.
Page 26: Deactivating The Daily Reboot Of The Camera
D12 Camera Manual Part 1 1.6.8 Deactivating the Daily Reboot of the Camera In its factory state, the MOBOTIX camera will automatically reboot every morning at Deactivating the camera 3:36 am. In very rare cases, external influences (e.g. radiation in high locations) reboot can lead to camera malfunctions.
Page 27: Additional Information
Camera Status the camera's browser interface. Another source of information on all dialogs and parameters of the MOBOTIX ca- mera is the Reference Manual that you can download from www.mobotix.com. The Reference Manual consists of the MOBOTIX camera's online help in one PDF file.
Page 28: Installing The Camera & The Outdoor Wall Mount
D12 Camera Manual Part 1 INSTALLING THE CAMERA AND THE OUTDOOR WALL MOUNT Quick Start To install the MOBOTIX D12D and the Outdoor wall mount follow these steps: • Checking the Delivered Parts (sections 2.2.1 and 2.2.3) • Planning the Installation (section 2.3) •...
Page 29: Camera Casing And Connectors Of The Mobotix D12D
2.2.2 The MOBOTIX D12D-FixDome consists of three main components (camera casing (item 1), body shell (item 9) and dome (item 8)). Like the M10 models, the MOBO- TIX D12 is also delivered with PIR sensor, microphone and speaker. External Sensors • PIR sensor •...
Page 30: Delivered Parts And Components Of The Outdoor Wall Mount
Stainless steel wood screws with hex head 8x70 mm Wall sealing Stainless steel Allen screws M4x10 mm Stainless steel hex nuts M4 Stainless steel Allen screws M4x25 mm Stainless steel washers dia. 4.3 mm © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 31: Dimensions Of The Outdoor Wall Mount
D12 Camera Manual Part 1 2.2.4 Dimensions of the Outdoor Wall Mount rectangular hole the rear covers the wall outlet Depth: 275 mm Width: 293 mm © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 32: Optional Accessories
IEEE 802.3af! Network Power Adapter (MX-NPA-3-RJ) The Network Power Adapter allows injecting the power supply for the MOBOTIX camera into the network cable. It thus allows using a single cable for connecting to the camera and for remotely supplying power (up to Power supply for smaller 100 m/300 ft).
Page 33 For additional information on the MOBOTIX Cam-IO, see section 3.7.2, MOBOTIX Cam-IO : Expansion Mo- dule for Easy Installation . The MOBOTIX Cam-IO will be available from Q1 2007. Split cable for ISDN-only power supply Power injection into one If only ISDN is available for the camera and only one cable should be used for con-...
Page 34: Planning Where To Install The Camera
D12 Camera Manual Part 1 2.4 Planning Where to Install the Camera Before installing the MOBOTIX D12D and the Outdoor wall mount (item 13), the following questions should be solved: • Where should the camera be installed and which area should the...
Page 35: Installation Using The Outdoor Wall Mount
The lenses play a very important role when determining the correct position for the camera. In order to find the proper lenses for your application, you should consult the lens table available on www.mobotix.com in the Products >Lens Options section. The exact positioning of the camera casing itself is largely dependent on the area that the camera's PIR sensor should cover.
Page 36: Deciding On The Connections (Network/Isdn/Rs232)
Free software updates mounting the camera is not an option. SIP telephony reduces costs ISDN connection of MOBOTIX cameras is not required if the network permits SIP Internet telephony connections for Internet phone connections. Thanks to the SIP capabilities of the MOBOTIX D12D (see chapter 9, Telephony Features , in the Software Manual ), the...
Page 37 In contrast to the MOBOTIX D10, it is not possible to use an ISDN ISDN operation: NT and the S0 bus to supply power to the D12. Using the ISDN split - Euro ISDN cable and MOBOTIX PoE products (see section 2.3, Optional Acces-...
Page 38: Selecting The Power Supply
Power over Ethernet (IEEE 802.3af) network compo- PoE components without fans increase overall nents for supplying power to the MOBOTIX D12, make sure that these reliability of the entire components do not have a fan. Since the power consumption of MO- system...
Page 39: Using Uninterruptible Power Supplies (Ups)
When using more powerful 19" rack-mounted USPs, you can also protect all other network components (e.g. switches, routers, PoE switches, etc.). Since MOBOTIX cameras do not require any heating even in the wintertime, the po- wer consumption of 3 W is quite low. This in turn means that you can centralize the USP-protected power supply by injecting power into the network cables (max.
Page 40: Providing The Connections (Network/Isdn/Rs232)
Once the camera position, the position of the cable outlets, and the method of power supply have been decided upon, the cabling should be installed. Before mounting the MOBOTIX D12D-Outdoor, you should make sure that the network and ISDN connections are properly tested, so that proper functioning of the camera is guaranteed.
Page 41: Mobotix D12 Lens Options
L22 Super Wide-Angle 90° has very little distortion, even when using the 4x digital zoom of the D12. Moun- ting a camera with the Super Wide Angle lens in the corner of a room will allow you to see the complete room (see figure right).
Page 42 D12 Camera Manual Part 1 Note The focal lengths of MOBOTIX lenses do not reflect the actual focal Focal lengths of MOBO- length of the lenses, but the focal length ( Lxx mm) converted to 35 mm TIX lenses are always camera format.
Page 43: Preparing The Camera
Adjusting the lens Adjusting the lens mounts and the lenses carriers mounts and the lenses Examples for lens positioning: Variable positioning of lenses for ceiling/wall mount!! © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 44: Connectiong The Cat5 Cables
D12 Camera Manual Part 1 2.6.3 Connecting the CAT5 Cables If the MOBOTIX D12D-Outdoor should use a network (Ethernet) and an ISDN connection, make sure to install a second CAT5 cable (min. 50 cm for D12 only, 70 cm for D12 with outdoor wall mount) and to guide it to the camera casing.
Page 45 When attaching the cable cover, take care to properly align the cover with the seal of the camera casing and the two cable guides. This will ensure that the camera remains weatherproof (IP65). © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 46: Connecting A Cable To The Serial Interface (Rs232)
2.6.4 Connecting a Cable to the Serial interface (RS232) Switching external relays If the RS232 interface of the MOBOTIX D12D-Outdoor is to be used for switching using the RS232 interface external relays (lights, alarm sirens, gates, etc.), evaluating...
Page 47 D12 Camera Manual Part 1 Notes: © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 48: Mounting The Casing To A Wall Or Ceiling, Connecting The Cables
There are two ways to accommodate cable that is too long (see figures): (1) Loop near the RJ45 connectors (2) Loop beneath the camera © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 49: Installing The Camera With The Outdoor Wall Mount
The PIR sensor reaches about 10 meters and has a field of view of ± 15°. The positions that are available depend on how high the MOBOTIX D12D-Outdoor has been mounted and the position of the camera on the bottom plate (item 2), which can be adjusted in steps of 15 degrees (see also section 2.6.3, Determining...
Page 50: Installing The Outdoor Wall Mount
(network, ISDN, Power over Ethernet) to the camera. Mounting the Outdoor Wall Mount and the Wall outlet Camera D12D-Outdoor wall mount CAT5-Kabel D12D All measurements in mm! © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 51 Cable length from wall: cable, make sure that the installed cable approx. 70 cm has a minimum length of 70 cm from the wall or wall outlet. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 52: Determining The Position Of The Camera On The Bottom Plate
• PIR sensor of the camera looks to the left: Use the PIR looking to the left: 7 holes marked with the number for the 20 mm hex nuts (item 20). © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 53: Fixing The Camera To The Bottom Plate
PIR sensor of the camera case) and use the two Allen screws looks straight ahead: M4x25 mm (item 21) with Position 1 corresponding washers to fix the camera to the bottom plate. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 54: Connecting The Camera And Attaching The Bottom Plate
• Push the front of the bottom plate upwards. • Mount the bottom plate to the wall mount (eight Allen screws M4x10 mm; item 19) and make sure the screws are all properly fastened. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 55: Completing The Installation
• Attach the dome using the cotton cloth (see section 2.10.1, Assembling the Camera , item (4)) and finally check the focus of the lenses on the monitor. Tighten the dome by turning clockwise © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 56: Attaching The Camera's Outer Shell
Disassembling the Camera ). Caution The MOBOTIX D12D-Outdoor is only weatherproof if the camera casing has been mounted tightly to the bottom plate and both the camera dome and the outer shell are properly seated. © MOBOTIX AG • Security-Vision-Systems • Made in Germany...
Page 57: Assembling And Disassembling The Camera
2.10 Assembling and Disassembling the Camera 2.10.1 Assembling the Camera (Detailed Description) For adjusting the D12, you need the supplied Allen wrench; for attaching the dome, a lint-free cotton cloth is required (see also section 2.9, Cleaning Instructions ). (1) Inserting the lens units and fixing the central lens screw Insert the lens units into the seating.
Page 58 If only one cable is used, close the unused cable guide with the supplied rubber plug © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 59 Dismount the outer shell using the supplied custom tool (see section 2.8.2, Disassembling the Camera ). © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 60: Disassembling The Camera (Detailed Description)
D12 Camera Manual Part 1 2.10.2 Disassembling the Camera (Detailed Description) For disassembling the outer shell of the D12, you need the supplied custom tool; for dismounting the dome, a lint-free cotton cloth is required (see section 2.9, Cleaning Instructions ).
Page 61 (4) Removing the dome Dismount the dome by Take cotton cloth remove turning it counter- transparent dome by turning it in a counter- clockwise clockwise direction. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 62 (7) Remove the central lens screw and the lens units Remove the central lens screw using the supplied 3 mm Allen wrench. Lift the lens units out of their seats. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 63 D12 Camera Manual Part 1 Notizen: © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 64: Cleaning Instructions
When installing the wiring in or out of buildings, make sure you always adhere to the relevant regulations on wiring, fire prevention and protection against lightning. MOBOTIX recommends having MOBOTIX cameras installed only by certified specialists accustomed to installing network devices and having proper respect for the applicable regulations regarding lightning protection and fire prevention as well as the current technology for preventing damages from electrical surges.
Page 65: Fire Prevention
This includes surge protectors for 19" racks, add- ing an uninterruptible power supply (UPS) to the MOBOTIX camera, and installing surge arresters or similar for routers, switches, servers, etc.
Page 66: Operating The Camera
OPERATING THE CAMERA 3.1 General Procedure The MOBOTIX camera does not require any software installation; all you need is your preferred browser with JavaScript support to operate the camera. Thus, the MOBOTIX camera is supported by all common operating systems (such as Windows, Macintosh and Linux, ...).
Page 67 D12 Camera Manual Part 1 Note After first booting the new MOBOTIX camera or after resetting to facto- ry defaults, accessing the Administration menu (Admin Menu button) will automatically start the Quick Installation wizard. This is where you Always use Quick Instal-...
Page 68: Overview Of The Configuration Settings
Live screen. • The image settings are already optimized The factory image settings of MOBOTIX cameras deliver excellent images for most application scenarios and should not be changed. If you do wish to make changes, your changes should be minor and gradual. If you would like...
Page 69 If all options are displayed, the Less button appears. Clicking this button will hide the advanced options. Click on the More/Less buttons to show/hide the advanced options © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 70: Connecting The Camera
NPR-4 for smaller instal- lations connector of the camera. In order to inject the power supply into the network cabling, MOBOTIX PoE products have proven reliable and Use the 19" MOBOTIX easy to install for one camera (MX-NPA-3-RJ), for up to four came-...
Page 71: Ethernet: Power Supply Using A Network Power Rack (Mx Poe)
PoE can be used (lower risk of failure). • Easy installation on DIN rails ( MX-NPR-4 ) or in 19" racks ( MX- NPR-8/20 ). © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 72: Ethernet: Power Supply Using Poe Products (Power Over Ethernet)
IEEE 802.3af Power over Ethernet network compo- fans increase overall reli- nents for supplying power to MOBOTIX cameras, make sure that these ability of the entire sys- components do not have a fan. Since the power consumption of MO- BOTIX cameras is very low compared to other products, this increases the reliability of the entire system and expands the life cycle of these components.
Page 73: Isdn: Power Supply Using A Network Power Adapter
Caution Missing termination resistors and wrong cable lengths are the most common installation errors! Always observe the instructions regarding maximum cable lengths and proper ISDN termination! © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 74: Isdn: Directly Supplying Power Using The External Power Supply
Power is supplied only via the Ethernet cable and the 10BaseT/NET connector of the camera (using MOBOTIX PoE products or Power over Ethernet according to IEEE 802.af). Ethernet ISDN © MOBOTIX AG • Security-Vision-Systems • Made in Germany...
Page 75: Camera Startup Sequenze
During the startup sequence, the LEDs will always light up, even if they Signals of the camera have been deactivated in Admin Menu > LED Setup. LEDs: Camera Network Camera © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 76: The First Image From The Camera
• Direct access using a browser (section 3.4.4, The First Image in the Browser ) Working with the web- • Display the camera using MxViewer (free Windows client for MOBOTIX ca- based user interface only requires a web browser meras;...
Page 77 If you receive an answer from another network device although the camera is not the IP address of your ca- connected, you will have to remove that device until you have reset the MOBOTIX mera instead of 10.1.0.99! camera to a free IP address. We recommend using the Quick Installation wizard for this task.
Page 78: Preparing The Isdn Connection
Password: 3.4.3 Simultaneously Using ISDN and Ethernet Connections (Gateway) In most cases, MOBOTIX cameras will be used either on an Ethernet LAN or on ISDN, not both. The gateway (for accessing computers outside of the local network) needs to be set manually for Ethernet; it is usually obtained automatically for ISDN.
Page 79: The First Image In The Browser
After entering the camera's IP address in the browser address bar (e.g. http:// Make sure that you use 10.1.0.99), you will see the Live screen of the MOBOTIX camera with its user the IP address of your interface controls, such as softbuttons, buttons for the different camera screens,...
Page 80: Additional Information
In order to obtain more information on the camera and its current configuration, Camera status open the Camera Status dialog by clicking on the yellow icon in the top right corner of the camera's browser interface. Another source of information on all dialogs and parameters of the MOBOTIX camera Reference Manual that...
Page 81: Camera Screens In The Browser
D12 Camera Manual Part 1 3.4.6 Camera Screens in the Browser Per factory default, the MOBOTIX camera first shows the Live screen. You can set a different start page in order to prevent others from changing the settings. In additi-...
Page 82: The First Image In Mxviewer
MxViewer can do quite a bit more than simply display the video and audio data from MOBOTIX cameras. The unique features of MxViewer and the MOBOTIX ca- meras create a full-featured security system: Intelligent alarm handling, various ways of arranging the camera views on different layouts (MultiView screens), ability to display cameras that are sending alarm notifications, and integrated camera management functions.
Page 83 Defining Video Sources If you start MxViewer for the first time on a computer without having defined any vi- Defining cameras as video deo sources (MOBOTIX cameras) before, the MxViewer Video Sources dialog will sources appear. Depending on the task at hand,...
Page 84 In the first pass, MxViewer searches the selected subnet for MOBOTIX cameras and in the second pass, MxViewer verifies if it can access the cameras. MxViewer then highlights all cameras in the list, which have a status of OK or Ac-...
Page 85 MOBOTIX cameras. video streams • Add: Add the IP address or DNS name of the MOBOTIX camera you entered to the list. If possible, MxViewer shows the image of the last camera you added in the pre- view window.
Page 86: Starting The Camera With An Automatic Ip Address (Dhcp)
DHCP server is running properly. If this is not the case, the camera address cannot obtain a valid IP address and will fall back to its last IP address. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 87: Starting The Camera Using The Factory Ip Address
As opposed to resetting the camera using Admin Menu > Reset configuration to factory defaults, the user names and passwords will not be reset when the camera is booted using the factory IP address. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 88: Connecting External Devices And Sensors: Mx Interface Connector And Mobotix Cam-Io
MOBOTIX Cam-IO 3.7.1 MX Interface Connector for Direct Connections The MOBOTIX camera has one signal input and one signal output for switching loads as well as two signal inputs and two signal outputs of the RS232 interface on the MX Interface Connector (D Sub 15 HD). You can use the camera's signal input/output pins to detect an opening door (using a Reed switch) or to switch an external device (e.g.
Page 89: Mobotix Cam-Io: Expansion Module For Easy Installation
D12 Camera Manual Part 1 camera (e.g. when using a MOBOTIX camera as a video conferencing system and in access control scenarios). 3.7.2 MOBOTIX Cam-IO: Expansion Module for Easy Installation This expansion module has the following main tasks: • It represents a unified installation platform with power supply for the MOBOTIX D12, M12 and M22 models with SecureFlex mount.
Page 90: Signal Input/Output, Rs232 Interface
3.8 Signal Input/Output, RS232 Interface The signal lines of the se- The MOBOTIX camera provides a signal input/output as well as two additional sig- rial interface can also be nal input pins and two signal output pins on its RS232 interface (not available on programmed as additional WEB and BASIC models).
Page 91: Signal Output Pins
D12 Camera Manual Part 1 3.8.2 Signal Output Pins When an event is detected, the MOBOTIX camera can switch the signal output (pin 1). Use the corresponding options in Setup Menu > Actions to set how long the camera should close the signal output.
Page 92: Drilling Templates D12
When printing the PDF file, you should print two pages onto one to obtain an unscaled printout of the drilling templates. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 93 D12 Camera Manual Part 1 D12 wall mount and weather protection © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 94: Hardware And Software Features
CF slots (MOBOTIX extensions) Microphone/Speaker External audio (Line-In/Out) Signal input Signal output Concealed cabling In stock Outdoor Wall Mount (accessory) D12 with Outdoor Wall Mount IP65 © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 95 Model Limitations Image size Mega Mega Image sensor (color / BW) Color Color Color & BW Color & BW Standard lens for software version Audio support (Microphone/Speaker) © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 96: Ip65 Certificate
D12 Camera Manual Part 1 IP65 CERTIFICATE © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 97: Declaration Of Conformity
D12 Camera Manual Part 1 Declaration of Conformity © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 98 D12 Camera Manual Part 1 Notes: © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com • 23.11.2006...
Page 99 D12 Camera Manual Part 1 MOBOTIX ... the new face of IP video All pictures in this user manual are genuine MOBOTIX camera images. Enjoy the image quality! Manufacturer: CEO: MOBOTIX AG Dr. Ralf Hinkel Luxemburger Str. 6 67657 Kaiserslautern...
Page 100 CMOS www.mobotix.com > Services > Manuals without mechanical iris Wall bracket with cable cover for RJ45 wall outlet MOBOTIX AG • Security-Vision-Systems • Made in Germany Robust no moving parts www.mobotix.com • sales@mobotix.com • 23.11.2006 fiber glass housing...

Mobotix D12 Manual

1 Introduction

2 Installing the Camera & the Outdoor Wall Mount

3 Operating the Camera

Appendix

Hardware and Software Features

Ip65 Certificate

Declaration of Conformity

Quick Links

Live viewing

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mobotix D12

Summary of Contents for Mobotix D12

Table of Contents
