  • Page 1 > Support > Manuals HiRes Video Innovations The German company MOBOTIX AG is known as the leading pioneer in network camera technology and its decentralized concept has made high-resolution video systems cost eicient. MOBOTIX AG • D-67722 Langmeil • Tel: +49-6302-9816-103 • Fax: +49-6302-9816-190 • sales@mobotix.com...
  • Page 2 Admin User Name: Default User Name: admin Password: meinsm Admin Password: Note MOBOTIX ofers inexpensive seminars that include workshops and practical exercises: Basic Seminar three days, Advanced Seminar two days. For more information, please visit www.mobotix.com. © MOBOTIX AG • Security-Vision-Systems • Made in Germany...

  • Page 3: Table Of Contents

    Preparing The Installation 2.1.1 Flexible Installation Using VarioFlex Mount 2.1.2 Mounting To A Ceiling Or Wall 2.1.3 Mounting Tips For The M24M With L11 Lens (180° Fisheye) 2.1.4 Optional: Mounting To A Pole (With Accessories) 2.1.5 Network Connection And Power Supply, UPS 2.1.6 Preparing The Camera Connections, Wall Outlets...
  • Page 4 3.2.4 First Images And Network Parameter Coniguration In MxEasy 3.2.5 Starting The Camera With An Automatic IP Address (DHCP) 3.2.6 Starting The Camera With The Factory IP Address © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 5 Download the latest version of this manual and the MxEasy and MxControlCenter manuals as PDF iles from www.mobotix.com (Support > Manuals). All rights reserved. MOBOTIX, MxControlCenter, MxEasy, ExtIO and CamIO are internationally protected trademarks of MOBOTIX AG. Microsoft, Windows and Windows Server are registered trademarks of Microsoft Corporation.

  • Page 6: Foreword

    3.1 megapixel color sensor, an internal long-term memory with a maximum capacity of 32 GB and the latest technology platform from MOBOTIX. This makes the M24M the irst camera among the M models that can be itted with the MOBOTIX standard lenses (image angles from 15° to 90°), the hemispheric L11 lens (image angle of 180°) for high-resolution panorama images and with com-...
  • Page 7 /146 M24M - High-resolution video surveillance with optimal weather protection (IP66) MOBOTIX original Double Panorama image High-Resolution Double Panorama Original full image © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 8: The Mobotix Concept

    Technology Leader Of Network Cameras In a short time, MOBOTIX has gained the second place in Europe and the fourth place worldwide in terms of market share. MOBOTIX has been producing megapixel cameras exclusively for years and, in this area, ranks as the global market leader in high-resolution video systems with a market share of over 60%.
  • Page 9 The PC now serves purely for viewing, not for analysis or recording. As a result, MOBOTIX cameras can record in response to an event, even without the PC being switched on, and digitally store the videos with sound.

  • Page 10: Mobotix Hemispheric Technology

    This makes it hard to comprehend the overall setting. The L11 lens and hemi- new panorama function of the M24M delivers a widescreen image of a high-resolution spheric technology 180° allround view. High image quality is achieved through the use of a 3.1 megapixel sensor and the new hemispheric lens.
  • Page 11 Virtual PTZ is available for each of the four views. Together with the 180° panorama the M24M can deliver two more views simultaneously, making it possible to see the overview and to focus on two scenes at the same time (Display Mode “Panorama Focus“).

  • Page 12: Superior Storage Solution

    Central PC is a bottleneck and a risk for the total system MOBOTIX Stores HiRes Cost Eiciently MOBOTIX solves the PC storage bottleneck problem using a unique and yet amazingly efective method - through the camera itself. High-resolution video with lip synchronized sound is saved either remotely over the network or locally on lash memory devices (com- mercial SD or CF cards, USB memory).
  • Page 13 • Ring bufer: Old images can be overwritten automatically or automatically deleted after a speciied period of time MOBOTIX Stores Data Reliably The MOBOTIX Flash ile system (MxFFS) prevents unauthorized persons from reading or transferring the internally stored data, even if the card is stolen. MOBOTIX Only Saves What Is Necessary...

  • Page 14: Added Security Value

    SSL when they are transferred over the network. Notiication Of Failure MOBOTIX cameras will automatically report any impairment or failure. This ensures maxi- mum reliability and readiness for use. Subsequent Searches Events rarely conine themselves to just one spot.
  • Page 15 /146 Sound Increases The Chance Of Detection In the event of an alarm, MOBOTIX cameras can turn on their built-in microphones and record lip-synchronous sound. They are therefore an even greater help in analyzing a situation and easing clariication. In addition, the video system can be used for bidirectional communication via a loudspeaker/microphone.

  • Page 16: Cost Beneits And Technical Advantages

    /146 M24M Camera Manual: Cost Beneits and Technical Advantages THE MOST IMPORTANT COST BENEFITS Increased resolution reduces amount of cameras needed 1536-line, high-resolution sensors give a better overview and allow monitoring an entire room with just one camera from the corner...
  • Page 17 SIP standard with automatic alarm call and remote control MxControlCenter included Dual screen technology with building plans, free camera positioning, event search, image processing, lens distortion correction and PTZ support © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 18: Introduction

    With the M24M series, MOBOTIX ofers extremely compact, versatile and cost-efective allround cameras with an integrated video sensor, lip-synchronous audio transmission and long-term internal storage on a MicroSD card (4 GB card as standard). Since the M24M is equipped with the latest MOBOTIX technology platform, it is the irst HempisphericReady camera in the M series –...
  • Page 19 Thanks to their low power consumption of 3 watts and the total absence of mechanical moving parts, M24M cameras feature the highest operating temperature range (-30°C to +60°C, or -22°F to 140°F). Since MOBOTIX cameras neither fog up nor require heating, power can be supplied via the network cabling according to the PoE standard IEEE 802.3af.
  • Page 20 180° Panorama image (L11 lens) The M24M-Sec-CSVario is an M24M model that is shipped with a CS mount and a compact L24-L54 1/2" Vario lens. To protect the lens against the weather, this model comes with a longer lens cover with an integrated glass pane which includes threads for an external ilter.
  • Page 21 Each M24M is available for delivery with a lens of your choosing or no lens at all. The image area captured by the camera varies depending on the selected lens (see With an M24M equipped Section 1.5).
  • Page 22 Virtual PTZ (vPTZ) – Panning, Tilting, And Zooming With No Motor The M24M can also zoom in on detail as well. This vPTZ function (virtual Pan, Tilt, Zoom) is a standard feature in the integrated M24M camera software. The image from the hemispheric camera can be enlarged using, for example, the mouse wheel, a joystick or a software-controlled PTZ panel and you can "move"...
  • Page 23 "visible" portion of the image; the rest is lost and cannot be examined later on. For this reason, MOBOTIX has added the new full image recording feature to the M24M. This will not store the currently viewed image that relects the pan/tilt position and the zoom setting chosen by the user, but the full sensor image –...
  • Page 24 Furthermore, ive further factory lenses with image angles of 15°, 31°, 45°, 60° and 1.5 for more details) 180° as well as a version with a CS Vario lens are available upon request. Every M24M is provided with a pre-formatted and installed 4 GB MicroSD card and a VarioFlex mount for fast and easy installation.
  • Page 25 /146 M24M Overview © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 26: M24M With Hemispheric Special L11 Lens

    M24M, which replaces the time-consuming and expensive installation of several standard cameras. The overview image provided by a single M24M, which may be personalized in a number of ways according to speciic user requirements, not only reduces the number of required cameras, but also minimizes the system costs by reducing the wiring complexity, emergency power requirements and number of recording devices required.
  • Page 27 /146 M24M With Hemispheric Special L11 Lens The factory default setting of an M24M with an L11 lens is a high-resolution 180° panorama image, in which parts of the protective cover are still visible in the upper right and left corners of the image.
  • Page 28 M24M Camera Manual: INTRODUCTION L11 Lens: Panorama Focus – One Camera, Three Views Maximum room overview while simultaneously viewing detail in a single image: the M24M is capable of providing two more views simultaneously with the 180° panorama, allowing you to focus on two scenes in parallel ("Panorama Focus" display mode).
  • Page 29 M24M With Hemispheric Special L11 Lens L11 Lens: Surround View (Quad View) The M24M's "Surround" display mode replaces four cameras all at once and simultane- ously delivers four diferent directions "at a glance." If the camera is installed in the ceiling and is looking straight down, all four cardinal directions can be displayed, for example.
  • Page 30 L11 Lens: Full Image And Normal View In addition to Panorama, Double Panorama, Panorama Focus and Surround views, the M24M image may be displayed on a monitor as the original isheye version ("Full Image" display mode) or as the camera-corrected image section ("Normal" display mode). Switching to one of the other display modes described is possible at any time within seconds.
  • Page 31 L11 Lens: Factory Settings Of The Standard Views For A Wall Installation In order to fully exploit the potential of the M24M in the desired view, it may be necessary to adjust the factory settings using the integrated vPTZ function. We have summarized the factory default settings of a wall-mounted M24M with an L11 lens (with a downward tilt of approx.

  • Page 32: M24M: Hires Allround Camera With Widest Range Of Lenses

    3 from the camera software in order to precisely adjust the functionality of the camera, its accessories and the PoE switch. Only 3 Watt Power Consumption Despite the use of a more powerful processor, the power consumption of the M24M is maintained at an extremely low level of only 3 watts. New Audio Functionalities...
  • Page 33 /146 M24M: HiRes Allround Camera With Widest Range Of Lenses © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 34: General Mobotix Camera Functions

    M24M Camera Manual: INTRODUCTION General MOBOTIX Camera Functions Like all MOBOTIX cameras, the M24M line has a variety of software functions: from motion detection and long-term storage right through to alarm notiication via video IP telephony. Unlike in camera systems from other manufacturers, it is not necessary to buy and install additional software on the computer.
  • Page 35 Long-Term Storage On File Servers Included MOBOTIX cameras have an integrated long-term storage system for Linux, Windows, and Mac OS X computers. Every camera manages its own ring bufer storage to a shared folder.
  • Page 36 The cameras can use network/wi-i, GSM/GPRS/UMTS (3G), or Internet connections for this purpose. Integrated Power Over Ethernet Power is supplied as Power over Ethernet via the network cabling using the MOBOTIX NPA- No heating required – PoE is no problem, PoE-Set or from a PoE-compatible switch (both according to the IEEE 802.3af PoE standard).
  • Page 37 No license costs Free updates MxEasy – Intuitive Application For Windows, Apple And Linux The new MOBOTIX MxEasy aims at easy operation of the most important camera functions Suitable for up to 16 MOBOTIX cameras through its intuitive user interface, thus creating a new user experience when viewing and controlling MOBOTIX cameras.
  • Page 38 A Linux version will be available soon. Diverse Installation Options Not only can MOBOTIX cameras be used under almost all weather and temperature conditions, they also ofer suitable installation materials from a wide range of accessories for any conceivable application scenario.
  • Page 39 SSL-protected transmission of the video sequences and the data (using SSL encryption and X.509 certiicates). Free Software Updates (www.mobotix.com) Free software MOBOTIX provides software updates free of charge at regular intervals that improve updates at and expand the camera’s functionalities. Chapter 6, Software Update , in the Software www.mobotix.com Manual provides more information on the process.

  • Page 40: Lens Options, Hardware And Software Features

    M24M Camera Manual: INTRODUCTION Lens Options, Hardware And Software Features MOBOTIX ofers the M24M with lenses in three diferent classes of focal length. Since MOBOTIX cameras are backlight-proof, none of these lenses requires a mechanical auto iris, thus making the camera extremely robust and maintenance-free. MOBOTIX lenses deliver good image quality even when using maximum digital zoom.
  • Page 41 Another beneit is that you can easily set a 35 mm camera (analog or digital) to the same focal length as the MOBOTIX lens (Lxx) to obtain the same ield of vision. This approach greatly facilitates lens selection.
  • Page 42 Speaker and Microphone Warranty (months) Concealed cabling M24M Software Features Digital zoom (continuous) with panning Additional storable views Full image recording Video motion window Exposure windows Echo elimination © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 43 M12 lenses included if requested by customer Image sensor Color Color Color & B/W Color & B/W Standard lens for software version Audio support (Microphone/Loudspeaker) -/L** -/L** M/L** M/L** © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 44: Installation

    2.1.1 Flexible Installation Using VarioFlex Mount Like all MOBOTIX cameras, the M24M is extremely lexible in terms of how and where it can be installed. An M24M can be used for both indoor and outdoor applications. In ixed or mobile applications - constantly changing locations or in/on vehicles of any kind. The M24M cameras have been certiied weatherproof according to IP66 and can work reli- ably in temperature ranges from -30 °C to +60°C (-22°F to +140°F) without extra housing,...
  • Page 45 (does not apply to the M24M-Sec with hemispheric L11 lens). © MOBOTIX AG • Security-Vision-Systems • Made in Germany...

  • Page 46: Mounting To A Ceiling Or Wall

    Super Wide Angle lens (90°, L22) allows the room to be monitored almost entirely by an M24M mounted to the ceiling in one of the corners. Using the PTZ software, you can easily zoom in on image details in either the live image or the recording. The camera can be turned or tilted 360°...

  • Page 47: Mounting Tips For The M24M With L11 Lens (180° Fisheye)

    High-Resolution Panorama Images The M24M with L11 lens is primarily suited to providing an excellent overview in the form of a high-resolution panorama image, and less suitable for more exact details. For active operation, the camera should be mounted at an (out of direct reach) height ranging from 2.50 m to 3.50 m.
  • Page 48 /146 M24M Camera Manual: INSTALLATION Allround View Thanks to its hemispheric lens, a single M24M can monitor an entire room right into each The allround view of the M24M is restricted by the of the four corners (360° Allround View). The camera's ideal position is on the ceiling in the weatherproof cover, which center of the room at an angle of 90°.

  • Page 49: Optional: Mounting To A Pole (With Accessories)

    Note Part of the captured image area is concealed behind the protective cover of the M24M housing, especially in the full image. For this reason, M24M cameras with L11 lens should be adjusted so that the concealed areas are not those that are supposed to be monitored.

  • Page 50: Network Connection And Power Supply, Ups

    M24M Camera Manual: INSTALLATION 2.1.5 Network Connection And Power Supply, UPS Power over Ethernet (PoE Conforming To IEEE 802.3af) All M24M models are supplied with power using the PoE standard. The PoE Adapter Set The M24M sup- ports the Power over (MX-NPA-PoE Set) may be used for smaller installations.

  • Page 51: Preparing The Camera Connections, Wall Outlets

    Once the camera position, the position of the cable connectors, and the method of power supply have been decided upon, the cabling can be installed. Before mounting the MOBOTIX M24M, you should make sure that the network connections have been properly tested, so that the proper functioning of the camera is guaranteed.

  • Page 52: Wiring, Fire Prevention, Lightning And Surge Protection

    When installing the wiring inside or outside of buildings, make sure you always adhere to the relevant regulations on wiring, ire prevention, and protection against lightning. MOBOTIX cameras are protected against the efects of small electrical surges by a range of measures. These measures, however, cannot prevent the camera from being damaged when stronger electrical surges occur.
  • Page 53 More information on preventing lightning or surge damage is available from organizations such as the International Electrotechnical Commission (www.iec.ch) or from the man- ufacturers of lightning and surge protectors (for example, Dehn: www.dehn.de). © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 54: M24M-It/Secure: Delivered Parts, Components, Dimensions

    1.11 Stainless steel washers 6.4 mm 1.12 Screw anchors S8 1.13 Cable retainer with bayonet catch (patch cable, Mini USB) 1.14 4 GB MicroSD card 1.15 Lock plug Mini USB © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 55: Camera Housing And Connectors

    /146 M24M-IT/Secure: Delivered Parts, Components, Dimensions 2.2.2 Camera Housing And Connectors The MOBOTIX M24M consists of the camera in the weatherproof housing and the VarioFlex mount. Connectors • Network (Ethernet network including PoE supply) • Mini USB (e.g. for ExtIO) •...
  • Page 56 The cable can now be pulled out of the camera. Open the cable retainer by rotating the bayonet catch to the marked position Bayonet catch open © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 57 (opening points to the right). Rotate the bayonet catch clockwise to the "illed circle" symbol (see diagram). The cable is now properly retained. Close the cable retainer by rotating the bayonet catch to the marked position Bayonet catch closed © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 58: Dimensions (Mm) For Wall Installation

    /146 M24M Camera Manual: INSTALLATION 2.2.3 Dimensions (mm) For Wall Installation 106,5 140,5 2.2.4 Dimensions (mm) For Ceiling Installation 106,5 106,5 140,5 © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 59: Dimensions (Mm) Of Wall Mount

    Find the folded drilling template at the end of the manual. Make sure that the drilling template is not scaled or adjusted to the paper size when printing the PDF ile (enlarged or reduced). © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 60: Available M24M Accessories - Overview

    Available M24M Accessories - Overview NPA-PoE Set (MX-NPA-PoE-EU and MX-NPA-PoE-INT) The MOBOTIX Network Power Adapter Set (NPA-PoE set) is a high-quality, robust, ultra- compact, and, above all, multifunctional PoE injector with three connectors (network, camera/PoE device, PC) and a universal power supply unit with adapter plugs.
  • Page 61 The Ethernet patch cables for the M24M were devel- oped by MOBOTIX and have a specially integrated seal. Every M24M is supplied with a 0.5 m long patch cable as standard. Patch cables of 1 m, 2 m, 5 m, and 10 m in length can also be ordered on request.
  • Page 62 2 input and 2 output contacts and 2 illuminated buttons. It is ideal for door communication, elevators, access control, etc. The ExtIO can be operated directly with the M24M over a separately available MOBOTIX USB cable. The ExtIO can operate in two diferent modes: •...
  • Page 63 Mx2wire Mx2wire Two-wire cable Ethernet cable Max. 500 m • PoE out: max. 7 watts RJ45 RJ45 PoE switch/injector IEEE 802.3af TCP/IP © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 64: Mounting The Camera With Wall Mount

    Mounting The Camera With Wall Mount 2.4.1 Mounting Instructions The M24M is an allround camera designed for use in indoor and outdoor applications. See Section 3.9.1 The camera must always be installed with the VarioFlex mount, which has been prepared at the factory for wall mounting and allows the cabling to be concealed.
  • Page 65 The connection to the camera patch cable can be established using a suitable adapter within the wall mount. Pliers to break through a cable guide © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 66: Required Tools

    • MOBOTIX drilling templates (at the end of this manual) • Scissors to cut out the template • Pen to mark the drill holes • Materials and any tools needed to connect the pre-installed MOBOTIX network cable in the camera with the on-site network cable Caution Never use screws with recessed heads to install the VarioFlex mount as these screws will destroy the mount.

  • Page 67: Procedure

    RJ45 outlet. Make sure that for example, with shrink tubing the cables are not bent or squashed. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 68 Check image sections on the computer monitor. Note The VarioFlex mount and Wall Mount must always be used for wall installation. Use the VarioFlex Ceiling Mount for ceiling installation! © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 69 /146 Mounting The Camera With Wall Mount © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 70: Mounting The Camera With Ceiling Mount

    Mounting The Camera With Ceiling Mount 2.5.1 Mounting Instructions The M24M is an allround camera designed for use in indoor and outdoor applications. The See Section 3.9.1 camera is always installed together with the VarioFlex mount, which has been prepared at the factory for wall mounting and can be converted to a ceiling mount in just a few steps.
  • Page 71 The camera patch cable must be connected to the network cable using a suitably sealed adapter. Pliers to break through cable guides © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 72: Required Tools

    • MOBOTIX drilling templates (at the end of this manual) • Scissors to cut out the template • Pen to mark the drill holes • Materials and any tools needed to connect the pre-installed MOBOTIX network cable in the camera with the on-site network cable Caution Never use screws with recessed heads to install the VarioFlex mount as these screws will destroy the mount.

  • Page 73: Procedure

    (drilling depth just slightly less than screw length). 4. Attach ceiling seal: Place the white rubber seal with the groove on the edge of the ceiling mount. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 74 Check image sections on the computer monitor. Note Use the VarioFlex Ceiling Mount for ceiling installation. The VarioFlex mount and Wall Mount must always be used for wall installation. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 75 /146 Mounting The Camera With Ceiling Mount © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 76: Mounting The Camera With Pole Mount

    Mounting The Camera With Pole Mount 2.6.1 Mounting Instructions If you are intending to mount the camera on a pole, you should consider using the MOBOTIX M24M Pole Mount. This mount is made of 3 mm powder-coated stainless steel (white) and has been designed speciically for outdoor use.

  • Page 77: Pole Mount (Mx-Mh-Secureflex-Esws)

    When mounted to a pole, the camera can be turned or tilted as follows, just like wall installation: • horizontally: 180° • vertically: 110° 180° +20° -90° Pole Mount Dimensions Width: 140 mm Depth: 45 mm © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 78 The following additional tools are required for installation: • Screwdriver • Materials and any tools needed to connect the pre- installed MOBOTIX network cable in the camera with the on-site network cable. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 79: Procedure

    5. Connect the cable: Connect the on-site network cable with the camera patch cable via adapter in the cavity socket of the wall mount. Make sure that the cables are not bent or squashed. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 80 Check image sections on the computer monitor as well. Note The VarioFlex Wall Mount must always be used for pole installation. The VarioFlex Ceiling Mount should not be used. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 81 /146 Mounting The Camera With Pole Mount © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 82: Adjusting The Camera And Changing The Lens

    4. If required, clean the lens cover using a clean, lint-free cotton cloth. 2.7.2 Correcting The Image Horizon (For L11 Lens Only) The M24M-Sec with hemispheric L11 lens allows the cor- Section 3.5 provides rection of an uneven image horizon via OnScreen Control more details and informa- +30°...

  • Page 83: Changing The Lens

    M24M-Sec-CSVario nor for lenses with CS or C mounts. Only lenses with CS or C mounts may be used with the CSVario version of the M24M (Secure model only). Only standard MOBOTIX lenses (L22, 32, 43, 65, 135) with M14 thread may be used with standard versions of the M24M (Secure, IT and Basic).

  • Page 84: Replacing The Microsd Card

    Gently push on the MicroSD card in the card slot of the camera. The card will be released from the slot and can then be removed from the camera. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 85: Inserting The Microsd Card

    External File Server / Flash Device. Once the camera has been rebooted, it auto- matically activates recording. 6. If you have inserted a new MicroSD card, it must irst be formatted as described in Section 3.6 MicroSD Card Recording. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 86: Network And Power Connection

    Network And Power Connection 2.9.1 Notes On Cable Lengths And Power Supply • Power may only be supplied to the camera via its Ethernet connector. A MOBOTIX PoE adapter or similar high-quality PoE product is recommended to provide the power supply via the network cable (see Section 2.3 Available M24M Accessories ): •...

  • Page 87: Power Supply Using A Switch

    /146 Network And Power Connection The MOBOTIX factory default is PoE class 2. This default is usually ine and nothing needs Variable PoE: multiple cameras can be oper- to be changed. However, if the lower power level class 1 is suicient for your application, ated simultaneously it may –...

  • Page 88: Power Supply When Connected Directly To A Computer

    Connect the factory pre-installed cable of the camera to the Ethernet connector of the PoE switch/router. The switch/router must support the PoE standard IEEE 802.3af. LAN/www Switch/router The IP addresses in the diagram are shown only as an example (10.8.0.11/255.0.0.0) Camera (10.8.0.99) © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 89: Camera Startup Sequence

    L key LEDs Notes During the startup sequence of the camera, the LEDs will always light up, even if they have been deactivated in Admin Menu > LED Setup. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 90: Operating The Camera

    (for example, 10.8.0.99). However, local computer networks usually have IP addresses in the 172 or 192 ranges. In order to access a MOBOTIX camera via the network, the camera needs to obtain an IP address in the same address range. You can set up the network parameters of the MOBOTIX camera using one of the following methods: Manually, using MxCC and MxEasy or by DHCP.

  • Page 91: Manually Using A Computer In The 10.X.x.x Ip Address Range

    • The computer or the network needs to operate in the 10.x.x.x IP address range or needs to be able to access such a network. • The setup does not work automatically. • You need to know the relevant network parameters. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 92: Automatically Using Mxcontrolcenter Or Mxeasy

    MxControlCenter or MxEasy (see Sections 3.2.3 and 3.2.4). You can also use one of these applications to automatically conigure the network parameters of MOBOTIX cameras that are not operating on the same IP address range as the computer.

  • Page 93: Automatically Using Dhcp

    • The camera needs to be physically accessible as you need to press a key on the camera housing to boot it using DHCP. • Requires a running DHCP server on the network. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 94: First Images And The Most Important Settings

    IP address over the speaker. 3.2.1 Manually Setting Up The Network Parameters In A Browser In order to manually set up the network parameters of the MOBOTIX camera, you need a computer that is using a 10.x.x.x IP address. The computer's network parameters usually have to be changed for this purpose.
  • Page 95 Pressing Enter displays the user interface of the MOBOTIX camera (see also Section 3.2.2 First Images And The Most Important Settings In The Browser ). 2. Click the Admin Menu soft key in the user interface of the MOBOTIX camera. The Quick Installation starts automatically once the admins...

  • Page 96: First Images And The Most Important Settings In The Browser

    3.2.2 First Images And The Most Important Settings In The Browser Once the MOBOTIX camera has been connected to the power supply and to the network, you can access the user interface with the live camera image in the Web browser. Internet Explorer, Firefox, Safari, Konqueror, Opera, Camino, or any other graphical browser with activated JavaScript is suitable.
  • Page 97 For more information on camera screens, see Section 4.1.1 Camera Screens in the Browser , the Camera Software Manual Part 2 , or the online help of the camera's browser interface. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 98: First Images And Network Parameter Coniguration In Mxcontrolcenter

    If you do not have the installation CD or just want to install an update, you can download the latest Windows installer from the MOBOTIX website as an MSI ile and install it manu- ally. The latest versions are available at www.mobotix.com in the Support > Software Downloads >...
  • Page 99 Camera preview Note Video sources in this context not only refer to MOBOTIX cameras, but also to third- party IP cameras, ile server paths, MxPEG clips and analog cameras connected via MxServer (e.g. analog dome cameras). These video sources are not found automati- cally and need to be added manually.
  • Page 100 Note MxControlCenter inds all MOBOTIX cameras, even when the computer and the cameras are not located in the same subnet. Select the cameras that you would like to display in a Layout (a view with cameras) and click Add selected video sources.
  • Page 101 (OK). Conirm the Open Video Sources dialog again by clicking OK. Deining Additional Video Sources In addition to the MOBOTIX cameras that are found automatically, you can also manually add video sources to the list of video sources for MxControlCenter.
  • Page 102 Otherwise, the selected video sources will only be added to the MxCC system and can then be used to create layouts at a later date. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 103: First Images And Network Parameter Coniguration In Mxeasy

    If this is not the case or if you would like to update to a newer version, you can download the latest MxEasy version for your operating system from the MOBOTIX website ( www.mobotix.com > Support > Software Downloads in the MxEasy section).
  • Page 104 MxEasy will be displayed in a diferent color. If all the desired MOBOTIX cameras are highlighted as Accessible in the video source list, you can proceed to the Selecting Cameras section below. Cameras with the status Invalid Network can be reconigured for the "proper"...
  • Page 105 In addition, you can display further information of a camera and change the user name/password of a camera. For more information on this topic, see the MxEasy User Manual. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 106 If MOBOTIX cameras with a hemispheric L11 lens are selected in the selection list, MxEasy Assistant displays the dialog shown here for each of the cameras. Here, you can determine the mounting position and the desired image view of each camera (wall or ceiling).
  • Page 107 Double-click on a small camera panel to move this camera's live image to the large panel. Use Cameras > Add Cameras at any time to add MOBOTIX cameras to MxEasy (max. 16 cameras in total). © MOBOTIX AG • Security-Vision-Systems • Made in Germany...

  • Page 108: Starting The Camera With An Automatic Ip Address (Dhcp)

    M24M Camera Manual: OPERATING THE CAMERA 3.2.5 Starting The Camera With An Automatic IP Address (DHCP) If your network has a DHCP server, you can start the MOBOTIX camera with DHCP support. In this case, the DHCP server automatically assigns and announces an IP address.

  • Page 109: Starting The Camera With The Factory Ip Address

    As opposed to resetting the camera using Admin Menu > Reset coniguration to Users and factory defaults , the user information will not be reset if the camera is booted using passwords will be changed! the factory IP address. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 110: Virtual Ptz

    Operation Using The Mouse And Scroll Wheel The vPTZ function of the M24M can be controlled in the browser using the mouse. By clicking any position on the image displayed on the monitor, this position becomes the new image center.
  • Page 111 PTZ Features), and the MxControlCenter manual, Section 2.4.6 (Using the vPTZ Features) and Section 3.1.4 ("PTZ Controls" in the sidebar panel). The latest versions of all manuals are available at www.mobotix.com, Support > Manuals. © MOBOTIX AG • Security-Vision-Systems • Made in Germany...

  • Page 112: Correction Of Lens Distortion (L22 Only)

    M24M Camera Manual: OPERATING THE CAMERA Correction Of Lens Distortion (L22 Only) If you are using an M24M with the L22 90° Wide Angle lens, the image, particularly the edges, may be slightly distorted due to the extreme angle of the lens.
  • Page 113 We recommend activating lens distortion correction, especially for applications with a low frame rate and non-zoomed images (for example, when using the M24M as a webcam). However, images can usually be corrected at a later point in time when searching recorded images.

  • Page 114: Special Hemispheric Coniguration In The Browser (L11 Only)

    M24M Camera Manual: OPERATING THE CAMERA Special Hemispheric Coniguration In The Browser (L11 Only) Thanks to its hemispheric lens, the MOBOTIX M24M with L11 lens provides certain special coniguration options for the image settings. Depending on where the camera is mounted...
  • Page 115 Tilted vertical lines may also be optically straightened to the image edges using the panorama correction function. These tilted lines are primarily caused if the camera itself is tilted or if the image tilt has been modiied. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 116 Caution To permanently save the standard image setting deined for the M24M, select the "Store Complete Coniguration" option under the "Manage Settings" in Quick Control. The settings will then remain in efect, even after rebooting.
  • Page 117 CORRECTION Bring columns together at the (necessary to correct the example on the left); weather- proof cover is removed from the image Bring columns together at the bottom © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 118 Ceiling-Mounted: Set North (User-deined North Direction) If the camera has been mounted to a ceiling, the M24M should be set to "North." This is not the "real" direction of North but rather the main line of sight or the focus of the camera. It serves as a reference for the North direction in the "Surround"...
  • Page 119 "Double using the lock icon (open lock - correct display - close lock again). Panorama" mode © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 120: Microsd Card Recording

    Menu > Camera Status dialog. Conservative Memory Usage Thanks To MOBOTIX MxFFS File System MxFFS formatting of the MicroSD card means that the MOBOTIX camera software will use the lash device as evenly as possible, thus allowing for the maximum possible number of write/delete cycles.
  • Page 121 Monitoring The Cell Wear Of Flash Storage Devices (Patent Pending) MOBOTIX uses its own technology for this purpose and has a pending patent. You can view the lash wear in the status bar of the live image or by opening Admin Menu >...

  • Page 122: Formatting The Card

    Server / Flash Device (Admin Menu > Storage on External File Server / Flash Device): 1. Make sure that there is a MicroSD card in the card slot of the MOBOTIX camera. 2. Click on the Format button under SD Flash Card.

  • Page 123: Activate Recording

    Storage on External File Server / Flash Device 1. Make sure that there is a MicroSD card in the card slot of the MOBOTIX camera. 2. Make sure that the MicroSD card has been MxFFS-formatted (see Section 3.6.2 Formatting the Card ).

  • Page 124: Accessing Camera Data

    • In MxControlCenter: Play back the recorded video sequences with audio by access- ing the MicroSD card in the MOBOTIX camera via the camera or with a direct access to the MicroSD card via a card reader connected to the computer. Access the card by setting the MicroSD card's drive/volume as a "directory"...

  • Page 125: Using A Microsd Card In A Diferent Mobotix Camera

    MxFFS formatting, this is limited to 4 MB of lost data per incident. 3.6.6 Using A MicroSD Card In A Diferent MOBOTIX Camera A MicroSD card containing recorded video data from a MOBOTIX camera can be inserted into any MicroSD card-enabled MOBOTIX camera. Once MicroSD card recording has been activated (requires a reboot), the "new"...

  • Page 126: Full Image Storage

    The main advantage of full image storage lies in the special functionality of the M24M, in that it can always maintain availability of a maximum size (full) image for later searches, despite vPTZ actions carried out on the live image.
  • Page 127 "Full Image Recording" option. Notes Post-event search in the full image: If you are using Full Image Recording on M24M cameras, you should use at least MEGA resolution when storing. This will facilitate later searches in MxControlCenter or MxEasy. The advanced distortion correction features require this function to deliver satisfactory image quality.

  • Page 128: Coniguration In The Browser

    HTTP commands using programs and scripts of the embedded software. The settings are stored in the camera's lash memory. This section contains an overview of the general browser settings of the MOBOTIX camera, as well as further coniguration options. The Software Camera Manual Part 2 contains more detailed descriptions of the software features.
  • Page 129 (Image Programs Quick Control). => ( Software Camera Manual Part 2 , Section 5.5.2) • Set the resolution of the live image: By factory default, all MOBOTIX cameras are delivered with an image resolution of 640 x 480 pixels. You can select the desired resolution using the Resolution Quick Control.
  • Page 130 Click on the Arm & Record button to activate event control. This will activate video motion detection and recording. Cameras with integrated lash memory (MOBOTIX R models and models with SD card) will use the lash memory by default to store the image and video data (recording target). If desired, you can set additional events and adjust the settings of the recording and storage parameters (Setup Menu >...

  • Page 131: Additional Coniguration Options

    This allows you to manually synchronize the camera with a computer or automatically using a time server or another MOBOTIX camera. The camera can use either NTP time servers or Time Protocol servers. For additional information, see Section 5.4.2 Date and Time/ Time Zones and Time Servers in the Camera Software Manual Part 2 .

  • Page 132: Additional Notes

    Due to its robust and carefully constructed design and the lack of mechanical moving parts, the M24M has some outstanding weatherproof features and is resistant to moisture and dust. Certiied according to the IP66 standard, the camera is even resistant to water jets but is not completely airtight.

  • Page 133: Password For The Administration Menu

    If you lose the administrator password and cannot access the Administration menu, the password can only be reset at the factory. This service is subject to a service charge! © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 134: Permanently Deactivating The Microphone

    3.9.5 Reset The Camera To Factory Settings The coniguration All settings of the MOBOTIX camera can be permanently reset to the factory default settings. can also be reset This makes sense if you have, for example, obtained a camera without any information partially or you would like to reset all settings after testing the camera.

  • Page 135: Deactivate Text And Logo Options

    MOBOTIX camera only displays the Text WWW.MOBOTIX.COM, the time stamp, and can also be deactivated or the MOBOTIX logo at the top of the image. Once the camera arming has been activated, customized the text at the bottom of the live image (event, action, messaging, and recording symbols) will also appear.

  • Page 136: Cleaning The Camera And Lens

    Electrical surges can be induced by other electrical appliances, improper wiring, but also from the outside (for example, lightning strikes to phone or power lines). MOBOTIX cameras are protected against the efects of small electrical surges by a range of measures. These measures, however, cannot prevent the camera from being damaged when stronger electrical surges occur.

  • Page 137: Additional Information

    Furthermore, detailed information on the camera and its current coniguration is displayed in the Camera Status dialog. Click on the symbol to open the relevant page. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 138 Control element on Windows computers which may also be used in other programs (including Windows Internet Explorer) to run special tasks. The MxPEG ActiveX control element allows video and audio data from MOBOTIX cameras to be displayed in other applications (includ- ing Internet Explorer).
  • Page 139 16 Mbps for a typical household. DualDome Dome camera with two lenses and image sensors such as the MOBOTIX D12D. These lenses can deliver Wide Angle and Telephoto images independently of one another. Abbreviation for Digital Video Recorder.
  • Page 140 /146 M24M Camera Manual: Glossary ExtIO MOBOTIX signal module that the camera uses to directly operate lamps, sirens and door openers, as well as external audio components (speakers and microphones). Fixdome Camera without moving parts in a dome-shaped housing. Flash Memory See CF Card.
  • Page 141 MOBOTIX cameras and add-on modules that emits light when a current lows through the component in the correct direction. Linux Free and open source operating system. Serves as the operating system for all MOBOTIX cameras. Megapixel Images that have more than 1 million pixels.
  • Page 142 USB sticks. Search Monitoring of recordings or searching for a particular event. Sequencer Feature that automatically switches the camera displayed in the main window after a speciic time delay. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 143 VoIP Voice over IP. Telephony using computer networks. WLAN Wireless Local Area Network. Used to provide Internet connections without the need for cables. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 144 /146 M24M Camera Manual: Notes © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 145 /146 © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 146 /146 /146 M24M Camera Manual: Declaration Of Conformity DECLARATION OF CONFORMITY © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 147 MOBOTIX – The HiRes Video Company To demonstrate our conidence in the quality of our products, MOBOTIX cameras were used to capture all the images that appear in this manual. Manufacturer Executive Board MOBOTIX AG Dr. Ralf Hinkel Kaiserstrasse D-67722 Langmeil...
  • Page 148 > Support > Manuals HiRes Video Innovations The German company MOBOTIX AG is known as the leading pioneer in network camera technology and its decentralized concept has made high-resolution video systems cost eicient. MOBOTIX AG • D-67722 Langmeil • Tel: +49-6302-9816-103 • Fax: +49-6302-9816-190 • sales@mobotix.com...

Table of Contents
